PLCM32 InstructionManual
3.5"TFT LCD MONITOR/UNIVERSAL MOUNT REARVIEW CAMERA
HT1P:fNNIW.PYLEAUDIO.coM

Specification
MONITOR:
-Screenslze:3.5"(4:3)
*Reaolution:64QxRGBx480
*AutomaticallySwitchWhenReversing
*TwoVideolnputs,V1N2swHchlng
*Poweron/offwhensignalinput/nosignalinput
*Visiblearee.:72x52.56
*Powersupp/y:DC12N
*Powerconsumption:O.53W
*Operatingtempar8ture:O*C-8O*C
*Storagetemperature:-10"C-8O"C
*NTSC/PAl...SysternAuloSwitch
*Brighlness:200cd/m2
*Contrast:200:1
*Dimensions:3.7'Wx3.3"HxO.67"O
CAMERA:
Universal Mount
Backup CMD Camera 1/3"
Water Proof/NightVision
Distance ScanlsLine Camera
17 FootMale to Male RCAVideo Cable
Image Sensors: 580x540
Total Pixels: 580x540
Resolution: 420 TV Lines
Min. lIIumination:1.0 LUX
IP Rating: 68; LensAngle:
170'
Auto ImageAdjustment
Built-In Distance Scale Line
Video Output: 1.0Vpp-75 Ohm
Power Supply: DC
12V
Dimensions: 0.67" (W)XO.67" (H)XO.9" (l)
Connection:
14
Video(oul)
Monitor
6m
~I
--@--+
Backup light power
Red:+12V(in)
Bleck:GND(ln)
Camera
