Digital Midi Controller
PMIDI100
INSTRUCTION MANUAL
Connection ................................................... 2
Install Virtual DJ Program ............................... 3
Soundcard Setup ............................................ 6
Description
of the Functions ............... 8
Connection

2
Install Virtual DJ Program (CD Included)
Please click the icon of install_virtualdj_le_v6.0.7.
Follow the steps below to continue installation.

3
1. Select Language
2. Welcome Screen - Press Next
3. End User LicenseAgreement – ReadAnd Press Next

4
4. Application Path – Choose and Press Next
5. Start Installation - Press Next
6. Finish Installation - Press Finish

5
7. Click VDJ Icon on Desktop And Enter Serial Number –
Start Virtual DJ LE
Soundcard Setup

6
1. Click CONFIG at The Upper Right of The SKIN
2. Choose Output And Soundcard
Soundcard: 2 CARDS
You will notice that the drop down to the right of the output has changed
to show – Master: Chan1&2/Headphones: Chan3&4
The drop down of Soundcard has to be selected ME100.
The drop down to the right of ME100 has to be selected the respective
soundcard of your PC. The screen below is an example.

7
*After setting your soundcard, load a song to test if music has the output
from your PC.

8
DESCRIPTION OF THE FUNCTIONS
1. Master
Control the output volume of Speakers. It’s the line out from your PC.
2. Headphone:
Control the volume of your headphone.
3. Track
a. Select the track you would like to play.
b. Press to confirm the selection of folder and track.

9
4. Gain and EQ
Gain: Adjust the input signal level.
Hi: Adjust the input tremble response.
Mid: Adjust the input midrange response.
Low: Adjust the input bass response.
5. Load A, B/Back(Holding PAGE First)
a. Load A, B: Load the track to respective channel.
b. Back: It’s for going back to the previous browser tree and then selecting other
folders. Press Shift and then press this button to execute this function.
6. Play/Pause
Play or pause the track.
7. Cue/Play
Restart the music from the last memorized point.
8. Set Cue
Pause the music and press this button to have a memorized point.
9. SHIFT
Search: Hold it and dial the wheel to search the certain point you would like to play
from.
Compound Function: Hold it to enable specific button to do the compound function.
These buttons have black boxes up or next their function description.
10. Effect/Sample(Holding PAGE first)
a. ON/OFF: Switch on/off digital effect or switch on/off sample function.
b. EFX-S: Choose a certain effect or a sample.
c. EFX1-S: Adjust the parameter 1 of VDJ effect or adjust the volume of VDJ
sample.
d. EFX2: Adjust the parameter 2 of VDJ effect.
11. Seamless Loop
a. Press IN and then press Out to form a loop.
b. Hold PAGE and then press IN to decrease the loop length or press OUT to
enlarge the loop length.

10
12. Scratch/TAP(Holding PAGE First)
a. Scratch: To switch on/off this function.
b. Tap: Press with the beat to get a manual BPM value.
13. PFL
Press it to monitor a specific channel.
14. SYNC
Press it to immediately synchronize with the BPM of the other channel.
15. KEY
Press it to switch KEY mode on or off. If it is ON, the unit maintains at a constant
tempo and doesn’t change while the pitch slider is moving.
16. Line Fader
Adjust the channel output sound level.
17. Crossfader
Switch between or mix together with music of two channels.
18. Pitch Fader
Use it to adjust the pitch up or down to match the beat with the other channel.
19. Jog Wheel
Use it to dial for slight adjusting pitch value or to scratch.
20. Headphone Output
Use it to connect to a 3.5mm plug of a headphone.
21. USB Connector
Use it to connect with a laptop or a desktop via USB cable.

11
Audio Specification
Sampling Frequency 44.1 KHz, Audio Resolution : 16 bit
Output level: 1.2V+-0.2V
THD+N: < 0.03%
S/N: > 80dB
Crosstalk: > 80dB

The Video DJ section can’t match the operation with this controller.
If you would like to know more about it, please refer to the user’s
guide.
*For understanding more about the features of Virtual DJ, please
refer to User Guide in Virtual DJ installation folder.
