PureTools PT-HDBT-702-RX User manual

User Manual
PT-HDBT-702-RX
User Manual
HDBaseT Receiver 4K (60Hz 4:2:0) with IR and RS232
Model PT-HDBT-702-RX
Designed in Germany
© 2017 PureLink GmbH All rights reserved. VersionV1.0

User Manual
PT-HDBT-702-RX
Preface
Read this user manual carefully before using this product. Pictures shown in this
manual are for reference only. Different model layouts and specifications are subject
to the physical product.
This manual is for operation instructions only, not for any maintenance usage.
In the constant effort to improve our product, we reserve the right to make changes in
functions or parameters without prior notice or obligation.
Trademarks
Product model and logo are trademarks. Any other trademarks mentioned in this
manual are acknowledged as the properties of the trademark owner. No part of this
publication may be copied or reproduced without the prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. It has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in
a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in
which case the user at their own expense will be required to take whatever measures
may be necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

User Manual
PT-HDBT-702-RX
REACH | 1907/2006/EU
ROHS | 2011/65/EU
PureLink hereby declares that this product PureTools PT-HDBT-702-RX complies with
Directives 1907/2006/EU und 2011/65/EU.
EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive)
PureLink GmbH hereby declares that this product PureTools PT-HDBT-702-RX
complies with Directives 2014/30/EU and 2014/35/EU. The full text of the EU
Declaration of Conformity is available at the following Internet address:
http://www.purelink.de/ce/4251364706770_CE.pdf

User Manual
PT-HDBT-702-RX
SAFETY PRECAUTIONS
To insure the best from the product, please read all instructions carefully before
using the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material
for possible future shipment
Follow basic safety precautions to reduce the risk of fire, electrical shock and
injury to persons.
Do not dismantle the housing or modify the module. It may result in electrical
shock or burn.
Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install
this product near water.
Do not put any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by
overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on to the housing, unplug the module
immediately.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power
to the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

User Manual
PT-HDBT-702-RX
1
Introduction to PT-HDBT-702-RX
The PT-HDBT-702-RX is a mini-size HDBaseT Receiver to receive HDMI signal from
HDBaseT Transmitter or Matrix Switcher via CAT5e/CAT6a cable. HDBaseT technology
is used to transmit high-resolution 1080p/ 4k signal from transmitter to the
PT-HDBT-702-RX via a CAT5e/CAT6a cable at a distance of up to 70/40m. Moreover, it
support CEC, bi-directional RS232&IR control, and bi-directional PoH function.
Feature
Support Full HD: Delivers high resolution image (1080p@60Hz@48
b/pixels/3D/4Kx2K).
Maximum transmission distance is 70m for 1080p and 40m for 4Kx2K over
single CAT5e/CAT6a cable
High Bandwidth: 10.2Gps.
HDTV Compatible, use HDMI 1.4 and HDCP2.2 compliant.
Support CEC/IR/RS232 passthrough.
Support bi-directional PoH function.
Bi-directional RS232/IR control.
Use HDBaseT technology.
LED indicators show work status.
Package Content
1 x PT-HDBT-702-RX
4 x Plastic Cushions
1 x User Manual
2 x Mounting Ears with 4 Screws
1 x IR Receiver

User Manual
PT-HDBT-702-RX
2
Panel Description
No.
Name
Description
①
LINK
HDBT Link status indicator:
OFF: No Link
GREEN:Link Successful
Blinking GREEN: Link abnormal
②
HDCP
HDCP compliant indicator
OFF: No HDMI traffic (no picture)
GREEN: Traffic with HDCP.
Blinking GREEN: Traffic without HDCP
③
Power
OFF: No power; RED: DC power present.
④
RS232
RS232 connector.
⑤
IR IN
Connect with 5V IR receiver (with carrier) to collect infrared
signal, work with far-end IR OUT port
⑥
IR OUT
Connect with 5V IR emitter to send infrared signal, work with
far-end IR IN port
⑦
HDMI OUT
Connect with HDMI display
⑧
HDBT IN
Connect to the HDBT OUT socket on the transmitter via CAT5e/
CAT6a cable.
⑨
DC 24V
Connect with power supply (Not necessary if transmitter
connects with power adaptor).
Note: Pictures shown in this manual are only for reference.
123456789

User Manual
PT-HDBT-702-RX
3
Specification
Input & Output
Input
IR, HDBT& RS232
Input Connector
3.5mm mini jack, RJ-45, 3p captive screw connector
Output
HDMI, IR, RS232
Output Connector
HDMI female, 3.5mm mini jack, 3p captive screw
connector
General
Resolution Range
640x480@60Hz~4K×2K@30Hz
Transmission Mode
HDBaseT
Transmission Distance
1080p ≤70m; 4Kx2K ≤ 40m
Bandwidth
10.2Gbps
HDMI Standard
Support HDMI1.4 and HDCP2.2
Temperature
0~ 50℃
Humidity
10% ~ 90%
Power Supply
Input: 100VAC~240VAC, 50/60Hz;
Output: DC 24V, 1.25A
Power Consumption
14W
Dimension (W*H*D)
115mmx16.2mm x109mm
Net Weight
196g

User Manual
PT-HDBT-702-RX
4
System Diagram
RXTXRXTX
PT-HDBT-702-TX PT-HDBT-702-RX
4K 40m
1080P 70m
Laptop
IR Receiver
Projector
Remote
Projector
IR Emitter
HDMI:
RS232:
IR:
HDBaseT:

User Manual
PT-HDBT-702-RX
5
After-Sales Service
If there appear some problems when running the product, please check and deal with
the problems referring to this user manual. Any transport costs are borne by the users
during the warranty.
1) Product Limited Warranty: This product will be free from defects in materials and
workmanship for two years (The purchase invoice shall prevail).
Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the unit is within the Warranty period must be presented to obtain
warranty service.
2) What the warranty does not cover (servicing available for a fee):
Warranty expiration.
Factory applied serial number has been altered or removed from the product.
Damage, deterioration or malfunction caused by:
Normal wear and tear.
Use of supplies or parts not meeting our specifications.
No certificate or invoice as the proof of warranty.
The product model showed on the warranty card does not match with the
model of the product for repairing or had been altered.
Damage caused by force majeure.
Servicing not authorized by distributor.
Any other causes which does not relate to a product defect.
Delivery, installation or labor charges for installation or setup of the product.
3) Technical Support: For any questions or problems, contact your distributor or
reseller and tell them the respective product name and version, the detailed
failure situation as well as the formation of the cases.

User Manual
PT-HDBT-702-RX

User Manual
PT-HDBT-702-RX

User Manual
PT-HDBT-702-RX
Asking for Assistance
Technical Support:
Phone: [phone] - 0
Fax: [phone]
Technical Support Hours:
8:30 AM to 5:00 PM Monday thru Thursday
8:30 AM to 4:00 PM Friday
Write to:
PureLink GmbH
Von-Liebig-Straße 10
D - 48432 Rheine
www.purelink.de
[email protected]
