Pytes Ecox 18 Pro User manual

USER MANUAL
PORTABLE POWER STATION

Please read and understand all safety instructions carefully to ensure safe operation
and application of the power station. Severe injury or property damage may be caused
by failure to follow instructions.
The loss caused by misuse of POWER STATION is not covered by our Warranty
Please FULLY charge the POWER STATION as soon as possible once you receive it.
The battery may be in sleep mode or lose power during long periods of transport and
storage.
Plug the POWER STATION into the wall outlet for 10 minutes to reactivate the battery.
If the battery still not charged after 10 minutes, please contact customer service team.
CHARGE NOW
When turning on the AC Button, the LCD Display may show Output Power watts
being drawn before you plug the load into the AC outlet. This is normal reaction
caused by the "no-load" discharge. It is recommended that you turn off the output
button(s) when not in use.
Note:
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INFORMATION

FEATURE DETAILS
13. AC Input 14. Protective Cover
2. AC Outlets
1. LCD Screen Display
12. Reset Button
4. USB-TYPE-C 60W
3. USB QC3.0
6. Cigarette Lighter Output
9. Handle
10. LED Light 11. Anderson Input
5. Parallel Connection Ports
15. Power ON/OFF Button 16. LED Light (SOS) ON/OFF Button
17. ECO Mode ON/OFF Button
19. AC Outlet ON/OFF Button
18. DC/USB Output ON/OFF Button
8. Wireless Charger7. DC 5525
ᶒ
ᶔ
ᶓ
ᶕ
ᶖ
ᶗ
ᶎ
BACK
ᶍ
ᶅ
ᶑ
ᶌ
ᶉ
ᶊ
ᶋ
ᶈᶇ
ᶆ
ᶐ
ᶏ

POWER ON/OFF BUTTON is the Master Switch. Press POWER ON/OFF BUTTON to activate
the DC/AC/ECO BUTTONS.
15: POWER ON/OFF Button
Press DC Output ON/OFF BUTTON to activate DC/USB Output ports.
18: DC/USB Output ON/OFF Button
17: ECO Function ON/OFF Button
ECO Mode: If the output ports are not in use, the power station will automatically shut down
after 1 hour for energy saving.
Press the POWER ON/OFF Button, ECO Mode will be activated by default. If you do not need
this function, please press the ECO ON/OFF Button to turn it off. Press ECO Button to activate
the ECO Mode.
Press AC Output ON/OFF BUTTON to activate AC Output Ports.
19: AC Outlet ON/OFF Button
ECO
17:
ECO Mode ON/OFF Button
18:
DC/USB Output ON/OFF Button
15:
Power ON/OFF Button
19:
AC Outlet ON/OFF Button
FUNCTION BUTTONS
OPERATION GUIDE
16: LED LIGHT ON/OFF Button
Press LED LIGHT ON/OFF Button once to turn on the LED LIGHT, press it again
to turn off the LED LIGHT.
Press and hold the LED LIGHT ON/OFF Button over 3 seconds to switch to the SOS mode.
16:
LED LIGHT ON/OFF Button
20: WIRELESS CHARGER
Press Power ON/OFF Button before charging. Press the Power ON/OFF Button to turn off
the output.

DETAILS DISPLAYED ON LCD
OPERATION GUIDE
Battery Level: The percentage figures and the number of battery bars represent
remaining capacity.
PLEASE BE AWARE that this value varies as the energy consumption of the load
changes. Charge the POWER STATION when the battery level is below 20%. Please
note that when you first charge the POWER STATION, either a solar panel or an AC
Charger, it may take a few minutes to detect and adjust its charging circuit before
it begins to draw power.
Remaining Charging Time: Real-time display of remaining charging time in hours
and minutes.
Input Power: Real-time display of Input Power in Watts.
Remaining Usage Time: Real-time display of remaining service time in hours and
minutes.
Output Power: Real-time display of the total Output Power in Watts (Cigarette Lighter
Port, USB-A, USB-C and AC).
Low Voltage Warning: Please recharge the power station when the low voltage warning
sign lights up.
Temperature Warning: The Temperature Warning sign will light up when the battery
temperature of POWER STATION is too low/high. All functions will return to normal
when the battery temperature revert to the working range.
Low Battery Alarm: The "TO EMPTY" sign will light up when the battery level is below 20%.
Please charge it as soon as possible to extend battery lifespan.
LCD FEATURES
Remaining Charging Time Input Power
Remaining Usage Time
Battery Level
G:
Output Power
E:
H:
A: B: C:
F:D: Low Voltage Warning
Temperature Warning Low Battery Alarm
G
A
E
H
C
D
F
B

UPS MODE
Parallel Connection Kit (Sold Separately)
NOTICES:
WOULD NOT work when two power stations connected in parallel.
ONLY WORKS when AC ON/OFF BUTTON is ON.
When the AC charging cable is connected to the Utility Power and the device is charged by
the Master with the AC Button on, it won't consume power from Power Station. When there
is a power outage, it automatically switches from Utility Power to Power Station power supply
within 10milliseconds.
Additional Function
NOTICES:
The red part of the DC plug is positive, and the black part is negative.
Please connect the positive to positive and the negative to negative to ensure proper use.
Please connect the parallel cable first, then press the AC output button to activate the
parallel function.
The total output watts are separately displayed in the LCD of power station.
UPS WOULD NOT work when paralleling two power stations.
Please parallel two same power station with the provided parallel box (sold separately).
Ecox 18 Pro can double the power by connecting the two power stations with an additional parallel
connection box (sold separately).
Plug the DC port of the parallel box separately into the two same power stations as below
to expand the power watts.

• User Manual
ACCESSORIES
AC Charging Cable•
NOTICES:
Check the input charge cable. The charging process can work efficiently only the input charge
cable meets the specification outlined in the GENERAL SPECIFICATIONS section.
Charge POWER STATION with provided AC adapter only.
GENERAL SPECIFICATIONS
Model
Battery
Capacity
Dimensions
Weight
Charging Temperature
Discharging Temperature
AC Input
Solar Input
AC Outlet
DC Ports
USB-A Ports
USB-C Port
Wireless Charger
LED Lighting（SOS mode）
Ecox 18 Pro
Lithium Battery
1466Wh (44.4V, 43Ah)
L350 x W265 x H240 mm
31.1 lbs(14.1kg)
32 to 104°F (0 to 40°C)
14 to 104°F (-10 to 40°C)
800W
12-60V, 800W Max
3x 1800W, 3600W surge
1x 12V/10A, 2x 12V/10A（DC5525）
2x 5V/3.4A、9V/2A、12V/1.5A, total 36W Max
2x 5V/9V/12V/15V/20V, 3A, total 60W Max
1x 10W
1x 1W

OPERATION GUIDE
HOW TO CHARGE
From Solar Charger
From Car Port 12V
From Wall Charger 100 - 240V
depend on the solar conditions
The LCD shows the battery level while charging. POWER STATION is fully charged when the
figure turns to 100%.
It is recommended to FULLY charge POWER STATION every 3 months to extend the battery
lifespan.
CHARGING POWER STATION
RECOMMEND TO UNPLUG THE POWER STATION WHEN IT’S FULLY CHARGED.
WHEN IT CANNOT CHARGE THE POWER STATION, PLEASE CHECK IF THE RESET
BUTTON IS ON.
OPERATING INSTRUCTIONS
POWERING / CHARGING DEVICES
Select the required output port by pressing the corresponding switch button (DC (DC/USB
output), AC or ECO). The output port will be activated when the indicator on the button lights
up green. The LCD will display output details. Press the POWER ON/OFF BUTTON(S) to turn
off the output(s) power when not in use.
Press the ON/OFF BUTTON(s) to shut down the output(s) when not in use.
PASS-THROUGH CHARGING
The advanced battery management system of the POWER STATION allows powering a device
via DC & USB & AC output port(s) while it’s charging itself.
OVERLOAD CONDITION
If the overload condition occurs to the OUTPUT, POWER STATION will automatically shut
down the outlet’s power.
• The LCD still display values.
• The DC Output will still be the same status as normal.

Make sure any input power and output devices are NOT plugged into the POWER STATION.
Wipe it with a clean, dry, soft, lint-free cloth. Remove any debris, dirt, or other blockages from
the side vents and prevent them from falling into the interior of the Power Station.
DO NOT use abrasive cleaners or corrosive solvents.
DO NOT use compressed air to clean side vents.
DO NOT use metal objects to clean the ports to avoid the risk of electric shock.
Please fully charge the POWER STATION if the storage time is more than one month. Recharge
the POWER STATION every 3 months to avoid possible damages from a full discharge. Please
store in a cool, moderately humid room out of direct sunlight (Refer to GENERAL SPECIFICATIONS
section). Leaving POWER STATION in a car or other confined space with extremely hot temperatures
will overheat the battery, resulting in a shortened lifespan and even fires.
Extremely cold temperatures will affect the performance and lifespan of the POWER STATION. Keep
away from corrosive chemicals and gases. After taking the POWER STATION out of storage, check
and make sure all the accessories are in good condition. Review the air intake and side vents to
ensure they are clear of debris.
Ensure safe environmental conditions are met before the POWER STATION recharge or charging
other appliances.
Recharge as you need. There are no pre-designated intervals at which to recharge as long as
the POWER STATION is used regularly. Avoid fully depleting the battery to 0%, it will impact the
quality and lifespan of the battery. Periodically inspect all ports and wall chargers for any debris,
dirt, damage, and corrosion.
DO NOT attempt to fix it on your own.
DO NOT cover the POWER STATION with towels, clothing, or other items. Periodically check the
side vents to make sure there is no dirt or dust. If there is debris, follow the cleaning procedures in
the manual to clean the POWER STATION.
Please fully discharge the battery before disposing it. Due to the presence of hazardous chemicals,
please dispose of batteries only in designated recycling channels, not with regular trash. Consult
your local laws regarding battery recycling and disposal.
If the battery cannot be fully discharged due to product failure, please contact a professional battery
recycling company for further processing.
Please dispose of batteries that no longer recharge.
MAINTENANCE
MAINTENANCE
CLEANING
STORAGE
DISPOSAL/RECYCLE
