Pure-Pro ERO-S7 PERFECT WATER SERIES User manual

PRO
P
URE
DRINKING WATE R SYSTEM
19
PURE-PRO PERFECT WATER SERIES
PRO
P
URE
DRINKING WATE R SYSTEM
Type ofproduct
Date of purchase
Name Tel
Address
Memo
ERO-S7
ERO-S7
PERFECT WATER SERIES
USER'S MANUAL
Thank you verymuch for selectingPure-Pro WaterCorp.
In order tobring the bestuse of yoursystem, please readthe user's manual
carefully before installationand follow theregulations.
01 Aboutperfect water
03 Why perfectwater is popular
04 Components
05 Cartridge filters
07 Preparation
08 Panel operationsand functions
11 Tubing connectiondiagram
12 Installation diagram
14 Change filters
16 Change membrane
17 Troubleshooting guide
18 FAQ
19 Memo

01
PURE-PRO PERFECT WATER SERIES
18
PURE-PRO PERFECT WATER SERIES
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
About Perfect Water FAQ
Q: What is the guaranteeon the PurePro system ?
The PurePro system (excluding filters) is guaranteed for 1 year for material and
workmanship. All defective parts will be replaced free within the first year under
natural breakdown. The membrane has one year pro-rated guarantee.
Q: What factors affect thequantity and the quality ofthe water production?
There are four major variablesto consider:
1.Pressure-The greater the water pressure, the better water quantity and
quality it produced. Water pressure of 60 PSIis ideal.
00
2.Temperature-76 F is the ideal water temperature for R.O. 40 F water will
0
cause the production of R.O. water to fall to half of that at 76 F. The maximum
0
water temperature recommended is 85 F.
3.Total Dissolved Solids (TDS)-The higher the amount of dissolved
contaminants in the water, the lower the quantity of water produced. A high
level of TOTAL DISSOLVED SOLIDS can be overcome with additional water
pressure.
4.Membrane-Different membranes have different characteristics. Some
produce more water than others; some have better contaminant rejection
capabilities; some have greater resistance to chemical abrasion for longer life.
PurePro system includes NF33-1812-100 The Thin Film Composite (TFC)
membranes combine the best of these characteristics and are considered the
finest membrane in the world.
Q: What is the maintenanceschedule for the PurePro system?
The three pre-filter cartridges should be changed every 6 months. The 5 micron
sediment cartridge filter is the first one; the second is a carbon cartridge filter,
and the third one is a 1 micron sediment filters. (some systems comes with the
Extruded carbon filter.) Failure to change the cartridge every 6 months may
cause chlorine to destroy themembrane.
Q: What does the PureProseries drinking water taste like?
The taste of the PurePro water depends on the amount of contaminants in the
tap water originally. If 95% of dissolved minerals and chemicals are removed,
the R.O. water may taste like distilled water (no minerals), bottled water (low
mineral), or natural spring water(moderate mineral content).
¨PurePro Most Perfect Water System
More and morepeople understand thatthe "perfect water"system would combine
the purity ofReverse Osmosis (R/O)and the tremendousbenefits provided by
alkaline, ionized water. Historically thishas not beeneasily achieved fora variety
of reasons. Ourwater technology expertsat PurePro havesolved the problemof
combining these twophenomenal yet verydifferent water technologies. Now you
can have perfectlyclean ANDperfectly healthy waterby installing ROsystem with
water ionizer!
Model: S800-Alkaline
Membrane: 100 GPD/ 378 LPDNF Membrane
Water storagetank: 2.2 gallons+ 3.2 gallons
Operation pressure: 50- 100 PSI
Dimensions: (cm) 47(L) x 27(W) x 40(H) - System
(cm) 28 (L)x 28 (W)x 35 (H)-Tank
Weight: 11.5 kg - system
4 kg -tank
¨Specifications: (Reverse Osmosis)
Four levels ofalkaline water.
Two levelsof acid water, including super-oxide.
Built-in auto-flushing electrode.
Filter water (non-ionized)- by ReverseOsmosis WaterSystem
Super anti-oxidant water
Alkaline water withpH8.0~10.0
Stainless steel outputspout
Unique post-operation automaticand silent cleansingfor extended lifespan
Sound confirmation everytime you selecta different pH level
Filter change requiredindicator
Easy 1-minute changefilter compartment
Hydrogen-rich water (hydrogengas bubbles inyour glass)
High negative ORPwater (to fightfree radicals)
Smaller molecular clusters
Mineralized with traceminerals
PurePro USAWater Ionizer faucet
Clean, safe, tastywater - straightfrom your tap
Energizing & Healingwater
¨Features

17 02
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
¨Specifications: (Water Ionizer)
About Perfect Water
PURE-PRO PERFECT WATER SERIES PURE-PRO PERFECT WATER SERIES
Processing rate of water 2./minute:
2
[In-water pressure is 0.1Mpa(about 1kgf/cm )]
Water exit volume 3L/minue:
2
[In-water pressure is 0.2Mpa(about 2kgf/cm )](estimate)
Electrolysis capacity level: Alkaline 3 level; Acidic 1 level
Possible continuous electrolysis duration:
(Level 1~2) about 1 hours (Level 3) about 30
Plate cleaning automatically performs every time being used.
When intensive cleaning is required after a period of time,
Intense cleaning indicator is on.
Automatic back cleaning when tap water is closed after
processing.
0
40 C
Power supply AC: 220V/50HZ(customized product)110V/60HZ
100-200W
Nanometer titanium alloyselectrolysis trough
Power consumption
Electrolysis material
In-water pressure 2
1 ~ 6.5kg/cm
Electrolysis technique Continuous electrolysis technique(water volume and
temperature gauge built-in)
Machine protection
installation
Fuse 10Aand electricalboard: 2Aelectrical power
overheating protection installed,transformer
temperature protection installed.
Electrolysis
Main machine
dimension Height 315mm xWidth 255mm xDepth 135mm
Machine weight About 5.5kg
Purifier
Totalwater flowing volume:about 12000L
Purifying capacity: takeaway salty particleresidue
Remove foul andbad odor
Max.wate temperature
for continuous usage
Power cable length About 9 feet
Model JA-703
+500MV ~ -700MV
ORP level
Phenomenon Reason for problems and handling guideline
Power background
light mot on displays
nothing
Ensure power cord is connected to an electrical outlet
Back light is mot on
and nothing get
displayed when
generating
1.Water pressure too low, the machine does not work
correctly, operator installs additional water pump.
2.Check for correct installation of filter cartridge. The
machine does not work when filter cartridge is misplaced.
Unfold the bent part of the water supply hose.
Ionized water or pure
water come out dirtily
1.Maybe it is time to replace filter cartridge? (Filter cartridge
can be bought in distribution agencies)
2.Is the tap only half on? Please let more water flow out from
the tap.
3.Is water supply line frozen? Defrost the water supply line
before using. Is the indicator light for cleaning required on?
Please perform cleaning.
Electrolyzed a lk al in e
water appears to have
white colored stain
Alkaline ionized water is usually white color after being
generated. This is due to the air bubbles formed as a result
of reaction with electrolysis. It will turn into transparent in a
short while and is perfectly safe for drinking.
1.The white floating object is a crystal formation(the solid
form of calcium) which reaction of Calcium ion and Carbon
Dioxide in the air generates. It is perfectly safe for drinking.
2.The thin layer that can be seen is the solid form of Calcium.
Please use vinegar to clean it.
Container for storing
alkaline water shows
white floating object
or develops thin layer
on its inner wall
Not using the ionizer
for long period of time
Alkaline water flowing
out from alkaline
faucet becomes slower
and slower
Maybe gradual formation of Calcium crystal in hose blocks
the water outlet, which makes the water flow-out become
slower and slower. Please consult with a professional to
clean inner hose or purchase special filter cleanser for the
ionizer from our company.
Please ensure the power cord is unplugged. Remove water
separator and filter device from the purifier.
Trouble Shooting Guide

03 16
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Why Perfect Water is Popular
Water Ionizeris a medical device in Japan.
Why? Read on . . .
ALKALINE WATER IMPROVES CHRONICHEALTH CONDITIONS
Research in Japansince the 1950'sand testimonials indicatethe following
conditions have beenimproved from drinkingalkaline water:
Arthritis
Heartburn
Chronic fatigue
Indigestion
Leg cramps
High blood pressure
Poor circulation
Migraines
Nausea
Obesity
Osteoporeosis
Psoriasis
Stress
Dr. OttoWarberg received the Nobel Prizefor discovering thecause of cancer-
this being lackof oxygen whichis low alkaline pH. No disease can exist inan
alkaline environment. Japanesemedicine has proventhis over thelast 15 years.
Water ionizercan restore properalkaline pH withinweeks.
PURE-PRO PERFECT WATER SERIES PURE-PRO PERFECT WATER SERIES
Change Membrane
¨Change membrane: (Reverse Osmosis)
Jaco
PRO
P
URE
DRINKINGWATERSYSTEM
3Loose the Jaco fitting anticlockwise. 4Remove the membranehousing
cap anticlockwise.
PRO
P
URE
DRINKINGWATERSYSTEM
5Remove the membrane by a pincer. 6Install the membraneby carefully
pushing the spigotend into the
socket at thefar end ofthe housing
until completely in.
2Switch off water tank.1Turn off water source.
ToRO system
Tankball
shut-off valve

15 04
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Components
Snake hose x1 Hose clip x2
Hanging fixture 1x
PH testing liquid 10ml
Water inlet/ Outlet
hose x 2
Suction used tofix
water drain hose
12
46
3
5
¨Components: (Water Ionizer)
Water storagetank
x 1
Drain saddle x1
¨Components: (Reverse Osmosis)
Tank ball shut-off
valve x 1
45
123
Water Ionizerfaucet
x 1
7
¨Change filters: (Reverse Osmosis)
Change Filters
PURE-PRO PERFECT WATER SERIES PURE-PRO PERFECT WATER SERIES
Tubing x1
6
Deliver-valve x 1
Water supply
connector x 1
2Switch off water tank.
Tankball
shut-off valve
5 Drain out 1Gallon of waterto
purify replacement filters.
DRAIN OUTLET INLET
S300STS300NDS300RD
S300ST
DRAIN OUTLET INLET
S300STS300NDS300RD
S300ST
3 Loose the used pre-filter clockwise
and remove it.
4 Screw in andinstall the newfilter
anticlockwise.
1Turn off water source.
ToRO system

05 14
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Cartridge Filters
¨Cartridge filters: (Water Ionizer)
¨Cartridge filters: (Reverse Osmosis)
Change Filters
¨Change filters: (Water Ionizer)
PURE-PRO PERFECT WATER SERIES PURE-PRO PERFECT WATER SERIES
Type:
Main parameter:
Water quality:
Water source:
Things to note:
Carbon filter
Filter life 12000L
Water pressure0.1M pa~0.4M pa
Meet the requirementof "Sanitary safetyand criteria of
drinking machine" (2001).
Municipal tap water
Replace filter regularly(The filter lifecan one year atmost.
it is necessaryto replace thefilter.)
function
water
last for
If clogged,
This 5micron sediment filter is made of 100% pure polypropylene fibers. High
capacity filter removesdusts, particles andrusts. (Service Life: 6Months)
(Stage 1) 5Micron Sediment Filter
(Stage 2) GACCarbon Filter
This block carbon filter is composed of high-performance carbon that removes
free chlorine, odor, organic contaminants, pesticides and chemicals that
contributed to tasteand odor.(Service Life: 6Months)
(Stage 3) CTO Carbon Filter
This block carbon filter is composed of high-performance carbon that removes
free chlorine, odor, organic contaminants, pesticides and chemicals that
contributed to tasteand odor.(Service Life: 6Months)

0613
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
(Stage 5) PostCarbon Filter
NSF approved. This post carbon filter is designed to improve taste. It removes
any residual impurities and odors from the tank and provides a finer conditioning
of pure water. (Service Life: 1Years)
Cartridge Filters
PURE-PRO PERFECT WATER SERIES PURE-PRO PERFECT WATER SERIES
Installation Diagram
Install faucet :
Input water : Install water tank:
Install drain saddle:
Drill a 1/4"hole into
the drain pipe.
Mount drain
saddle aligning
holes.
Hand tighten
plastic shut-off
valve to tank.
Then connect
color tubing.
ToRO system
Tankball shut-
off valve
ToRO system
Deliver valve
Water supply connector
Towater
source pipe
Nanofiltration membrane has a slightly larger pore size than reverse osmosis
membrane. Thus monovalent salts like sodium chloride (common table salt)
molecules passes through the membrane but large divalent salts of calcium,
magnesium and othermetals like iron,heavy metals..etc. areall blocked.
(Service Life: 2Years)
(Stage 4) NFMembrane
Assemble membrane :
PRO
P
URE
DRINKINGWATERSYSTEM
Loose the Jacofitting anticlockwise.
Jaco
Remove the membranehousing cap.
Install the membraneby carefully
pushing the spigotend into the
socket at thefar end ofthe housing
until completely in.
(Stage 6)Alkaline Plus Filter
The Alkaline plus filter changes the acidic RO water into a perfect Natural Alkali
Calcium Ionized Water. The Alkaline plus filter simply gives back minerals such
as ionized calcium, magnesium, sodium, potassium ion, which were taken away
while purifying thewater. (Service Life: 1 Years)

07
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
12
Preparation
Operation panel
Water drain hose
Alkaline water
Acidic water
Power supply cable
¨Preparation: (Water Ionizer)
¨Preparation: (Reverse Osmosis)
Installation Diagram
Flexible hose :
PURE-PRO PERFECT WATER SERIES PURE-PRO PERFECT WATER SERIES
RO membrane housing
Housing bracket white
Post carbon filter
Tank
Auto shut-off valve
Tankball shut-off valve
Mini flow restrictor
Alkaline plus filter

Tank
D
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
11 08
PURE-PRO PERFECT WATER SERIES PURE-PRO PERFECT WATER SERIES
Panel Operations and Functions
Tubing Connection Diagram
CONNECTING THE COLORTUBING:
A. Connect theWHITE tubing tothe water supplyconnector.
B. Connect theBLUE tubing tothe sink topfaucet.
C. Connect theBLACK tubing tothe drain saddle.
D. Connect theRED tubing tothe storage tank.
DRAIN OUTLET INLET
S300STS300NDS300RD
Input water A
Faucet
B
Drain
C

PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
09 10
PURE-PRO PERFECT WATER SERIES PURE-PRO PERFECT WATER SERIES
Panel Operations and Functions Panel Operations and Functions
