Pwnie express Pwn plug r3 User manual

Pwnie Express User Manual

Pwn Plug R3 Fixed Sensor

The latest version of this manual is maintained here:

https://www.pwnieexpress.com/support/

Contents

Legal Disclaimers.....................................................................................................4

Specifications..........................................................................................................4

Getting Started .......................................................................................................4

Using the Pwnix UI ..................................................................................................5

Setup page .............................................................................................................5

System Authentication ........................................................................................5

Network Config ..................................................................................................6

Reverse Shell Key...............................................................................................7

Clean up History and Logs ...................................................................................8

Update Device....................................................................................................8

Restart Device ...................................................................................................9

Services page .......................................................................................................9

Passive Recon ....................................................................................................9

Evil AP ............................................................................................................10

NTP ................................................................................................................11

Reverse Shells page ............................................................................................11

Activating the reverse shells ..............................................................................11

Configuring Kali to receive the reverse shells .......................................................12

Connecting to the reverse shells.........................................................................13

Deploying to target network...............................................................................14

Using SSH port forwarders on Kali.........................................................................15

Connecting to remote RDP servers......................................................................15

Connecting to remote web servers......................................................................15

Creating an SSH VPN...........................................................................................16

Activating the SSH VPN tunnel ...........................................................................16

Using the wireless hardware ...................................................................................17

802.11 wireless ..................................................................................................17

Connecting to an open Wi-Fi network ..................................................................17

Running Airodump-ng & Kismet..........................................................................18

Packet injection................................................................................................18

Wireless client de-authentication ........................................................................19

Bluetooth ...........................................................................................................19

Using the Bluetooth adapter...............................................................................19

4G/GSM Cellular .................................................................................................20

Using the unlocked GSM adapter ........................................................................20

Connecting to the Internet using the adapter .......................................................23

Accessing the pentesting tools ................................................................................26

Accessing Metasploit............................................................................................26

Running additional pentesting tools .......................................................................26

Pentesting Resources ........................................................................................27

Using advanced features ........................................................................................27

Stealth Mode ......................................................................................................27

NAC/802.1x Bypass.............................................................................................28

NAC Bypass overview........................................................................................28

Enabling NAC Bypass mode ...............................................................................29

NAC Bypass troubleshooting ..............................................................................30

Disabling NAC Bypass mode...............................................................................30

Maintaining your Pwnie sensor ................................................................................31

Updating the Pwnix software ................................................................................31

Reviewing the Pwnix environment .........................................................................31

How to obtain support .........................................................................................32

Legal Disclaimers

All Pwnie Express products are for legally authorized use only.

By using this product you agree to the terms of the Rapid Focus Security, Inc. EULA:

(http://www.pwnieexpress.com/wp-content/uploads/2014/12/Pwnie-Express-EULA-10-13-14-.pdf)

This product contains both open source and proprietary software:

oProprietary software is distributed under the terms of the Rapid Focus Security, Inc. EULA:

(http://www.pwnieexpress.com/wp-content/uploads/2014/12/Pwnie-Express-EULA-10-13-14-

.pdf)

oOpen source software is distributed under one or more of the following licenses:

GNU PUBLIC LICENSE

(https://www.gnu.org/licenses/gpl.html)

BSD-3-CLAUSE LICENSE

(http://opensource.org/LICENSES/BSD-3-CLAUSE)

OPENSSL TOOLKIT DUAL LICENSE

(https://www.openssl.org/source/license.html)

APACHE LICENSE, VERSION 2.0

(https://www.apache.org/licenses/LICENSE-2.0.html)

As with any software application, any downloads/transfers of this software are subject to export controls

under the U.S. Commerce Department's Export Administration Regulations (EAR):

(http://www.bis.doc.gov/index.php/regulations/export-administration-regulations-ear). By using this

software, you certify your complete understanding of and compliance with these regulations.

Specifications

Hardware

oProcessor: 1.1GHz dual-core Intel Celeron (2 threads, 64-bit)

oMemory: 2GB 1600MHz DDR3

oDisk Storage: 32GB mSATA SSD

oOnboard I/O: 1x Gigabit Ethernet, 3x USB ports, 1x HDMI

oDimensions: 4.6” x 4.4” x 1.5”

Wireless

oOnboard high-gain dual-band 802.11a/b/g/n wireless supporting packet injection & monitor mode

(internal antenna)

oOnboard Bluetooth supporting device scanning & monitor mode (internal antenna)

4G GSM LTE USB Adapter

oCompatible with SIM cards from AT&T, T-Mobile, Vodafone, Orange, and GSM carriers in over

160 countries (SIM card not included)

o4G LTE FDD - B20/B8/B1/B3/B7 800/900/1800/2100/2600Mhz

oGSM: 850/900/1800/1900MHz

oSIM/USIM card: standard 6-pin SIM card interface

Getting Started

1. Connect the onboard Ethernet port (eth0) to the local area network (LAN).

2. Connect the AC adapter to a power source.

3. Press the round power button on the top of the sensor.

4. Use a web browser to login to the Pwnix UI, acquire all available updates and configure the sensor.

5. After the sensor has been configured for use, the sensor is accessed either through an SSH connection

established to the sensor or through a Reverse SSH connection established from the sensor.

Note: By default, the Ethernet port (eth0) on the sensor uses DHCP to acquire its IP address. Whereas this will

initially be unknown, it is recommended to run nmap (e.g. nmap x.x.x.0/24 –p 22,1443 --open) to scan the

network subnet from a laptop (or desktop) to discover the IP assigned to the eth0 interface. Once learned, open

a web browser and go to https://

x.x.x.x

:1443 (where x.x.x.x is the IP address assigned) to access the Pwnix UI.

If DHCP is not used within the LAN or if the sensor is unable to acquire an IP address via DHCP, the sensor has a

virtual Ethernet interface (eth0:1) with IP address 192.168.9.10/24 already assigned. To access the sensor via its

virtual Ethernet interface will require IP address 192.168.9.11/24 assigned to a laptop (or desktop). Then, from

this system plugged into the same LAN the sensor is located within and assuming the network allows the

simultaneous broadcast of the additional 192.168.9.0/24 network, the laptop or desktop should be able to PING

the IP address assigned to the sensor, (i.e. ping 192.168.9.10). If successful, open a web browser and go to

https://192.168.9.10:1443 to access the Pwnix UI.

Tip: If unsuccessful with accessing the virtual Ethernet interface in this manner, the most likely cause would be

the network not allowing the simultaneous broadcast of the 192.168.9.0/24 network. To resolve, simply connect

the Ethernet interface on the sensor directly to the Ethernet interface on the laptop (or desktop), then try to ping

the IP address assigned to the sensor’s virtual Ethernet interface, (e.g. ping 192.168.9.10). If successful, open

a web browser and go to https://192.168.9.10:1443 to access the Pwnix UI.

Using the Pwnix UI

Note: When accessing the Pwnix UI for the first time, you will need to accept/acknowledge the warning about a

self-signed certificate to continue.

1. At the login prompt, enter pwnie for the username and enter pwnplug8000 (the default) for the

password.

2. Next, the “Setup” page appears.

Setup page

System Authentication

1. From the “Setup” page, under “General Configuration”, click “System Authentication”.

2. Enter the current password for the “pwnie” user account, then enter a new password and provide its

confirmation.

IMPORTANT: We strongly recommend changing the default password for the “pwnie” user account as

soon as possible.

3. Next, click “Change Password” button.

Note: This will change the password for the “pwnie” UI user and the “pwnie” system (Linux/SSH)

account. Pwnix UI authentication is integrated with Linux PAM, allowing the UI and system passwords to

be synchronized for the “pwnie” user.

4. Afterward, click “Logout” on the top menu and then re-login to re-authenticate with your new credentials.

Tip: After the sensor is deployed, and if accessing the sensor through an SSH connection, you can also set the

“pwnie” user’s password via the command line, as shown:

# passwd pwnie

Note: Please note that if you change the password from the command line it will change the Pwnix UI password

as well.

Network Config

Note: If the sensor is being accessed via the virtual Ethernet interface (eth0:1), then it is recommended to

manually set an IP address to the Ethernet interface (eth0), restart the sensor, then access the sensor via the

Ethernet interface (eth0) and the IP address assigned from this point forward.

1. From the “Setup” page, under “General Configuration”, click “Network Config”.

2. Under “Current Network Settings”, the Ethernet network interface(s) will be displayed reflecting the IP

assigned and their state.

Depending on configuration, the following interfaces may be visible:

eth0 - This Ethernet interface is located on the rear of the sensor and is configured for DHCP by default

eth0:1 - This virtual Ethernet interface is used if DHCP is not available

eth1 –This Ethernet interface is only available when using the external USB Ethernet adapter (See NAC

Bypass)

wlan0 - The onboard 802.11 wireless adapter (DOWN by default)

wlan0mon - The onboard 802.11 wireless adapter in monitor mode (DOWN by default)

3. To change the IP configuration for eth0, click the “eth0” link in the adapter table.

4. Under “Configuration for eth0”, the Ethernet interface eth0 is configured to use DHCP by default. To set

a static IP for eth0, click “Static Config” under “Configure eth0 Settings”, then enter a new IP Address,

Netmask, Default gateway IP, and Primary DNS server IP.

5. Afterward, click the “Apply Static IP Settings” button.

Note: After the sensor’s IP address is changed for the Ethernet interface (eth0), logout and reconnect to the

Pwnix UI using the newly assigned IP address.

If the IP address to the Ethernet interface eth0 has been set to a Static IP, to set eth0 to acquire its network

settings from a DHCP server instead, select “DHCP”, then click the “Enable” button.

Under “Change eth0 MAC Address”, the current MAC Address assigned to the Ethernet interface (eth0) is

displayed. To change the MAC Address, enter a new MAC Address and click the “Change MAC” button.

Note: The eth0 MAC address will always revert back to the hardware default if the sensor is rebooted.

Tip: If it is desired to shut down the virtual Ethernet interface (eth0:1), this can be performed by running the

following command with an SSH connection with the sensor.

# ifdown eth0:1

Under “Change Hostname”, the current hostname assigned to the sensor is displayed. To change the

hostname, provide a new hostname and click the “Change Hostname” button.

Tip: After changing the hostname, log out of any active SSH terminal sessions, then re-login to update the

prompt.

Under “Configure NTP Servers”, the current NTP servers are displayed. To change the NTP Servers for

use, enter two or more NTP Servers and click the “Configure NTP” button. Afterward, go to the

“Services” page and under “Service Management”, select “Manage Service” for NTP and ensure it is set to

enabled.

Reverse Shell Key

1. From the “Setup” page, under “General Configuration”, click “Reverse Shell Key”.

2. Under “Current Key”, if it has already been generated, the current SSH Public Key for the sensor is

displayed, which is used establish the Reverse Shells.

Tip: If no key pair is displayed a key pair will be generated automatically after enabling one or more

reverse shells on the “Reverse Shells” page.

Optional: If desired to create or change the key pair, click the “Generate” button (found under

“Generate New Key”) to generate a new key pair for the Reverse Shells.

Pwn Pulse is a distributed security assessment service providing unparalleled visibility, vulnerability scanning, and

insight into your remote branch offices and networks. By aggregating data from multiple sensors, Pwn Pulse is

able to combine real time Wired, Wireless, and Bluetooth asset discovery with local, on-demand vulnerability

scanning to provide unprecedented risk awareness of your organization’s hardest to reach areas.

If you have purchased a subscription to Pwn Pulse to allow a specific number of sensors and you have completed

the registration process to successfully login to Pwn Pulse, you are eligible to “join” that number of sensors to

Pwn Pulse by performing the steps below.

IMPORTANT: Do not register the sensor to Pwn Pulse unless the sensor is already physically located within the

network it is to report data upon. Additionally note the connectivity from the sensor requires TCP port 443 to the

Internet and because of bidirectional certificates used to secure the connection, the use of a proxy server is

unsupported.

1. On the System Setup page, under “General Configuration”, click “Register to Pwn Pulse”

2. When a sensor has yet to be registered, three fields will be visible; see screenshot below.

a. Provide the Dispatch Hostname (i.e. Pwn Pulse) required for use (#1). Specifying the port is not

required.

b. Provide the Sensor Name required for use (#2). It is encouraged the name of the sensor is

indicative of the geolocation location or branch office where the sensor is located.

c. Provide the Contact Name (#3) of an individual who might be responsible for the administration

of the sensor

3. After providing the required fields, click the “Connect to Dispatch” button (#4) to join the sensor to Pwn

Pulse.

4. Wait five minutes, then login to Pwn Pulse and go to the “Unapproved Sensors” page.

5. When the sensor appears on the list, click the Approve button to complete the process of joining the

sensor to Pwn Pulse.

6. In approximately 10-15 minutes, the main Dashboard will reflect statistics based upon the default tasks

configured to run by the sensor.

Repeat the above steps to join additional sensors to Pwn Pulse.

Clean up History and Logs

On the “Setup” page, under “General Configuration”, click the “Cleanup now” button.

This clears the root user’s bash history, UI logs, and all logs in /var/log.

Note: The bash history for any currently active root user sessions will be cleared upon the next logout.

Tip: If accessing the sensor through an SSH connection, the cleanup script can also be run from the command

line, as shown:

# /opt/pwnix/pwnix-scripts/cleanup.sh

Update Device

IMPORTANT: To acquire updates, the following external web sites *must* be accessible from the sensor via

the ports specified below. If access to one or more is blocked the result of a firewall, proxy server or web

filtering solution in use, the update process will fail rendering the Pwnix UI to become inaccessible. If it is

necessary, add the exclusion(s) below to the firewall, proxy server or web filtering solution *before* attempting

to update the sensor:

Allow TCP port 443 to *.pwnieexpress.com

Allow TCP port 80 to *.kali.org

Allow TCP port 443 to *.rubygems.org

Allow TCP ports 22, 443, and 9418 to *.github.com

1. On the “Setup” page, under “Update Device”, click the “Update Now” button.

Note: Depending upon connection speed and the number of updates to install, please allow 3-5 minutes

to allow the process to complete. While updating the sensor, the Pwnix UI may become temporarily

unavailable. To determine if/when the process has completed, please review the “Pwnix Update Log”

under “System Logs”, on the “System Details” page. When the update process has completed, the last

line in the log will show “

System update completed

”.

Tip: If accessing the sensor through an SSH connection, you can also update the sensor as follows:

# /opt/pwnix/chef/update.sh

Note: After the update has completed it is recommended to restart the sensor.

Restart Device

1. On the “Setup” page, under "Restart Device", click the "Reboot Now" button and the sensor will reboot

immediately.

Tip: If accessing the sensor through an SSH connection, you may also restart the sensor as follows:

# reboot

Services page

From the Services page, the Passive Recon, Evil AP, and NTP services can be managed (i.e. enabled or disabled)

Passive Recon

On the “Services” page, under “Service Management”, click “Manage Service” to change the status of the Passive

Recon service.

Depending upon its status, click “Enable Service” to start the passive recon service or “Disable Service” to stop

the passive recon service.

Note: When enabled, the sensor will passively listen on the Ethernet interface eth0, recording HTTP requests,

user-agents, cookies, OS guesses, and clear-text passwords to the following logs:

HTTP requests: /var/log/pwnix/passive_recon/http.log

OS guesses: /var/log/pwnix/passive_recon/p0f.log

Clear-text passwords: /var/log/pwnix/passive_recon/dsniff.log

Note: Passive Recon is most effective when the sensor is in NAC Bypass / transparent bridging mode, or when

connected to a switch monitor/SPAN port or network tap.

Tip: If accessing the sensor through an SSH connection, you may also enable or disable the Passive Recon

service from the command line, as follows:

To enable the Passive Recon service, run the following commands:

# service pwnix_passive_recon start

# update-rc.d pwnix_passive_recon defaults

To disable the Passive Recon service, run the following commands:

# service pwnix_passive_recon stop

# update-rc.d -f pwnix_passive_recon remove

Evil AP

On the “Services” page, under “Service Management”, click “Manage Service” to change the status of the “Evil

AP” service.

Depending upon its status, click “Start Service” to start the Evil AP service or “Disable Service” to stop the Evil AP

service.

Note: When enabled, the Evil AP will perform a “Karma” attack against all wireless client devices, which results

with wireless client devices to connect automatically to the Evil AP created by the sensor, based upon the

broadcasted probe requests learned from the client devices. When wireless client devices connect to the Evil AP,

the traffic from the wireless client devices is routed through the Ethernet interface (eth0).

Tip: If accessing the sensor through an SSH connection, to view real-time Evil AP activity from the command line,

type the following:

# tail -f /var/log/pwnix/evilap.log

Tip: If accessing the sensor through an SSH connection, you may also enable or disable the Evil AP service from

the command, as follows:

To enable Evil AP, run the following commands:

# service pwnix_evil_ap start

# update-rc.d pwnix_evil_ap defaults

To disable Evil AP, run the following commands:

# service pwnix_evil_ap stop

# update-rc.d -f pwnix_evil_ap remove

Tip: The configuration of the Evil AP can customized in /opt/pwnix/Pwnix config/services/evil_ap.conf file.

NTP

On the “Services” page, under “Service Management”, click “Manage Service” to change the status of the “NTP”

service.

Depending upon its status, click “Start Service” to start the NTP service or “Disable Service” to stop the NTP

service.

Reverse Shells page

All Pwnie sensors include aggressive, reverse tunneling capabilities to allow persistent, remote SSH

access.

The use of reverse SSH access provides the ability to use the sensor as a “beach-head” or “pivot point” to

perform testing of the remote network.

SSH over HTTPS/SSL, SSH over DNS, SSH over ICMP, and other covert tunneling options are available for

traversing strict firewall rules, web filters, & application-aware IPS solutions.

All tunnels are encrypted and will maintain access wherever the sensor has an Internet connection.

Typical deployment overview

1. On a staging/lab network, enable the desired reverse shells (see “Activating the reverse shells”)

2. Next, configure a Kali Linux system (i.e. “SSH Receiver”) to receive the reverse shells (see “Configuring

Kali to receive the reverse shells”)

3. Test the reverse shells to confirm all enabled shells are working as expected (see “Connecting to the

reverse shells”)

4. Deploy the sensor to your target network and watch your SSH receiver for incoming shells (see

“Deploying to target network”)

Activating the reverse shells

1. Open a browser and log into the Pwnix UI.

2. Click “Reverse Shells” on the top menu.

3. Choose the shell you wish to configure from the drop-down list.

Tip: To best maintain persistent remote access, enable all of the reverse shells.

4. Enter the SSH shell receiver IP address or DNS name for each selected reverse shell, as well as any other

configuration settings as necessary. The device will connect to this shell receiver system to establish the

reverse shell connections.

5. Click "Submit" to apply your changes for the reverse shell(s) you are configuring.

Note: The following SSH client config directives (/etc/ssh/ssh_config) are set on all devices to allow for

automation of reverse shell connections. Be sure you understand the security implications of these

settings before connecting to other SSH servers from the sensor.

StrictHostKeyChecking no

UserKnownHostsFile /dev/null

6. After the reverse shell(s) have been configured, proceed to configure Kali to receive the reverse shells.

Configuring Kali to receive the reverse shells

A system running Kali Linux (1.0.6 or later) will serve as the “SSH Receiver” system. The sensor will connect to

this system when initiating the reverse shell connections.

1. Place the sensor and the SSH Receiver system on the same local network/subnet

2. Login to the SSH Receiver system, open a web browser and connect to the sensor via the Pwnix UI (e.g.

https://x.x.x.x:1443)

3. Login to the Pwnix UI when prompted.

4. From the top menu, click “Reverse Shells”.

5. If they haven’t already been configured, configure desired shells (

see “Activating the Reverse Shells”

section

)

6. Next, click the “Download Shell Receiver script for Kali Linux” link at the top of the page to download the

"pwnix_ssh_receiver.sh" script.

7. Save the script file (pwnix_ssh_receiver.sh) into the user’s home directory (selected by default)

8. Open a Terminal window and enter the following commands:

# chmod +x pwnix_ssh_receiver.sh

# /pwnix_ssh_receiver.sh

Note: The first time the script is run on the SSH Receiver system, it will download and install various

packages required to support the functionality.

9. When prompted, enter the desired certificate information for the stunnel SSL certificate (or just press

ENTER to accept the defaults)

10. Once the auto-config script completes you will see:

[+] Setup Complete.

[+] Press ENTER to listen for incoming connections..

11. Press ENTER to watch for incoming device connections. This may take up to two minutes.

Note: When an incoming connection from the sensor is successfully established to the SSH Receiver, the

Reverse SSH method being used can be determined based upon the port number displayed amongst the

listening connections.

Port 3333 is associated with Standard SSH

Port 3334 is associated with Egress Buster

Port 3335 is associated with SSH over DNS

Port 3336 is associated with SSH over SSL

Port 3337 is associated with SSH over 4G/GSM

Port 3339 is associated with SSH over ICMP

Tip: If two minutes have passed and nothing is displayed under listening connections, this indicates the

sensor is unable to establish a connection with the SSH Receiver. The most likely cause can be attributed

to a firewall protecting the SSH Receiver system from being able to receive the incoming connection(s).

If a firewall is protecting the SSH Receiver, ensure it is configured to allow the incoming port(s) relevant

to the methods enabled.

If Standard Reverse SSH is enabled, then forward the port specified in the UI (default is 22) to the

same on the SSH Receiver system.

If SSH over SSL is enabled, then forward/allow port 443 to the SSH Receiver system.

If SSH over DNS, is enabled, then forward/allow UDP port 53 to the same on the SSH Receiver system.

If SSH over ICMP is enabled, the ICMP protocol must be allowed to pass through the firewall.

Generally, this will not be allowed. Hence SSH over ICMP may not be expected to work successfully.

If SSH over 4G is enabled, then forward/allow the port specified in the UI to port 22 on the SSH

Receiver system.

If SSH Egress Buster, is enabled, then forward all of the ports specified in the UI (defaults are 21, 22,

23, 25, 110, 123, 161, 500, 1723, and 4500) to the SSH Receiver system.

12. Proceed to “Connecting to the reverse shells”.

Connecting to the reverse shells

1. Open a second terminal window on the SSH Receiver system and use the SSH command (with the –p

switch) to establish a reverse connection using the port number displayed.

For example, if ports 3333 and 3336 are the ports displayed as “Listening” when viewing the incoming

connections, type either of the following to establish a reverse SSH connection to the sensor:

# ssh pwnie@localhost –p 3333

# ssh pwnie@localhost –p 3336

2. When prompted to login, enter “pwnie” for the username, the password and voila! You are now remotely

connected to the sensor through the reverse shell.

3. Proceed to “Deploying to target network”

Tip: The SSH receiver address can be anonymized using the “Tor Hidden Service” feature as described here

http://www.securitygeneration.com/security/reverse-ssh-over-tor-on-the-pwnie-express/

Special thanks to Sebastien J. of Security Generation for streamlining the SSH receiver setup process, and to

Lance Honer for his resilient autossh script improvements.

Deploying to target network

1. Place the SSH Receiver system behind an Internet facing firewall.

2. Configure the appropriate rules on the firewall to allow:

If enabling Standard Reverse SSH, then forward the port specified in the UI (default is 22) to port 22

on the SSH Receiver system.

If enabling SSH over SSL, then forward port 443 to port 443 on the SSH Receiver system.

If enabling SSH over DNS, then forward UDP port 53 to UDP port 53 on the SSH Receiver system.

If enabling SSH over ICMP, the ICMP protocol must be allowed to pass through the firewall. Generally,

this may not be allowed.

If enabling SSH over 4G, then forward the port selected in the UI to port 22 on the SSH Receiver

system.

If enabling SSH Egress Buster, then forward all ports specified in the UI (defaults are ) to port 22 on

the SSH Receiver system.

3. In the Pwnix UI (“Reverse Shells” page), configure the reverse shells to connect to your firewall’s public

IP address (or DNS name if available).

4. You can now deploy your Pwnie sensor to your target network. The device will automatically ”phone

home” to the designated SSH Receiver system, providing encrypted remote access to your target

network.

Tip: In some environments, you may wish to schedule a nightly reboot of the sensor to re-initiate all connections

from the sensor side. This way, if some part of the connection process crashes on the sensor side (for example,

sshd), the connection process will start “fresh” again after the reboot.

Using SSH port forwarders on Kali

Connecting to remote RDP servers

Perform the following steps to use the sensor as a “pivot point”, to connect to remote RDP servers, through a

Reverse SSH connection.

1. First, run the Shell Receiver script on the system running Kali Linux.

2. Once the system is waiting for incoming connections, open a new Terminal window and run the following

command:

# ssh pwnie@localhost -p

XXXX

-NL 3389

:xxx.xxx.xxx.x

xx:3389

.. where "

XXXX

" is the local listening port of an active reverse shell (such as 3333 for standard reverse

SSH), and where "

xxx.xxx.xxx.xxx

" is the IP address of an RDP target system on the remote network

your Pwnie sensor is physically connected to.

3. When prompted, login to the sensor using the “pwnie” user account.

4. Next, connect to the remote RDP server through the SSH tunnel by using the rdesktop command and

"localhost" as the target server.

# rdesktop localhost

Connecting to remote web servers

Perform the following steps to use the sensor as a “pivot point”, to connect to a remote web server, through a

Reverse SSH connection.

1. First, run the Shell Receiver script on the system running Kali Linix.

2. Once the system is waiting for incoming connections, open a new Terminal window and run the following

command:

# ssh pwnie@localhost -p

XXXX

-ND 8080

.. where "

XXXX

" is the local listening port of an active reverse shell (such as 3333 for standard reverse

SSH).

3. When prompted, login to the sensor using the “pwnie” user account.

4. Next, open Firefox (install Firefox if necessary), and go to Options | Advanced | Network | Connections

and click Settings. Configure the options as follows:

5. Next, save the changes, then exit and re-open Firefox.

6. At this time, you can now connect to any web server on the remote network by entering the IP address

or URL into address bar within Firefox.

Creating an SSH VPN

The OpenSSH server on the Pwn Plug R3 supports SSH-based VPN tunneling through any active reverse shell,

allowing transparent (albeit slow) access to your target network from the designated SSH Receiver system

running Kali Linux. This is mainly useful when the need arises to access a GUI-based or third party, penetration

testing tool, such as BurpSuite, Nessus, Remote Desktop client, etc.

Sample environment

The steps below assume the following IP addresses/ranges. Substitute the addresses/ranges for your target and

local networks where appropriate.

Target network (where the Pwn Plug R3 is deployed): 172.16.1.0/24

Local network (where the SSH Receiver system is located): 192.168.1.0/24

VPN network: 10.1.1.0/30

Kali VPN address (tun0 interface): 10.1.1.1

Pwn Plug R3 VPN address (tun0 interface): 10.1.1.2

Assumes a reverse shell is currently established and listening on localhost:3333 (Standard Reverse SSH).

Any active reverse shell can be used to carry the VPN tunnel (change “3333” where appropriate).

Activating the SSH VPN tunnel

1. Ensure that the root user on your Kali receiver has an SSH key generated. To do so, type the command

below and follow the prompts.

# ssh-keygen

2. Open Firefox on your Kali SSH receiver. From the reverse shells UI

(https://

[device_ip_address]

:1443/reverse_shells), click “Download SSH VPN script for Kali Linux” to

download the “ssh_vpn.sh” script.

3. Save the script file (ssh_vpn.sh) into the user’s home directory (selected by default)

4. Open a terminal window and enter the following commands:

# cd

# chmod +x ssh_vpn.sh

# ./ssh_vpn.sh

5. Follow the on-screen prompts to configure the SSH VPN. The default values assume a standard reverse

shell to the target machine is open on port 3333 (see ‘Configuring Kali to use the reverse shells’ above).

6. When the script completes, the Kali receiver should have an interface ‘tun0’ that tunnels directly to the

Pwn Plug R3. Type

# ping 10.1.1.2

to test the SSH VPN tunnel.

7. Type

# route add 172.16.1.0/24 gw 10.1.1.1

to route any traffic from the receiver to the 172.16.1.0/24 subnet over the VPN connection. (Substitute

the subnet of the Pwn Pug R3 for 172.16.1.0/24.)

To disable the VPN tunnel on the Kali side:

# ifconfig tun0 down

To disable the VPN tunnel on the Pwn Plug R3 side:

# service pwnix_ssh_vpn stop

Using the wireless hardware

802.11 wireless

Connecting to an open Wi-Fi network

1. Set the wireless interface to managed mode by typing the following command and press Enter:

# iwconfig wlan0 mode managed

2. Bring the wireless interface up by typing the following command and press Enter:

# ifconfig wlan0 up

3. Scan for access points in the area by typing the following command and press Enter:

# iwlist scan

4. Associate with an access point with SSID “example” on channel 6 by typing the following commands and

press Enter after each:

# iwconfig wlan0 essid “example”

# iwconfig wlan0 channel 6

5. Restart the interface by typing the following commands and press Enter after each:

# ifconfig wlan0 down

# ifconfig wlan0 up

6. Acquire a DHCP address by typing the following command and press Enter:

# dhclient wlan0

Running Airodump-ng & Kismet

1. Bring the wireless interface down by typing the following command and press Enter:

# ifconfig wlan0 down

2. Run airodump-ng by typing the following command and press Enter:

# airodump-ng wlan0

3. When finished, press CTRL+C to exit

4. Run Kismet by typing the following command and press Enter:

# kismet

5. Press ENTER 3 times, then press TAB, then press ENTER to display the main window.

6. When finished, press CTRL+C to exit

Tip: Certain wireless tools may leave the wireless adapter in a mode that is not compatible with other

wireless tools. It is strongly recommended to set the interface to a “down” state before running most

wireless tools by typing the following command and press Enter:

# ifconfig wlan0 down

Packet injection

1. To run a simple packet injection test, execute the following commands. This example assumes a WEP-

enabled access point on channel 6 with SSID “

example

” is within range of the sensor.

# ifconfig wlan0 up

# iwconfig wlan0 channel 6

# ifconfig wlan0 down

# aireplay-ng -e

example

--test wlan0

2. Next, Look for output similar to the following::

17:19:45 Waiting for beacon frame (ESSID: example) on channel 6

Found BSSID "00:13:10:9E:52:3D" to given ESSID "example".

17:19:45 Trying broadcast probe requests...

17:19:45 Injection is working!

17:19:46 Found 1 AP

Wireless client de-authentication

1. This example assumes the target access point is on channel 6:

# iwconfig wlan0 channel 6

2. In one terminal, start airodump-ng:

# airodump-ng --bssid

[MAC of target AP]

-c 6 wlan0

3. Then, in a second terminal, start the client de-authentication:

# aireplay-ng -0 0 -a

[MAC of target AP]

-c

[MAC of target client]

wlan0

Bluetooth

Using the Bluetooth adapter

The Bluetooth interface is internal and will appear as Bluetooth device “hci0”.

1. Confirm the output of the following commands:

# lsusb

Look for output similar to the following::

Bus 001 Device 002: ID 0a12:0001 Cambridge Silicon Radio, Ltd Bluetooth

Dongle (HCI mode)

# hciconfig hci0

Look for output similar to the following::

hci0: Type: BR/EDR Bus: USB

BD Address: XX:XX:XX:XX:XX:XX ACL MTU: 310:10 SCO MTU: 64:8

DOWN

RX bytes:466 acl:0 sco:0 events:18 errors:0

TX bytes:73 acl:0 sco:0 commands:17 errors:0

2. Enable the Bluetooth interface and set it to “Non-Discoverable”:

# hciconfig hci0 up

# hciconfig hci0 noscan

3. To scan for remote Bluetooth devices

# hcitool -i hci0 scan --flush --info –class

4. To ping the address of a remote Bluetooth device

# l2ping -i hci0

XX:XX:XX:XX:XX:XX

5. To dump Bluetooth packets:

# hcidump -i hci0 -t –X

6. To pair with a remote Bluetooth device:

# bluez-simple-agent hci0

XX:XX:XX:XX:XX:XX

IMPORTANT: Before disconnecting the USB Bluetooth adapter, always set the interface to a DOWN

state first by running the command below.

# hciconfig hci0 down

4G/GSM Cellular

Using the unlocked GSM adapter

Either of the unlocked GSM adapters will support five GSM cell bands and is compatible with AT&T, T-Mobile,

Vodafone, Orange, and GSM carriers in over 160 countries.

E369 2G/3G USB Modem Adapter

E3276 4G LTE Modem Adapter

Table of contents

Popular Security Sensor manuals by other brands

AVS

AVS OUTSPIDER PA manual

RAB Lighting

RAB Lighting Mini Sensor installation manual

Steren

Steren ALA-MOV user manual

hager

hager TX511 User instructions

Niko

Niko 350-41752 Technical manual

Niko

Niko 351-25039 manual

TOOLCRAFT

TOOLCRAFT 1712612 operating instructions

RKI Instruments

RKI Instruments 35-3001-01H-DIL Operator's manual

Vonaq

Vonaq RapidTrace 1200 user guide

Leviton

Leviton CRS4K manual

Visonic

Visonic MCT-302 quick start guide

Crewsaver

Crewsaver CREWFIT 165 SPORT owner's manual

Johnson Controls

Johnson Controls LC-203 Installation

Omron

Omron E8M - manual

Silux Home

Silux Home Seeker Operation manual

Takex

Takex MX-12FAMD instruction manual

FGD

FGD FlameSpec IR3 H2 HD user manual

Waters

Waters 3100 Operator's guide

PWNIE Express Pwn Plug R3 User manual

Popular Security Sensor manuals by other brands
