PureLink FX-I545 User manual

Version 1.0 | 2020
Instruction manual (EN)
FX-I545 USB 3.1 AOC Cable

2
USB 3.1 AOC Cable
TABLE OF CONTENTS
CHAPTER PAGE
Introduction ............................................................................................. 3
Intended Use ............................................................................................ 3
Safety Instructions ............................................................................. 4- 5
Delivery content ..................................................................................... 5
Features ..................................................................................................... 6
Application ............................................................................................... 6
Specications ..................................................................................... 7-8
Mechanical properties and Environmental performance ������������� 7
 Specications������������������������������������������������������������������������������������������������� 8
Environmental Conditions ����������������������������������������������������������������������� 8
Cross Section ........................................................................................... 9
Construction ���������������������������������������������������������������������������������������������������� 9
Cable Construction �������������������������������������������������������������������������������������� 9
Operation and connection diagram ................................................. 10
Maintenance ......................................................................................... 11
Cleaning ................................................................................................. 11
Warranty and Liability ........................................................................ 12
CE-Conformity ...................................................................................... 13
Disposal of the Device ........................................................................ 13
Disclaimer .............................................................................................. 14

3
INTRODUCTION
Thank you for purchasing the Fiber Optic USB 3.1 AOC Cable.
This Cable allows you to transmit USB signals to a distance of
up to 30m without external power supply. This cable is a hybrid
cable containing both ber optic and copper cores.. It supports
a maximum data rate of 10 Gbps per channel, is light weight,
exible, and has an ultra-small xed installation bending radius
of 20mm.
INTENDED USE
This product is intended for indoor use only. Do not use it out-
doors. Contact with moisture, e.g. in bathrooms, must be avoided
under all circumstances.
For safety and approval purposes (CE), you must not rebuild and/
or modify this product. If you use the product for purposes other
than those described above, the product may be dam- aged. In
addition, improper use can cause hazards such as short circuiting,
re, electric shock etc.
Read the instructions carefully and keep them. Make this prod-
uct available to third parties only together with its operating
instructions.

4
SAFETY INSTRUCTIONS
Read the operating instructions carefully and especially observe
the safety information. If you do not follow the safety instructions
and information on proper handling in this manual, we assume no
liability for any resulting personal injury or damage to property.
Such cases will invalidate the warranty/ guarantee.
The device is not a toy. Keep it out of the reach of children and
pets. Do not leave packaging material lying around carelessly.
These may become dangerous playing material for children. Risk
of suocation!
The maximum pulling tensile load of the cable is 157N (16kg).
Never pull the cable with higher load. The minimum bending
radius of the hybrid cable is approximately 20mm, bending the
cable to a smaller radius will irreversibly destroy the cable.
Pay attention to trip hazards; make sure that the cable is installed
safely.
Protect the product from extreme temperatures, direct sunlight,
strong jolts, high humidity, moisture, ammable gases, vapors
and solvents.
Do not place the product under any mechanical stress.
If it is no longer possible to operate the product safely, take it out
of operation and protect it from any accidental use.

5
Safe operation can no longer be guaranteed if the product:
• is visibly damaged
• is no longer working properly
• has been stored for an extended period in poor ambient
conditions or
• has been subjected to any serious transport-related stresses.
Please handle the product carefully. Jolts, impacts or a fall even
from a low height can damage the product.
Also observe the safety and operating instructions of any other
devices which are connected to the product.
Consult an expert when in doubt about the operation, safety or
connection of the device.
DELIVERY CONTENT
1x USB 3.1 AOC Cable
1x User Manual DE/EN
1x Warning Insert

6
FEATURES
This AOC Cable has many features that enable it to perform in a
superior manner. Among those features you will nd:
• Extends USB 3.1 signals up to 30 m
• Supports all USB 3.1 device types
• Works with USB 3.1 Super Speed Host Controllers
• Supports all major operating systems including Windows,
Mac OS and Linux
• Number of devices can be increased by additional hubs
• Power adapter is not required
• The remote unit requires a standard power supply for the
USB 3.1 AOC port
• Not downward compatible with USB 2.0 devices
APPLICATION
This cable can be used for:
• Computers / PCs
• Home networks
• Medical applications
• LED video walls
• Digital Signage
… and more

7
SPECIFICATIONS
Mechanical properties and Environmental performance:
Item Units Specied values
Tensile strength
(Long-term)
N bis zu 157N
Crush resistance
(Long-term)
N/100mm 1000N
Minimum bending radius
(dynamic)
mm 20 D*
Minimum bending radius
(static)
mm 10 D*
*D = the diameter of the cable body, in this case it is 4.5mm

8
Spezications
Item Description
Units Transmitter (Source) Receiver (Display)
USB Version USB 3.1 Standard
Video Bandwidth 10Gbps.
O/E Converter 2 channel 850 nm
VCSEL array
2 CH GaAs PD array
Connector Type USB AM to Type B Type
Cable Type Hybrid type with OM3 ber and copper wire
Cable Outer Diameter 4.5 mm
Jacket Outer Material PVC
Dierential Input 100 Ohm
Power Consumption 0.5W
Power Supply Non external power required
Passive Power Supply 5V
Environmental Conditions:
Operating Temperature: -10– 50°C
Storage Temperature: -20– 60°C
Relative Humidity: 10– 80%RH

9
CROSS SECTION
Construction:
Hybrid cable, ber (high speed data) & copper (low speed
signals)
Cable construction:
2 ber cores and 2 cooper conductors
Cable jacket: PVC / TPU
Diameter: 4.5mm
Connector dimensions: AM: 40x18x9mm
Type B: 36.3x12x13.3mm
Connector material: zinc alloy
Al-Mylar
Insulating layer
Copper
Fiber
Semi-tighted
Jacket

10
OPERATION AND CONNECTION DIAGRAM
Attention:
The FX-I545 is designed for use with the + 5V passive power
supply, provided by the host device through the USB connection.
This +5V connection, as well as powering the internal ber optic
module, is also carried through to the other sink via a full stand-
ard copper connection. Please make sure, that the host device is
capable of delivering more than 500mA.
Before using this cable, please make sure that all devices which
will be connected with the AOC USB Cable are shut down and
without power.
Then you can start to connect the “host side” of the USB plug to
the transmitter and connect the “remote(device) side” of the oth-
er USB plug to the receiver/display.
This works without additional power supply.
We do not recommend using any intermediate cables or adapters
between the connections, as the signal transmission performance
maybe attenuated.
Switch on the power of the device of the USB host and the remote.

11
MAINTENANCE
There are no components located inside the product you need to
maintain. Never open/dismantle the product.
Maintenance, modications and repairs are to be performed ex-
clusively by an expert or at a qualied shop.
If you have questions which remain unanswered by these oper-
ating instructions, contact our technical support service or other
technical personnel.
CLEANING
Before cleaning the product it must be disconnected from all oth-
er connected products.
Do not use abrasive or solvents or any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as they can cause
damage to the housing and malfunctioning.
To clean the product, a dry, soft and clean cloth is sucient. Do
not apply too much pressure to the housing as this may cause
scratch marks. You can easily remove dust using a long-haired,
soft and clean brush.

12
WARRANTY AND LIABILITY
The producer grants 2 years warranty to a new device.
As the manufacturer has no inuence on installation, warranty
only applies to the product itself.
If any fault or damage is detected on your product, please contact
your dealer and provide your sales slip or invoice as evidence of
the purchase, if necessary. Your dealer will repair the fault either
on site, or send the device to the manufacturer. You make the
work of our technicians considerably easier, describing possible
faults in detail – only then you can be assured that faults, occur-
ring only rarely, will be found and repaired with certainty!
The manufacturer is not liable for damages to persons or prop-
erty caused by improper installation, operation or maintenance,
not described in this manual.
Do not alter or modify the product or its accessories.
Any use other than described in this user`s manual is not per-
mitted and causes loss of warranty, loss of guarantee, and non-li-
ability.

13
CE CONFORMITY
PureLink GmbH hereby declares that the FX-I545-XX
Series complies with Directive 2014/30/EU.
The full text of the EU Declaration of Conformity is
available at the following Internet address:
www.purelink.de/ce/FX-I545-XXX_CE.pdf
DISPOSAL OF THE DEVICE
WEEE-Reg. Nr.: DE 93847290
According to the European WEEE directive, any elec-
trical and electronic equipment must not be disposed
with consumers waste. As a consumer, you are commit-
ted by law to reposit electrical and electronic devices
to public collecting points or to the dealer for free at
the end of the device’s lifetime. Details are regulated
in the respective national legislations. The garbage can
symbol on the product, in the manual or on the
packaging refers to these terms. With the return of
your used devices you actively take part in protecting
the environment.

14
DISCLAIMER
This product complies with the statutory national and European
requirements. All company names and product names are trade-
marks of their respective owners.
All rights reserved.
We reserve our right for misprints and changes of the device,
packing or user`s manual.
