Pyle view PLVW1770IR User manual

17" Overhead TFT-LCD 16:9 Wide Screen
Monitor With Infrared Wireless Headphone
PLVW1770IR

1
1. Table of Contents------------------------------------------------------ 1
2. Warning ---------------------------------------------------------------- 1
3. Usage Notice ---------------------------------------------------------- 2
4. Package ---------------------------------------------------------------- 3
5. Function Descriptions -------------------------------------------------4
6. ------------------------------------------------- 4
7. ----------------------------------------- 5
8. --------------------------------------------- 6
9. --------------------------------------------- 7
10. Closing Monitor ------------------------------------------------------ 7
11. OSDMenus in A/V Source -------------------------------------------8
12. Remote Control----------------- --------------------------------------9
13. Appendix--------------------------------------------------------------9
14. Specifications --------------------------------------------------------10
Start Your Installation
Setting Up The Dome Lamps
Installation Your Monitor
Operating the Monitor---
Table of Contents
1
WARNING
This unit is not intended for installation in the front Driver /Passenger Compartment
where it may be seen by the Driver.Installation of this unit in any portion of the vehicle
which could impair or distractthe Driver is improper and dangerous and
assumes No liability whatsoever for failure to follow the proper installation of this
product.
To reduce the risk of electric shock,please do not expose this unit to rain,moisture or
open the unit.Dangerous high voltages are present inside the unit.
Our warranty could be voided if you make changes or modifications not expressly
approves by

Usage Notice
Follow all warnings, precautions and maintenance as
recommended in this user's manual to maximize the life of your
LCD monitor
To avoid the damage of the LCD monitor and risk of electronic
shock, do not permeate the LCD monitor with water or any
drink.
When this happens, turn off the power, unplug the power cord
and send the LCD monitor to your local dealer or our service
cen-ter as soon as possible.
Use a regular power specification of DC 12V . Do not use any
other power supply different from the regularity.
Do not place objects on or suspend them with the power cord.
This will make the power cord damaged.
Do not assemble or twist the power cord arbitrarily. And do not
put it together with heated object.
Do not try to repair the power cord when it is damaged or
broken, change a new one immediately.
Avoid any metal objects or inflammable dropping into the LCD
monitor from ventilation slots.
Do not attempt to open or disassemble the LCD monitor
yourself as this may cause electronic shock.
When there is smile or peculiar smell in use, unplug the power
cord immediately and send it to your local dealer or our service
center.
When there is damage or breach on the LCD monitor casing,
send it to your local dealer or our service center.
Do not use this LCD monitor in the areas susceptible to
excessive dust, dirt, and humid.
Do not setup the LCD monitor in direct sunlight, extremely hot,
and cold environment.
Do not expose the LCD monitor to rain or moisture.
2

3
Package
This LCD monitorcomes with allthe items below. Check tomake sure yourunit
complete. Contact your dealer immediately if anything is missing.
* 17" High RES TFT-LCD Wide Screen Monitor
* Overhead Console Mounting Bracket
* Credit Card Size Remote Control with Batteries
* Interface Cable with RCA jacks for Audio / Video
Connection and 12V DC
* User's Manual
* Warranty Card
User Control Overview
*Panel Control
IR
MUTE
DOWN
UP
MENU
POWER

Function Descriptions
* Menu: Pop up the OSD menus. Press the "Menu" button again
to exit the OSD menus. When in sub-menu, press "MENU"
again to go back to the main menu.
* +/- Keys: 1. Press the "+/-" key to increase or decrease volume.
2. Make item selection in OSD menus to increase or
decrease parameters as well.
* Mute: Press the "Mute" button from the remote control
to still the sound of the LCD monitor.
* Power:
You may also turn on or off the
monitor by this
"Power" button.
Start Your Installation
* Monitor connection
FUSE
(OPTION)
( AV1 IN )
( AV1 IN )
WHITE
BLACK
FOR TUNER
IR SIGNAL
YELLOW
RED
RED
WHITE
YELLOW
RED(+)
BLACK(-)
(SIGNAL CABLE)
AUDIO
VIDEO
( AV2 IN )
VIDEO
AUDIO
9 PIN MINI DIN
CAR INDOOR LIGHT
CONTROL SW 5M POWER CABLE
2P CAR POWER CABLE
2P CAR POWER CABLE
4

Setting Up The Dome Lamps
*Operating the dome Lamps
1. There are three function buttons for the Dome lamps operation: OFF,
DOOR, and ON. (Refer to the following figure)
A. OFF: To turn off the lamps.
B. DOOR: To make the lamps turned on
only when car doors are
opened.
C. ON: To turn on the lamps.
ON
DOOR
OFF
5
* The electric circuit figure
Point Power Cord Color Connection
R
W
B
Red
White
Black
Connecting With Power Supply
Connecting With Sensor of Car Doors
For Ground Connection
* Remarks:
1. There would be no any power cord puling out from "B" point as
"B" have been connected with a ground connection by screws.
2. Power supply should be used in 12 Voltages.
W
B
OFF
DOOR
ON
LAMPS R
BATTERY +

Installation your Monitor
Take care to select a suitable fitting location and securing method for
the monitor:
*The unit should not distract or obstruct the driver.
*The installation should not inhibit the entry to, or the exit from the
vehicle.
*The unit should not interfere with other vehicle components e,g
(sliding sunroof).
*Make sure the unit is installed to a secure, robust mounting location
and cannot become dislodged in the event of an emergency stop.
*Do not support the unit using only the vehicle interior roof lining.
*If driving is required, take care not to penetrate through the other
sheet metal of the vehicle.
*Avoid prolonged use of the monitor when the engine is not running
to prevent draining the vehicle battery.
*Place the mounting metal plate with the nuts facing upward, then,
mount the monitor by screws included
6

Closing Monitor
1. Return the monitor to the central viewing position.
(Refer to the following figure)
2. Push the monitor back into the monitor base unit until
the screen engages with the release button.
Operating the Monitor
* Powering up the monitor
The monitor will be automatically turned on when releasing the
monitor from the base unit and "OFF" when it is closed.
Operating Instructions
Opening the Monitor
1. Press the monitor release button to lower the LCD screen.
2. Lower the monitor until is fixed 90 from the monitor base
unit for viewing (Refer to the following figure.)
7

8
* OSD Menus in A/V Source
MAIN MENU
CUBS.1 = VTSC
H. SYNC = +15.7K Hz
V. SYNC = +60.0Hz
BRIGHTNESS
CONTRAST
COLOR
HUE
SOURCE
AUDIO
RECALL
EXIT
1
SOURCE
AUTO DETECT
VIDEO 1
VIDEO 2
RETURN
AUDIO
MUTE
VOLUME
RECALL
RETURN
A. Source Selection Menu
B. Audio Input Selection Menu
VOLUME
* Quick Adjustment OSD Menus
1. By pressing "MENU" button, you may open the MAIN MENU, using "+" or "-"
together to pick out OSD functions.
2. In order to select desire options, it is necessary to press "MENU" again to
enter each mode, than using " "/ " " to increase or decrease parameters as well.
3. Press "+" or "-" button directly to adjust speaker volume.
4. Select out of " EXIT" mode to storing your selected parameter and
leaving OSD Menus.

Appendix
Changing the New Battery in Remote Control
1. Push the cassette button to wards the right. (As shown # 1 in below
figure)
2. Pull the all battery cassette away from the remote control. As shown
# 2 in below figure) Change a new battery.
Cassette Button
1
2Battery
9
Remote Control
1234
5678
90
Number Pad
POWER
MUTE
TV/AV
TV/CATV
SETUP
FM/AM
Monitor
FUNC
UP
+
MODE
DN
-
CHVOL
Power
MUTE
SETUP
Monitor
TV/CATV interchange
TV/AV
Channels convertible(CH)
Volume control buttons

Specifications
1. Type Roof Mount Color Display Monitor
Sync. : Separate TTL sync.
Video : Composite sync.
System : NTSC M,N PAL
SECAM
Audio : 1.0Vp-p
2. Signal Input
3. Display System Active Matrix High Resolution TFT-LCD Monitor
Operating Temperature : 0 C~35 C
Storage Temperature : -20 C~ 60 C
Humidity : 20% ~ 90%
4. Environment
17" High Resolution TFT-LCD 16:9 Wide Screen Flip-Down
Monitor With Infrared Wireless Headphone and Dome Lights
Features
* Active Matrix High Resolution TFT-LCD Monitor
* 17" Widescreen (16:9) Display
* Polarized, Anti-glare, Hard Coated Panel
* 400 cd/m brightness for unparalleled picture quality
* Wide Viewing Angle: H 160 degree, V 160 degree
* Multi-System Video: NTSC/PAL/SECAM
* Overhead Console Flip-Down Mounting Bracket Included
* Wireless Remote Control Included
* On screen Menu
* Built-in Twin Dome Lights
* Interface Cable with RCA Jacks for Easy Connection
* Dual RCA Audio / Video Inputs.
* 11~13.8V DC Power source with Noise Filter Circuit
* Display Colors : 6 bits interface (16 M colors)
* Infrared wireless headphone included
