Pulsar PSB1552455 User manual

1
PSB1552455
PSB 27,6V/5,5A enclosed switch
mode b
uffer power supply
Edition: 1 z from 17.11.2011
Supercedes edition: ……………….. EN
Features of the power supply:
•DC 27,6V/5,5A uninterruptible power supply
•wide AC input voltage range 176÷264V
•high efficiency 84%
•controlling of battery charging and maintaining
•protecting of battery against excessive
discharging (UVP)
•battery charging current 0,5A/2A,
changed by jumper
•battery output is full protected against short-
circuit and reverse connection
•LED optical signalisation
•protections:
•SCP short-circuit protection
•OVP overvoltage protection
•overvoltage protection (output AC)
•overload (OLP)
1. Technical description.
1.1.General description.
Buffer-type power supply units are intended for continuous power supply to devices that require stabilised voltage
of 24 V DC (+/-15%). The power supply provides a voltage of U=27,6 V DC with an output current of:
1. Output current of 5A + 0,5A battery charging.
2. Output current of 3,5A + 2A battery charging.
Total device current + battery: 5,5A max.
In case of power voltage decay, prompt switching to battery supply occurs. The power supply has the following
protections: short-circuit (SC ), overload (OL ), and overvoltage (OV ).
1.2.Technical parameters.
Supply voltage 176÷264V AC 50÷60Hz
Current consumption 1,4A@230VAC max.
Supply power 155W max.
Efficiency 84%
Output voltage 27,6V DC – buffer operation
19V÷27,6V DC – battery operation
Output current
5,0A + 0,5A
battery charging
3,5A + 2A battery charging
Output current t
AMB
<30°C 5A + 0,5A battery charging - refer to graph 1.
3,5 A + 2A battery charging - refer to graph 1.
Output current t
AMB
=40°C 3,3 A + 0,5A battery charging - refer to grap h 1.
1,8 A + 2A battery charging - refer to graph 1.
Voltage adjustment range 24÷28V DC
Ripple voltage 150mV p-p max.
Battery charging current 0,5A max. or 2A max.
Short-circuit protection SCP electronic
Overload protection (battery) OLP polymer fuse (PTC)
Overvoltage protection OVP U>115% ÷ 150% of the output voltage, isolation of the
output voltage, atomatic recovery
Excessive discharge protection UVP U<19 V (± 5%) – disconnection of battery
Optical signalisation green LED- presence of AC voltage
Output of optical signalization LED AC- presence of AC voltage
LED DC- presence of DC voltage on power supply output
Operation conditions 2-nd enviromental class, temperature: -10
o
C÷40
o
C
relative humidity 20%...90%, without condensation
Dimensions (LxWxH) 199 x110 x 50 [mm]

2
Net/gross weight 0,76kg / 0,82kg
Protection class PN-EN 60950-1:2007 I (first) - requires a protective conductor (PE)
Connectors power-supply: Φ0,63÷2,5 I/O PCB : Φ0,41÷1,63
battery output BAT: 6,3F-2,5/40cm,
output of optical signalization: plug 3-pin 5 mm
Electrical strength of insulation:
- between input (network) circuit and output circuits
of power-supply (I/P-O/P)
- between input circuit and PE protection circuit (I/P-
FG)
- between output circuit and PE protection circuit
(O/P-FG)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
Insulation resistance:
- between input circuit and output or protection
circuit
100 MΩ, 500V/DC
Storage temperature -20ºC...+60ºC
Vibrations and impulse waves during transport according to PN-83/T-42106
1.3. Output current vs temperature.
Graph 1.
Allowable output current from the power
supply depending on ambient temperature.
2. Installation.
2.1. Requirements.
The buffer power supply shall be mounted by the qualified installer having appropriate (required and necessary
for a given country) permissions and qualifications for connecting (operating) 230V/AC installations and low voltage
installations. The device shall be mounted in closed rooms, according to the environment class II, of the normal air
humidity (RH=90% max. without condensation) and the temperature within the range from -10°C to +40°C.
The power supply shall be mounted in a close casing (a cubicle, a terminal device) and in order to fulfill LVD and
EMC requirements the rules for power-supply, encasing and shielding shall be observed according to application.
Due to the power supply design, the PE wire has to be connected to the corresponding connector of the
supply unit. Operation without proper grounding of the power supply is not allowed!
Prepare the power supply loading balance before installation:
1. Output current of 5A + 0,5A battery charging.
2. Output current of 3,5A + 2A battery charging.
Total device current + battery: 5,5A. max.
2.2. Installation procedure.
1. Before beginning installation, ensure that the power in the 230V AC power supply circuit is disconnected.
2. Install the unit in the previously selected place.
3. Connect the 230VAC power leads. Connect the PE cable (yellow-green) to an appropriate terminal on the
power supply unit (marked with ).
The circuit of the shock protection shall be performed with a particular care, i.e. the yellow and green
protection wire of the power cable shall be connected from one side to the terminal marked by the
symbol of in the casing of the power-supply. Operation of the power-supply without the properly
made and fully operational circuit of the shock protection is
UNACCEPTABLE!
It can result in failure of devices and electric shock.
4. Connect load/loads to proper output connectors of the power supply (positive end is marked as +V,
negative as -V).
5. Connect battery to the unit according marks (colors).

3
6. After the completion of tests and trial activation, close the housing, cabinet etc.
2.3. Description of terminals.
Elements/connectors
[Fig.1] Description
L, N,
L
-
N
- input voltage connectors 230 V AC,
– protective conductor connector
-V Power supply output (0V)
+V Power supply output (+27.6V)
LED1 LED signals the presence of AC voltage
ADJ Potentiometer - output voltage adjust
I1/I2
Jumper -battery charging current configuration:
Ibat =0,5A
Ibat =2A
Legend: jumper installed, jumper
removed
B+ Battery terminal- positive (+)
Fig 1. Description of terminals.
B- Battery terminal- negative (-)
Z1 Connector of optical signalization
2.4.Dimensions and fitting of the PSB1552455 power supply.
Fig. 2. Dimensions of power supply.
3. Maintenance.
All maintenance procedures can be performed after the disconnection of the power supply from the electrical grid.
The power supply does not require any special maintenance procedures, but in the case of significant dust accumulation,
dusting using compressed air is recommended.

4
