Pyle PLCM32 User manual









WARNING:Failuretoreadandfollowthesewarningsandinstructionsmayresultinseriousinjury,includingdamaged
property,sopleasepaycloseattentionandexhibittheutmostcare.

•TheDigitalBackupCameraisdesignedasanaidtothedriverindetectingpotentiallyhazardousdrivingconditions,
obstructions,andlargestationaryobjects.You,thedriver,mustalsoremembertodrivesafelyandproperly.Useofthe
DigitalBackupCameraisnotasubstituteforsafe,properandlegaldrivingpractices.

•Neverbackupwhilelookingonlyatyourconnectedmonitordisplayscreen.Youshouldalwayscheckbehindandaround
thevehiclewhenbackingupjustasyouwouldifthevehicledidnothavetheDigitalBackupCamera.Alwaysmakesure
yourdrivingareaisclear.Alwaysbackupslowlyandwithcaution.

•NeverdependontheBackupCameraentirelywhenbackingup.Theimageonthemonitordisplayscreenmaybeslightly
differentfromactualandrealͲtimeconditions.Objectsviewedintherearviewmonitordifferfromactualdistances
becauseawideͲanglelensisused.Sousethecameraasanaidandalwaysfollowintendeddrivingpracticestoproperly
judgedistancesfromobjects.

•TheBackupCamera'sassistedlowluxlightingperformancefeatureisalsoanaidtoadriver.Alwaysuseyourowneyes
toconfirmthevehicle’ssurroundings,asthedisplayedimagemaybenotwelllitornotentirelyvisible.Alwaysproceed
withcautionandperformdoubleͲchecksbeforeproceeding.

•TheareadisplayedbytheBackupCameraislimited.Itdoesnotdisplayobjectsthatareclosetoorjustbelowthe
bumper,underneaththevehicle,orobjectsoutofthecamera’sview.Thecamera'sviewcanchangeaccordingtoyour
vehicle'sorientationontheroadorchangingroadconditions.

•Besuretocheckthecameraisproperlyfunctioning,isproperlypositionedandsecurelymounted,everytimeyou
operateyourvehicle.

•Makesureyourtrunkorhatchoperatescorrectly,asintended,beforeandafterinstallation.

•Proceedwithcautionwhencleaningyourvehiclearoundthecamera.Avoidexcesswaterexposurearoundthecamera
especiallywithsprayingorapowerwasher.

•Pleasemakesuretokeepthecameracleanandunobstructedfromanydebris

•Followalltrafficlawsandmotorvehicleregulations.

•Consultlocallawsandregulationsforanyrestrictionsoninstallationoruse.

•UsingaBackupCameraSystemisnotadequateenoughtocompletelyeliminateavehicle’sblindspot.Alwaysremember
todrivewithcaution,followingalltrafficlaws.
Pleasereadalloftheinstallationinstructionscarefullybeforeinstallingtheproduct.Improperinstallationwillvoid
manufacturer’swarranty.Theinstallationinstructionsdonotapplytoalltypesofvehicles,andarewrittenas
guidelinestoassistininstallingthesystem.Pleaseconsultanexperiencedtechnicianifyouarenotcomfortable
installingtheproduct.PriortousingandinstallingtheBackupCameraSystem,pleasereadthesafetyinformation
providedinthisusermanual.Besuretousetheproductasoutlinedinthisusermanual.Altercationormodifications
carriedoutwithoutappropriateauthorizationmayinvalidatetheuser'srighttooperatetheequipment.


SystemInstallationandWiring
Note:CameraSysteminstallationondieselvehiclesmayrequireaslightlydifferentwiringinstall.







QuickInstallation:
Thisrearviewbackupcamerasystemcomesintwoparts,oneisthecamera,theotheristhemonitor.When
installing,thecameracanbemountedeitherintherearofyourvehicle(preferablyjustabovethelicenseplate)
andhastwopossiblemountingoptions:flushmountorhangingmount.

Thiskitincludesnecessarywiringandcableconnectoraccessoriessufficientfortypicalconnections.
However,additionalaccessorycablesandinstallationmaterialsmaybenecessaryforacompletely
secureandoperationalbackupcameraperformance.

CameraConnection:
Connectthecamera,usingtheredwire,oftheincludedDC12Vpowercable,tothepositive12Vreversetail
lightintherearofyourcar.Then,connecttheblackwire,oftheDC12Vpowercable,makingsuretoground
properly.Thisconnectedpowerandgroundcablethenconnectstothecamera,andwillsupplypowertothe
cameradirectly.
Next,usetheincludedyellowRCAvideoconnectorcable,andrunthatcablefromtheyellowRCAvideo
connectorjackofthecamera,totheyellowvideoconnectoroftheincludeddisplaymonitor.
DisplayMonitorConnection:
Connectthemonitor,usingtheredwire,oftheotherincludedDC12Vpowercable.Connectthiswiretoyour
vehicle'sfusepaneltoprovidepowertothemonitor.ThenconnecttheblackwireoftheDC12Vcablemaking
suretheconnectingisgroundedproperly.



Theadditionalvideoinputonthemonitor(whitecableconnector)isavailableforconnectinganadditional
monitorordisplayscreen.Theincludeddisplaymonitorassembly,whenconnected,automaticallyretrievesthe
videosignalwhenactivated.



Caution:Connectingtoothertypesofelectricalsystemswillcausedamagetoyourvehicle.Pleasecontactthemanufacturerifyouare
unawareofthesystemtypeinyourvehicle.Refertothemodel'spowerrequirementspriortoconnectionandinstallation.


InstallationTranscript:

1.Locatethereversetaillightwiringbehindyourvehicle'sreverselight.Youmayneedtoremoveaninteriorpanel,orothercover,in
ordertolocatethewiring.Connecttheincludedpower12VDCpowercabletothereverselight.

2.Connectthecameratothis'reverselight'connectioninstallation,thenmountthecamerainthedesiredlocation.

3.AttachtheDisplayMonitor.

4.Toconnectthemonitor:usetheotherincludedpowercableandconnectto,preferably,yourvehicle'sfusepanel.

5.ConnectyourDisplayMonitortothis'fusepanel'connection.

6.ConnecttheRCAvideocablefromthecamera,totheDisplayMonitor.










CameraWiringInstallationTranscript:
a.Connectthecamerapowercable'sRedwiretoyourvehicle'sreverselightpositivewire.
b.Connectthecamerapowercable'sBlackwiretoyourvehicle'sreverselightnegativewire.




*Pleaseremembertoruncablesintheleastobtrusiveroutepossible.Vehiclevibrationsandbumpydrivingconditionscanresult,so
extracareshouldbetakentosecurelymountthecameraandfastenallcablesandwiringtosecurelocations.

*Ensurethewiresaresafelyandsecurelyconnected,withproperisolationappliedtoallconnections.






AdditionalNotes:
ͲDeterminethebestlocationforthecamera(Thecameraispreferablymountedjustabovethelicenseplate).
ͲBesurewhenrunningtheconnectioncablestoleaveasmallamountofslacksoyoucanstillmovethecameraaround
thelicenseplate,ifyoudecidetoslightlyadjustthecamera'spositioningatalatertime.
Ͳ Afterinstallation,Testthecamerabeforeuse.Placingyourvehicleinreverseshouldprovideapictureinthemonitor
withintherearviewmirrorassembly.
