PulseAudio PA-ADS1 User manual
pulseaudio1.com | vanco1.com | 800.626.6445
AU DIO DEL AY
DEVICE
PART NUMBER PA-ADS1
DELAYS ANALOG AUDIO TO SYNC UP WITH VIDEO FOR ANY “LIP SYNC” ISSUES
2
1. Do not install or place this unit
in a built-in cabinet, or other
confined space without adequate
ventilation.
2. To prevent risk of electrical shock
or fire hazard, due to overheating
do not obstruct unit’s ventilation
openings.
3. Do not install near any source of
heat, including other units that
may produce heat.
4. Do not place unit near flames.
5. Only clean unit with a dry cloth.
6. Unplug unit during lightning
storms or when not used for an
extended period of time.
7. Protect the power cord from being
walked on or pinched, particularly
at the plugs.
8. Use unit only with accessories
specified by the manufacturer.
9. Refer all servicing to qualified
personnel.
WARNING
THIS PRODUCT IS 100% INSPECTED AND TESTED IN THE
UNITED STATES TO VERIFY PERFORMANCE PARAMETERS.
Thank you for purchasing this product. For optimum
performance and safety, please read these instructions
carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
DEAR CUSTOMER
3
The PA-ADS1 is an analog audio delay device with simple stereo RCA audio
input and output to resolve “lip sync” issues in audio and video systems. Often
analog audio would be processed faster than the digital video content which
results in audio and video out of sync. The PA-ADS1 is a simple and perfect
solution with 16 increments to delay audio anywhere from 20ms to 340ms
with a turn of a dial.
Part # PA-ADS1
• Adjustable up to 16 increments ranging from 20 – 340ms
• Analog L/R RCA input and output
• Simple and easy to use with a manual adjustment dial
• Compact size for discreet placement
• DC 5V Power
• Dimensions: 2.5” W x 0.9” H x 3” D
FEATURES
PACKAGE CONTENTS
• PA-ADS1 Device
• Power Supply
• Product Manual
Analog Audio Delay Device
Dimensions ....................................................................2.5” W x 0.9” H x 3” D
Weight.............................................................................0.2 lbs
Operating Temperature ............................................32 to 95F; 0 to 35C
Operating Humidity ...................................................5-90% RH
Power Supply ...............................................................5V, 1A
Power Consumption ..................................................5W
Input.................................................................................Analog RCA
Output.............................................................................Analog RCA
Certification...................................................................CE, FCC
SPECIFICATIONS
4
1
1. Power: Connect the included 5V 1A power supply
2. RCA Left and Right Stereo Audio Input
3. RCA Left and Right Stereo Audio Output
4. Audio Delay Dial; adjust on the fly, with increments ranging from 20 – 340ms
PANEL DESCRIPTIONS
2
34
5
CONNECT AND OPERATE
1. Connect RCA stereo input from the A/V source
2. Connect RCA stereo output from the PA-ADS1 to an external amplifier
3. Connect power
4. Adjust the Audio Delay Dial as desired
5. 16-Way Audio Delay Selector
Setting Delay (ms)
0 20
1 43
2 64
3 85
4107
5 128
6149
7 171
8192
9 213
A235
B 256
C277
D 299
E 320
F 340
HDMI
Source
RCA Audio Cable
RCA Audio Cable
Amplifier
Speaker Wire
Speake
rS
peaker
HDTV
6
SAFETY AND NOTICE
The PA-ADS1 has been tested for conformance to safety regulations and
requirements, and has been certified for international use. However, like all
electronic equipment, the PA-ADS1 should be used with care. Please read and
follow the safety instructions to protect yourself from possible injury and to
minimize the risk of damage to the unit.
• Follow all instructions and warnings marked on this unit
• Do not attempt to service this unit yourself, except where explained in this manual
• Provide proper ventilation and air circulation and do not use near water
• Keep objects that might damage the device and assure that the placement of this
unit is on a stable surface
• Use only the power adapter and power cords and connection cables designed for
this unit
• Do not use liquid or aerosol cleaners to clean this unit
• Always unplug the power to the device before cleaning
TECHNICAL SUPPORT
In case of problems, please contact Vanco Technical Support by dialing
1-800-626-6445. You can also email technical support issues to techsupport@
vanco1.com. When calling, please have the Model Number, Serial Number
(axed to the bottom of the unit) and Invoice available for reference during
the call. Please read this Instruction Manual prior to calling or installing this
unit, since it will familiarize you with the capabilities of this product and its
proper installation. All active electronic products are 100% inspected and
tested to insure highest product quality and trouble-free installation and
operation. The testing process utilizes the types of high-definition sources and
displays typically installed for entertainment and home theatre applications.
For additional information please visit www.vanco1.com.
7
LIMITED WARRANTY
With the exceptions noted in the next paragraph, Vanco warrants to the
original purchaser that the equipment it manufactures or sells will be free from
defects in materials and workmanship for a period of two years from the date
of purchase. Should this product, in Vanco’s opinion, prove defective within
this warranty period, Vanco, at its option, will repair or replace this product
without charge. Any defective parts replaced become the property of Vanco.
This warranty does not apply to those products which have been damaged
due to accident, unauthorized alterations, improper repair, modifications,
inadequate maintenance and care, or use in any manner for which the product
was not originally intended.
Items integrated into Vanco products that are made by other manufacturers,
notably computer hard drives and liquid crystal display panels, are limited
to the term of the warranty oered by the respective manufacturers. Such
specific warranties are available upon request to Vanco. A surge protector,
power conditioner unit, or an uninterruptible power supply must be installed in
the electrical circuit to protect against power surges.
If repairs are needed during the warranty period the purchaser will be required
to provide a sales receipt/sales invoice or other acceptable proof of purchase
to the seller of this equipment. The seller will then contact Vanco regarding
warranty repair or replacement.
LIABILITY STATEMENT
Every eort has been made to ensure that this product is free of defects. The
manufacturer of this product cannot be held liable for the use of this hardware
or any direct or indirect consequential damages arising from its use. It is
the responsibility of the user and installer of the hardware to check that it is
suitable for their requirements and that it is installed correctly. All rights are
reserved. No parts of this manual may be reproduced or transmitted by any
form or means electronic or mechanical, including photocopying, recording
or by any information storage or retrieval system without the written consent
of the publisher. Manufacturer reserves the right to revise any of its hardware
and software following its policy to modify and/or improve its products where
necessary or desirable. This statement does not aect the legal rights of the
user in any way.
