Purlette PL400G User manual

Owner’s Manual
Reverse Osmosis Water Filtration System
Model # PL400G
Scan QR code for installation video
or visit www.purlette.com

Congratulations!
You are now the owner of a Purlette System! Purlette is an under-the-
sink water ltration system that makes tracking your water quality
and keeping it clean and drinkable simpler than ever before.
Using the accompanying mobile app you can monitor the potability of
your water, know at all times exactly how much life your lter has left
in it, and even order replacement lters directly through the app.
With the Purlette system you can rest assured that the water your
family drinks is safe and clean.

System Features
Operation Touch Panel
Before Installation
What is in the Box
Introduction
Three-Way Valve
Drinking Faucet
Drain Saddle
How to Install an Air Gap
Connect Water Line
System Connection Diagram
How to Install a Partition
Flushing the Filters
Installation
Replacing and Resetting the FilterMaintenance
Warnings and PrecautionsSafety
Certications and Test Results
Performance Data
Self-Troubleshooting GuideTroubleshoot
Three Year Limited WarrantyWarranty

Introduction Installation Maintenance Troubleshoot WarrantySafety
• Sediment Filter: Traps large sediment such as sand, dirt, silt and rust.
• Active Carbon: Separates volatile organic carbon compounds, pesticides,
and chemicals.
• High Precision PP: Removes ne particles from tap water.
• Reverse Osmosis: Eliminates up to 99% of common drinking water contaminants.
• Post Carbon Block: Improves drinking water taste and gets rid of odors.
General Filter Replacement Intervals
• RO Filter - Replace every 24 months*
• HYBRID Filter - Replace every 12 months*
*Filter life may vary depending upon water usage and source water quality
The Purlette system will regularly enter auto-cleaning mode. This is based on usage and will
take place at random. The Purlette system will make an audible sound when it is in auto-
cleaning mode.
If user leaves the drinking faucet turned on, the Purlette system will shut off automatically after
two hours. To exit safety mode, restart the Purlette system by unplugging and replugging the
power plug.
User can monitor drinking water quality, check the remaining lter life, and purchase
replacement lters through the Purlette mobile app.
Advanced Multistage Dual Cell Filtration
Auto-Cleaning
Safety Mode
Real Time Monitoring via App
Sediment
Filter
Active Carbon
Filter
High Precision PP
Filter
Reverse Osmosis
Filter
Carbon Block
Filter

Introduction Installation Maintenance Troubleshoot WarrantySafety
Network Connection Short press the NETWORK and RESET touch button simultaneously. The network indicator
light will begin blinking, indicating that the system is searching for nearby WiFi, and upon successful connection, will
stay lit (non-blinking). If a network connection is not established, the network indicator light will continue to blink and
the Purlette system will attempt to establish a network connection for 10 minutes and then turn off.
Energy-Saving Mode After 3 hours of non-use the Purlette system will automatically switch to energy-saving
mode. All indicator lights will be off during energy saving mode. When the drinking water faucet is used, an operation
panel button is pushed, or the system enters auto-cleaning mode the Purlette system will exit energy saving mode
and indicator lights will illuminate automatically.
Power-on All indicator lights blink for 5 seconds when the Purlette
system is plugged in, signaling that the system is starting.
Operation Mode Filter indicator lights will stay lit (non-blinking) while
lters are functioning properly. When the service life of a lter expires, the
lter indicator light for the expiring lter will begin blinking. The unexpired
lter light will continue to stay lit (non-blinking) until that particular lter
need to be replaced.
Auto-Cleaning The two lter indicator lights will blink in alternating
sequences during auto-cleaning mode.
Operation Panel
RO Filter
Indicator Light
HYBRID Filter
Indicator Light
RESET
Touch-Button
Network
Indicator Light
NETWORK
Touch-Button
RO
HYBRID
RESET
NETWORK

Introduction Installation Maintenance Troubleshoot WarrantySafety
Before Installation
Operation Parameters
INDOOR USE ONLY we recommend that the Purlette system installed under the kitchen sink. However, you may install
the Purlette system in any suitable indoor location away from direct exposure to the environment, with adequate
space for the Purlette system to stand upright.
DO NOT USE with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or
after the system.
APPLICABLE FEED WATER: municipal tap water
MAXIMUM INPUT WATER FLOW: 2.5 gpm
OPERATING WATER PRESSURE: 15–100 psi
OPERATING FEED WATER TEMPERATURE RANGE: 40–100º F
OPERATING GFCI VOLTAGE: 100–125 V
Recommended Tools
• Variable speed drill
• 1/4” drill bit (for drainpipe)
• Protective eye gear
• Adjustable wrench
• Phillips-head screwdriver
• Tube cutter (for adjusting PE tube length if desired)
Installation must be performed in compliance with local plumbing codes
Failure to comply with above installation and operation parameters can result in void of warranty

Introduction Installation Maintenance Troubleshoot WarrantySafety
What is in the Box
Purier Dust Lid RO Filter Hybrid Filter Drinking Water
Faucet
and Parts
Thread
Seal Tape
Three-Way
Feed Water
Ball Valve
Drain
Saddle
1/4” Color Coded
PE Tubes
Locking
Clips
Quick
Connectors

Introduction Installation Maintenance Troubleshoot WarrantySafety
Step 1: Install the three-way feed water ball valve
Locate the cold water supply stop valve under the kitchen sink. Turn
the incoming cold water off (typically by turning the valve in clockwise
direction). Turn on the kitchen faucet to release any pressure in the pipes
and to make sure the water has stopped before proceeding to the next
step.
The cold water supply stop valve is usually located on the right-hand
side. However, to ensure this is the case, turn the hot water on for two
minutes. Feel both hoses with your palm. The hot water supply riser hose
should feel warm. The one remaining cool is the cold water supply.
Once you have ensured that the cold water supply is turned off,
disconnect the cold water riser hose tting from the cold water supply
stop valve that you just turned off. Using an adjustable wrench, loosen
the nut (typically by turning in a counter-clockwise direction) until
disconnected. There may be some residual water inside the riser hose
so have a bucket or towel to catch it.
Now install the three-way feed water ball valve. The three way feed water
ball valve has a top and a bottom that are threaded nut connectors with
a side quick-connect tting. Use the thread seal tape to wrap the threads
of the three-way feed water ball valve and attach the cold water riser
hose to it. Use the thread seal tape to wrap the threaded stem from the
cold water supply stop valve coming out of the wall and gently screw the
three-way ball valve on over the tape. Make sure that both connections
are secure, but do not over tighten or you can damage the ttings.
If your pipe connection is 1/2”, the three-way feed water ball valve is
3/8”, but comes with a 1/2” converter for your convenience.
Liberally Apply
Thread Seal Tape
Liberally Apply
Thread Seal Tape
Add 1/2” Converter
if Necessary
Add 1/2” Converter
if Necessary
Installation

Introduction Installation Maintenance Troubleshoot WarrantySafety
Step 1: Install the three-way feed water ball valve (cont.)
Step 2: Attach water line to three-way feed water ball valve
Now it’s time to connect the tap water input line to the three-way feed
water ball valve.
Locate the tap water input line (blue PE tube) and connect one end to
the three-way feed water ball valve by pressing the one end of the tube
into the quick-connect tting. Be sure to push it in all the way until you
feel it stop otherwise leaks may occur. Then slide the locking clip into
place to secure the tube. Tug on the water line gently to ensure that it is
secure.
Do not connect the other end to the Purlette system at this time
Close
Open
Locking Clip
Optional
Installation
Point
Recommended
Installation
Point
Installation

Introduction Installation Maintenance Troubleshoot WarrantySafety
Step 3: Install the drinking water faucet
Installation
When installing an additional faucet, many times there are already pre-drilled
holes available. Many sinks have a soap dispenser or spray hose hole that
can be used for this purpose. If there is no pre-drilled hole, please consider
hiring a professional, since some kitchen countertop materials may require
specialized tools. The hole should be at least 7/8” in diameter and no greater
than 1-3/8” in diameter.
Place the pop-up rubber gasket and base on the counter over the hole and
place the stem of the drinking faucet through in the order shown in the
illustration. The stem of the drinking faucet should be accessible from under
the sink.
Place the silicon washer onto the threaded stem and secure under the
counter by placing the 3/4” mounting nut on threaded stem and tightening the
mounting nut until the faucet can’t move freely.
Locate puried water output line (white PE tube) and insert into the drinking
water faucet quick-connect tting and ensure that it is secure. Once secured,
slide the locking clip into place.
Certain faucet models may not be equipped with a quick-connect tting.
Do not connect the other end to the Purlette system at this time

Introduction Installation Maintenance Troubleshoot WarrantySafety
Step 4: Install the drain saddle
Mount Drain Saddle
at Either Location.
Locking Clip
Select a location on the drain pipe that is at least 3” straight length of
pipe, preferably on a horizontal plane (B), for drilling a 1/4” hole through
one side of the drain pipe.
Next, align and install the 1/4” drain saddle’s quick connect tting with
the drilled hole. Attach the drain saddle to the drain pipe and tighten the
two screws. Once the drain saddle is secured, push the waste water
drain line (yellow PE tube) through the quick-connect tting on the saddle
and insert the locking clip to secure the yellow PE tube in place.
Do not connect the other end to the Purlette system at this time
Align the holes of the drain saddle and drain pipe with a drill bit.
A
B
Installation

Introduction Installation Maintenance Troubleshoot WarrantySafety
How to install an air gap
While Purlette can operate without the need for an air gap, your local plumbing code may require one to be installed.
Use a Dual Air Gap for Dishwasher and Reverse Osmosis Filters if necessary.
Follow the installation instructions that come with your Air Gap or Dual Air Gap.
Installation
Dishwasher
Dual Air Gap
Purlette System
Garbage Disposal
Yellow PE Tube

Introduction Installation Maintenance Troubleshoot WarrantySafety
Step 5: Connect water lines to Purlette system
Remove the protective silicon cover from the back of
purier to reveal connection ports.
Remove
Inlet
Outlet
Drain InletOutlet
Drain
Connect each PE tube (now with quick-connector) to
corresponding port. Read the label carefully before
inserting. If a mistake is made, simply remove the
locking clip and gently push the quick connector release
lock in, near where the tube is attached, with one nger
to release the lock and pull the PE tube out. Do not use
force.
Attach quick-connectors to all three water lines and
make sure to push in to the marked line until you feel it
stop. Slide the locking clip in to secure the water line.
Repeat this process for all three water lines (white,
yellow, and blue PE tubes).
Installation

Introduction Installation Maintenance Troubleshoot WarrantySafety
Step 6: Turn on the cold water supply and check for leaks
Connection Diagram
Turn on the cold water supply and open the three-way
feed water ball valve. Check each connection point
for any leaks. If a leak is spotted, immediately turn
off the cold water supply stop valve and ensure all
ttings are properly installed and tightened. Turn on
the cold water stop valve and open the three-way feed
water ball valve once again and check for any leakage.
Proceed to the next step if there are no leaks.
Now it’s time to check the system to make sure that
there are no leaks!
Do not plug in the Purlette system at this time.
Close
Open
Installation

Introduction Installation Maintenance Troubleshoot WarrantySafety
11/2 in.
How to properly install a partition
We recommend the power-supply receptacle for the Purlette system be
installed in a cabinet or on a wall adjacent to the undercounter space in which
the purier is to be installed.
There shall be an opening through the partition between the compartments
specied in that is large enough for the power plug to pass through. The
longest dimension of the opening shall not be more than 1 ½” (38 mm).
The edges of the opening shall, if the partition is wood, be smooth and
rounded, or, if the partition is metal, be covered with an edge protector
provided for this purpose by the manufacturer. Care shall be exercised, when
the purier is installed or removed, to reduce the likelihood of damage to the
power supply cord.
Installation

Introduction Installation Maintenance Troubleshoot WarrantySafety
Step 8: Flush the Purlette system
Filters need to be ushed at least 15–20 minutes prior
to use. People with sensitive taste may choose to ush
the lter for a longer period of time to remove all of the
organic compounds from the lters to improve taste.
HYBRID Filter - Manufacturer recommends a ush time
of 15 minutes.
RO Filter - Refer to page 21 of this manual for detailed
ushing instructions required to obtain maximum
membrane performance.
15Min
Step 7: Plug in the Purlette system
Now it is time to plug in the Purlette system.
Insert the power plug into the 110 V GFCI outlet socket.
The indicator lights will blink for 5 seconds signaling
that the system is starting.
The Purlette system will enter auto-cleaning mode for
80 seconds. No water will come out from the drinking
faucet during this time.
80sec
Installation

Introduction Installation Maintenance Troubleshoot WarrantySafety
Maintenance
Replacing lter when indicator light is blinking
When a lter needs
to be replaced, the
corresponding lter
indicator light will
start to blink.
Close the three-
way feed water ball
valve.
Unplug the power
supply.
Remove the dust lid. Lift quick release
arm.
Locate the lter
handle and gently
pull up the expired
lter.
Open the drinking
water faucet to
release pressure for
easy lter removal.
1. 2. 3. 4. 5. 6. 7.
Re-open the three-
way feed water ball
valve and check to
make sure there are
no water leaks.
Re-plug the power
supply.
To install a new
lter, rst make sure
the lter connectors
are aligned to the
ports.
Press the quick
release arm down
gently until you
hear a pop sound.
Remember to put
back dust lid.
Flush the new lter,
before use, for at
least 15 mins.
Wait approximately
80 seconds for the
Purlette system to
initialize.
Long press the lter
RESET button for 3
seconds until you
hear a beep.
80 sec
RESET
3sec
8. 9. 10. 11. 12. 13. 14.

Introduction Installation Maintenance Troubleshoot WarrantySafety
Maintenance
Replacing lter when indicator light is not blinking
When replacing the lter without being prompted to by the system, you have to manually reset the lter.
Follow steps 2-12 on the previous page to replace the lter. Then follow these next steps to manually reset the lter:
One of the lter lights
will start blinking
indicating that lter has
been selected.
Short press the RESET
button to switch
between the RO lter
and the HYBRID lter.
Long press the RESET
touch button for 3
seconds until you hear a
“D” sound.
Once the correct lter
has been selected, long
press the RESET button
for 3 seconds until you
hear a “D” sound.
Once you have
successfully reset the
lter, the indicator light
should remain lit (non-
blinking).
RO
HYBRID
RESET
NETWORK
RO
HYBRID
RESET
NETWORK
RO
HYBRID
RESET
NETWORK
RO
HYBRID
RESET
NETWORK
RESET
3sec
RESET
3sec
Remember to ush the
lter prior to use.
1. 2. 3. 4. 5. 6.

Introduction Installation Maintenance Troubleshoot WarrantySafety
Safety
WARNING: To ensure safety and avoid injury and property loss to you and others, please be sure to adopt the
following safety precautions. Ignoring safety precautions may result in damage to the system and void of warranty.
Safety Precautions [Prohibited]
• Avoid installing the Purlette system where unit will be in direct sunlight.
• Avoid exposure and storage in temperatures below 40 degrees Fahrenheit.
• Avoid strong magnetic devices, which may cause re, product damage, or circuit failure.
• Avoid wet and dusty areas, which can cause circuit damage.
• Do not place heavy objects on the Purlette system.
• Do not allow children to operate, mishandle, or climb onto the system unit. Children and intellectually disabled
adults shall use the product under guardian supervision.
• Do not pull the power cord directly when unplugging. Take the plug and pull to prevent damage. Please keep your
plug dry and clean.
• Do not use wet hands to plug or unplug the power cord.
• Do not allow ammable/volatile substances near the Purlette system.
• Do not allow the Purlette system to be in contact, or close to, the source of heat or open re.

Introduction Installation Maintenance Troubleshoot WarrantySafety
Safety
• If the source of feed water does not meet municipal water standards, including high sediment content and
excessive residual chlorine, etc. (e.g. private well water), a pre-treatment device shall be installed before
using the system.
• Do not plug the Purlette system directly into a pressure boosting or pressure reducing device.
• In case of product failure, quickly cut off the power and water supply and call our customer service hotline at
1-800-928-7624.
• When the ambient temperature and feed water temperature is low, the water ow rate will be reduced, which is
the inherent feature of the lter element.
• Maintain and replace lters on a regular schedule, as specied in this manual.
• Only use genuine replacement parts provided by our company.
• It is normal for the system to have a slight vibration and noise when water is being processed/treated.
• The Purlette system is only intended for indoor installation and use.
• If you plan not to use the Purlette system for an extended period of time, please disconnect power and close the
three-way feed water ball valve. Run the water 3–5 minutes before use when you restart the Purlette system.
Contents you shall [Notice] which may cause minor injury or property damage.
• In the event of a water shutdown or pipeline maintenance, it is vitally important that the three-way feed water ball
valve is closed and the Purlette system be unplugged. Once the water shutdown or pipeline maintenance has
been completed, before re-opening the three-way water ball valve, always be sure to ush water lines to clear any
sediment that may be inside. Failure to do so may result in sediment blocking the lter and damaging the system.
• Do not bend, smash, pull, knot or damage the power cord.
• Do not attempt to disassemble the system unit.
• Do not attempt to repair the power cord yourself if it is damaged.
•The required working pressure of the Purlette system is 15–100 psi. If the water pressure is lower or higher
than this, please install pressure boosting device or pressure reducing device accordingly.
