Purivortex Vortex V3 User manual

Before using this product, please
READ AND SAVE THE INSTRUCTION
User Manual
HEPA Air Purifier
Model: Vortex V3

1. Warranty
01
This product should be used only in accordance with the
specifications outlined in this User Guide. Usage other than
what has been specified here may result in serious injury.
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electric shock,
and injury to persons, including the following:
Read all instructions before using the appliance.
Keep the cord out of heavy traffic areas. To avoid fire hazard,
NEVER put the cord under rugs, near heat registers, radiator,
stoves, or heaters.
To protect against electrical hazards, DO NOT immerse in water
or other liquids. Do not use this device near water.
Children cannot recognize the hazards associated with the usage
of electrical appliances. For this reason, always supervise children
when they are near the unit.
Always unplug the air purifier before moving it, opening the
grille, changing filters, cleaning or whenever the air purifier
is not in use. Be sure to pull by the plug, not the cord.
NEVER drop or insert any objects into any openings.
DO NOT run the cord under carpeting.
DO NOT cover the cord with throw rugs or similar coverings.
DO NOT route the cord under furniture or appliances. Arrange
the cord away from traffic area and where it will not be tripped
over.
DO NOT operate any appliance with a damaged cord or plug,
if the motor fan fails to rotate, after the appliance malfunctions,
or if it has been dropped or damaged in any manner. Send to
Customer Service for assistance.
Use appliance only for intended household purposes as described
in this manual. Any other use is not recommended that may cause
fire, electric shock, or injury to persons.
DO NOT use outdoors.
DO NOT place anything on top of the unit.
NEVER block the air openings, grille/outlets or place the unit on a
soft surface such as a bed or sofa, as this could cause the unit to
tip over, blocking the air inlet or outlet.
DO NOT attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void your warranty. The inside
of the unit contains no user serviceable parts. All servicing should
be performed by qualified personnel only.
WARNING: To reduce the risk of fire or electric shock, do not use
this purifier with any solid-state speed control device.

3. Note:
4. Introduction:
02
2. Before Operating the Air Purifier
1. Carefully remove your air purifier from the packaging
box and plastic bag.
2. Place it on a firm, level and flat area.
Make sure none of the grilles are blocked.
Do NOT stick any external objects or your fingers inside
of the unit.
Do NOT use gasoline, benzene, and other abrasive or harsh
cleaners, etc. on and/or in the unit while cleaning as they will
damage the product.
NEVER use alcohol or other solvents.
The air purifier works the best in a closed environment. Its
performance may be compromised in a well-ventilated room.
Put the air purifier under the sun for an hour before using it
again if the purifier has not been used for a long time.
Thanks for purchasing our Vortex V3 air purifier. This User
Manual is meant to provide you with a brief walkthrough of
the device’s features and usage protocols. We hope you find
this manual helpful. For additional information and technical
support. Please feel free to contact us.

Table of ContentsTable of Contents
03
2. Specifications
1. Package Contents
1. Package Contents
2. Specifications
3. Get to Know Your Air Purifier
4. Controls
5. Decomposition Diagram of Filter Element
6. How to Operate the Machine
7. Cleaning and Replacing Filters
8. Common Faults and Troubleshooting
1 x HEPA Air Purifier
1 x HEPA 4-Stage Filter (Pre-Installed)
1 x User Manual
1 x Pre-Filter Fabric
Model
Power Supply
Rated Power
Noise Level
Dimensions
Net Weight
Vortex V3
55 W
100-120 V, 60 Hz
≤55 dB (A)
20.07 x 12.99 x 6.69 in
9.14 lbs.

04
2
1
3
6
Product Structure
4
1. Touch Panel
2. Air Outlet
3. Carrying Handle
4. Sensor
5. Pre-Filter Fabric
6. Housing
7. Power Cord
8. Air Inlet
8
5
7

05
4. CONTROLS
Air Quality Indication
Green
Blue
Yellow
Red
Very Good
Good
Moderate
Bad
Speed
Timer
Sleep Mode
Power ON/OFF
Replace Filter Indicator
Child Lock
3. Get to Know Your Air Purifier
a. Press button to select speed from the following options: 2, 3, 1, Auto.
b. Auto Mode adjusts to the appropriate fan speed according to indoor
air quality feedback.
a. You can set a timer for 1-12 hours.
b. You can set a timer to turn the air purifier on/off.
a. Sleep mode operates quietly by using the lowest fan speed.
b. All lights will turn off and only SLEEP button will appear with partial lighting.
Press button once. POWER indicator will turn on. After 30 seconds, the unit
will turn onto Speed 2.
a. The filter indicator will light up as reminder to replace the filter. Depending
on how often you use the air purifier, the indicator should turn on within
3-6 months.
b. Press and hold time button and Power ON/OFF button for 3 seconds to
reset the filter replacement indicator.
a. Press and hold child lock button for 3 seconds. All functional buttons will
be locked.
b. Press and hold again child lock button for 3 seconds. All functional
buttons will be un-locked.

06
HEPA Filter
Purification Process of Filter Mesh
5. Filter Core Decomposition Graph
Improve your indoor air quality with our new air cleaning system. Multiple levels of cleaning include a combination of pre-filter
that traps big particles.
1. The pre-filter filters out abrasive substances as a defence for the HEPA
2. HEPA filter eliminates 99.5% of pollutants as small as 0.3 µm or larger pollen and dust mites and filters air pollution of PM 2.5.
3. Heavy-duty activated carbon filters reduce unwanted odors in your living

07
1
5 6 7
234
6. How to Operate the Machine
Unpack the air purifier Take away the grilles from
the purifier
Remove the filter from its
plastic packaging
Place the filter back into the
purifier
Reattach the grilles to
the purifier
Plug the power cord into a
standard AC outlet Press Power ON/OFF button

08
(Figure 3)
(Figure 1) (Figure 2)
How to Replace the Filter Wash Pre-Filter Fabric
1. Unplug the air purifier. (Figure 1)
2. Take away the grilles from the purifier and pull the tabs to
remove the old filter.
Take away the grilles from the purifier and pull the tabs to
remove the old filter. (Figure 2)
3. Remove the new filter from its plastic packaging and install
a new filter with the white side facing out (tabs will be visible).
4. Press and hold time button and Power ON/OFF button for
3 seconds to reset the replace filter indicator.
5. Reattach the grilles to the purifier and plug the power cord
into a standard AC outlet.
When the filter indicator light
turns red, it needs to replace
the filter.
1. Take away the grilles to take the pre-filter fabric away.
2. Wash the pre-filter fabric with cold water and dry in
the air.
3. Reattach pre-filter fabric to the grilles. The position
of the mesh maintenance label needs to be kept in
the middle above the front cover. (Figure 1)
4. Reattach the grilles to the purifier. (Figure 2)

09
7. Cleaning and Replacing Filters
Product daily cleaning and maintenance.
a. Make sure that the power cord is disconnected while the appliance is cleaned and maintained.
b. Wipe the appearance with a soft cloth that is moderately moist and clean, and then dry with a dry cloth.
Please do not wet the machine directly with water. Keep the machine dry during cleaning to avoid electricity source failure.
c. The filter must be replaced at least every 4 to 6 months.
b. Use a brush to clean the air inlet of the machine.
If not in use for a long time, store the machine in a dry and ventilated place.
※ If your problem is not listed, please contact Customer Support.
NOTE：This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

10
No.
1Air purifier will not turn on or respond to
button contronls.
Strange smell coming from the purifier.
Airflow is sighnificantly reduced.
Air purifier makes an unusual noise while the
fan is on.
Not effective in removing smoke; No odor
removal function.
The indicator is still on after replacing the filter.
Poor air purification quality.
2
3
4
5
6
7
Problems Solutions
8. Common Faults and Troubleshooting Methods
If your problem is not listed, please contact Customer Support.
a. Tap SPEED button to increase the fan speed.
b. Make sure no objects are blocking the sides.
c. Make sure the filter is removed from its packaging and properly in place.
d. Mare sure the room is smaller than 247 ft²/23 ㎡. The air purifier may not be as
effective in larger rooms.
e. Replace the filter.
a. Press and hold time button and Power ON/OFF button for 3 seconds to reset the
filter replacement indicator.
a. Please replace the filter screen, as it may have reached the suction capacity.
b. You need to replace the new strainer.
a. Make sure the filter is properly in place with plastic packaging removed.
b. Make sure the air purifier is operated on a hard flat, even surface.
c. Replace the filter.
d. The air purifier may be damaged, or an external object may be inside. Stop using the
air purifier and contact Customer Support. Do not try to repair the air purifier.
a. Make sure the filter is removed from its packaging and properly in place.
b. Tap SPEED button to increase the fan speed.
c. Leave 15 in of clearance on all sides of the air purifier.
d. The pre-filter may be clogged by large particles, such as hair or lint, blocking
air flow. Wash or clean the pre filter.
e. Replace the filter.
a. Clean the filter or replace it if necessary.
b. Make sure not to use your purifier in an area with high humidity or white diffusing
essential oils.
a. Plug in the air purifier.
b. Press POWER ON/OFF button.

9.warranty Information
Product Name
Model
True HEPA Air Purifier
vortex V3
Default Warranty
For your own reference, we strongly
recommend that you record your order ID
and date of purchase.
Date of Purchase
Order ID
Period
1 Year
Terms & Policy
Purivortex warrants all products to be of the highest quality in
material, craftsmanship, and service,effective from the date of
purchase to the end of the warranty period.
Purivortex will replace any product found to be defective due to
manufacturer flaws based on eligibility. Refunds are available
within the first 30 days of purchase. Refunds are only available to
the original purchaser of the product.This warranty extends only
to personal use and does not extend to any product that has been
used for commercial, rental, or any other use for which the product
is not intended. There are no warranties other than the warranties
expressly set forth with each product.
This warranty is non-transferrable. Purivortex is not responsible in
any way for any damages, losses, or inconveniences caused by
equipment failure or by user negligence, abuse, or use noncompliant
with the user manual or any additional safety or use warnings
included in the product packaging and manual.
This warranty does not apply to the following:
Purivortex and its subsidiaries assume no liability for damage
caused by the use of the product other than for its intended
use or as instructed in the user manual. Some states do not
allow this exclusion or limitation of incidental or consequential
losses so the foregoing disclaimer may not apply to you. This
warranty gives you specific legal rights and you may also have
other rights which may vary from state to state.
Register your product at https://purivortex.com/
warranty to extend your 1-year warranty by an additional year.
Please fill out all required fields and include your
order ID, place of purchase, and purchase date, if applicable.
Extend Your Warranty by 1 Year
All expressed and implied warranties, including
the warranty of merchability, are limited to the
period of the limited warranty.
Damage due to abuse, accident, alteration,
misuse, tampering, or vandalism.
Improper or inadequate maintenance.
Damage in return transit.
Unsupervised use by children under 18 years of age.
11

11
