PureMate PM 4002 User manual

DIGITAL AIR FRYER
Model No: PM 4002
Ensure that all safety precautions are followed when using electrical appliances for
the proper operation of the device. This instruction booklet describes the safety
precautions to be observed during operation to prevent injuries to yourself, other
persons and damage to the device. The content not only is suitable for this product
but also suitable for electrical appliances in general.
WARNING!
!
INSTRUCTION MANUAL

SAFETY PRECAUTIONS
Read and follow all instructions carefully.
This appliance is not intended for use by persons (including children younger
than 8 years) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruc-
tion concerning the use of appliance by a person responsible for their safety.
Check if the voltage indicated on the appliance corresponds to the local mains
voltage before you connect the appliance.
Do not use the appliance if the plug, the mains cord or the appliance itself is
damaged.
If the mains cord is damaged, you must have it replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
Children should be supervised to ensure that they do not play with the appli-
ance. Cleaning and user maintenance shall not be made by children unless they
are older than 8 years and supervised.
Keep the appliance and its mains cord out of the reach of children younger than
8 years when the appliance is switched on or is cooling down.
Keep the mains cord away from hot surfaces.
Do not plug in the appliance or operate the control panel with wet hands.
Only connect the appliance to an earthed wall socket. Always make sure that
the plug is inserted into the wall socket properly.
Never connect this appliance to an external timer switch or separate
remote-control system in order to avoid a hazardous situation.
Do not place the appliance on or near combustible materials such as a table-
cloth or curtain.
Do not place the appliance against a wall or against other appliances. Leave at
least 10cm free space on the back and sides and 10cm free space above the
appliance. Do not place anything on top of the appliance.
Do not use the appliance for any other purpose than described in this manual.
Do not let the appliance operate unattended.
During hot air frying, hot steam is released through the air outlet openings. Keep
your hands and face at a safe distance from the steam and from the air outlet
openings. Also be careful of hot steam and air when you remove the pan from
the appliance.
The accessible surfaces may become hot during use.
After using the appliance, the metal cover inside is very hot, avoid to touch the
hot metal inside after cooking.
Immediately unplug the appliance if you see dark smoke coming out of the
appliance. Wait for the smoke emission to stop before you remove the pan from
the appliance.
When using electrical appliances, basic safety precautions should always
be followed including the following:
English | 1
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■

English | 2
PARTS
CONTROL PANEL
1. Power On/Off
2. Temperature Control
3. Pre-set Modes
4. Timer (0-60 minutes)
5. Pre-set Symbols
6. Heating Up Symbols
7. Fan Working Symbol
8. Temperature Display
9. Timer Display
PRE-SET COOKING MODES
1. Fry basket
2. Protective cover
3. Push-release button
4. Handle bar
5. Fry pot
6. Upper housing
7. Air inlet
8. Control panel
9. Air outlet
10. Power cable
78
6
9
10
1234
5
78, 9
14
65
23
1. Chips 200°C | 20mins
2. Lamb Chops 180°C | 15mins
3. Prawns 160°C | 20mins
4. Cake 160°C | 40mins
5. Chicken 180°C | 25mins
6. Steak 160°C | 20mins
7. Fish 180°C | 20mins
1 2 3 4
765

English | 3
USING THE APPLIANCE
BEFORE THE FIRST USE
1. Remove all packaging material,
2. Remove any stickers or labels from the appliance.
3. Thoroughly clean the basket and pan with hot water, some washing-up liquid
and a non-abrasive sponge.
Note: You can also clean these parts in the dishwasher.
4. Wipe the inside and outside of the appliance with a moist cloth.
This is an air fryer that works on hot air. Do not fill the pan with oil or frying fat.
1. Plug the mains plug into an earthed wall socket.
2. Carefully pull the pan out of the air fryer.
3. Put the ingredients in the basket.
Note: You can preheat the appliance without any ingredients inside. Please set
the timer to 5 minutes and press the Power On/Off button to start heating. When
the timer has counted down to zero, a beeping will sound. You may now add
the ingredients.
Note: Never fill the basket in full or exceed the recommended amount
(Refer to "Settings"), as this could affect the quality of the end result.
4. Slide the pan back into the air fryer properly.
Never use the pan without the basket in it. If the pan doesn't fit in the air
fryer properly, the appliance will not power!
Caution: Do not touch the pan during and sometime after use, as it gets
very hot. Only hold the pan by the handle.
Never use the pan without the basket in it. If the pan doesn't fit in the air fryer
properly, the appliance will not power!
Caution: Do not touch the pan during and sometime after use, as it gets
very hot. Only hold the pan by the handle.
5. Use the temperature controls to set the required temperature and the timer
controls to set the required cooking time. Refer to "Settings" to determine the right
temperature and time.
Alternatively, select a pre-set cooking mode by using the Mode button.
6. Press the Power On/Off button to begin cooking.
7. Some ingredients require shaking halfway through the preparation time
(Refer to "Settings"). To shake the ingredients, pull the pan out of the appliance
by the handle and shake it. Then slide the pan back into the air fryer and
continue to cook.
Caution: Do not press the button of the handle during shaking.

English | 4
SETTINGS
8. When you hear the timer bell, the set preparation time has elapsed. Pull the pan
out of the appliance and place it on a heat-resistant surface.
Note: You can also switch off the appliance manually. To do this, press the
Power On/Off button.
9. Check if the ingredients are ready. If the ingredients are not ready yet, simply
slide the pan back into the appliance and set the timer to a few extra minutes.
10. To remove small ingredients (e.g. fries), press the basket release button and lift
the basket out of the pan.
Do not turn the basket upside down with the pan still attached to it, as any excess
oil that has collected on the bottom of the pan will leak onto the ingredients.
After hot air frying, the pan and the ingredients are hot. Depending on the type
of the ingredients in the air fryer, steam may escape from the pan. After hot air
frying, the pan and the inside metal cover are hot, avoid touching.
11. Empty the basket into a bowl or onto a plate.
Tip: To remove large or fragile ingredients, use a pair of tongs to lift the
ingredients out of the basket
12. When a batch of ingredients is ready, the air fryer is instantly ready for
preparing another batch.
Tip: To reduce the weight, you can remove the basket from the pan and shake the
basket only. To do so, pull the pan out of the appliance, place it on a heat-resistant
surface and press the button of the handle.
Tip: If you set the timer to half the preparation time, you hear the timer bell when
you have to shake the ingredients. However, this means that you have to set the
timer again to the remaining preparation time after shaking.
The table below helps you to select the basic settings for the ingredients you want to
prepare.
Note: Keep in mind that these settings are indications. As ingredients differ in origin,
size, shape as well as brand, we cannot guarantee the best setting for your ingredi-
ents. Due to rapid hot air technology instantly reheating the air inside the appliance,
pulling the pan briefly out of the appliance during hot air frying barely disturbs the
process.
Tips
• Smaller ingredients usually require a slightly shorter preparation time than larger
ingredients. A larger amount of ingredients only requires a slightly longer preparation
time, a smaller amount of ingredients only requires a slightly shorter preparation time.
• Shaking smaller ingredients halfway through the preparation time optimizes the end
result and can help prevent unevenly fried ingredients.

English | 5
• Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the air fryer
within a few minutes after you added the oil. Do not prepare extremely greasy ingredi-
ents such as sausages in the air fryer.
• Snacks that can be prepared in an oven can also be prepared in the air fryer.
• The optimal amount for preparing crispy fries is 500 grams.
• Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough
also requires a shorter preparation time than home-made dough.
• Place a baking tin or oven dish in the air fryer basket if you want to bake a cake or
quiche or if you want to fry fragile ingredients or filled ingredients.
• You can also use the air fryer to reheat ingredients.
-
-
-
-
-

English | 5
CLEANING AND MAINTENANCE
TECHNICAL SPECIFICATIONS
Note: Do not use harsh or abrasive cleaning detergents or scourers to
clean the air fryer or its parts as this could cause damage.
- Rated Voltage: 220-240V~50/60 Hz
- Rated power: 1400W
- Net weight: 4.7 Kg
- Product Size: 34 x 30 x 38 CM
Please clean the appliance after every use. Please allow the appliance needs to
cool down before cleaning!
Do not use metal kitchen utensils or abrasive cleaning materials to clean the
pan, the basket & separator, as this may damage the non-stick coating.
1.Remove the mains plug from the wall socket and let the appliance cool down.
Note: Remove the pan to let the air fryer cool down more quickly.
2. Wipe the outside of the appliance with a moist cloth.
3. Clean the pan and the basket with hot water, some washing-up liquid and a non-
abrasive sponge. You can use a degreasing liquid to remove any remaining dirt.
Note: The basket & separator are dishwasher-safe.
Tip: If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot water with
some washing-up liquid. Put the basket in the pan and let the pan and the basket soak
for approximately 10 minutes.
4. Clean the inside of the appliance with a damp cloth or non-abrasive sponge.
DO NOT IMMERSE THE FRYER IN ANY LIQUID
5. Clean the heating element with a cleaning brush to remove any food residues
.

English | 6
At the end of the product life cycle, you should not throw this
machine into the normal household garbage but bring the product
to a collection point for the recycling of electrical and electronic
equipment.
DISPOSAL OF THIS DEVICE
TROUBLESHOOTING
Problem Possible Cause Solution
Does not work
Power cord has not been inserted
into the power socket
Closely insert the power cord into the
grounded power socket.
Did not set the cook model Click the model selection button to
select appreciate cook model, then
click the ON/OFF button
Didn’t click the ON/OFF button
after select cook model.
Click the ON/OFF button
Food is rare
when time out
Too much food in the basket Fry food in turns
Temperature set is too low Set to an appropriate temperature, re-
fry food.
Cooking time is short Set an appropriate cooking time, re-
fry food.
Did not fry food
evenly
Certain foods need to be shaken
in the middle of cooking.
In the middle of cooking process, pull
the pot out and shake it to separate the
overlapped food material, then push
the pot back to continue.
Fried food is
not crisp
Some food materials have to be
fried with oil
Plush a thin layer of oil on the surface
of the food first, then start to fry
them.
Can not
smoothly push
the pot back to
appliance
The pot with too many food
materials is too heavy
The food material in the basket can
not exceed the max. line.
The basket is not correctly
placed in the pot.
Press the basket into thepot.
Handle bar stuck Place the handle bar in horizontal
position.
Smoking
Frying oily food Normal phenomenon.
Fryer contain oil from last use Please clean thepot and basket after
use.
