Pyle PPHP818B User manual

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
PASpeaker&MicrophoneSystem
Portable Karaoke Speaker with Wired Mic,
Built-in LED Party Lights, FM Radio,
MP3/USB/Micro SD Readers, (8’’Subwoofer, 300 Watt MAX)
PPHP818B

WARNING
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception
which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
NOTE: This device and its antenna(s) must not be co-located or operation in
conjunction with any other antenna or transmitter.
RF Exposure Statement
To maintain compliance with FCC’s RF Exposure guidelines. This equipment should
be installed and operated with minimum distance of 20cm the radiator your body.
This device and its antenna(s) must not be co-located or operation in conjunction
with any other antenna or transmitter.
IMPORTANT SAFETY MEASURES
Before using this machine, please read all the safety and operating instructions.
Meanwhile, please observe all the indications about safe operating.
1. Protection of electric power supply line: Be aware that the electric power supply
line is not tramped, pressed by heavy objects. Pay special attention to the plug of
power supply line and outlet on the machine. DO NOT lengthen the electric shock,
DO NOT pull or drag or the power supply line.
2. Ventilation: This set must be put in ventilated place. DO NOT put disk on it or cloth
to cover it. The distance away from the wall should not be less than 10 centimeters.
DO NOT put this set on the bed, sofa, carpet or other objects with similar surface
in case of good ventilation.
3. Casing Dismantling: DO NOT dismantle the casing. If one touches the inner
components, he will probably get serious electric shock.
4. Unusual smell: When you discover unusual smell and smoke, cut power supplies
immediately and pulls out the plus from the outlet on the wall.
Contact the sell shop or nearest repairing center.
PRODUCT FEATURES
1. High-Powered PA Loudspeaker
2. Wired Microphone for Home Karaoke Style Fun
3. Ported Enclosure for Extended Bass
4. Full Range Stereo Sound Reproduction
5. Wireless Music Streaming Ability
6. Multi-Color Flashing LED Party Lights
7. Aux (3.5mm) Input Connector Jack
www.PyleUSA.com
2www.PyleUSA.com 3
What's in the Box:
• PA Speaker System
• Remote Control
• Power Adapter
• Wired microphone

1. MODE: Used to switch the BT, FM, AUX, USB, SD
2. Power: Standby button.
3. MUTE: Mute button
4. : Previous song/Previous channel
5. : Play/Stop Auto-search by press and hold
the FM button, press and hold the BT button to
turn on TWS
6. : Next song/Next channel
7. VOL - : Main volume decrease
8. EQ: Choose from EQ1,EQ2,EQ3,EQ4...
9. VOL + : Main volume increase
10. REPEAT: Single repeat/repeat all
11. U/SD: Switch to Micro SD/USB mode
12. Choose song number directly/channel directly.
www.PyleUSA.com
4www.PyleUSA.com 5
GETTING STARTED
1. Ensure the Portable PA Speaker is turned o. Ensure all volume controls are turned
all the way down. Next, connect one side of the included power cable to the
Portable PA Speaker’s power inlet and the other to a grounded power outlet.
2. Ensure that the power supply complies with the power requirements listed on the
identication sticker located on the bottom of your product. Turn on the power to
the Portable PA Speaker using the power switch.
3. Slowly turn up the function keys until the desired level is reached.
WIRELESS BT CONNECTION
Switch the Portable PA Speaker to MODE, then switch to BT (BT MODE) pairing
mode and connect to a new BT device using BT Network Name: ‘PYLE USA’.
Warning: To prevent the risk of re or electric shock, do not expose this appliance to
rain or moisture. To prevent electric shock do not remove the cover. No user serviceable
parts inside. Refer servicing to qualied service personnel.
Safety: Prior to connecting mains, ensure that the supply voltage is correct and the
mains lead is in good condition. Avoid ingress of water or particles into the enclosure.
Placement: Keep the unit out of direct sunlight and away from heat sources.
Place the unit in an upright position during use and storage. Keep the unit away
from moisture or dusty environments.
Cleaning: Use a soft cloth with a neutral detergent to clean the cabinet, panel and
controls. To avoid damage, do not use solvents to clean this equipment.
REMOTE CONTROL FUNCTIONS
UNIT DESCRIPTION
1. IR: Infrared remote control receiver
2. Display Screen
3. MIC. IN: Mic input
4. MIC.VOL: Mic volume knob
5. ECHO: Echo eect for mic
6. USB port
7. Micro SD port
8. PREV: Previous song/channel
9. PLAY/TWS: Play/stop, Auto- search by press and hold the FM button, press and
hold the BT button to turn on TWS
10. NEXT/MIC. PRI: Next song/next channel/press and hold mic priority
11. MODE/LED. SW: Mode Switch for BT，FM，AUX，USB，SD/press and hold to turn
on/o LED light
12. AUX: AUX in
13. DC5V: DC 5V charging port
14. CHARGE: Charge indicator
15. POWER/VOLUME: Power ON/OFF/ main volume knob
1
15
2
34 5
6
78910 11 12 13 14
1
3
4
6
7
9
10
11
2
5
8
12
