Qilive Q.6467 User manual

Front washing dryer
8KG
Q.6467
FR LAVE-LINGE SÉCHANT HUBLOT 8 KG
ES LAVADORA-SECADORA DE CARGA FRONTAL 8 KG
PT MÁQUINA DE LAVAR E SECAR DE CARREGAMENTO
FRONTAL 8 KG
PL PRALKO-SUSZARKA ŁADOWANA OD PRZODU 8 KG
HU ELÖLTÖLTŐS MOSÓ-SZÁRÍTÓGÉP 8 KG
RO ФРОНТАЛЬНАЯ СТИРАЛЬНАЯ МАШИНА С СУШКОЙ
8 KG

EN User manual P. 4
Manuel d’utilisation P. 27
Manual del usuario P. 52
Manual do utilizador P. 77
Instrukcja użytkownika S. 102
Használati útmutató 127. o.
Manual de utilizare P. 152
FRFR
ESES
PL
RO
PT
PL
HU
RO

1
2
3
4
5
6
9
8
7
FR
EN
ES
PT
PL
HU
RO

44
EN
1. SAFETY INFORMATION
Before using this electrical appliance, carefully read
these instructions and keep the user manual for future
reference:
1. This appliance is intended for domestic use and
similar applications, such as:
- kitchen areas designated for store and office
personnel, and other professional environments;
- farms;
- use by guests in hotels, motels and other residential
environments;
- guesthouse environments.
2. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
3. Before connecting the appliance to a wall socket,
ensure that the local electrical current matches the
one specified on the appliance’s nameplate. This
appliance should only be connected to a grounded
socket.
4. Unplug the mains cable from the mains as soon
as you stop using it and before any cleaning or
maintenance operation.
5. This appliance can be used by children aged from
8yearsandabove and persons with reduced physical,
TABLE OF CONTENTS:
1. SAFETY INFORMATION P. 4
2. TECHNICAL DATA P. 9
3. DESCRIPTION P. 13
4. INSTALLATION P. 16
5. USE P. 19
6. MAINTENANCE AND CLEANING P. 23
7. WARRANTY AND LIMITATIONS OF LIABILITY P. 26

55
EN
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
unless they are older than 8 and supervised. Keep
the appliance and its cord out of reach of children
less than 8 years.
6. Electrical and electronic equipment are collected
through a separate form of waste collection. Do
not dispose of electrical and electronic equipment
alongside household waste. Dispose of them at the
appropriate sites. Collection systems and locations
(sortingcentres,wastedisposal centres) are available
from local authorities and distributors. By disposing of
your end-of-life product at the appropriate recycling
sites, you can help protect the environment as well
as your health.
7. WARNING: To avoid deteriorating the appliance,
transport it in its operating position, along with its
transport brackets (depending on model). At the time
of unpacking, and to prevent risks of suffocation or
injury, keep packaging materials out of children’s
reach.
8. WARNING: When disposing of your appliance, and
to avoid any risk of injury, remove what may be
hazardous: cut the power cable so it is flush with the
appliance. Check with your local services for places
where you are allowed to dispose of the appliance.
Remove the door lock in order to prevent children
from becoming trapped inside.
9. Instructions for installing, using, and performing
maintenance on the appliance are provided in
the sections titled “INSTALLATION”, “USE”, and
“MAINTENANCE AND CLEANING”.

66
EN 10. The appliance is designed for a maximum load
weight of 8 kg of dry laundry for cotton items, 3.5 kg
for synthetics and delicates, and 2.5 kg for wool.
11. The appliance must be connected to the water
distribution network using a new set of pipes. It is
recommended to not reuse old pipe sets.
12. The minimum inlet water pressure permitted is
0.05 MPa .
13. The maximum permitted water pressure of the water
supply is 1 MPa.
14. Never force the door open when the appliance is
running.
15. Never open the laundry drawer while the appliance
is running.
16. Keep pets away from the appliance.
17. RISK OF BURNS!
Do not touch the drain hose or the water supply
hose. The appliance may reach high temperatures
while operating.
18. RISK OF DEATH BY ELECTRIC SHOCK!
Avoid using multiple plugs or extension cords.
Do not connect the appliance to damaged outlets.
Never pull the cable to disconnect the appliance -
always disconnect from the plug.
Avoid connecting or disconnecting the appliance
with wet hands as this poses a risk of electrocution.
Never touch the appliance with wet hands or feet.
19. Risk of flooding!
Take all necessary measures to prevent the hose
from slipping.
20. Risk of fire!
Do not leave flammable liquids within close proximity
of your appliance.
The openings must not be obstructed by a carpet.
21. Child safety!
Never leave children unattended near the appliance.
Children may lock themselves inside the appliance,
with a risk of death.

77
EN
The door glass and its surface may become extremely
hot while the unit is operating. Therefore, touching
the appliance may cause burns to children’s skin.
Keep packaging materials out of the reach of children.
Children of less than 3 years should be kept away
unless continuously supervised.
22. The appliance must not be installed behind a lockable
door, a sliding door or a door with a hinge on the
opposite side to that of the tumble dryer, in such a
way that a full opening of the tumble dryer door is
restricted.
WARNING!
- The tumble dryer is not to be used if industrial chemicals
have been used for cleaning;
- The lint trap has to be cleaned frequently, if applicable;
- Lint must not be allowed to be accumulated around the
tumble dryer (not applicable for appliances intended to
be vented to the exterior of the building);
- Adequate ventilation has to be provided to avoid the
back flow of gases into the room from appliances
burning other fuels, including open fires.
- Do not dry unwashed items in the tumble dryer.
- Items that have been soiled with substances such
as cooking oil, acetone, alcohol, petrol,kerosene,
spot removers, turpentine, waxes and wax removers
should be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
- Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
- Fabric softeners, or similar products, should be used
as specified by the fabric softener instructions.
- The final part of a tumble dryer cycle occurs without
heat (cool down cycle) to ensure that the items are left
at a temperature that ensures that the items will not be
damaged.

88
EN - Remove all objects from pockets such as lighters and
matches.
- Never stop a tumble dryer before the end of the drying
cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
- For appliances with ventilation openings in the base, a
carpet must not obstruct the openings;
- Exhaust air must not be discharged into a flue which
is used for exhausting fumes from appliances burning
gas or other fuels.
Disposal
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To
return your used device, please use the return and
collection systems or contact the retailer where the
product was purchased. They can take this product
for environmental safe recycling.
Warning: hot surface. Surfaces may become hot during appliance use.
This symbol shows that the operation manual should be read carefully.

99
EN
2. TECHNICAL DATA
2.1 Product Data Sheets
Washing capacity 8 kg
Drying capacity 5.0 kg
Spin speed 1300 rpm
Energy efficiency class ❶B
Energy consumption per cycle (to wash and dry a full
capacity load at 60°C) 6.48 kWh/cycle
Water consumption per cycle (total) 136 L/cycle
Estimated annual energy consumption for a 4-person
household always using the dryer (200 cycles) ❷1296 kWh/year
Estimated annual water consumption for a 4-person
household always using the dryer (200 cycles) ❷27200 L/year
Estimated annual energy consumption for a 4-person
household never using the dryer (200 cycles) ❸258 kWh/year
Estimated annual water consumption for a 4-person
household never using the dryer (200 cycles) ❸12800 L/year
Washing performance class ❹A
Standard washing cycle ❺Cotton ECO
Energy consumption of Cotton ECO 60°C at full load
(washing) 1.29 kWh/cycle
Water consumption of Cotton ECO 60°C at full load
(washing) 64 L/cycle
Remaining moisture content of Cotton ECO 60°C at full
load (washing) 53 %
Programme duration of Cotton ECO 60°C at full load
(washing) 330 min
Energy consumption at full load (drying) 5.19 kWh/cycle
Water consumption at full load (drying) 72 L/cycle
Programme duration at full load (drying) 360 min
Power consumption in off mode 0.5 W
Power consumption in standby mode 1.0 W
Noise level washing 60 dB(A)
Noise level spinning 79 dB(A)
Noise level drying 62 dB(A)
Energy test programme: Cotton ECO 60/40°C. Speed: highest speed, not default.
Drying: Drying only, Speed: 0 rpm.

1010
EN
❶The energy efficiency class is from A (highest efficiency) to D (lowest efficiency).
❷Energy consumption per year, based on 220 standard washing cycles for
standard programme at 60°C and 40°C at full and partial load, and the consumption
of the low-power modes. Actual energy consumption will depend on how the
appliance is used.
❸ Water consumption per year based on 220 standard washing cycles for standard
programme at 60°C and 40°C at full and partial load. Actual water consumption will
depend on how the appliance is used.
❹Spin-drying efficiency class Bona scale from G (least efficient) to A (most
efficient).
❺The standard 60°C programme and the standard 40°C programme are the
standard washing programmes. These programmes are suitable to clean normal
soiled cotton laundry and they are the most efficient programmes in terms of
combined energy and water consumptions for washing that type of cotton laundry.
The actual water temperature may differ from the specified cycle temperature.
Select the suitable type of detergent for the various washing temperatures to get the
best results with less water and energy consumption.
Programme setting for testing in accordance with applicable standard EN60456.
When using the test programmes, wash the specified load using the maximum spin
speed.
The actual parameters will depend on how the appliance is used, and may differ
from above table.
The noise emissions during washing/spinning are for standard washing cycle at full
load.

1111
EN
Power supply 220 - 240 V~,50 Hz (EU)
Max. current 10 A
Standard Water Pressure 0.05 MPa - 1 MPa
Model
Power Supply 220 - 240 V~,50 Hz
Washing Capacity 8 kg
Drying Capacity 5.0 kg
Dimensions (WxDxH) 595 x 565 x 850 mm
Weight 74 kg
Rated Power 2050 W
Drying Power 1350 W
152156/154079/154080/154083/154081/154082

1212
EN 2.2 Programmes
Programmes are available according to the type of laundry.
Programmes
Cotton For hard-wearing garments, heat-resistant fabrics made of
cotton or linen.
Synthetic For washing synthetic articles, for example shirts, coats,
blended fabric. When washing knitwear, detergent quantity
should be reduced due to it easily forming bubbles.
Baby Care For washing baby clothing, it cleans and rinses more
intensive to protect the baby skin.
Mix Mixed loads consisting of garments made of cotton and
synthetics.
Jeans Programme especially for denims.
Color For washing brightly coloured garments, protecting the
colours.
Quick 15’ For quickly washing a small load of slightly soiled garments
within 15 minutes.
Delicate For delicate, washable fabrics, e.g. silk, satin, synthetic
fibres or blended fabrics.
Spin Only Only spinning with selectable spin speed.
Rinse&Spin Only rinsing and spinning.
Cotton Eco To increase the washing effects, the washing time is
increased.
Sport Wear For washing active and sportswear.
Drain Only For draining off the water.
1 Hour W/D For a small load of synthetic garments or shirts up to 1 kg
(approx. 4 shirts). This programme will help you in shirt
emergencies, since the duration for washing and drying is
only 1 hour. This programme is not suitable for towels or
jeans.
5 kg W/D For washing and drying a load up to 5 kg.
Drum Clean Special programme for cleaning the drum. The drum is
sterilised at 90°C. Do not use this programme for washing
garments. Add the correct amount of bleach to increase the
cleaning effect. Use this programme according to need.

1313
EN
3. DESCRIPTION
3.1 Front View
1
2
3
4
5
6
9
8
7
1. Top cover
2. Control panel
3. Power supply cord
4. Drum
5. Service filter
6. Drain hose
7. Door
8. Detergent dispenser
9. Water supply hose
3.2 Control Panel

1414
EN 1. On/Off
Switch the product on or off.
2. Start/Pause
Press this button to start or pause the washing cycle.
3. Option
This allows you to select an additional function; it will light up when selected.
4. Programmes
Available according to the laundry type.
5. Display
The display shows the settings, estimated remaining time, options, and status messages
for your washing machine. The display will remain on during the entire cycle.
3.3 Display
A Display
Wash Time Delay Time
1:25 2h
Speed Error
100 E30
End
End
B Child Lock
C Door Lock
D Delay
E Temp.
F Dry
Note!
The line drawings are for reference only. Refer to real product as standard.
3.4 Detergent Dispenser
IPre wash detergent
II Main wash detergent
Softener
Dam-board Dam-board
Liquid detergent Powder detergent Pull out the dispenser
Caution!
Detergent only needs to be added in “compartment I” after selecting pre-washing for
washing machines with this function.

1515
EN
Programme I II Programme I II
Cotton Eco *Dry Only
Sport Wear *Synthetic
Quick 15’ *Mix
Jeans *5kg W/D
Delicate *1 Hour W/D
Color *Cotton
Baby Care
Spin Only
Rinse & Spin
Means must Means optional
Note!
• As for the clumped together or tacky detergent or additive, before they are poured
into the detergent dispenser, we suggest using some water for dilution to prevent
the inlet of the detergent dispenser from being blocked and overflowing while filling
water.
• Please choose a suitable type of detergent for the various washing temperatures to
get the best performance with less water and energy consumption.
3.5 Accessories
Transport hole
plug Supply hose cold water Supply hose hot water (optional) Drain hose support
(optional)
Owner’s manual

1616
EN 4. INSTALLATION
4.1 Installation Area
Warning!
• Stability is important to prevent the product from wandering!
• Make sure that the product should not stand on the power cord.
Before installing the washing machine, the location characterized as
follows shall be selected:
1. Rigid, dry, and level surface.
2. Avoid direct sunlight.
3. Sufficient ventilation.
4. Room temperature is above 0°C.
5. Keep far away from heat resources such as coal or gas.
4.2 Unpacking the Washing Machine
Warning!
• Packaging material (e.g. films, styrofoam) can be dangerous for
children.
• There is a risk of suffocation! Keep all packaging well away from
children.
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing. Make
sure the small triangle foam is removed with the bottom one
together. If not, lay the unit down on its side surface and then
remove the small foam from the unit bottom manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
4.2.1 Removing the Transport Bolts
Warning!
• You must remove the transport bolts from the backside before using the product.
• You will need the transport bolts again if you move the product, so make sure you
keep them in a safe place.
Please take the following steps to remove the bolts:
1. Loosen 4 bolts with a spanner and then remove them.
2. Stop the holes with the transport hole plugs.
3. Keep the transport bolts properly for future use.
4.3 Levelling the Washing Machine
Warning!
• The lock nuts on all four feet must be screwed tightly against the housing.
1. Check if the legs are closely attached to the cabinet. If not, please turn them to their
original positions and tighten the nuts.
2. Loosen the lock nut and turn the foot until it closely contacts with the floor.
3. Adjust the legs and lock them with a spanner, make sure the machine is steady.
Raise Lower
foot
Lock nut

1717
EN
4.4 Connecting the Washing Machine
4.4.1 Connecting the Water Supply Hose
Warning!
• To prevent leakage or water damage, follow the instructions in this chapter!
• Do not kink, crush, modify or sever the water inlet hose.
• For models equipped with hot water valve, connect it to a hot water tap with the
hot water supply hose. Energy consumption will decrease automatically for some
programmes.
Connect the inlet pipe as indicated. There are two ways to connect the inlet pipe.
4.4.1.1 Connection between ordinary tap and inlet hose
clamp nut
slide bushing
Loosen clamp nut
and four bolts Tighten clamp nut Press slide bushing, insert inlet hose into
connecting base
Connection finished
4.4.1.2 Connection between screw tap and inlet hose
slide bushing
Tap with threads and inlet hose Special tap for washing machine
Connect the other end of the inlet pipe to the inlet valve at the back of the product and
fasten the pipe tightly clockwise.
water Inlet valve water supply hose

1818
EN 4.4.2 Connecting the Drain Hose
Warning!
• Do not kink or protract the drain hose.
• Position the drain hose properly, otherwise damage might result of water leakage.
There are two ways to place the end of the drain hose:
1. Put it into the water trough. 2. Connect it to the branch drain pipe of
the trough.
Water
trough
Max. 100cm
Min. 60cm
Note!
If the washing machine has drain hose support, please install it as follows.
Max. 100cm
Min. 60cm
Trough
Hose Retainer
Bind
Max. 100cm
Min. 60cm
Warning!
• When installing the drain hose, fix it properly with a rope or chain.
• If the drain hose is too long, do not force it into the washing machine as it will cause
abnormal noises.

1919
EN
5. USE
5.1 Quick Start
Caution!
• Before washing, please make sure the washing machine is installed properly.
• Before washing the first time, the washing machine shall be operated one cycle of the
whole procedure without clothes as follows.
5.1.1 Before Washing
Main
wash
Softener
Prewash
Plug in Open tap Load Close door Add detergent
Note!
Detergent only needs to be added in “compartment I” after selecting pre-washing for
washing machines with this function.
5.1.2 Washing
Select
Programme Select function or default Start
Note!
• If default is selected, step 2 can be skipped.
• The ambient temperature must be 0 - 40°C. If used below 0°C, inlet valve and
draining system may be damaged due to frost.
• Check the labels and explanations of used detergent before washing. Use non-
foaming detergent suitable for machine washing only.
Check the label Take out the items out of
the pockets Knot long straps, zips or buttons

2020
EN
Put small clothes into the
pillow slip Turn easy-pilling and long- pile fabric inside out Separate clothes with different textures
Warning!
• When washing a single garment, it may easily cause great unbalance. Therefore it is
suggested to add one or two more garments to be washed together so that draining
will be done smoothly.
• Don’t wash clothes that have been in contact with kerosene, gasoline, alcohol and
other flammable materials.
5.1.2.1 Delay
Setting the Delay function:
1. Select a programme.
2. Press the (delay) button to set the time (the delay time is 0 - 24 h).
3. Press the (start/pause) button to commence the delay operation.
Select the Programme Set the time Start
Cancelling the Delay function:
Press the (delay) button until the display shows 0 hours. The button should be pressed
before the programme has started. If the programme has already started, press the
(on/off) button to reset the programme.
Caution!
• If there is any interruption in the power supply while the washing machine is operating,
a special memory stores the selected programme. After the power is restored, the
program will continue.
5.1.2.2 Temperature
Press the (temperature) button to set the temperature (Cold, 20°C, 40°C, 60°C, 90°C).
5.1.2.3 Speed
Press the (speed) button to change the spinning speed. 1000: 0-400-600-800-1000
1300: 0-400-600-800-1000-1200-1300
