PURSUIT PRO 9244 User manual

128-4088D
1 OF 7
Active / Passive Operation
Remote Control Automotive Security System
Congratulations! Yourpurchaseofthisstate-of-the-artsecuritysystemexpresses
adeepconcernforthesecurityofyourvehicle,itscontents,andpassengers. Tofully
appreciate the many functions and safeguards incorporated in this system, please
spend a few minutes reading this manual. You may find unexpected features that
could mean the difference between "protected" and "fully protected".
FEATURES AND AVAILABLE OPTIONS:
User Programmable Transmitters offer 1/2 Million Different Codes
Instant Arming and Disarming with a Remote Keychain Transmitter
PowerDoorLockscanbeLockedandUnlockedatthesametimewiththeOptionalPower
Door Lock Interface
The Vehicle's Starter is Disabled whenever the Alarm is Armed
A Concealed Valet/Emergency Disarm Switch will by-pass the Alarm in the event your
Transmitter is lost, or if you wish to deactivate the Alarm for Service Work
Programmable Active/Passive Arming Capability
Programmable 6 Tone (Multi Tone) Siren Included
Visual L.E.D. Arm/Disarm indicator with Audible"chirp" confirmation
The Vehicle's Parking Lights Flash when Arming, Disarming, and Alarm sounding
Theinteriorcourtesylightswillilluminatewhenthesystemisremotelydisarmed,providing
bothconvenienceandaddedsecuritytothepassengers. Anoptionalrelayisrequired(not
included)
7 Function Dash Mounted L.E.D. Alarm Status Indicator
RemoteKeychainPanicallowsAlarmActivationinEmergenciesatdistancesupto75feet
from the vehicle
Intrusion Alert with Three Zone Monitoring lets you know When and How the Alarm was
Activated in your Absence
AnAdditionalRadioFrequencyChannelisBuiltintotheKeychainTransmittertoallowthe
use of the Following Optional Accessories:
TrunkReleaseRelay-NoMoreFumblingwithKeys! Thisdeviceallowsyouto"pop"
thetrunkwiththepushofabuttonfromdistancesupto75feet(forvehiclesequipped
with electronic trunk release)
RemoteStarter-Thisdeviceallowsyoutostartthevehicle,withthepushofabutton,
from inside your home. A great feature on those cold winter mornings! (available
for fuel injected, automatic transmission vehicles only)
GarageDoor Interface-This device allowsyou to activateyourgarage dooropener
via the Alarm Keychain Transmitter
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
Model PRO 9244
Owner's Manual
Rev. C - Replaced 'System Functions' page. 3-3-94
Rev. D - Revised "larger button" to read "Button 1" and "smaller button" to read
"Button 2" - 6-27-95.

128-4088D
2 OF 7
YOUR KEYCHAIN TRANSMITTERS:
The transmitters included with this security system are pre-programmed at the
factory, with button assignments (channels) prioritized in a standard format. You
canselectwhich transmitterbuttoncontrolsaparticularfunction,(seethetransmit-
ter programming guide).
This manual explains the operation of the system assuming that the transmitter
buttons are prioritized in their standard, factory pre-set format.
1. Turn off the engine. exit the vehicle, and close and lock all doors, hood, and
trunk.
2. The dash mounted L.E.D. will begin to flash rapidly, indicating that the system
is automatically (passive) arming. As an added convenience, the automatic
passive arming will not begin until all doors and trunk lid are closed, allowing
passengers to exit the vehicle at their convenience.
3. In30seconds,youwillhearasingleshort"chirp"fromthesiren,andthevehicle's
parkinglampswillflashonetime,indicatingthesystemisARMED. Atthistime,
the dash mounted L.E.D. will begin to flash slowly, providing a visual indication
that the system is fully ARMED.
OPTION NOTE: If the optional (not included) power door lock interface
has been installed, the alarm control module can be programmed to...
a) Automatically lock the doors during step 3 above, or,
b) Only lock the doors when step 4 is executed.
3. Youwillhearasingleshort"chirp"fromthesiren,andthevehicle'sparkinglamps
will flash one time, indicating the system is ARMED. At this time, the dash
mounted L.E.D. will begin to flash slowly, providing a visual indication that the
system is fully ARMED.
3A. Iftheoptionaldoorlockinterfacehasbeeninstalled,thedoorswillautomatically
lock when the system is armed.
NOTE: If the siren "chirped" three times when ARMING, then one of the entry
points (hood, trunk, doors) has been left opened. Closing the hood, trunk, or
doors will correct the problem, and you do not need to disarm the system to
make the correction.
1. Turnofftheengine,exitthevehicle,andcloseandlockalldoors,hood,andtrunk.
2. Momentarily depress button 1 on the keychain transmitter.
WARNING! Excessive pressure on the transmitter buttons will damage
theinternalcomponents on the circuitboard. Allthat is required isalight
push to the button.
ARMING THE SYSTEM (CHANNEL 1) : ACTIVE
ARMING THE SYSTEM (CHANNEL 1) : PASSIVE

128-4088D
3 OF 7
4. If you wish to arm the system immediately, simply press and release button 1
on the keychain transmitter. The siren will "chirp" once, the vehicle's parking
lamps will flash once, the doors will lock (optional), and the dash mounted
L.E.D.will begin to slowly flash.
PROTECTION WHILE THE SYSTEM IS ARMED :
1. Openingany door,hoodortrunk willcausethealarmto immediatelysound. The
siren will continue to sound for 60 seconds, then stop and automatically re-arm
thevehicle. Ifthepotentialthiefleftadooropened,thesirenwillsoundforthree
60 second cycles, then re-arm and ignore the opened door.
2. Wheneverthesystemisarmed,theReddashmountedL.E.D.indicatorwillslowly
flash. Thisservesasavisualdeterrenttothepotentialthief. TheL.E.D.isavery
lowcurrent bulb, and will not cause the vehicle'sbattery to drain, even when left
unattended for extended periods.
3. Whenever the system is triggered, the vehicles parking lights will flash for the 60
second alarm cycle, attracting added visual attention to the vehicle.
4. Iftheoptional(notincluded)entryilluminationrelayhasbeeninstalled,whenever
thesystemistriggered,theinteriorcourtesylightswillflashforthedurationofthe
full alarm cycle.
5. Whenever the system is armed, the vehicle's starter will be bypassed. If a thief
should choose to ignore the siren, the vehicle can not be started.
DISARMING THE SYSTEM (CHANNEL 1) :
1. As you approach the vehicle, press and release button 1 on the keychain
transmitter.
WARNING:Excessivepressureonthetransmitterbuttonswilldamagethe
internalcomponentsonthecircuitboard. Allthatisrequiredisalightpush
to the button.
2. Thesirenwill"chirp"2times, andthevehicle's parkinglampswillflashtwotimes,
indicating the system is DISARMED.
a) If the door lock interface (optional) is installed, the vehicle's doors will
automatically unlock.
b) If the entry illimination relay (optional) is installed, the vehicle's interior
lights will turn on for approximately 20 seconds.
3A. ACTIVE : The dash mounted L.E.D. will turn off, and remain off until the system
is armed.
3B.PASSIVE: Neverattempttodisarmthesystemfromadistancethatpreventsyou
from opening a door within 30 seconds. Since the system is programmed for
passive arming, it will begin to re-arm until a door is opened. Opening the door
will suspend the passive arming cycle.

128-4088D
4 OF 7
INTRUSION WARNING SIGNALS :
Thesystemwill informyou ifan intrusionattempt hasoccurredwhileyouwereaway
from the vehicle. If an intrusion attempt has occurred, the siren will "chirp" 4 times
when disarming the system.
The vehicle's parking lights will also flash 3 times to indicate an intrusion has
occurred. Enter the vehicle and observe the dash mounted L.E.D. for further
information.
1. If the L.E.D. is flashing one time...pause...one time... etc., then an intrusion
attempt was made to a voltage sensing, light activated entry point, or to an
optional sensor that has been connected to zone 1.
2. If the L.E.D. is flashing two times...pause...two times...etc., then an intrusion
attempt was made to the hood, trunk, or an optional sensor that has been
connected to zone 2.
3. Ifthe L.E.D.isflashing threetimes... pause...threetimes...etc.,then anintrusion
attempt was made through one of the vehicle's doors.
These intrusion warning indicators are stored in the system's memory, and will only
be erased from memory when the ignition key is turned on.
VALET / SYSTEM OVERRIDE SWITCH:
The "Valet" switch allows you to temporarily bypass all alarm functions, eliminat-
ingthe needto handyour transmitterto parkingattendantsor garagemechanics.
Whenthesystemisin valetmode, allalarmfunctions arebypassed,however, the
remotepanicfeature andremote doorlocks (optional)will remainoperational. To
use the valet mode;
1. Enter vehicle and turn the ignition key to the "on" position.
2. Move the valet toggle switch to the "on" position. The dash mounted L.E.D.
will turn on solid, and remain on as long as the system is in the valet mode.
3. To return to normal operation, move the valet switch to the "off" position any
time the ignition is on.
In the event you lose your keychain transmitter, or if the transmitter fails to
disarm the system, the valet switch can be used as a system override switch.
Open the car door (the alarm will sound). Turn the ignition key on, and move
the valet switch to the "on" position. The alarm will stop sounding, and the
vehicle can now be started.
NOTE: AlwaysremembertomovetheValetSwitchbacktothe"off"position. This
will ensure that the vehicle remains protected at all times.

128-4088D
5 OF 7
ELIMINATING THE ARM / DISARM CHIRPS :
The normal arming and disarming confirmation “chirps” can easily be turned on and
off using the valet toggle switch. To do this....
1. The valet switch must be in the “off” position.
2. Turn the ignition key on, and then off.
3. Within 10 seconds of turning the ignition key off, move the valet toggle switch
to on - off - on - off -on -then off.
4a. If,before proceeding with step 1, the chirps were on, thenyou will hear 2 chirps
to indicate that the chirps have been turned off.
4b. If, before proceeding with step 1, the chirps were off, then you will hear 1 chirp
to indicate that the chirps have been turned on.
5. Whenever power to the system is disconnected (for repair or service of the
vehicle), the chirps will be active when the power is re-connected. To turn the
chirps off, simply execute steps 1 through 3 above.
NOTE: Whenever the chirps are by-passed, the 4 chirp intrusion indicator will
always operate. This feature will always warn you if the vehicle was tampered
withinyourabsence,evenifthenormalarminganddisarmingchirpshavebeen
turned off.REMOTE PANIC OPERATION (CHANNEL 1) :
The arming button on your keychain transmitter also functions as a "panic" switch
for instant activation of the alarm in emergency situations. To use the remote panic
switch;
1. Press and hold the arming button on the keychain transmitter for 3 seconds or
more, The alarm will immediately sound.
2. To stop the alarm, press and release the arming button on the keychain
transmitter. If the button is not pressed, the alarm will automatically stop after
60 seconds.
WARNING! Excessive pressure on the transmitter buttons will damage the
internal components on the circuit board. All that is required is a light push
to the button.

128-4088D
6 OF 7
TRUNK RELEASE (CHANNEL 2) :
This security system has an additional feature that can be wired to a number of
different optional accessories. Some of the more common uses for this "channel"
are; Remote Trunk Release - available for any vehicle with factory installed
electronic pushbutton trunk release.
RemoteCarStarter-availableformostautomatictransmission,fuelinjected
vehicles.
Remote Window Roll Up - available for most vehicles equipped with power
windows.
To activate the optional accessory;
1. Pressandholdbutton2onthekeychaintransmitterforapproximately3seconds.
*
*
*

PASSIVE ARMING
ARMED
DISARMED
VALET MODE
INTRUSION ZONE 3
INTRUSION ZONE 2
INTRUSION ZONE 1
ARM
DISARM
ARM / DOOR OPEN
DISARM / INTRUSION
ARM
DISARM
DISARM / INTRUSION
DASH L.E.D. INDICATORS
RAPID FLASHING ..........................
SLOW FLASHING ............................................
OFF .............................................................
ON - SOLID ............................................
3 FLASH ... PAUSE .....................
2 FLASH ... PAUSE .....................
1 FLASH ... PAUSE .....................
SIREN CHIRP INDICATIORS
1 CHIRP * .............................................................
2 CHIRPS* ......................................................
3 CHIRPS .....................................
4 CHIRPS .................................
* These chirps are optional, and can be de-activated.
PARKING LAMPS
1 FLASH ...............................................................
2 FLASH ..........................................................
3 FLASH ...................................
Optional Channel 2 Device
Your System Has These Features Activated:
Page 6
128-4088D
7 OF 7
Audiovox Corp. 150 Marcus Blvd. Hauppauge, N.Y. 11788 Form No. 128-4088D
PRO 9244
SYSTEM FUNCTIONS AT A GLANCE
No Lock in Passive Mode
Starter Cut-out
Door Lock Interface
Shock Detector
Motion Detector
Hardwire
q
q
q
q
q
q
