Pyle PLM4135BT User manual

1 Specification:1 Specification:
1 Display Size:
2 Display:
3 Resolution:
4 Brightness:
5 Contrast:
6 Visual Angle:
7 Chromatic System:
8 Working Power:
9 Working Current:
10 Operation temperature:
11 Input Port:
4.2Inch;
TFT LCD 16:9Panel;
320 RGB 234;
400;
250;
145;
NTSC/PAL(Auto Switch);
12V;
500mA;
0-45;
One Video Input One Camera Input;
2 Features:2 Features:
1 Type of Car:Saloon Car Business Car Minitype Truck;
2 Installation Measure:Can be Instead of the origin Rearview Mirror
Directly;
3 Special Customized Lens in order to be Consistent with the Rear-
view Image;
4 Auto switch to Rearview system when backing a car to insure the
safety.
1 Pay Attention to the Polarity when connecting in case of damaging
the machine;
2 Do not Dismantle the machine because of its high exactitude, If
you have some problem;
Please contact with current Distributor.
3 Do not use the cleanser of other impregnate to clean the lens and
that you can use soft cloth bumf.
4 Avoiding Being laid the machine below the Sunshine,Dust,Hum-
idity;
5 It is common theat appear few luminosity in panel;
6 The chromatic system of the camera matched with machine is
NTSC system,so in order to avoiding frequently switching display
chromatic system,please enact the Chromatic system of DVD or
VCD to be NTSC.
3 Caution:3 Caution:
1 After the unit is ON, theBLUETOOTH signal lightflashes
every 5 seconds. First connect yourcell phone tothe unit, pass-
word of unitis 8888 .After successfulconnection, the BLUET-
OOTH light remainsconstantly on.Incoming callnumbers will be
displayed on the LCD. (Due tofunction limit ofsome cell phon-
es, the numbercannot be displayed.However, user still can ans-
wer the incoming calls.) Press theBLUETOOTH button onfront
panel once toanswer calls.
2 When dialing calls, you could speakdirectly once theother
party has acceptedthe call. Keepthe distance no farther than 1
meter from themicrophone on frontpanel for best result.
4. There isa BLUETOOTH antennaat the back of the unit, keep
it away from GND connection inorder to avoid dialing and
receiving problems.
5.After phone connectionis successful,if conversationis private,
press and hold BUETOOTH for 3seconds to switch to cell phone
connection.
6.After cell phoneconnects to BLUETOOTH,pressthe BLUE-
TOOTH button twiceto dial back the last number you have
dialed.
3. Once yourcell phone isconnected to the unit, you no longer
have to connectagain even thepower is turned OFF and ON
again. (If connectionto the unitis failed, please Refer to the cell
phone manual for BLUETOOTH connection instruction).
BLUETOOTH Annotate
-1-
-4-

6¡¢The Instruction ofConnection:6¡¢The Instruction ofConnection:
(1)Power Line(Red):ConnectDC+12V
(2)Ground Line(Black):Connect Power Line of Ground;
(3)Rearview control Line(Green):Connect Power Line of Rearview Light;
(4)Video Input one(Yellow RCA):Connect video input of VCD or DVD;
(5)Video Input Two(Yellow RCA):Connect Rearview Camera.
(6)BLUETOOTH Audio output. (White RCA)
7¡¢The Instruction ofInstallation:7¡¢The Instruction ofInstallation:
1 Method of Installation:As the following drawing one,sticking the
3M double side pastern on the side which is used for installing the
shelf when installing this machine(fittings are attached),then stick
the machine directly to the vehicle window.Specially pay attention to:
a the position of the vehicle window used for sticking up should be
cleaned up.Do not leave behind dusty and other sundries in case
effecting stickup result.
b pay attention to throw definite pressure to make the pastern and
the stickup face touch adequately to strength the agglutinate.
c requiring several hours to get the best result after sticking up the
plaster, so do not use the machine after several hours of installing
the machine.
1
2
3
4
5
4¡¢Front Panel4¡¢Front Panel
1 Power Button
2 Mode Button
3 Volume IncreasingButton
4 Menu Button
5 Volume ReducingButton
6 Bluetooth Button
7
Bluetooth
Microphone
8 Led
9 Caller-ID LCD
5¡¢Instruction of OperatingRemote:5¡¢Instruction of OperatingRemote:
1 Volume Reducing Button;
2 Menu Button;
3 Display Mode Select Button;
4 Power Button;
5 Input Switch Button;
6 Volume Increasing Button;
1
2
3
4
5
6
MENU
MODE
SELECT
VIDEO
SELECT
LCD REMOTE
4
5
6
3
1
2
7
8
9
-2- -3-
6
