QEES 0100002 User manual

When you are leaving your home you are
switching all light off, switching all standby
power offand turning down the heat
– all with one single push on your personal
QEES-Ring.
Save the energy, when you are not using it.
When you are leaving your home…
8

Technical specifications
Design Søren Blandford
Size (mm) 53x33x12 (HxWxD)
Colour Black / Brown / Red
Battery CR2032
Range 100 ft.
RF Z-Wave EU / US
No. of groups 4
Z-Wave type Controller
:: Z-Wave Remote control
:: 4 Programmable groups
:: Primary controller functionality
:: Up to 400 ft. range with routing
QEES-Ring – quality and design
QEES-Ring controller is a Z-Wave based remote control.
Z-Wave is a fast growing RF wireless technology for con-
trolling and automating homes and offices. The QEES-Ring
lets you control other Z-Wave based devices such as lights,
blinds, HVAC, standby power, etc.
The QEES-Ring is a stylish and easy to use remote control
with advanced functionality made simple. The QEES-Ring
is designed to fit in a key chain, making it available when
leaving home or when returning home.A total of 4 groups are
supported for individual controlling of devices or scenes.
The QEES-Ring controller also supports including and
exclusion of devices in the Z-Wave network as well as other
Z-Wave administrative tasks.
The QEES-Ring controller allows you to control any Z-Wave
product regardless of vendor.
QEES @ Home
Add comfort to your living with theQEES-Ring. TheQEES-Ring
allows you to control light setting, HVAC, blinds, etc. – Or
everything else that makes use of the Z-Wave technology.
Use the QEES-Ring to make sure all light and standby power
are offwhen leaving home. Open or close the garage door
from your car. Use the QEES-Ring to turn on the light, before
entering you home when coming home at night or evening.
The QEES-Ring uses RF to overcome the limitations with IR,
meaning you will be able to control devices in other rooms
without line of sight.
QEES @ Work
In office automation the QEES-Ring lets you impress your
clients in your conference room. Adjust light settings, blinds,
AV equipment such as projectors, etc. Prepare the room for
your AV presentation with one push on your QEES-Ring.
After presentation, push your QEES-Ring and the light
comes on, the projector is turned offand blinds opens. The
QEES-Ring allows you to control the surrounding environ-
ment from your pocket, and lets you keep focus on clients.
QEES-Ring Controller - Model 0100002/0101002
9

10

11

Congratulations!
Congratulations on your new QEES product. QEES Ring
is a miniature remote control designed to be placed in a
key chain. With a QEES Ring, you always have the remote
control handy. QEES Ring uses Z-Wave technology to com-
municate with other units and can control a large number of
different units.You can for example use QEES Ring to switch
offlight and standby consumption when leaving the home,
to open the garage door, to switch on the light in the hall to
avoid having to enter a dark house, etc.
Unpacking and installation
When you receive your QEES Ring, the box contains 1
QEES Ring and 1 battery of the type CR2032. In order to
insert the battery, you need a small screwdriver. Carefully
remove the 2 screws and disassemble the QEES Ring. Insert
the battery, make sure that it is turned the right way, and
reassemble the QEES Ring. After this, you are ready to set
up your QEES Ring.
Setup and configuration
Your QEES can be used as the primary controller of a
Z-Wave-based home automation network, or can be used as
part of an already existing installation.This means that you do
not need a dedicated Z-Wave master, such as QEES Master,
to use QEES Ring. If you want to useQEES Ring in connection
with a master or another Z-Wave remote control, you have to
include QEES Ring on this unit and then follow the instruc-
tions for the unit to associate functionality with QEES Ring.
If you do not have a master or another Z-Wave remote
control, and QEES Ring is your first Z-Wave-based remote
control, you can include units by pushing one time, briefly,
on the service button placed on the back of your QEES Ring.
QEES Ring flashes green 1 time per second, and activate the
unit to be included. When you have included the unit, you
can choose to associate it with a button on yourQEES Ring.
QEES Ring has a total of 4 buttons that can each have one
or more associations to units in the Z-Wave network. In
order to create an association, you have to push the service
button 1 time, followed by push 1 time on the button you
want to use to control the unit. QEES Ring flashes red and
green, and you can activate the unit to be included.
It is important that the unit you want to use withQEES Ring
is not already part of a Z-Wave network. If this is the case,
you have to exclude the unit first.You can useQEES Ring to
exclude any unit by pushing the service button twice and
then activating the unit you want to exclude.
Daily use
When you have set up your QEES Ring, you are ready to
control light, curtains, standby power, etc. Each button on
QEES Ring has 4 different push combinations that are used
to control your units. To switch on a unit, you have to push
the button briefly 1 time. To switch offa unit, you have to
push the button briefly 2 times. To turn up light or open
window or curtain more, etc., hold down the button until
you achieve the desired setting.To turn down light or close
window or curtain slightly, push the button briefly 1 time,
followed by holding down the button until you achieve the
desired setting.
Disposal
QEES Ring contains electronics and should therefore not
be disposed of with regular household waste. The unit
must be handed in at a recycling centre that is capable of
handling electronics waste.
LED signals
Flashes GREEN: Inclusion / exclusion in progress.
Shines GREEN: Inclusion / exclusion ok.
Shines RED: Inclusion / exclusion error.
Shines RED + GREEN: Processing.
12

Include unit
1) Push service button briefly 1 time.
2) Wait for QEES Ring to flash 1 time per second.
3) Activate the unit to be included.
4) QEES Ring shines green constantly for about
2 seconds, and inclusion is ok.
Associate unit with button
1) Push service button 1 time, followed by push 1 time
on the button to be associated with the unit.
2) Wait for QEES Ring to flash orange. (Red + Green).
3) Activate the unit to be controlled.
4) QEES Ring shines green for about 2 seconds, and
association is ok.
Exclusion of unit
1) Push service button briefly 2 times.
2) Wait for QEES Ring to flash 2 times per second.
3) Activate the unit to be excluded.
4) QEES Ring shines green for about 2 seconds, and
exclusion is ok.
Remove unit from button
1) Same method as association. If an association
already exists, it will be removed.
Remove all functionality from one button
1) Push service button 2 times, followed by push 1
time on the button that need functionality removed.
2) QEES Ring shines green for about 2 seconds.
Include QEES Ring on a Z-Wave controller
1) Push service button briefly 3 times.
2) Wait for QEES Ring to flash 3 times per second.
3) Activate inclusion on the Z-Wave controller.
4) QEES Ring shines green for about 2 seconds, and
inclusion is ok.
Reset to default setting
1) Push service button 3 times, followed by push
button 4, 3 times.
2) QEES Ring shines green for about 2 seconds.
3) QEES Ring has now been reset to default setting.
Send info (node info)
1) Push service button 1 time, followed by hold down
service button.
2) QEES Ring shines green for about 2 seconds.
Send wake-up
1) Hold down service button.
2) QEES Ring shines green for about 2 seconds.
Quick guide
Service button
2
4
1
3
13

QEES ApS :: www.qees.eu :: [email protected]
Tag kontrollen i bestyrelseslokalet
– mødet skal til at starte, alle er på plads,
du ruller persiennerne for og dæmper lyset.
Tænder den lille røde lampe, som viser at
lokalet er optaget, tænder for storskær-
men og PCén, for at starte din PowerPoint
præsentation – alt sammen ved et enkelt
tryk på din personlige QEES-Ring.
Spar på tiden, og behold fokus.
Take control in the boardroom
The meeting is about to start, all board
members are ready, you adjust the light set-
tings, blinds, AV equipment, projectors and
