PulseTec EXCEL 200 QUAD User manual

EXCEL
2OO
QUAD
INSTRUCTION MANUAL
#PC-020-002
Download
English Manual
Download
French Manual
Téléchargez
le Manuel en
Français
Download
German Manual
Download
Deutsche
Anleitung

2
Introduction.......................................................................................................................1
Special Features...............................................................................................................3
Warning And Safety Notes ...............................................................................................7
Explanation of Buttons.................................................................................................... 11
Operation Program.........................................................................................................14
Lithium Battery Program (LiPo/LiFe/LiIon/LiHV).............................................................15
NiMH/NiCd Battery Program ..........................................................................................18
Pb Lead-acid Battery Program .......................................................................................22
Battery Memory Set and Call Out...................................................................................24
System Setting ...............................................................................................................26
Battery Voltage Meter.....................................................................................................28
Battery Resistance Meter ...............................................................................................29
Controlling the Charger Using the App...........................................................................31
Using the Charge Control Software “Charge Master PRO”............................................37
Use Voltage Calibration..................................................................................................38
Specication ...................................................................................................................38
Regulatory Information ...................................................................................................40
Warranty and Service .....................................................................................................42
WARNING
This charger is not intended for use by persons (including children) with reduced phys-
ical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the charger.
Do not recharge non-rechargeable batteries!
During charging, the battery must be placed in a well-ventilated area!
Never leave the charger unattended when charging the battery.
Table Of Contents

3
Congratulations on your choice of PULSETEC EXCEL 200 QUAD AC/DC Dual Balance
Charger/Discharger/Power Supply. This unit is simple to use, but the operation of a so-
phisticated automatic charger such as PULSETEC EXCEL 200 QUAD does require some
knowledge on the part of the user. These operating instructions are designed to ensure
that you quickly become familiar with its functions. It is therefore important that you read
right through the Operating Instructions, Warning and Safety Notes before you attempt
to use your new charger for the rst time. We hope you have many years of pleasure and
success with your new battery charger.
PULSETEC EXCEL 200 QUAD is a high-performance, microprocessor-controlled
charge/discharge station with battery management suitable for use with all current bat-
tery types, with an integrated balancer for 6-cell Lithium-Polymer (LiPo), Lithium Iron
Phosphate (LiFe) and Lithium-Ion (LiIon) batteries; the additional LiHV mode is able to
charge the new generation of LiPo batteries with a 4.35V end of charge voltage.
The EXCEL 200 QUAD is a four-channel charger with four independent circuits, which
can charge four different kinds of batteries simultaneously, and is equipped with a
480x320 colour LCD display. The two dual channels support power distribution in AC
power mode to make full use of the power when charging a small battery in one chan-
nel and allocating all remaining power to charge another big battery pack in the second
channel. What’s more, users could connect the charger to PC for operation and rmware
upgrade. Besides that, users could also use it as Lithium Battery Voltage Meter and Bat-
tery Internal Resistance Meter.
There are safety settings such as Automatic Charge Current Limit, Capacity Limit, Tem-
perature Threshold and Processing Time Limit which make the charger safe to use.
Finally, your charger gets its own apps. Bluetooth Module is inside of the charger and you
could control your charger by your smart phone via Bluetooth 4.0
Please BE SURE to read these INSTRUCTIONS, WARNING and SAFETY NOTES be-
fore you use the charger for the rst time.
Mishandling batteries and battery chargers is extremely dangerous, which may
cause re and explosion.
Introduction

4
Please read this manual carefully before use. This manual contains important information on
the safe use of this charger. If you are a beginner in battery charging, please use this charger
with an experienced user.
LCD-Colour
Display
Temperature
Sensor Port
Power Switch
USB Port
5V/2.1A
Micro USB Port for
PC Link
DC Input : 11-18V
AC Input : 100 - 240V
Output Charge Lead
4mm Banana Plug
Cooling Fan
CHANNEL A
CHANNEL C
CHANNEL B
CHANNEL D
Balance Lead Sock-
et JST-XH Ports
Introduction

5
LiPo Battery
LiHV Battery
NiMH Battery
Pb
Channel A
Channel B
Channel C Channel D
EXCEL 2OO QUAD
DISPLAY
LIPO BALANCE
2.0A 7.4V(2S)
A
B
C
LIPO BALANCE
2.0A 7.4V(2S)
D
AC Max Power Set
65W
AC Max Power Set
35W
100W
Four-Channel Charger
PULSETEC EXCEL 200 QUAD allows you to connect 4 batteries to one charger simulta-
neously, the charger will intelligently and automatically charge 4 batteries at once to their
maximum capacities. And the batteries being charged do not even need to have the same
cell conguration or same battery chemistry. You can connect different chemistry (NiMH/
NiCd/LiPo/LiFe/Lilon/LiHV/Pb) batteries to any of the charging channels.
Colour LCD Display
The charger is equipped with a 480x320 w3.5” color LCD display.
The user interface looks clean and intuitive.
Dual Input and Power Distribution
PULSETEC EXCEL 200 QUAD has a AC/DC input
comprised of AC 100-240V and DC 11-18V.
In AC mode, it supports power distribution.
For example, the output power total = Channel A
(65W) + Channel C (35W) = 100W
Special Features

6
LP4s 1.5A 12.14V
BAL 000:50 00022
Optimized Operating Software
PULSETEC EXCEL 200 QUAD features the so-called AUTO function that sets the feeding
current during the process of charging or discharging. Especially for lithium batteries, it
can prevent the overcharging which may lead to an explosion due to the user’s fault. It
can disconnect the circuit automatically and alarm once detecting any malfunction. All the
programs of this product were controlled through two way linkage and communication, to
achieve the maximum safety and minimize the trouble. All the settings can be congured
by users.
Battery Memory (Data Store/Load)
The charger can store up to 10 different charge/discharge proles for each channel. You
can keep the data pertaining to program setting of the battery of continuous charging or
discharging. Users can call out these data at any time without any special program setting.
Charge/Discharge Indication
When the charger is active, a clear icon on the display
indicates the charge or discharge status and the present
capacity percentage. (The percentage display is for Lithi-
um batteries only.)
Terminal Voltage Control(TVC)
The charger allows user to change the end voltage. (for expert user only)
PC Control Software “Charge Master PRO”
The free “Charge Master PRO” software gives you unparalleled ability to operate the
charger through the computer. You can monitor pack voltage, cell voltage and other data
during the charging, view charge data in real-time graphs. And you can initiate, control the
charger from “Charge Master PRO”.
Smart Phone Control via Bluetooth (both iOS and Android)
The charger can be operated with a smart phone via Bluetooth 4.0
connection.
Internal Independent Lithium Battery Balancer
EXCEL 200 QUAD employs an individual-cell-voltage balancer. It isn’t necessary to con-
nect an external balancer for balance charging.
Special Features

7
Supports Various Types of Lithium Batteries
EXCEL 200 QUAD supports various types of lithium batteries, such as LiPo, LiIon and the
new LiFe series of batteries.
LiHV Mode Available
The additional LiHV mode is able to charge the new generation of LiPo and LiIon batteries
with a higher end of charge voltage (4.35V).
Fast Charge Mode and Storage Mode of Lithium Battery
Special modes for specic needs. Fast Charge reduces the duration of charging. Storage
Mode lets you control the nal voltage of your battery as preparation for long time storage
in order to prolong the usable lifetime of the battery.
Re-Peak Mode of NiMH/NiCd Battery
In re-peak charge mode, the charger can peak-charge the battery once, twice or thrice in a
row automatically. This is good for making certain the battery stays fully charged.
Delta-peak Sensitivity for NiMH/NiCd
Delta-peak sensitivity for NiMH/NiCd battery: The automatic charge termination program
based on the principle of the Delta-peak voltage detection. When the battery’s voltage
exceeds the threshold, the process will be terminated automatically.
Cyclic Charging/Discharging
1 to 5 cyclic and continuous process of charge > discharge or discharge > charge is opera-
ble for battery refreshing and balancing to stimulate the battery’s activity.
Automatic Charging Current Limit
You can set up the upper limit of the charging current when charging your NiMH or NiCd
battery, it is useful for the NiMH battery of low impedance and capacity in the ‘AUTO’
charging mode.
Battery Voltage Meter
The user can check battery’s total voltage, the highest voltage, the lowest voltage and each
cell’s voltage.
Battery Internal Resistance Meter
The user can check battery’s total internal resistance and each cell’s internal resistance.
Capacity Limit
The charging capacity is always calculated as the charging current multiplied by time. If the
charging capacity exceeds the limit, the process will be terminated automatically when you
set the maximum value.
Special Features

8
Temperature Threshold*
The battery’s internal chemical reaction will cause the temperature of the battery to rise. If
the temperature limit is reached, the process will be terminated.
* This function is only available by connecting optional temperature probe, which is not included in the package.
Processing Time Limit
You can also limit the maximum process time to avoid any possible defect.
USB Power 5V/2.1A
You can charge your Smartphone
or Tablet using the built-in USB
power output port.
BOX CONTENT
XH Adaptor (4pcs)
Charging Cable
(2pcs)
Power Cord
EXCEL 200 QUAD
Charging Cable with XT60 connector
(4pcs)
Special Features

9
These warnings and safety notes are particularly important. Please follow the
instructions for maximum safety; otherwise the charger and the battery can be
damaged or at worst it can cause a re.
🛑
Never leave the charger unattended when it is connected to its power supply. If any
malfunction is found, TERMINATE THE PROCESS AT ONCE and refer to the opera-
tion manual.
🛑
Keep the charger well away from dust, damp, rain, heat, direct sunshine and vibra-
tion. Never drop it.
🛑
The allowable DC input voltage is 11~18V DC.
🛑
The allowable AC input voltage is 100~240V AC.
🛑
This charger and the battery should be put on a heat-resistant, non-inammable and
non-conductive surface. Never place them on a car seat, carpet or similar. Keep all
the inammable volatile materials away from operating area.
🛑
Make sure you know the specications of the battery to be charged or discharged to
ensure it meets the requirements of this charger. If the program is set up incorrect-
ly, the battery and charger may be damaged .It can cause re or explosion due to
overcharging.
LiPo LiIon LiFe LiHV NiCd NiMh Pb
Nominal
Voltage 3.7V/Cell 3.6V/Cell 3.3V/Cell 3.8V/Cell 1.2V/Cell 1.2V/Cell 2.0V/Cell
Max Charge
Voltage 4.2V/Cell 4.1V/Cell 3.6V/Cell 4.35V/Cell 1.5V/Cell 1.5V/Cell 2.46V/Cell
Storage
Voltage 3.8V/Cell 3.7V/Cell 3.3V/Cell 3.85V/Cell n/a n/a n/a
Fast Charge ≤ 1C ≤ 1C ≤ 4C ≤ 1C 1C-2C 1C-2C ≤0.4C
Min. Discharge
Voltage 3.0-3.3V/Cell 2.9-3.2V/Cell 2.6-2.9V/Cell 3.1-3.4V/Cell 0.1-1.1V/Cell 0.1-1.1V/Cell 1.8V/Cell
Standard Battery Parameters
Be very careful to choose the correct voltage for different types of battery otherwise you
may cause damage to the batteries. Incorrect settings could cause the cells to re or
explode.
Warning and Safety Notes

10
🛑
Never attempt to charge or discharge the following types of batteries.
A battery pack which consists of different types of cells (including different manufacturers).
A battery that is already fully charged or just slightly discharged.
Non-rechargeable batteries (Explosion hazard).
Batteries that require a different charge technique from NiCd, NiMh, LiPo or Gelcell (Pb,
Lead acid).
A faulty or damaged battery.
A battery tted with an integral charge circuit or a protection circuit.
Batteries installed in a device or which are electrically linked to other components.
Batteries that are not expressly stated by the manufacturer to be suitable for the currents
the charger delivers during the charge process.
🛑
Please bear in mind the following points before commencing charging:
Did you select the appropriate program suitable for the type of battery you are charging?
Did you set up adequate current for charging or discharging?
Have you checked the battery voltage? Lithium battery packs can be wired in parallel
and in series, i.e. a 2 cell pack can be 3.7V (in parallel) or 7.4V (in series).
Have you checked that all connections are rm and secure?
Make sure there are no intermittent contacts at any point in the circuit.
🛑
Charging
During charge process, a specic quantity of electrical energy is fed into the battery.
The charge quantity is calculated by multiplying charge current by charge time. The
maximum permissible charge current varies depending on the battery type or its perfor-
mance, and can be found in the information by the battery manufacturer. Only batteries
that are expressly stated to be capable of quickcharge are allowed to be charged at
rates higher than the standard charge current.
Connect the battery to the terminal of the charger: red is positive and black is negative.
Due to the difference between resistance of cable and connector, the charger can not
detect resistance of the battery pack, the essential requirement for the charger to work
properly is that the charge lead should be of adequate conductor cross-section, and high
quality connectors which are normally goldplated should be tted to both ends.
Always refer to the manual by battery manufacturer about charging methods, recom-
mended charging current and charging time. Especially, the lithium battery should be
charged according the charging instruction provided by the manufacturer strictly.
Attention should be paid to the connection of lithium battery.
Do not attempt to disassemble the battery pack arbitrarily.
Warning and Safety Notes

11
Please get highlighted that lithium battery packs can be wired in parallel and in series. In
the parallel connection, the battery s capacity is calculated by multiplying single battery
capacity by the number of cells with total voltage stay the same. The voltages imbalance
may cause re or explosion .Lithium battery is recommended to charge in series.
🛑
Discharging
The main purpose of discharging is to clean residual capacity of the battery, or to reduce
the battery voltage to a dened level. The same attention should be paid to the discharg-
ing process as charging. The nal discharge voltage should be set up correctly to avoid
deep-discharging. Lithium battery can not be discharged to lower than the minimum volt-
age, or it will cause a rapid loss of capacity or a total failure. Generally, lithium battery
doesn‘t need to be discharged. Please pay attention to the minimum voltage of lithium
battery to protect the battery.
Some rechargeable batteries have a memory effect. If they are partly used and recharged
before the whole charge is accomplished, they remember this and will only use that part
of their capacity next time. This is a memory effect. It is said that NiCd and NiMH batteries
are suffering from memory effect. NiCd has more memory effect than NiMH.
🛑
The socket-outlet should be installed near the equipment and easily accessible.
FCC Caution:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Any changes or modications not expressly approved by the party responsible for com-
pliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiv-
er is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Warning and Safety Notes

12
BATT/PROGRAM
Pb BATT
ENTER
START
Pb CHARGE
2.0A 2.0V (1P)
DEC
INC
Pb DISCHARGE
0.1A 2.0V (1P)
BATT/PROGRAM
NiCd BATT
NiCd CHARGE
CURRENT 2.0A
ENTER
START
DEC
INC
NiCd DISCHARGE
0.1A CUT: 1.0V
DEC
INC
NiCd CYCLE
CHG>DCHG 1
BATT/PROGRAM
NiMH BATT
ENTER
START
NiMH CHARGE
CURRENT 2.0A
DEC
INC
NiMH DISCHARGE
0.1A CUT: 1.0V
NiMH CYCLE
CHG>DCHG 1
DEC
INC
BATT/PROGRAM
LiPo BATT
LiPo BALANCE CHG
2.0A 7.4V (2S)
LiPo CHARGE
2.0A 7.4V (2S)
LiPo FAST CHARGE
2.0A 7.4V (2S)
LiPo STORAGE
2.0A 7.4V (2S)
LiPo DISCHARGE
2.0A 7.4V (2S)
ENTER
START
DEC
INC
DEC
INC
DEC
INC
DEC
INC
DECINC
DECINC
BATT/PROGRAM
LiFe BATT
Lilo BALANCE CHG
2.0A 7.2V (2S)
Lilo CHARGE
2.0A 7.2V (2S)
Lilo FAST CHARGE
2.0A 7.2V (2S)
Lilo STORAGE
2.0A 7.2V (2S)
Lilo DISCHARGE
2.0A 7.2V (2S)
ENTER
START
DEC
INC
DEC
INC
DEC
INC
DEC
INC
BATT/PROGRAM
LiIo BATT
LiFe BALANCE CHG
2.0A 6.6V (2S)
LiFe CHARGE
2.0A 6.6V (2S)
LiFe FAST CHARGE
2.0A 6.6V (2S)
LiFe STORAGE
2.0A 6.6V (2S)
LiFe DISCHARGE
2.0A 6.6V (2S)
ENTER
START
DEC
INC
DEC
INC
DEC
INC
DEC
INC
DECINC
BATT/PROGRAM
BATT METER
4.20 4.19 4.19 V
0.00 0.00 0.00 V
MAIN 0.00V
H0.000V L0.000V
DEC
INC
DECINC
DECINC
DEC
INC
NiCd RE-PEAK
1
DEC
INC
NiMH RE-PEAK
1
DEC
INC
NiMH Auto CHARGE
CURRENT 2.0A
DEC
INC
NiCd Auto CHARGE
CURRENT 2.0A
DECINC
DECINC
DECINC
LiHV BALANCE CHG
2.0A 7.6V (2S)
LiHV CHARGE
2.0A 7.6V (2S)
LiHV FAST CHARGE
2.0A 7.6V (2S)
LiHV STORAGE
2.0A 7.6V (2S)
LiHV DISCHARGE
2.0A 7.6V (2S)
BATT/PROGRAM
LiHV BATT
ENTER
START
DEC
INC
DEC
INC
DEC
INC
DEC
INC
DECINC
BATT/PROGRAM
BATT MEMORY
ENTER
START
[ BATT MEMORY 1 ]
ENTER SET->
ENTER
START
BATT TYPE
LiPo
DEC
INC
BATT VOLTS
7.4V ( 2S )
DEC
INC
CHARGE CURRENT
4.9A
DEC
INC
DSCH CURRENT
2.2A
DSCH VOLTAGE
3.0V/CELL
TVC=YOUR RISK
4.20V
DEC
INC
ENTER
START
ENTER
START
BATT/PROGRAM
SYSTEM SETTING->
ENTER
START
Stop
Batt Type
DECINC
SAVE PROGRAM
ENTER
SAVE PROGRAM
SAVE….
[ BATT MEMORY 1 ]
LiPo 7.4V (2S )
[ BATT MEMORY 1 ]
C:4.9A D:2.2A
ENTER CHARGER
LOAD……
LiPo BALANCE CHG
4.9A 7.4V(2S)
LiPo CHARGE
4.9A 7.4V(2S)
DEC
INC
LiPo FAST CHARGE
4.9A 7.4V(2S)
DEC
INC
LiPo STORAGE
4.9A 7.4V(2S)
LiPo DISCHARGE
2.2A 7.4V(2S)
DEC
INC
DEC
INC
BATT TYPE
NiMH
DEC
INC
BATT VOLTS
2.4V (2S)
ENTER
START
CHARGE CURRENT
3.3A
DEC
INC
DEC
INC
TRICKLE
100mA
DEC
INC
PEAK DELAY
1Min
DECINC
DSCH CURRENT
2.0A
DEC
INC
DSCH VOLTAGE
1.1V/CELL
SAVE PROGRAM
ENTER
ENTER
START
BATT TYPE
Pb
BATT VOLTS
4.0V (2P)
DEC
INC
CHARGE CURRENT
3.3A
DSCH CURRENT
1.5A
DSCH VOLTAGE
1.7V/CELL
DEC
INC
SAVE PROGRAM
ENTER
DECINC
DEC
INC
DEC
INC
DECINC
BATT/PROGRAM
BATT RESISTANCE
DECINC
ENTER
START
005 003 003 mΩ
005 mΩ
DEC
INC
TATAL: 16mΩ
H: 5mΩ L: 3mΩ
ENTER
START
STARG/ENTER>3 Seconds
SAVE PROGRAM
SAVE….
ENTER
START
[ BATT MEMORY 2 ]
NiMH 2.4V (2S )
[ BATT MEMORY 2 ]
C:1.0A D:1.0A
START /ENTER>3s
ENTER CHARGER
LOAD……
NiMH CHARGE
CURRENT 1.0A
NiMH Auto CHARGE
CURRENT 1.2A
DEC
INC
DEC
INC
NiMH DISCHARGE
1.0A CUT: 2.0V
NiMH RE-PEAK
2
NiMH CYCLE
CHG>DCHG 1
[ BATT MEMORY 2 ]
ENTER SET->
[ BATT MEMORY 3 ]
ENTER SET->
SAVE PROGRAM
SAVE….
ENTER
START
[ BATT MEMORY 3 ]
Pb 4.0V (2S )
[ BATT MEMORY 3 ]
C:3.3A D:1.5A
ENTER CHARGER
LOAD……
Pb CHARGE
3.3A 4.0V(2P)
Pb DISCHARGE
1.5A 4.0V(2P)
Rest Time
CHG>DCHG 10Min
DEC
INC
Safety Timer
ON 120Min
DEC
INC
Capacity Cut-Off
ON 5000mAH
DEC
INC
DECINC
DEC
INC
Temp Cut-Off
ON 50°C 122°F
NiMH Sensitivity
D.Peak 4mv
DEC
INC
NiCd Sensitivity
D.Peak
4mv
Key Beep ON
Buzzer ON
DEC
INC
DEC
INC
Version
HW:1.00 SW: 1.00
Load Factory Set
ENTER
DEC
INC
DC Input Low
CUT-OFF 11.0V
AC Max Power Set
50W
DEC
INC
Temperature Unit
Celsius
DEC
INC
START
START ENTER > 3s
Bal. Connection
ON
DECINC
ENTER
DEC
INC
DEC
INC
DEC
INC
DEC
INC
Note: The Flow Chart shows the example of a single output.
(Channel A, B,C and D are identical)
Program Flow Chart

13
CH A / CH B
It is used to switch from Channel A, B ,C ,D
BATT PROG / STOP
It is used to STOP the progress or GO Back to previous Step/Screen
DEC Button
It is used to go through the menus and DECREASE the parameter value
INC Button
It is used to go through the menus and INCREASE the parameter value
ENTER/START Button
It is used to ENTER parameter on screen and START the program
When you are willing to alter the parameter value in the program, press the START/ENTER
button to make it blink then change the value by pressing DEC and INC button. The value
will be stored by re-pressing the START/ENTER button. If there is another parameter can
be altered in the same screen, when you conrm the rst parameter value, the next param-
eter value will start to blink which means it is ready to alert.
When you are willing to start the process, press and hold the START/ENTER button for 3
seconds.
When you are willing to stop the progress or go back to previous step/screen, press the
BATT PROG/STOP button once.
Buttons Explanation

14
EXCEL 2OO QUAD
DISPLAY
XT60
EXCEL 2OO QUAD
DISPLAY
1. Connecting to Power Source
There are two kinds of inputs for EXCEL 200 QUAD, DC 11-18V and AC 100-240V.
AC 100-240V POWER SOURCE CONNECTION.
12V DC BATTERY / DC POWER SUPPLY CONNECTION.
Power and Battery Connection

15
LiPo
EXCEL 2OO QUAD
DISPLAY
NiMH
EXCEL 2OO QUAD
DISPLAY
NOTE : We will explain the operating procedure of one channel.
The procedure for Channel A, B, C, D is identical.
2. Connecting the Battery
TO AVOID SHORT CIRCUITS, ALWAYS CONNECT THE CHARGE LEADS TO
THE CHARGER FIRST, AND THEN TO THE BATTERY.
REVERSE THE SEQUENCE WHEN DISCONNECTING THE PACK.
1) LiPo Battery Connection with Balance Adapter
2) NiMH/NiCd or Pb Battery Connection
Balance Socket
For safety reasons, the default setting for charging Lithium (LiPo, Lilo, LiFe and
LiHV) battery is using balance adaptor to connect battery and charger in Charge,
Fast Charge, Balance Charge and Storage modes. But if the battery comes with
no balance wire, you could disable this function in the system settings as follows :
The balance wire attached to the battery must be connected to the charger with
the black wire aligned with the negative marking. Ensure correct polarity!
BATT/PROGRAM
SYSTEM SETTING
BAL.Connection
OFF
Power and Battery Connection

16
BATT/PROGRAM
SYSTEM SETTING->
LIPO BALANCE
2.0A 7.4V(2S)
A
B
LIPO BALANCE
2.0A 7.4V(2S)
C
LIPO BALANCE
2.0A 7.4V(2S)
D
LIPO BALANCE
2.0A 7.4V(2S)
A
B
LIPO BALANCE
2.0A 7.4V(2S)
C
LIPO BALANCE
2.0A 7.4V(2S)
D
Safety Timer
ON 120Min
LIPO BALANCE
2.0A 7.4V(2S)
A
B
C
LIPO BALANCE
2.0A 7.4V(2S)
D
AC Max Power Set
50W
LIPO BALANCE
2.0A 7.4V(2S)
A
B
C
LIPO BALANCE
2.0A 7.4V(2S)
D
AC Max Power Set
65W
AC Max Power Set
35W
ENTER
Press DEC
Button 3
times and
push ENTER
Button
AC Max Power Set
50W
Press INC
or DEC
Button
1- Operating in AC Mode
EXCEL 200 QUAD comes with a built-in switching power supply. You can connect the AC
power cord directly to the AC mains socket. (100-240V AC).
In AC mode, it supports Power Distribution. You could set the AC Max Power for one chan-
nel (Take Channel A for example) as follows,
And the other channel (Channel C) will take the remaining power automatically (For exam-
ple, if you set Channel A as 65W, the Channel C will be 35W).
✽ If Channel A and Channel C are both charging, you can’t change the power distribution.
✽ If Channel A is charging, you can change AC power of Channel C and Channel A will
take the remaining power automatically.
2- Operating in DC Mode
Please connect EXCEL 200 QUAD to AC/DC power supply with the supplied DC input
cable. You could also use terminal clips with DC connectors and attach them directly to 12V
car batteries. It is critically important that you use either a fully charged 13.8V car battery or
a high quality AC/DC power supply in the range of 11-18V DC output with minimum power
400W or higher to ensure reliable performance.
Important Notice : Low quality DC power source may damage the charger.
Power Distribution

17
BATT/PROGRAM
LiPo BATT
LiPo BALANCE
2.0A 11.1V (3S)
LiPo BALANCE
2.0A 11.1V (3S)
LiPo BALANCE
2.0A 11.1V (3S)
LiPo BALANCE
2.0A 11.1V (3S)
START/ENTER
START/ENTER
START/ENTER
START/ENTER
START/ENTER
> 3 Seconds
(1) A memory prole is available for setting and storing pertinent information for up
to 20 different program sets; each channel can store 10 program. Once a battery
program is stored into memory, it will be retained until changed again manually.
Recalling a program memory number makes the charger instantly ready to go!
(2) If you do not wish to use the battery program memories, this charger can be man-
ually set before each use.
The following owchart shows how the program is set manually :
BATT/PROGRAM Select
Press INC and DEC to go through all the programs and press
START/ENTER to enter LiPo BATT Program.
Mode Select
Press INC and DEC to go through all the modes and press
START/ENTER to enter LiPo Balance Charge Mode.
Battery Setting
Press START/ENTER, the present value will start to blink.
Press INC and DEC to change the value and press START/
ENTER to conrm your setting.
At the same time, the battery pack’s cell count will start to
blink, press INC and DEC to change the value and press
START/ ENTER to conrm your setting.
Program Start
Press and hold START/ENTER for 3 seconds to start the
program.
Lithium Battery Program (LiPo/LiFe/LiIon/LiHV)

18
R:3SER S:3SER
CONFIRM(ENTER)
Lp4s 1.5A 12.14V
BAL 000:50 00022
START/ENTER
BATTERY CHECK
WAIT...
R:3SER S:3SER
CANCEL(STOP)
[ END: FINISHED ]
16.8V 2600mAh 100
[ Time: 00: 45: 32 ]
16.8V 2600mAh 100
The charger is detecting the battery cell.
R shows the number of cells detected by the charger and S is the
number of cells set by you on the previous screen. If the two numbers
are not identical, press STOP to go back to the previous screen to
recheck the number of cells of the battery pack that you set before
going ahead.
R shows the number of cells detected by the charger and S is the
number of cells set by you on the previous screen. If the two numbers
are identical, press START/ENTER to start the charging process.
Charging Status Monitor
During charge process, real-time status will be shown as seen on the
left.
Program Complete
Once the battery is fully charged, the screen will read
“END: FINISHED” and the charger will emit a ringing sound. The
charger also displays battery voltage, charged capacity and elapsed
time.
PROGRAM STOP
During the charging process, press STOP to stop the charging process.
Lithium Battery Program (LiPo/LiFe/LiIon/LiHV)

19
Lp3s 1.5A 12.14V
BAL 000:50 00022
4.07 4.06 4.11 V
0.00 0.00 0.00 V
Fuel= 90%
Cell= 4.10V
INC
INC
Lp4s 1.5A 12.14V
BAL 000:50 00022
Ext. Temp ----
Int. Temp 37°C
DEC
Temp Cut-Off
50C
DEC
DEC
DEC
DEC
DEC
End Voltage
12.6V(3S)
IN Power Voltage
12.56V
Safety Timer
ON 200min
Capacity Cut-Off
ON 5000mAh
VARIOUS INFORMATION DURING THE PROCESS
Press INC or DEC during the charging or discharging process to view further pertinent
information on the LCD screen.
Real-time status: battery type, battery cell count, charge current, battery
pack total voltage,working mode, elapsed time and charged capacity.
Voltage of each cell in the battery pack when the battery is connected
with balance lead.
Charged capacity percentage and average cell voltage of the battery
pack.
Final voltage when the program ends.
Input voltage.
Internal temperature.
Temperature probe needs to be connected to show external tempera-
ture.
Cut-off temperature.
Safety timer ON and duration of time in minutes.
Capacity cut-off ON and value of the set capacity limit.
Lithium Battery Program (LiPo/LiFe/LiIon/LiHV)

20
NiMH CHARGE
CURRENT 2.0A
NiMH 2.0A 5.42V
CHG 002:22 00106
START/ENTER
NiMH/NiCD:
This program is only suitable for charging/discharging NiMH/NiCd batteries.
The EXCEL 200 QUAD offers the following NiMH/NiCd charge modes: Charge, Auto
Charge, Discharge, Re-Peak and Cycle.
Selecting the Battery Type:
After powering on the EXCEL 200 QUAD, press the INC or DEC button repeatedly until you
reach the appropriate program for the battery type you wish to charge. For this example we
have chosen the “NiMH BATT“ or “NiCD BATT” program. Now press the ENTER button to
enter the desired program.
NiMH/NiCD Charge Mode:
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU HAVE READ
AND UNDERSTOOD ALL OF THE WARNINGS AND SAFETY INFORMATION CON-
TAINED ON PREVIOUS PAGES.
After selecting the correct battery type, if the screen does not read “CHARGE”, use the
DEC or INC buttons to change it to the “CHARGE” mode.
BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE YOU ARE
CHARGING NIMH/NICD BATTERIES. CHARGING LiPO BATTERY UNDER
NIMH/NiCD BATTERY WILL CAUSE FIRE.
Press the ENTER button and the amp rate value will begin blinking.
Use the DEC or INC button to adjust the value to the desired rate.
Follow the instructions provided on your battery when setting the
charge current.
Press and hold the ENTER button for 3 seconds to start charging.
Once charging has commenced, the charger will display the fol-
lowing real-time information: battery type, charging current, battery
voltage, working mode, elapsed time and charged capacity. Once
the battery is fully charged, the screen will read “END: FINISHED”
and the charger will emit a ringing sound. You can press the STOP
button at any time during the charging process to stop charging.
NiMH/NiCd Auto Charge Mode :
In this mode, the charger automatically detects the connected NiMH or NiCD battery and
determines the proper full charge and cut-off thresholds. Setting the upper charge current
limit for safe levels based on your battery specications will ensure safe charging of your
specic battery. If you are unsure of the maximum allowable charge rates, set the charger
to a maximum of 1C (battery mAh/1000, e.g. 3200mAh = 3.2A).
Battery Program (NiMH/NiCD)
