QIANGLI DUVOSS Q1 User manual
01
Take out the earbuds English
Before using the earbuds for the first time.
put them back into the charging compartment
and close the charging compartment. Connect
it to the Type-c cable to charge the Bluetooth
earbuds DUVOSS Q1.
Power on : The charging compartment is turned on when the cover
is opened. The left and right earphones are taken out from the
charging compartment, and the left and right earphones will be
automatically paired with an interval of no more than 5 seconds.
After the boot is successful, it will enter the Bluetooth connection
and pairing state with the mobile phone (the connected mobile
phone can automatically pair with the Bluetooth successfully).
Power off : Put the earphone into the charging box, and it will shut
down automatically when the cover is closed. If the Bluetooth has
not been connected after turning on, the headset will automatically
turn off in about 5 minutes.
In the power-on state, put the left and right
earbuds in the charging compartment, they
will automatically shut down and the charging
starts.
02
Cohnect the device
Key operation
Call control :
Click --- Answer (During the answering process, long-press the
left /right Touch key for 2 seconds to hang up)
Long press for 2 seconds --- Reject
(Support bilateral calls, that is. two earbuds can play sound at the
same time. Single earbud call is also supported)
After trying earbuds are turned on, the Bluetooth
interface of the mobile phone will display the
device named ‘DUVOSS Q1’; click to successful-
ly connect. The default PIN code for Bluetooth is
‘0000’.
Music control :
Play /Pause: touch the left/right touch key once
Volume addition and subtraction:
Long press the left/right touch button for 2 seconds to increase
and decrease the volume
Double click L: play the previous song
Double click R: play the next song
Clear pairing information:
7-click to clear the pairing in the single-earbud pairing state
Siri voice mode :
Click the left or right earbud three times
DUVOSS Q1
03
KEY OPERATION
Charge：
Insert Type_C to charge the green light flashes slowly, full: the
green light keeps on prompt
low battery :
The battery power is less than 10%, the LED red light is on, and it
flashes slowly for 60 seconds.
Put the headset in the charging compartment:
If one of the earphones is not charged, the yellow light flashes to
indicate(If the headset does not show a yellow light in the cabin)
Bluetooth name: DUVOSS Q1
Voltage: 3.7V
Bluetooth version: 5.3
Bluetooth distance: 10m
Resistance ohm: 32Ohms
Headphone battery capacity: 40mA
Trumpet: 1Omm *2 Hi-Fi stereo
Play time: 7 hours/0.09Wh
Frequency: 20Hz-24kHz
Product Features: Waterproof IPX5、 touch、 wireless Bluetooth
Light status description
Product parameter
04
KEY OPERATION
Change pairing. power off. charge
1.After power on, the Bluetooth earbuds will automatically connect
to the last paired mobile phone.
2. If you need to pair other mobile phones. please turn off the
Bluetooth of the original phone. After turning on the Bluetooth
earbuds, turn on the Bluetooth of other mobile phones to search
for the device name DUVOSS Q1.
3. When the music is paused, the earbuds stay in standby mode
with very low power consumption.
4. When not using the earbuds, put them in the storage box. The
earbuds will automatically shut down and charge. If you don't have
a storage box with you, please disconnect the Bluetooth manually.
After about 5 minutes. the earbuds will automatically turn off.
Indicator light description
pairing
Smart charging compartment :
Put the earbuds in, charging starts automatically.
After the earbuds are fully charged, charging stops automatically.
Warning :
Due to the small size of the earbuds, keep them out of the reach
of children when charging or when they are not in use to avoid
accidental ingestion.
05
Th
is eq
ui
pm
ent has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly
approved by manufacturer could void your authority to operate this
equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
FCC Statement
