Pyle Power sports PLUTV46BTA User manual

User Manual of Product 1:
Pyle 2-Way Dual Bluetooth Off-Road Speakers - 4 Inch 800W
Marine Waterproof Wakeboard, Full Range Outdoor for ATV,
Snow Mobile UTV, Quad, Jeep, Boat PLUTV46BTA, Black
User Manual of Product 2:
Pyle PLUTV41BK 2-Way Dual Waterproof Off-Road Speakers,
4 Inch 800 Watt Marine Grade Wakeboard Tower Speakers
System, Full Range Outdoor Audio Stereo Speaker for ATV,
UTV, Quad, Jeep, Boat -Black

PLUTV46BTA
4’’WaterproofRatedOff-RoadSpeakers
withAmplifiedWirelessBTRemoteControlReceiver
Compact Dual Vehicle Speaker System forATV,
UTV, 4x4, Jeep, PowerSports Vehicles

www.PyleUSA.com
2
PLUTV46BTA Installation
Speaker Mounting suggestion as below:
Auto Reconnection:
Step 1: Unbolting the mounting bracket.
Step 2: Slide in the buckle with rubber pad attached
to the bracket stand of the speaker.
Attach the set to the handle bar of vehicle/ship.
Step 3/4: Attach screw to lock the buckle.
Step 5: Use Butt Connector accessories to Connect Speaker wires
(See Illustration 1,2,3).
AMP
AMP
White Gray
White
+ +
+ +
-
-
-
-
AMP
12 3
/Black
Gray
/Black
EVA Pad

www.PyleUSA.com
3
BT Pairing and Connection
Power:
1. Press and hold the power button to power ON/OFF.
Wireless BT Streaming Connection:
a. Ensure BT ability is activated, then search for the PLUTV46BTA from your
BT-enabled device. The light will turn blue and blinks while waiting for BT
connection.
b. The PLUTV46BTA BT Network Name will appear as “PyleUSA” (No password
is required for connecting).
c. When the BT is connected, the light will turn blue and stops blinking.
AUX-IN:
a. Double click power button to switch BT mode to Aux-in mode.
Auto Reconnection:
a. When the device is out of the BT range, BT will be disconnected automatically,
the light turns blue while blinking.
b. BT will automatically reconnect when detected in range again in 10 minutes.
c. Disconnected BT after 10 minutes, you need to process BT connection
steps (above) to reconnect BT again.
d. If the other device occupied the BT during this period (10mins), you need
to process BT connection steps (above).
e. If there is no connection during this period (10mins), it will turn to standby
mode.

www.PyleUSA.com
4
Playing Music
1. Press and hold 3 seconds for Power ON or OFF
2. Short press to play music or pause
3. Double click power button to switch BT mode to Aux-in mode
4. Short press for next track
5. Short press for previous track
6. Press and hold VOL+ for volume up
7. Press and hold VOL- for volume down
Installation (Seamless Flush Mount)
Play / Pause
Previous Song Next Song
Volume Up
Volume Down
Size: 96mm / 3.8’’ (Out Diameter)
76mm / 3.0’’ (Cutout Diameter)
93mm / 3.7’’ (Depth)

www.PyleUSA.com
5
Wire Diagram
Wire Color
Red
Black
White
White/Black
Gray
Gray/Black
Description
Battery (+), 12dc
Battery (-), Ground
Output L (+)
Output L (-)
Output R (+)
Output R (-)

www.PyleUSA.com
6
System Features:
• Waterproof Rated Speakers + Wireless BT Controller System Kit
• Universal Mount System for Convenient Audio Control
• Wireless BT Music Streaming Ability
• Waterproof-Rated Marine Grade Construction
• Water-Resistant, Weatherproof Design
• Compact & High-Powered System Output
• Used For Cars, Trucks, ATV’s, UTV’s, 4x4’s, Boats, Marine Watercrafts,
& PowerSport Vehicles
What’s in the Box:
• (2) 4”-inch Marine Speakers
• Amplied Wireless BT Streaming Control Unit
• (2) 2 Meters Speaker Wire
• Audio Connection Cable, 3.5mm
• (2) 5.91'' x 0.75'' x 0.24'' -inches Rubber Pads
• (2) 6.5'' x 0.75'' x 0.08'' -inches Rubber Pads
• (4) Butt Connector (Red Color For A.W.G 16-22)
Wireless BT Control Unit:
• Built-in Wireless BT Audio Receiver
• 2-Channel Amplier Style
• Works with All of Today's Latest Devices
• Smartphones, Tablets, Laptops, Computers, etc.
• Connect & Stream Audio from Additional External Devices
• Aux (3.5mm) Input
• Full Range Stereo Sound Reproduction
• Integrated Power Wiring Harness
• Pre-Amp RCA Out to Any OEM/Factory-Made Mono-Block/
Full-Range Amplier
• Flush Mount Mounting Kits Included
• Universal Vehicle Mounting
• Can be In-Console Flush Mounted
• Anti-Thump Turn-on
• Soft Turn On/O Option
• Overload & Power Protection Circuitry

www.PyleUSA.com
7
Wireless BT Control Unit Technical Specs:
• Power Output: 800 Watt MAX
• 2x200 Watts RMS @ 4 Ohm
• 2x400 Watts MAX @ 4 Ohm
• Wireless BT Version: 5.0
• Wireless BT Network Name: ‘PYLEUSA’
• Wireless Range: 30’+ ft.
• Amplier Type: Class D
• Marine Grade IP65 Rating
• T.H.D: 0.1%
• S/N Ratio: > 95 dB
• Channel Separation: > 65 dB
• Frequency Response: 10 - 40 kHz
• Fuse: 10A
• Power: DC 12V
• Unit Dimensions (Diameter x Depth): 3.8” x 4.17” - inches
Marine Speakers:
• Pro Audio PowerSport Speakers
• Sound System: (2) x 4”Woofers + (2) x 0.5”Tweeters
• 2-Way Full Range Stereo Sound Reproduction
• Quick-Connect Spring-Loaded Speaker Terminals
• Impressive Bass Response
• Sleek Design, Machine Molded Speaker Cabinet Housing
• Rugged, Universal Mount Bracket Design for Roll-Bar/Roll-Cage
Marine Technical Specs:
• Power Output: 800 Watt MAX
• Marine Grade Waterproof Rating: IP-X5
• Speaker Style: Passive Speakers
• Speaker Type: Polypropylene Cone, Butyl Rubber Surround (x2)
• Tweeter Type: Neodymium Dome (x2)
• Frequency Response: 85Hz-20kHz
• Impedance: 4 Ohm
• Magnet Type: 20 oz. Circuit
• Mid-Woofer Voice Coil Type: 1.0", Aluminum
• Sensitivity: 90 dB +/- 2 dB @ 1M/1W
• Universal Mounting Brackets Roll-Bar/Roll-Cage Diameter: 1.25” ~ 2.0” -inches
• Power Supply: DC 12V
• Speaker Size (Front Diameter x Length): 5.6” x 7.3” -inches (Each)

Questions? Issues?
We are here to help!
Phone: [phone]
Email: [e-mail]

4’’WaterproofRatedOff-RoadSpeakers
Compact PowerSport Vehicle Speaker System
for ATV, UTV, 4x4, Jeep (800 Watt) (Pair)
PLUTV41BK

www.PyleUSA.com 2
PLUTV41BK Installation
Speaker Mounting suggestion as below:
Step 1: Unbolting the mounting bracket
Step 2: Slide in the buckle with rubber pad attached to the bracket stand of the speaker
Attach the set to handle bar of vehicle / ship
Step 3/4: Attach screw to lock the buckle
Step 5: Using accessories of Butt Connector to Connect Speaker wires (See Illustration 1,2,3)

www.PyleUSA.com
3
Features:
• Pro Audio PowerSport Speakers
• Compact & High-Powered Output
• Marine Grade Waterproof Rated Construction
• Weatherproof & Water-Resistant Housing
• Sound System: (2) x 4.0'' Woofers + (2) x 0.5’’Tweeters
• 2-Way Full Range Stereo Sound Reproduction
• Impressive Bass Response
• Sleek Design, Machine Molded Speaker Cabinet Housing
• Rugged, Universal Mount Bracket Design for Roll-Bar / Roll-Cage
• Used for O-Road Outdoor Vehicles: ATV, UTV, 4x4, Jeeps, Marine Watercraft
• Quick Butt Connector for Speaker Wiring
What’s in the Box:
• (2) O-Road Speakers
• (2) 2 Meters Speaker Wire
• (2) 5.91'' x 0.75'' x 0.24'' -inches Rubber Pads
• (2) 6.5'' x 0.75'' x 0.08'' -inches Rubber Pads
• (4) Butt Connector (Red Color For A.W.G 16-22)
Technical Specs:
• Power Output: 800 Watt MAX
• Marine Grade Waterproof Rating: IP-X5
• Speaker Size: 4’’ -inch (Each)
• Speaker Style: Passive Speakers
• Speaker Type: Polypropylene Cone, Butyl Rubber Surround (x2)
• Tweeter Type: Neodymium Dome (x2)
• Frequency Response: 85Hz-20kHz
• Impedance: 4 Ohm
• Magnet Type: 20 oz. Circuit
• Mid-Woofer Voice Coil Type: 1.0'', Aluminum
• Sensitivity: 90 dB +/- 2 dB @ 1M/1W
• Universal Mounting Brackets Roll-Bar / Roll-Cage Diameter: 1.25’’ ~ 2.0’’-inches
• Speaker Dimensions: 5.6’’ x 8.4’’ x 7.3’’-inches, with Bracket (-Each)

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]om
