Puls ZM1.WALL User manual

ZM1.WALL
Wall Mounting Bracket
Oct. 2007 / Rev. 1.2 DS-ZM1.WALL-EN / All parameters are specified at 25°C ambient unless otherwise noted.
The information presented in this document is believed to be accurate and reliable and may change without notice.
www.pulspower.com Phone [phone] Germany
1/2
1. GENERAL DESCRIPTION
BRACKET FOR WALL MOUNTING
This accessory is used to mount Dimension power
supplies and other Dimension units on a wall or on a
panel without using a DIN-Rail.
The two aluminum brackets and the black plastic slide
must be removed from the unit, to allow mounting of
the two zinc-plated steel brackets.
2. INSTALLATION DATA
Fig. 2-1 Unit equipped with wall mounting brackets Fig. 2-2 Mounting dimensions
N L PE
+ +- -
C
B
A
133 143
5.1
INPUT
OUTPUT
Unit A B C Unit A B C
CD5.XXX 32mm 4.8mm 22.5mm QT20.XXX 65mm 6.3mm 40.0mm
CS3.XXX 32mm 4.8mm 22.5mm QTD20.XXX 65mm 6.3mm 40.0mm
CS5.XXX 32mm 4.8mm 22.5mm QS20.XXX 82mm 8.0mm 66.0mm
CS10.XXX 60mm 5.8mm 48.5mm QS20.244 70mm 8.0mm 54.0mm
CT5.XXX 40mm 5.0mm 30.0mm UF20.XXX 64mm 12.0mm 40.0mm
CT10.XXX 62mm 5.7mm 50.6mm UB10.XXX 49mm 5.3mm 38.4mm
QS3.XXX 32mm 4.8mm 22.5mm YR2.DIODE 32mm 4.8mm 22.5mm
QS5.XXX 40mm 5.3mm 29.5mm YRM2.DIODE 32mm 4.8mm 22.5mm
QS10.XXX 60mm 5.8mm 48.5mm
3. ORDER NUMBERS
Accessory ZM1.WALL 2 pcs. wall-mounting brackets; 8x143x7mm,
The order number consists of a set with two brackets suitable for one unit

ZM1.WALL
Wall Mounting Bracket
Oct. 2007 / Rev. 1.2 DS-ZM1.WALL-EN / All parameters are specified at 25°C ambient unless otherwise noted.
The information presented in this document is believed to be accurate and reliable and may change without notice.
www.pulspower.com Phone [phone] Germany
2/2
4. ASSEMBLY AND MOUNTING INSTRUCTIONS
Fig. 4-1 Detaching DIN-Rail brackets Fig. 4-2 Detach slide Fig. 4-3 Mounting steel brackets
Detach the two aluminium
brackets by removing the four
screws with a Torx screwdriver
(Torx 10). Save the screws for
step 3.
Remove the plastic lock
mechanism by using a flat-blade
screwdriver to move the lock
downwards while at the same
time push the plastic slide
upwards. Detach the plastic slide.
Mount the two steel brackets with
the same screws from the DIN-Rail
brackets using caution not to
over-tighten the screws!
Recommended tightening torque
is 0.6Nm. (5.3lb.in).
5. PHYSICAL DIMENSIONS AND WEIGHT
Weight 25g / 0.06lb each
50g / 0.11lb for one set
Electronic files with mechanical data can be downloaded at www.pulspower.com
Fig. 5-1 Dimensions
