PureTools PT-SP-DP12 User manual

User Manual
PT-SP-DP12
User Manual
4K 1x2 DisplayPort Splitter
Model PT-SP-DP12
Designed in Germany
© 2019 PureLink GmbH All rights reserved. V1.0

User Manual
PT-SP-DP12
Preface
Read this user manual carefully before using this product. Pictures shown in this manual are
for reference only. Different model layouts and specifications are subject to the physical
product.
This manual is for operation instructions only, not for any maintenance usage.
In the constant effort to improve our product, we reserve the right to make changes in
functions or parameters without prior notice or obligation.
Trademarks
Product model and logo are trademarks. Any other trademarks mentioned in this manual are
acknowledged as the properties of the trademark owner. No part of this publication may be
copied or reproduced without the prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. It has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in which case
the user at their own expense will be required to take whatever measures may be necessary to
correct the interference.
Any changes or modifications not expressly approved by the manufacture would void the
user’s authority to operate the equipment.

User Manual
PT-SP-DP12
REACH | 1907/2006/EU
ROHS | 2011/65/EU
PureLink hereby declares that this product PureTools PT-SP-DP12 complies with Directives
1907/2006/EU und 2011/65/EU.
EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive)
PureLink GmbH hereby declares that this product PureTools PT-SP-DP12 complies with
Directives 2014/30/EU and 2014/35/EU. The full text of the EU Declaration of Conformity is
available at the following Internet address:
http://www.purelink.de/ce/4251364721469_CE.pdf

User Manual
PT-SP-DP12
SAFETY PRECAUTIONS
To ensure the best from the product, please read all instructions carefully before using the
device. Save this manual for further reference.
 Unpack the equipment carefully and save the original box and packing material for
possible future shipment
 Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to
persons.
 Do not dismantle the housing or modify the module. It may result in electrical shock or
burn.
 Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
 Refer all servicing to qualified service personnel.
 To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
 Do not put any heavy items on the extension cable in case of protrusion.
 Do not remove the housing of the device as opening or removing the housing may expose
you to dangerous voltage or other hazards.
 Install the device in a place with sufficient ventilation to avoid damage caused by
overheat.
 Keep the module away from liquids.
 Spillage into the housing may result in fire, electrical shock, or equipment damage. If an
object or liquid falls or spills on to the housing, unplug the module immediately.
 Do not twist or pull by force ends of the optical cable. It can cause malfunction.
 Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the
device before cleaning.
 Unplug the power cord when left unused for a long period of time.
 Information on disposal for scrapped devices: do not burn or mix with general household
waste, please treat them as normal electrical wastes.

User Manual
PT-SP-DP12
1
Product Introduction
Thanks for choosing the 4K 1x2 DisplayPort Splitter, which can distribute one DP input to
two outputs. The splitter supports DP video resolution up to 4K@60Hz 4:4:4 and
multi-stream transport (MST) feature. Besides, SST mode is used for both connected
displays show the same contents. It is ideal for PC/notebooks, docking stations, hub, 4K2K
TVs, daisy chain monitors, digital signage.
Features
 Simultaneously displays one DisplayPort source to two displays.
 DisplayPort 1.2a, 21.6Gbps.
 HDCP 1.3 compliant.
 Supports resolutions up to 4K@60Hz, HBR2 link rate.
 Supports the multi-stream transport (MST) feature.
 SST mode is used for both connected displays show the same contents.
 Ideal for PC/notebooks, docking stations, hub, 4K2K TVs, daisy chain monitors, digital
signage.
Packing List
 1x 4K 1x2 DisplayPort Splitter  1x Power Adapter (5V DC 1A)
 1x User Manual  2x Mounting Ears
Note: Please contact your distributor immediately if any damage or defect in the components is
found.

User Manual
PT-SP-DP12
2
DC 5V
12
3
Panel Description
① POWER LED: The LED illuminates red when power is applied.
DC 5V: DC barrel port to connect an AC power adapter.
② INPUT: DisplayPort input port to connect DP video source device.
③ OUTPUTS: Two DisplayPort output ports to connect DP video display devices.

User Manual
PT-SP-DP12
3
Technical Specification
Video Input
Input (1) DP IN
Input Connector (1) DP port
DP Input Resolution Up to 4K@60Hz 4:4:4
DP Standard 1.2a
HDCP Version 1.3
Video Output
Output (2) DP OUT
Output Connector (2) DP port
DP Output Resolution Up to 4K@60Hz 4:4:4
DP Standard 1.2a
HDCP Version 1.3
General
MST Function Support
SST Function Support
Bandwidth 21.6 Gbps
Operation Temperature -10℃ ~ +55℃
Storage Temperature -25℃ ~ +70℃
Relative Humility 10%-90%
Power Supply Input:100V~240V AC; Output: 5V DC 1A
Power Consumption 2W (Max)
Dimension (W*H*D) 71mm x 21mm x 61mm
Net Weight 115g

User Manual
PT-SP-DP12
4
System Connection
The following diagram illustrates the typical input and output connection of the splitter:
Under the MST mode
Note: Output resolution: 1.two
output ports support 4K@30Hz
(Max) simultaneously; 2.one
output port supports 4K@60 Hz,
another output port only supports
2K.
Under the MST mode, it does not
support MAC Computer as input
source device. When GPU as input
source device, only one of output
port supports audio.

User Manual
PT-SP-DP12
5
Under the SST mode
Note: Only under the SST mode,
SPDIF (192K 7.1ch) audio can be
used.
Under the SST mode, When GPU
as input source device, only one of
output port supports audio. When
MAC Computer as input source
device, both of output ports
support audio.

User Manual
PT-SP-DP12
6
Panel Drawing
DC 5V
71 .00 mm
61 .00
m
m
21 .00 mm
1x2
Splitter
4K (60Hz 4:4:4) with
MST support
PT-SP-DP12

User Manual
PT-SP-DP12
7
After-Sales Service
If there appear some problems when running the product, please check and deal with the
problems referring to this user manual. Any transport costs are borne by the users during the
warranty period.
1) Product Limited Warranty: The product will be free from defects in materials and
workmanship for two years (The purchase invoice shall prevail).
Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that
the unit is within the Warranty period must be presented to obtain warranty service.
2) What the warranty does not cover (servicing available for a fee):
 Warranty expiration.
 Factory applied serial number has been altered or removed from the product.
 Damage, deterioration or malfunction caused by:
 Normal wear and tear.
 Use of supplies or parts not meeting our specifications.
 No certificate or invoice as the proof of warranty.
 The product model shown on the warranty card does not match with the model
of the product for repairing or had been altered.
 Damage caused by force majeure.
 Servicing not authorized by distributor.
 Any other causes which does not relate to a product defect.
 Delivery, installation or labor charges for installation or setup of the product.
3) Technical Support: For any questions or problems, contact your distributor or reseller
and tell them the respective product name and version, the detailed failure situation as
well as the formation of the cases.

User Manual
PT-SP-DP12
Asking for Assistance
Technical Support:
Phone: [phone] - 0
Fax: [phone] – 99
Technical Support Hours:
8:30 AM to 5:00 PM Monday thru Thursday
8:30 AM to 4:00 PM Friday
Write to:
PureLink GmbH
Von-Liebig-Straße 10
D - 48432 Rheine
www.purelink.de
[email protected]
