Puloon LCDM-1000 Manual

Install Manual
Install Manual
Model : LCDM-1000
(Cash Dispensing Unit)
Total Page : 15 pages (including cover )
PULOON Technology Inc.
Date : 2002. 3
Version : V3.0(INT)

PULOON Technology Inc.
LCDM-1000
= Contents =
1. Mounting LCDM-1000
1-1. Preview
1-2. Left Side Mounting Points
1-3. Right Side Mounting Points
1-4. Layout of Mounting Points
2. Power Connection
2-1. Specification of Connector
2-2. Pin connection
3. Interface Connection
3-1. Pin Connection
3-2. Specification of Serial Communication
3-3. Location of Communication Connector
3-4. Specification of Dip Switch
4. How to Charge Notes
4-1. Aligning Notes
4-2. Laying Cassette
4-3. Arranging Notes
4-4. Locking Plate and Charging Notes
4-5. Unlocking Pushing- Plate
4-6. Check Point
4-7. Insertion of Cassette

PULOON Technology Inc.
LCDM-1000
1. Mounting LCDM-1000
M4 screw
1-1. Preview
To mount LCDM-1000 on ATM, a shelf will be installed on the bottom
of the system.
The manufacturer of ATM can fix 4 points with M4 fixing screw,
where every two mounting points are located both in front and on bottom
of LCDM-1000.
1-2. Left Side Mounting Points (Originated from Front View)

PULOON Technology Inc.
LCDM-1000
M4 screw
1-3. Right Side Mounting Points (Originated from Front View)

PULOON Technology Inc.
LCDM-1000
1-4. Layout of Mounting Points

PULOON Technology Inc.
LCDM-1000
2. Power Connection
2: GND
1: 24V
1: 24V 2: GND
The electric power connecter is located at the lower position of main
control board in the back of LCDM-1000 and should be supplied
with DC 24V.
2-1. Specification of Connector
Main Control Board in LCDM-1000(Female) : MOLEX 5566VWO-02
Opposite Connector (Male) : MOLEX 5557D-02
2-2. Pin Connection
< Main Board in LCDM-1000 > < Opposite Connector>
GND2
24 V1
FunctionPin No

PULOON Technology Inc.
LCDM-1000
3. Interface Connection
3-1. Pin Connection
Received dataRXD2
Transmitted dataTXD3
Not used4
System groundGND5
Not used6
Not used7
Not used8
Name
Not used9
Not used1
FunctionPin No
No parityParity
1 stop bitStop bits
8 bitsData bits
9600 bpsBaud rate
The communication connecter is 9 Pin D-type and located at the lower
position of main control board in the back of LCDM-1000.
3-2. Specification of Serial Communication

PULOON Technology Inc.
LCDM-1000
9 Pin D-type
3-3. Location of Communication Connector

PULOON Technology Inc.
LCDM-1000
3-4. Specification of Dip Switch
ON
OFF 1 2 3 4
ON
OFF 1 2 3 4
The switch should be set as
“ON”state like figure.
S2 S1
< Choice of currency >
ON : Height of Note 71mm ~ 78mm
OFF: Height of Note 62mm ~ 71mm
< Operation Mode >
ON : ON LINE
OFF: AUTO TEST
< Baud Rate >
ON : 9600 bps
OFF: 38400 bps
ON : note thickness = 0.10 ~ 0.12
OFF: note thickness = 0.13 ~ 0.15
< Thickness criterion for currency used in the
Cassette>
< Display of Reject code >
ON : Non-Display
OFF: Display
< Definition of Bill-End (option) >
ON : 10~30 remain
OFF: No bill remains
ON OFF
CAUTION !
CAUTION !
Please turn on power again after changing the Dip Switch

PULOON Technology Inc.
LCDM-1000
4. How to Charge Notes
The method of charging notes and the charging state give a great effect
on the performance of a cash dispenser and should be carefully charged
like below.
4-1. Aligning Notes
First, all notes to be charged are aligned in order like the below picture.

PULOON Technology Inc.
LCDM-1000
4-2. Laying Cassette
4-3. Arranging Notes

PULOON Technology Inc.
LCDM-1000
4-4. Locking Plate and Charging Notes

PULOON Technology Inc.
LCDM-1000
4-5. Unlocking Pushing Plate
Like below, the pushing plate should be unlocked by pressing the key.

PULOON Technology Inc.
LCDM-1000
4-6. Check point

PULOON Technology Inc.
LCDM-1000
4-7. Insertion of Cassette
The cassettes should be completely inserted up to the latching into
the main body
