PVI Industries 1000P1250A-TPGO User manual

Product is patented in the U.S., Canada, and Mexico.
PVI INDUSTRIES, LLC
FORT WORTH, TEXAS 76111
PV 6520 02/25/04 [phone] •www.pvi.com
LOW NOxTURBOPOWER®• PACKAGED WATER HEATER
POLYSHIELD®POLYMER-LINED STORAGE TANK
TANK SERIES 1250 GALLONS VERTICAL
Recovery gph cDimensions
(inches) Blower
Motor
MODEL
NUMBER 40° - 120°F 40° - 140°F
INPUT
Btu/h
Min. Inlet
Flow Gas
Pressure
" W.C. d
SCAQMD Energy
Model No. A B C HP Amps
Shipping
Weight
#
1000 P 1250A-TPL 1000 800 800,000 4.5 8TPL 800 MBtu/h 33 8 1 1/2 7 4570
1500 P 1250A-TPL 1500 1200 1,200,000 4.5 12TPL 1200 MBtu/h 33 8 1-1/4 1 14 4580
cRecoveries based on 83% thermal efficiency. ASHRAE 90.1 compliant for efficiency and standby loss.
dWith standard gas train
* The information presented is for natural gas 0.6 S.G.
Dimensions are in inches unless otherwise specified.
For standard and optional equipment, see form #PV 6453.
STANDARD GAS PRESSURE REQUIREMENTS:
SEE TABLE FOR MINIMUM PRESSURE BY MODEL.
MAXIMUM STATIC INLET GAS PRESSURE IS 10.5" W.C.
FOR GAS PRESSURES OUTSIDE OF THIS RANGE,
CONTACT YOUR PVI REPRESENTATIVE.
VENTING REQUIREMENTS:
-.02" TO -.06" W.C. (NEGATIVE PRESSURE).
TYPE B VENTING.
ENTIRE VENT SYSTEM SHOULD NEVER BE SIZED BASED UPON
THE VENT CONNECTION DIAMETER EXCLUSIVELY. CHECK
NATIONAL FUEL GAS CODE UNDER "FAN ASSISTED."
STANDARD ELECTRICAL REQUIREMENTS:
VOLTAGE: 120V, 1Ø, 60 HZ., 20 AMPS.
OTHER VOLTAGES REQUIRE AN EXTERNAL
STEPDOWN TRANSFORMER.
PVI RESERVES THE RIGHT TO CHANGE THE DESIGN AND
SPECIFICATION WITHOUT NOTICE.
