PURE-PRO REVERSE OSMOSIS SYSTEM
Type of product
Date of purchase
Name Tel
Address
PRO
P
URE
DRINKING WATER SYSTEM
USER'S MANUAL
01 Introduction of M500
02 What is reverse osmosis
03 Components &
04 Cartridge filters
05 The parts of M500
06
07
09
10
12
14
15
Selected filters
Tubing connection diagram
Installation diagram
08 Change filters
Change membrane
Operation regulation
FAQ
Maintenance checking list
Memo
Thank you very much for selecting Pure-Pro Water Corp.
In order to bring the best use of your system, please read
the user's manual carefully before installation and follow
the regulations.
Memo
M500
M500 In-Line Filter RO Systems

01
PURE-PRO REVERSE OSMOSIS SYSTEM
14
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
Introduction of M500
¨
¨
M500-In-Line Filter RO systems
Specifications
PurePro M500 reverse osmosis system uses the most advanced water treatment
technology available. Reverse Osmosis is recognized as one of the best
available technologies for producing high quality drinking water. It's also the
same method used by many bottled water companies to make safe and great
tasting drinking water.
The newly designed M series M500 is user friendly with design simplicity in mind.
It requires no tools for filter changes. Use in-line cartridge filter design makes
filter changes fast, clean and easy. This space saving allows maximum use of
your under counter space.
Maintenance checking list
Date
Filters
1st stage 2nd stage 3rd stage 4th stage 5th stage Other items
Production: 50 GPD / 189 LPD
Water storage tank: 3.2gallons / 12.2 liters
With a booster pump (optional):
Input in AC 110Volt, 220Volt or 240Volt (50 / 60Hz)
Operation pressure: 10 - 80 psi
Dimensions: (cm) 20 (L) x 28 (H) x 31.5 (W)
(cm)28(L)x35(H)x28(W)-tank
Weight:6kg-system
4kg-tank
M500 In-Line Filter RO Systems M500 In-Line Filter RO Systems

Reverse osmosis was originally designed to make sea water drinkable for the
navy. It is ideal for anyone on a low sodium diet. An R.O. membrane has a pore
size much smaller than bacteria virus, or the cryptosporidium parasite. When
functioning properly it will remove all microorganisms from tap water and produce
sterile water. Reverse osmosis is the reversal of the natural flow of osmosis. In a
water purification system, the goal is not to dilute the salt solution, but to
separate the pure water from the salt and other contaminants. When the natural
osmotic flow is reversed, water from the salt solution is forced to pass through the
membrane in the opposite direction by application of pressure-thus the term
REVERSE OSMOSIS. Through this process, we are able to produce pure water
by screening out the salts and other contaminants.
13
PURE-PRO REVERSE OSMOSIS SYSTEM
02
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
What is reverse osmosis
Reverse Osmosis
Pressure
Membrane
Water flow
Q: How will the Pure-Pro series water affect mixed beverages?
Because reverse osmosis removes invisible contaminants that mask flavor, it
allows the natural taste of your beverages to come through. You will be able to
use less coffee and still get the full flavor. Concentrated beverages like orange
juice will taste tangier. You will probably be drinking a lot more water as well,
since many people drink soda, Kool-Aid, concentrated juices, and beer as an
alternative to bad-tasting tap water. Also, Pure-Pro eliminates most of the lime
build up on drip coffee makers, preventing the need for frequent cleaning. No
longer will you find the white scum on the inside of pans after boiling water.
Q: How much water does the Pure-Pro system produce ?
Q: Don't people need minerals removed from the water ?
Q: What is the maintenance schedule for the Pure-Pro System ?
Under ideal conditions, the RE1812-70 TFC membrane is rated at 70gallons of
production per day (70gpd at 60psi, 95gpd at 100psi). Under the average
conditions, the consumer can expect 70-95 gallons of product water per day. But
that's still a lot of water for the average household's drinking and cooking
requirements.
Most of the minerals that we receive are from the foods we eat. Only a very
small percentage comes from the water we drink.
The three pre-filter cartridges should be changed every 6 months. The 5 micron
sediment cartridge filter is the first one; the second is a carbon cartridge filter,
and the third one is a 1 micron sediment filters. (some systems comes with the
Extruded carbon filter.) Failure to change the cartridge every 6 months may
cause chlorine to destroy the membrane.
FAQ
M500 In-Line Filter RO Systems M500 In-Line Filter RO Systems

03
PURE-PRO REVERSE OSMOSIS SYSTEM
12
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
Components & Selected filters
3.2G water storage tank
Deliver-valve Water supply connector Drain saddle
Tank ball shut-off valve
¨Selected filters
¨Components
Infra-red cartridge filter
PRO
P
URE
DRINKING WATER SYSTEM
Q: What is the guarantee on the Pure-Pro system ?
Q: What factors affect the quantity and the quality of the water production?
Pressure
Temperature
Total Dissolved Solids (TDS)
Membrane
Q: Can the Pure-Pro system be connected to an extra faucet?
Q: What does the Pure-Pro series drinking water taste like?
The Pure-Pro System (excluding filters) is guaranteed for 1 year for material
and workmanship. All defective parts will be replaced free within the first year
under natural breakdown. The membrane has one year pro-rated guarantee.
There are four major variables to consider:
1. -The greater the water pressure, the better water quantity and
quality it produced. Water pressure of 60 PSI is ideal.
2. -76 F is the ideal water temperature for R.O. 40 F water will
cause the production of R.O. water to fall to half of that at 76 F. The maximum
water temperature recommended is 85 F.
3. -The higher the amount of dissolved
contaminants in the water, the lower the quantity of water produced. A high
level of TOTAL DISSOLVED SOLIDS can be overcome with additional water
pressure.
4. -Different membranes have different characteristics. Some
produce more water than others; some have better contaminant rejection
capabilities; some have greater resistance to chemical abrasion for longer life.
Pure-Pro system includes RE1812-70 The Thin Film Composite (TFC)
membranes combine the best of these characteristics and are considered the
finest membrane in the world.
It only takes a 1/4" tee and tubing to run the water to a refrigerator or a extra
faucet. Some families run Pure-Pro system to all of their bathrooms.
The taste of the Pure-Pro water depends on the amount of contaminants in the
tap water originally. If 95% of dissolved minerals and chemicals are removed,
the R.O. water may taste like distilled water (no minerals), bottled water (low
mineral), or natural spring water (moderate mineral content).
0 0
0
0
FAQ
Standard faucet
T.D.S
UVC-LIGHTING
ULTRAVIOLET WATER STERILIZER
Mineral cartridge filter
UV water sterilizer
TDS meter
Upgraded european
ceramic faucet
Color tubing
M500 In-Line Filter RO Systems M500 In-Line Filter RO Systems
Infra-Red
Mineral

11
PURE-PRO REVERSE OSMOSIS SYSTEM
04
PURE-PRO REVERSE OSMOSIS SYSTEM
6 Months
4 Years
1 Year
PRO
P
URE
DRINKING WATER SYSTEM
Cartridge Filters
Stage 1
Stage3
Stage 2
GAC Filter
Stage 4
TFC Membrane
Stage 5
Post Carbon Filter
Cartridge Filters Filter Description
6 Months
6 Months
This 5micron sediment filter is made of 100%
pure polypropylene fibers. High capacity filter
removes dusts, particles and rusts.
It takes out 99% of the chlorine and organic
chemicals. It provides enhanced reduction of
taste, odor, and color.
It takes out 99% of the chlorine and organic
chemicals. It provides enhanced reduction of
taste, odor, and color.
Made in USA. High rejection TFC type membrane
with the capacity of producing 50 gallons per day.
This membrane removes the following hard water
contaminants that may be present in your water:
lead, cooper, barium, chromium, mercury, sodium,
cadmium, fluoride, nitrite, nitrate, and selenium.
NSF approved. This post carbon filter is designed
to improve taste. It removes any residual
impurities and odors from the tank and provides a
finer conditioning of pure water.
5 Micron
Sediment Filter
PRO
P
URE
DRINKING WATER SYSTEM
A.With everything connected, turn on the water check for leaks.
B.Make sure the storage tank shut-off valve is "OFF". Open the sink
top faucet.
C.Within a few minutes (up to 15) the water will start to run from the
faucet slowly.
D.Let the water run for at least 30 minutes. This flushes the carbon
filters on first time use.
E.After initial flushing, open the shut-off valve on the tank and close
the sink top faucet.
F.Tank will now full of water (usually 2 to 3 hours) after the tank has
filled. Open the sink top faucet and drain all water until the storage
tank is empty and there is only a small flow from the sink top
faucet.*** DO NOT USE FIRST TANK OF WATER.***
G.Close the sink top faucet. The system is now ready for use.
H.Change filters regularly every 6 to 12 months and have the
membrane checked annually.
Caution
1.Do not use hot water (over 45 C)!
2.Do not freeze the machine!
3.Switch off electricity and water source if away for more than 5 days,
and drain out pure water.
0
Operation regulation
Service Life
M500 In-Line Filter RO Systems M500 In-Line Filter RO Systems
GAC Filter

3Let the water run for at least 30
minutes. This flushes the carbon
filters on first time use.
05
PURE-PRO REVERSE OSMOSIS SYSTEM
10
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
Operation regulation
ThepartsofM500
M500 In-Line Filter RO Systems M500 In-Line Filter RO Systems
1st stage
2nd stage
3rd stage
Input water
To the faucet
To the tank
To drain out tube Mini flow restrictor
Post carbon filter
RO membrane housing
1Turn on water source.
To RO system
2Switch on water tank.
Side view
Front view
Back view
Auto shut-off valve

Jaco
06
PURE-PRO REVERSE OSMOSIS SYSTEM
09
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATER SYSTEM
Tubing connection diagram
Faucet
Tank
Drain
Input water
A
B
C
D
PRO
P
URE
DRINKING WATER SYSTEM
PRO
RE
NG WATE R SYSTEM
3Loose the Jaco fitting anticlockwise. 4Remove the membrane housing
cap anticlockwise.
O
5Remove the membrane by a pincer.
6Install the membrane by carefully
pushing the spigot end into the
socket at the far end of the housing
until completely in.
Change membrane
M500 In-Line Filter RO Systems M500 In-Line Filter RO Systems
2Switch off water tank.
1Turn off water source.
To RO system
CONNECTING THE COLOR TUBING:
A. Connect the WHITE tubing to the water supply connector.
B. Connect the BLUE tubing to the sink top faucet.
C. Connect the BLACK tubing to the drain saddle.
D. Connect the RED tubing to the storage tank.

Install European ceramic faucet :
PURE-PRO REVERSE OSMOSIS SYSTEM
07 08
PURE-PRO REVERSE OSMOSIS SYSTEM
Input water : Install water tank :
1.Remove the membrane housing cap.
2.Replace the membrane.
PRO
P
URE
DRINKING WATER SYSTEM
To RO system
Deliver valve
To faucet
To water source pipe
Install drain saddle :
Assemble membrane :
Hand tighten plastic
shut-off valve to tank.
Then connect color
tubing.
Drill a 1/4" hole into
the drain pipe.
Mount drain
saddle aligning
holes.
Installation diagram
5Turn on water source and water
tank, drain out 1 Gallon of water
to purify replacement filters.
PRO
P
URE
DRINKING WATER SYSTEM
Change filters
4Remove the used filters from clips
and replace with new ones.
2Switch off water tank.
1Turn off water source.
To RO system
M500 In-Line Filter RO Systems M500 In-Line Filter RO Systems
3Loose the Jaco fitting anticlockwise.
Jaco
