PURSUIT 2470 WALKAROUND User manual

2470 WALKAROUND
2470 WALKAROUND
OWNER’S MANUAL
FISHING BOATS
3901 St. Lucie Blvd.
Ft.Pierce,Florida34946
Print Date 10/2002

2470 WALKAROUND
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2470 WALKAROUND
i
SAFETY INFORMATION
Your 2470Walkaround Owner’s Manual has
been written to include a number of safety instructions to
assure thesafeoperationandmaintenanceofyourboat. These
instructions are in the form of DANGER, WARNING,
CAUTION, and NOTICE statements. The following
definitions apply:
IMMEDIATE HAZARDS WHICH WILL RESULT IN
SEVERE PERSONAL INJURY OR DEATH.
HAZARDS OR UNSAFE PRACTICES WHICH COULD
RESULT IN SEVERE PERSONAL INJURY OR DEATH.
HAZARDS OR UNSAFE PRACTICES WHICH COULD
RESULT IN MINOR PERSONAL INJURY OR PRODUCT
AND PROPERTY DAMAGE.
INFORMATION WHICH IS IMPORTANT TO PROPER
OPERATION OR MAINTENANCE, BUT IS NOT HAZARD
RELATED.
All instructions given in this book are as seen from the stern
looking toward the bow, with starboard being to your right,
and port to your left. A glossary of boating terms is included.
IMPORTANT NOTE: Your boat uses internal combustion
engines and flammable fuel. Every precaution has been taken
by Pursuit Fishing Boats to reduce the risks associated with
possible injury and damage from fire or explosion, but your
own precaution and good maintenance procedures are neces-
sary in order to enjoy safe operation of your boat.
NOTICE

2470 WALKAROUND
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2470 WALKAROUND
ii
BOAT INFORMATION
MAKE:
SERIAL #:
MODEL:
GVRW:
PHONE:
REPRESENTATIVE:
TRAILER
NAME:
DEALER/PHONE:
ADDRESS:
SERVICE MANAGER:
ADDRESS:
SALESMAN:
DEALER PURSUIT
MODEL:
PURCHASE DATE:
IGNITION KEYS #:
DRAFT:
HULL SERIAL #:
DELIVERY DATE:
REGISTRATION #:
WEIGHT:
TRANSMISSION(S) (Inboard)
OUTDRIVE(S) (Inboard/Outboard)
MAKE:
PORT SERIAL #:
MODEL:
STARBOARD SERIAL #:
PORT SERIAL #:
MAKE: MODEL:
STARBOARD SERIAL #:
PROPELLER(S)
MAKE: MODEL:
STARBOARD SERIAL #:
MAKE:
DIAMETER/PITCH:
PORT SERIAL #:
RATIO:
ENGINE(S)
BLADES:
OTHER:
BOAT
Pursuit Fishing Boats reserves the right to make changes and improvements in equipment, design and vendored
equipment items, at any time without notification.
Please fill out the following information section and leave it in your Pursuit
2470 Walkaround Owner’s Manual. This information will be important for
you and Pursuit service personnel to know, if and when you may need to call
Pursuit for technical assistance or service.

2470 WALKAROUND
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2470 WALKAROUND
IMPORTANT INFORMATION
Warranty and Warranty Registration Cards
ThePursuitLimitedWarrantyStatementisincludedwithyourboat. Ithasbeenwrittentobeclearly
statedandeasilyunderstood. Ifyouhaveanyquestionsafterreadingthewarranty,pleasecontact
thePursuitCustomerRelationsDepartment.
Pursuit, engine manufacturers, and the suppliers of major components maintain their own
manufacturer's warranty and service facilities. It is important that you properly complete the
warranty registration cards included with your boat and engine(s) and mail them back to the
manufacturer to register your ownership. This should be done within 15 days of the date of
purchaseandbeforetheboatisputintoservice. Aformforrecordingthisinformationisprovided
atthebeginningofthismanual. Thisinformationwillbeimportantforyouandservicepersonnel
to know, if and when you may need service or technical information.
The boat warranty registration requires theHull Identification Number “HIN” which islocated
on the starboard side of the transom, just below the rubrail. The engine warranty registration
requirestheengineserialnumber(s). Pleaserefertotheengineowner'smanualforthelocationof
theserialnumber(s).
IMPORTANT:
All boat manufacturers are required by the Federal Boat Safety Act of 1971 to notify first time
ownersintheeventanydefectisdiscovered“whichcreatesasubstantialriskofpersonalinjuryto
thepublic.” Itisessentialthatwehaveyourwarrantyregistrationcardcompletewithyour
nameandmailingaddressinourfilessothatwecancomplywiththelawifitshouldbecome
necessary.
Product Changes
Pursuit is committed to the continuous improvement of our boats. As a result, some of the
equipmentdescribedinthismanualorpicturedinthecatalogmaychangeornolongerbeavailable.
Pursuit reserves the right to change standard equipment, optional equipment and specifi-
cationswithoutnoticeorobligation. IfyouhavequestionsabouttheequipmentonyourPursuit,
pleasecontactthePursuitCustomerRelationsDepartment.
Transferring the Warranty
Foratransferfee,S2YachtswillextendwarrantycoveragetosubsequentownersofPursuitmodels
for the duration of the original warranty period. Please refer to the Pursuit Limited Warranty
Statementfortheprocedureto transfer the warranty.
To take advantage of this program, notification of the change of ownership, including the new
owner's name, address and telephone number together with the appropriate fee, must be sent to
Pursuit Fishing Boats, Customer Relations Department, 3901 St. Lucie Boulevard, Ft. Pierce,
Florida 34946, within 30 days of the date of resale.
iii

2470 WALKAROUND
S2Yachtswillconfirm,inwriting,thatthetransferofthewarrantyhastakenplace. Afterwhich,
thetransfereewillbetreatedastheoriginalpurchaserasoutlinedinthePursuitLimitedWarranty
Statement.
Service
AllwarrantyrepairsmustbeperformedbyanauthorizedPursuitdealer. Shouldaproblemdevelop
that is related to faulty workmanship or materials, as stated in the Limited Warranty, you should
contact your Pursuit dealer to arrange for the necessary repair. If you are not near your dealer or
anotherauthorizedPursuitdealerorthedealerfailstoremedythecauseoftheproblem,thencontact
thePursuitCustomerRelationsDepartmentwithin15days. Itistheboatowner'sresponsibility
to deliver the boat to the dealer for warranty service.
IMPORTANT INFORMATION
iv

2470 WALKAROUND
OWNER'S/OPERATOR'S
RESPONSIBILITIES
Registration and Numbering
Federal law requires that all undocumented vessels equipped with propulsion machinery be
registeredinthestateofprincipaluse. Acertificateofnumberwillbeissueduponregisteringthe
boat. These numbers must be displayed on your boat. The owner/operator of a boat must carry
avalidcertificateofnumberwhenevertheboatisinuse. Whenmovedtoanewstateofprincipal
use, the certificate is valid for 60 days.
Inorder to be valid,the numbersmustbe installed to theproper specifications. Checkwith your
dealer or State Boating Authority for numbering requirements. The Coast Guard issues the
certificate of number in Alaska; all others are issued by the state.
Insurance
In most states, the boat owner is legally responsible for damages or injuries he or someone else
operating the boat causes. Responsible boaters carry adequate liability and property damage
insurancefortheirboat. Youshouldalsoprotecttheboatagainstphysicaldamageandtheft. Some
states have laws requiring minimum insurance coverage. Contact your dealer or State Boating
Authorityforinformationontheinsurancerequirementsinyourboatingarea.
Reporting Boating Accidents
All boating accidents must be reported by the operator or owner of the boat to the proper marine
lawenforcementauthorityforthestateinwhichtheaccidentoccurred. Immediatenotificationis
required if a person dies or disappears as a result of a recreational boating accident.
Ifapersondiesorthereareinjuriesrequiringmorethanfirstaid,aformalreportmustbefiledwithin
48 hours.
Aformalreportmustbemadewithin10daysforaccidentsinvolvingmorethan$500.00damage
or the complete loss of a boat.
ABoatingAccidentReportform islocated nearthe backof thismanual toassist youinreporting
an accident. If you need additional information regarding accident reporting, please call the
BoatingSafety Hotline, 800-368-5647.
Education
Ifyou are not anexperiencedboater, werecommend that the boat operatorandotherpeople that
normallyaccompanytheoperator,enrollinaboatingsafetycourse. OrganizationssuchastheU.S.
Power Squadrons, United States Coast Guard Auxiliary, State Boating Authorities and the
AmericanRedCrossofferexcellentboatingeducationalprograms. Thesecoursesareworthwhile
even for experienced boaters to sharpen your skills or bring you up to date on current rules and
v

2470 WALKAROUND
regulations. Theycanalsohelpinprovidinglocalnavigationalinformationwhenmovingtoanew
boating area. Contact your dealer, State Boating Authority or the Boating Safety Hotline, 800-
368-5647for further information on boating safety courses.
Required Equipment
U.S.CoastGuardregulationsrequirecertainequipmentoneachboat. TheCoastGuardalsosets
minimumsafetystandardsforvesselsandassociatedequipment. Tomeetthesestandardssomeof
the equipment must be Coast Guard approved. “Coast Guard Approved Equipment” has been
determinedtobeincompliancewithUSCGspecificationsandregulationsrelatingtoperformance,
construction,ormaterials. Theequipmentrequirementsvaryaccordingtothelength,typeofboat,
and the propulsion system. Some of the Coast Guard equipment is described in the Safety
Equipmentchapterofthismanual. Foramoredetaileddescription,obtain“FederalRequirements
AndSafetyTipsForRecreationalBoats” bycontactingtheBoatingSafetyHotline800-368-5647
or your local marine dealer or retailer and read the book “Sportfish, Cruisers, Yachts - Owner's
Manual,” included with your boat.
Some state and local agencies impose similar equipment requirements on waters that do not fall
underCoastGuardjurisdiction. Theseagenciesmayalsorequireadditionalequipmentthatisnot
requiredbytheCoastGuard. Yourdealerorlocalboatingauthoritycanprovideyouwithadditional
informationforthe equipmentrequirements foryourboatingarea.
OWNER'S/OPERATOR'S
RESPONSIBILITIES
vi

2470 WALKAROUND
TABLE OF CONTENTS
Chapter 1::
::
:Propulsion System
1.1 General ....................................................................................1-1
1.2 Corrosion .................................................................................1-2
1.3 EngineLubrication ....................................................................1-2
1.4 EngineCoolingSystem .............................................................1-3
1.5 Propellers .................................................................................1-3
1.6 EngineInstrumentation ..............................................................1-4
Chapter 2: Helm Control Systems
2.1 General.................................................................................... 2-1
2.2 EngineThrottleandShiftControls............................................. 2-1
2.3 NeutralSafetySwitch............................................................... 2-2
2.4 EngineStopSwitch .................................................................. 2-2
2.5 EnginePowerTiltandTrim ...................................................... 2-3
2.6 SteeringSystem ....................................................................... 2-4
2.7 TrimTabs ................................................................................ 2-4
2.8 ControlSystemsMaintenance .................................................. 2-5
Chapter 3: Fuel System
3.1 General.................................................................................... 3-1
3.2 OutboardFuelSystem ............................................................. 3-2
3.3 FuelingInstructions................................................................... 3-4
3.4 FuelSystemMaintenance......................................................... 3-5
Page No.
vii

2470 WALKAROUND
TABLE OF CONTENTS
Chapter 4: Electrical System
4.1 General ................................................................................... 4-1
4.2 Batteries .................................................................................. 4-1
4.3 DCDistributionSystem ........................................................... 4-2
4.4 SwitchPanels .......................................................................... 4-2
4.5 ElectricalSystemMaintenance ................................................. 4-4
Chapter 5: Fresh Water System
5.1 General ................................................................................. 5-1
5.2 Fresh Water System Operation............................................ 5-1
5.3 Fresh Water System Maintenance ....................................... 5-2
Chapter 6: Raw Water System
6.1 General ................................................................................... 6-1
6.2 HighPressureWashdown ........................................................ 6-1
6.3 Livewell................................................................................... 6-2
6.4 RawWaterSystemMaintenance ............................................. 6-3
Chapter 7: Drainage Systems
7.1 CockpitDrainage .................................................................... 7-1
7.2 HardTopandRadarArchDrainage ........................................ 7-1
7.3 BilgeDrainage ......................................................................... 7-2
7.4 FishboxandStorageCompartmentDrainage............................ 7-3
7.5 SinkandLivewellDrains.......................................................... 7-3
7.6 RopelockerDrain ................................................................... 7-3
7.7 Maintenance ............................................................................ 7-3
Page No.
viii

2470 WALKAROUND
TABLE OF CONTENTS
Chapter 8: Ventilation System
8.1 CabinVentilation ...................................................................... 8-1
8.2 WindshieldVentilation .............................................................. 8-1
8.3 CarbonMonoxideandVentilation ............................................ 8-1
8.4 Maintenance............................................................................. 8-2
Chapter 9: Exterior Equipment
9.1 Deck ........................................................................................ 9-1
9.2 Hull .......................................................................................... 9-5
9.3 CockpitEquipment ................................................................... 9-5
Chapter 10: Interior Equipment
10.1 PortableHead .......................................................................... 10-1
10.2 MarineHeadSystem ................................................................ 10-2
10.3 CabinandV-Berth ................................................................... 10-3
10.4 CarbonMonoxideDetector ...................................................... 10-4
Chapter 11: Safety Equipment
11.1 General .................................................................................... 11-1
11.2 EngineAlarms .......................................................................... 11-1
11.3 NeutralSafetySwitch ............................................................... 11-2
11.4 EngineStopSwitch .................................................................. 11-2
11.5 RequiredSafetyEquipment....................................................... 11-2
11.6 CarbonMonoxideDetector...................................................... 11-5
Page No.
ix

2470 WALKAROUND
Page No.
TABLE OF CONTENTS
Chapter 11: Safety Equipment (Continued)
11.7 FirstAid................................................................................... 11-7
11.8 MaximumCapacityRating ........................................................ 11-8
11.9 AdditionalSafetyEquipment ..................................................... 11-8
Chapter 12: Operation
12.1 General .................................................................................... 12-1
12.2 RulesoftheRoad ..................................................................... 12-1
12.3 Pre-CruiseSystemCheck ........................................................ 12-3
12.4 OperatingYourBoat ................................................................ 12-5
12.5 GroundingandTowing ............................................................. 12-7
12.6 WaterSkiing ............................................................................ 12-8
12.7 Fishing .................................................................................... 12-9
12.8 TraileringYourBoat ................................................................ 12-9
Chapter 13: Routine Maintenance
13.1 ExteriorHullandDeck .............................................................. 13-1
13.2 Upholstery,CanvasandEnclosures ........................................... 13-4
13.3 CabinInterior............................................................................ 13-6
13.4 Bilge ......................................................................................... 13-7
13.5 DrainageSystem ....................................................................... 13-7
Chapter 14: Seasonal Maintenance
14.1 StorageandLay-up .................................................................. 14-1
14.2 Winterizing ................................................................................ 14-4
14.3 Recommissioning....................................................................... 14-6
x

2470 WALKAROUND
Chapter 15: Schematics
TwinEngine12-VoltWiringSchematic ................................................. 15-1
SingleEngine12-VoltWiringSchematic................................................ 15-2
HydraulicSteeringSystem .................................................................... 15-3
2StrokeTwinEngineFuelSystem. ...................................................... 15-4
2StrokeSingleEngineFuelSystem ...................................................... 15-5
4StrokeTwinEngineFuelSystem ........................................................ 15-6
4StrokeSingleEngineFuelSystem .................................................... 15-7
FreshWaterSystem............................................................................. 15-8
RawWaterSystem............................................................................... 15-9
RawWaterSystem-WithMacerator ................................................... 15-10
DrainageSystem................................................................................... 15-11
Appendix A: Glossary of Terms ........................................................... A-1
Appendix B: Maintenance Log ............................................................ B-1
Appendix C: BoatingAccident Report ................................................. C-1
TABLE OFCONTENTS
xi
Page No.

2470 WALKAROUND
THIS PAGE WAS LEFT BLANK
INTENTIONALLY

2470 WALKAROUND
Chapter 1:
PROPULSION SYSTEM
1.1 General
The Pursuit 2470 Walkaround is designed to be powered with single or twin 2-cycle or 4-cycle
outboardmotors.
4-cycleoutboard engines do not use an oil injection system and are not equipped with remoteoil
tanks. Theyhaveanoilsumpinthecrankcasethatmustbekeptfullofthetypeofoilrecommended
by the engine manufacturer. The oil must be checked before each use and changed regularly.
Eachmanufacturerofthevariousoutboardmotorsprovidesanowner’sinformationmanualwith
itsproduct. It is important thatyou read the manual verycarefully and become familiarwiththe
proper care and operation of the engine and drive system. A warranty registration card has been
furnishedwitheachnewengineandcanbelocatedintheengineowner’smanual. Allinformation
requested on this card should be filled out completely by the purchaser and then returned to the
respectiveengine manufacturer assoonaspossible.
DO NOT ATTEMPT TO SERVICE ANY ENGINE OR DRIVE COMPONENT
WITHOUT BEING TOTALLY FAMILIAR WITH THE SAFE AND PROPER
SERVICE PROCEDURES. CERTAIN MOVING PARTS ARE EXPOSED AND
CAN BE DANGEROUS TO SOMEONE UNFAMILIAR WITH THE OPERATION
AND FUNCTION OF THE EQUIPMENT.
1-1

2470 WALKAROUND
1.2 Corrosion
Each outboard motor is a complete drive system with the gear case being just forward of the
propeller and connected to the power head with a vertical drive shaft. Other than the routine
maintenanceoutlinedintheengineowner’smanual,thereislittletobeconcernedwithunlessthe
boat is to be kept in saltwater for extended periods of time. Then, the main concerns are marine
growthand galvanic corrosion.
Marinegrowth occurs when componentsareleftin the water forextendedperiodsand can cause
poorperformanceorpermanentdamagetotheexposedcomponents. Thetypeofgrowthandhow
quickly it occurs is relative to the water conditions in your boating area. Water temperature,
pollution, current, etc. can have an effect on marine growth.
Galvaniccorrosionisthecorrosionprocessoccurringwhendifferentmetalsaresubmergedinan
electrolyte. Sea water is an electrolyte and submerged engine components must be properly
protected. Outboard motors are equipped with sacrificial anodes to prevent galvanic corrosion
problems. The anodes must be monitored and replaced as necessary. For locations and
maintenance, please refer to the engine owner's manual.
Whenleavingtheboatinthewater,tiltthemotorashighaspossible. Thiswill decreasetherisk
ofmarinegrowtharoundthecoolinginlets,propellerandexhaustportsanddamagefromgalvanic
corrosion.
DO NOT PAINT THE OUTBOARD MOTORS WITH ANTIFOULING PAINTS DESIGNED FOR
BOAT HULLS. MANY OF THESE PAINTS CAN CAUSE SEVERE DAMAGE TO THE ENGINES.
CONTACT YOUR PURSUIT DEALER OR ENGINE MANUFACTURER FOR INFORMATION ON
THE PROPER PAINTING PROCEDURES.
1.3 Engine Lubrication
2-cycle outboard motors are lubricated by a variable ratio oil injection system. The oil tanks are
mounted below the stern bait station near the transom. Always monitor the oil level before each
cruisebycheckingthegaugeinthehelmorvisuallycheckingtheoillevelusingthereferencemarks
on the tanks. When additional oil is needed, use only the type of oil specified by the engine
manufacturer. Refertotheengineowner’smanualforoilspecificationsandadditionalinformation
onthe oilinjectionsystem.
Alwaysmonitor theoil level inthe tanksand only usethe typeof oil specified
by the engine manufacturer.
1-2
NOTICE

2470 WALKAROUND
4-cycleoutboardengineshaveanoil sump in the crankcase that must be kept full of the type and
gradeofoilrecommendedbytheenginemanufacturer. Itisnormalfor4-cycleenginestoconsume
asmallamountof oil. Therefore,theoil mustbe checkedbeforeeach useandchangedatregular
intervalsas instructed by theengine owner'smanual. As with 2-cycle engines, useonly the type
ofoilspecified by the engine manufacturer.
1.4 Engine Cooling System
Outboard engines are raw water (sea water) cooled. Water is pumped through the water inlets,
circulatedthroughtheengineblock,andrelinquishedwiththeexhaustgasesthroughthepropeller
hub. Thewaterpumpusesasmallimpellermadeofsyntheticrubber. Theimpellerandwaterpump
cannot run dry for more than a few seconds. In most outboard motors, some cooling water is
divertedthroughsmallportsbelowtheenginecowling. Thisallowstheoperatortovisuallycheck
theoperationofthecoolingsystem. Whentheengineisstarted,alwayscheckforasteadystream
of water coming out of those ports.
NEVER RUN AN OUTBOARD MOTOR WITHOUT WATER FLOWING TO THE WATER
PUMP. SERIOUS DAMAGE TO THE WATER PUMP IMPELLER OR ENGINE COULD RE-
SULT.
Note: Iftheboatisusedinsaltorbadlypollutedwater,theengine(s)shouldbeflushedafter
each use. Refer to the engine owner’s manual for the proper engine flushing pro-
cedure.
1.5 Propellers
Thepropellersconverttheengine’spowerintothrust. Theycomeinavarietyofstyles,diameters
and pitches. The one that will best suit the needs of your Pursuit will depend somewhat on your
applicationandexpectedaverageload. Propellersizesareidentifiedbytwonumbersstampedon
the prop in sequence. The 1st number in the sequence ( example 14 x 21) is the diameter of the
propellerandthe2ndnumberisthepitch. Pitchisthetheoreticaldistancetraveledbythepropeller
in each revolution. Always repair or replace a propeller immediately if it has been damaged. A
damagedandthereforeoutofbalancepropellercancausevibrationthatcanbefeltintheboatand
coulddamage the engine gear assembly. Refer totheengineowner’smanualfor information on
propellerremovalandinstallation.
1-3

2470 WALKAROUND
RUNNING AGROUND OR STRIKING AN UNDERWATER OBSTRUCTION CAN
RESULT IN SERIOUS INJURY AND DAMAGE TO THE MOTOR OR BOAT.
IF YOUR BOAT RUNS AGROUND, EVALUATE THE DAMAGE THEN PRO-
CEED AT LOW SPEED TO THE NEAREST SERVICE FACILITY AND HAVE
AN IMMEDIATE INSPECTION MADE BEFORE FURTHER USE OF THE
CRAFT. A DAMAGED BOAT CAN TAKE ON WATER. KEEP ALL LIFE
SAVING DEVICES CLOSE AT HAND WHILE DRIVING TO A DOCK AREA.
IF THE BOAT CANNOT BE IMMEDIATELY REMOVED FROM THE WATER,
THOROUGHLY INSPECT THE BILGE AREA FOR LEAKS SO THAT THE
BOAT DOES NOT SINK WHILE MOORED.
1.6 Engine Instrumentation
Thehelm stationisequippedwithasetofengine
instruments and/or alarms. These instruments
allowthepilottomonitortheengine’soperational
conditions. Close observation of these instru-
mentsallowsthepilottooperatetheengine(s) at
themostefficientlevelandcouldsavetheengine(s)
fromseriouscostlydamage. Theinstrumentation
isuniquetothetypeofoutboardmotorsinstalled
on your Pursuit. Some or all of the following
gauges may be present.
Tachometer
The tachometer displays the speed of the engine(s) in revolutions per minute (RPM) This speed
is not the boat speed nor necessarily the speed of the propeller. The tachometer may not register
zero with the key in the "OFF" position.
NEVER EXCEED THE MAXIMUM RECOMMENDED OPERATION RPM OF
THE ENGINE. MAINTAINING MAXIMUM, OR CLOSE TO MAXIMUM RPM
FOR EXTENDED PERIODS CAN REDUCE THE LIFE OF THE ENGINE.
Speedometer
The speedometer indicates the speed of the boat in miles per hour.
TemperatureWarning
The temperature warning indicates the temperature of the engine. A sudden increase in the
temperaturecouldindicate anobstructed waterinlet oran impellerfailure.
InstrumentPanel
1-4
