Pyle PCAU35A User manual

Features and Controls
1 2
5 6 8 9
10
11 12 13
15 14
43
1. Power ON LED Indicator
-Lights to indicate power is turned on.
2. Blue LED Output Level Display
3. Master Volume Control
-Lets you adjust the overall sound level,turn the knob clockwise to increase the volume.
4. Function Blue LED Display Window
5. AUX/CD IN
-Lets you easily connect the computerized MP3 Device (player) sources, such as PC(CD ROM) ,
laptop, walkman, iPod,and cell phone.
6. TREBLE
-Lets you adjust the TREBLE volume to high or low.
7. BASS
-Lets you adjust the BASS volume to high or low.
8. Buttons for MP3(USB/SD/MMC) Function Control
-Mode: For audio input selection.
-Play/Pause: Play and pause control.
-Prev./Next: Quick backward or next song.
9. SD/MMC Socket for playing SD/MMC cards
10. USB Socket for playing the USB funtion.
11. RCA L/R LINE Input
-Let you connect to the desired LINE input sources.
12. Push Type Speaker L/R Terminals
-Let you easily connect the speakers'wires directly to the amplifier
13. Fuse
-The amplifier uses a fuse for protection against surges and short circuit. If the amplifer
suddenly turn off and will not turn on, check the fuse. If necessary, replace it with a
1-amp, 250-volt, fast-acting, 5x20mm fuse(not supplied)
14. 110V/220V Switch
-According to power voltage, push this button to the correct station of the 110V or 220V.
15. AC IN Power Cord
-Connect to AC 110V/60Hz or 220V/50Hz
PCAU35A
2
7
1
Mini 2x75 Watt Stereo Power Amplifier USB/SD/MMC Card
Reader w/AUX, CD & Microphone Inputs & Blue LED Display
www.pyleaudio.com
PCAU35A PCAU35A
Mini 2x120 Watt Stereo Power Amplifier USB/SD/MMC Card
Reader w/AUX, CD & Microphone Inputs & Blue LED Display
PCAU46A PCAU46A

1
2
3
4
5
6
7
8
9
10
11
4
Features and Controls
1 2
5 7 9 10 11
12 13 14
16 15
43
6
1. Power ON LED Indicator
-Lights to indicate power is turned on.
2. Blue LED Output Level Display
3. Master Volume Control
-Lets you adjust the overall sound level,turn the knob clockwise to increase the volume.
4. Function Blue LED Display Window
5.AUX/CD IN
-Lets you easily connect the computerized MP3 Device (player) sources, such as PC(CD
ROM), laptop, walkman, iPod,and cell phone.
6. 1/4″PHONE JACK
-Accept headphones with 1/4” plug.
7. TREBLE
-Lets you adjust the TREBLE volume to high or low.
8. BASS
--Lets you adjust the BASS volume to high or low.
9. Buttons for MP3(USB/SD/MMC) Function Control
-Mode: For audio input selection.
-Play/Pause: Play and pause control.
-Prev./Next: Quick backward or next song.
10. SD/MMC Socket for playing SD/MMC cards
11. USB Socket for playing the USB funtion.
12. RCA L/R LINE Input
-Let you connect to the desired LINE input sources.
13. Push Type Speaker L/R Terminals
-Let you easily connect the speakers'wires directly to the amplifier
14. Fuse
-The amplifier uses a fuse for protection against surges and short circuit. If the amplifer
suddenly turn off and will not turn on, check the fuse. If necessary, replace it with a 1-
amp, 250-volt, fast-acting, 5x20mm fuse(not supplied)
15. 110V/220V Switch
-According to power voltage, push this button to the correct station of the 110V or 220V.
16. AC IN Power Cord
-Connect to AC 110V/60Hz or 220V/50Hz
PCAU46A
3
8
1.Power Standby Button
2.Play/Pause Button
3.Equilizar Button
4.Repeat Song Button
5.Mode: Menu Control Button
6.Mute Button
7.Previous Song Button
8.Next Song Button
9.Volume - & Volume + Buttons
10.USB/SD Switch Button
11.Number Buttons for Song Selection
Remote Control Function

5 6
15Wx2(PCAU35A)
20Wx2(PCAU46A) 1 % THD
4-OHM, 1 KHz, 1% THD. 15Wx2(PCAU35A)
4-OHM, 1 KHz, 1% THD. 20Wx2(PCAU46A)
Peak Power 120Wx2
250mV

7 8
PYLE PRO Audio,Inc.
1600 63rd Street
Brooklyn, NY 11204
