PureTools PT-HDBT-701-RXAD User manual

User Manual
PT-HDBT-701-RXAD
User Manual
HDBaseT Receiver 4K (60Hz 4:2:0) with Audio De-embedding
Model PT-HDBT-701-RXAD
Designed in Germany
© 2017 PureLink GmbH All rights reserved. VersionV1.0

User Manual
PT-HDBT-701-RXAD
Preface
Read this user manual carefully before using this product. Pictures shown in this
manual are for reference only. Different model layouts and specifications are subject
to the physical product.
This manual is for operation instructions only, not for any maintenance usage.
In the constant effort to improve our product, we reserve the right to make changes in
functions or parameters without prior notice or obligation.
Trademarks
Product model and logo are trademarks. Any other trademarks mentioned in this
manual are acknowledged as the properties of the trademark owner. No part of this
publication may be copied or reproduced without the prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. It has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in
a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in
which case the user at their own expense will be required to take whatever measures
may be necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

User Manual
PT-HDBT-701-RXAD
REACH | 1907/2006/EU
ROHS | 2011/65/EU
PureLink hereby declares that this product PureTools PT-HDBT-701-RXAD
complies with Directives 1907/2006/EU und 2011/65/EU.
EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive)
PureLink GmbH hereby declares that this product PureTools PT-HDBT-701-RXAD
complies with Directives 2014/30/EU and 2014/35/EU. The full text of the EU
Declaration of Conformity is available at the following Internet address:
http://www.purelink.de/ce/4251364706756_CE.pdf

User Manual
PT-HDBT-701-RXAD
SAFETY PRECAUTIONS
To insure the best from the product, please read all instructions carefully before
using the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing
material for possible future shipment
Follow basic safety precautions to reduce the risk of fire, electrical shock and
injury to persons.
Do not dismantle the housing or modify the module. It may result in electrical
shock or burn.
Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or
install this product near water.
Do not put any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by
overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment
damage. If an object or liquid falls or spills on to the housing, unplug the
module immediately.
Do not twist or pull by force ends of the optical cable. It can cause
malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the
power to the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

User Manual
PT-HDBT-701-RXAD
1
Introduction to PT-HDBT-701-RXAD
The PT-HDBT-701-RXAD is an Ultra-thin HDBaseT Receiver designed with audio
de-embedded outputs. It receives 4K/1080p HDMI signal via CAT5e/CAT6a cable
from HDBaseT Transmitter or Matrix Switcher at 40m/70m.
It supports unidirectional PoH function, the receiver can be powered by HDBaseT
Transmitter or Matrix Switcher.
Feature
Supports HDMI1.4 & HDCP2.2, and is backward compatible to the previous
version.
Maximum transmission distance is up to 40m (131ft) at 4Kx2K, and 70m (230ft) at
1080p.
Supports bi-directional IR and RS232 pass-through for long-distance control.
Supports unidirectional PoH for simplified wiring, and compatible with 48VDC
PoC, the HDBaseT Receiver can be powered by HDBaseT Transmitter or Matrix
Switcher.
Supports audio de-embedded outputs.
Package Content
1 x PT-HDBT-701-RXAD Receiver
2 x Mounting Ears & 2 x Screws
1 x User Manual
1 x 3-Pin Phoenix Connector (Male)
4 x Plastic Cushions

User Manual
PT-HDBT-701-RXAD
2
Panel Description
Front Panel
No.
Name
Description
①
RS232 MODE
switcher
CTRL: RS232 pass-through control mode;
UPDATE A: Update Valens IC program, connect a PC to the
RS232 port, and then double-click the update file (.bat).
UPDATE B: Update the IC program which is used for
de-embedding audio, the upgrade method is the same as the
above UPDATE A.
②
Link status
LED
OFF: No Link; GREEN:Link successful.
③
HDCP
compliant LED
OFF: No HDMI traffic (no picture); GREEN: Traffic with HDCP;
Blinking: Traffic without HDCP.
④
Power LED
OFF: No power; RED: DC power present.
HDCPLINK
UPDATE A CTRL UPDATE B
1234

User Manual
PT-HDBT-701-RXAD
3
Rear Panel
No.
Name
Description
①
RS232
connector
If one is connected with control device (e.g. PC), and the
other should be connected with the third-party that need to
be controlled.
②
IR IN
Work with far-end IR OUT port, connect with IR Receiver (with
carrier) to collect IR signal to control far-end display device
from local.
③
IR OUT
Work with far-end IR IN port, connect with IR Emitter to send
IR signal to control input source device.
④
HDMI OUT
HDMI type A connector, connect to display.
⑤
AUDIO OUT
3.5mm stereo audio jack, connect to analog stereo audio
device.
⑥
COAX OUT
Coaxial audio connector, connect to digital audio device.
⑦
OPTICAL OUT
Optical audio connector, connect to optical audio devices.
⑧
HDBT IN
Connect to the HDBT OUT socket on HDBaseT Transmitter or
Matrix Switcher via CAT5e/6a/7 cable, support unidirectional
PoH technology.
⑨
DC 12V power
port
Connect to 12VDC power adaptor, or it can be powered via
the HDBaseT Transmitter or Matrix Switcher by unidirectional
PoH technology.
Tx Rx
RS232 DC 12VIR OUT HDMI OUT HDBT IN
AUDIO
OUT OPTICAL OUT
IR IN COAX
OUT
123456789

User Manual
PT-HDBT-701-RXAD
4
Specification
Video& Audio
Input
HDBT IN
Output
HDMI OUT; AUDIO OUT; COAX OUT; OPTICAL OUT
Control Ports
IR IN, IR OUT, RS232
General
Transmission Mode &
Distance
HDBaseT; 1080P ≤ 70m; 4K×2K ≤ 40m
Resolution
Up to 4K×2K@60Hz 4:2:0
Bandwidth
10.2Gbps
HDMI Standard
HDMI1.4 & HDCP2.2
Power Consumption
10W (max)
Temperature
-10℃~ 50℃
Humidity
0% ~ 90%
Power Supply
Powered by HDBaseT Transmitter or Matrix Switcher
Dimension (W*H*D)
152mmx16.2mmx100mm
Net Weight (g)
223g

User Manual
PT-HDBT-701-RXAD
5
System Diagram
Tx Rx Tx Rx
IR Receiver
TV Remote
Laptop
IR Emitter
HDTV
4K 40m, 1080P 70m
Soundbar
PT-HDBT-702-TX PT-HDBT-701-RXAD
Speaker
HDMI:
HDBaseT:
RS232:
IR:
Audio:

User Manual
PT-HDBT-701-RXAD
6
After-Sales Service
If there appear some problems when running the product, please check and deal with
the problems referring to this user manual. Any transport costs are borne by the users
during the warranty.
1) Product Limited Warranty: This product will be free from defects in materials and
workmanship for two years (The purchase invoice shall prevail).
Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the unit is within the Warranty period must be presented to obtain
warranty service.
2) What the warranty does not cover (servicing available for a fee):
Warranty expiration.
Factory applied serial number has been altered or removed from the product.
Damage, deterioration or malfunction caused by:
Normal wear and tear.
Use of supplies or parts not meeting our specifications.
No certificate or invoice as the proof of warranty.
The product model showed on the warranty card does not match with the
model of the product for repairing or had been altered.
Damage caused by force majeure.
Servicing not authorized by distributor.
Any other causes which does not relate to a product defect.
Delivery, installation or labor charges for installation or setup of the product.
3) Technical Support: For any questions or problems, contact your distributor or
reseller and tell them the respective product name and version, the detailed
failure situation as well as the formation of the cases.

User Manual
PT-HDBT-701-RXAD
D

User Manual
PT-HDBT-701-RXAD
D
Asking for Assistance
Technical Support:
Phone: [phone] - 0
Fax: [phone]
Technical Support Hours:
8:30 AM to 5:00 PM Monday thru Thursday
8:30 AM to 4:00 PM Friday
Write to:
PureLink GmbH
Von-Liebig-Straße 10
D - 48432 Rheine
www.purelink.de
[email protected]
