Qlight S100D User manual

S100D / S125D
Thank you for purchasing Q.Light product. Please read this
manual carefully before installing this product for safe and long
use.
▪Ensuring high revolving durability by applying a special power
transmission system to minimize noise and wear which is
gained a patent.
▪Having a high tone signal sound Max. 105dB and can install at
a small place easily.
▪RPM: 120~140RPM.
▪Material: Lens-AS, Body-ABS, Reflector-thermostable ABS
▪Protection Class: IP54
▪Each model has 5 sound tones built-in. Select a suitable sound
tone for the purpose of use
▪Certificate: CE
1) S100D
▪ General Specification
Model
Voltage
Current
Bulb
Weight
Color
S100D
DC12V
1.266A
12V10W
T16x3515S
9
1.05Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
DC24V
0.766A
24V10W
T16x3515S
10
AC110V
0.187A
12V10W
T16x3515S
9
1.44Kg
AC220V
0.094A
12V10W
T16x3515S
9
S125D
DC12V
1.266A
12V10W
T16x3515S
9
1.07Kg
DC24V
0.766A
24V10W
T16x3515S
10
AC110V
0.187A
12V10W
T16x3515S
9
1.46Kg
AC220V
0.094A
12V10W
T16x3515S
9
▪S100D External View Drawing
S100D
▪S125D External View Drawing
S125D
Main Built-in
Sounds
CH
Sound Tone
DB(Max)
WS
5Warning
Sounds
ch1
ch2
ch3
ch4
ch5
Fire A-ANG Sound
Emergency WA-U Sound
Ambulance PI-PO Sound
Machinery Fault PI-PI Sound
High-Expasion Foamrelease PI~Sound
105dB
WM
5Melodies
ch1
ch2
ch3
ch4
ch5
Sweet Home
For Elise
Cuckoo Waltz
Piano Sonata
Turkish March
105dB
WA
5Alarms
ch1
ch2
ch3
ch4
ch5
Beep. intermittent
Door chime
Phone Ring sound
PI.PI.PI. short interval
Tripping bead sound
103dB
WV
3Voice Signals
Ch1
Ch2
Ch3
Voice recording 3 channels
95dB
Please kindly follow below picture and instruction.
1) Lens Removal
Remove lens①by turning it counterclockwise. and make sure
related parts(bulb etc.) on the assembling board②.
2) Bulb Change
▪Must turn off power supply and change bulb after 1 minute at
least.
▪Make sure the rated voltage and wattage of new bulb. If the
OPERATING MANUAL
Bulb Revolving Warning Light with Phone
S100D
S125D
Sound Tone Combination of Standard Product
Change Bulb

voltage of new bulb is higher than original bulb, the life of
product can be reduced and can cause damage on lens and
reflector. Therefore, please use the bulb which has the same
or lower rated voltage and wattage.
▪Bulb Removal: Press slightly the bulb downward and turn it
counterclockwise for removing.
▪Bulb Fitting: Fit new bulb into the socket by pressing it
clockwise.
Bulb removal Bulb fitting
3) Lens Assembling
Assemble the product in reverse order of separating.
Power lines and signal sound tone lines come out from the product.
Please connect them correctly after referring to below instruction.
▸Power line
▪Power line: UL1015-NO.18(0.75sq) Ⅹ2c 400mm
▪In case of product using AC voltage, connect the line without
Polarity(wire color).
▪In case of product using DC voltage, black line is negative(-).
▸Signal line
▪Signal line: UL1007-NO.22(0.3sq) 400mm
▪This product was manufactured with the structure for indoor use.
Installing in any direction is okay for indoor use.
▪Outdoor use is limited at a place where no water or very little
water percolates. Mounting also should be done only on the
vertical standing direction.
▪Mount at the place where exists low vibration, low impact, low
moisture and low dust as long as possible.
▪Please make a hole by a drill where you need to attach our
product and refer to below picture for a hole size. (Make sure
PCD from external view drawing.)
▪Fix the product by using nuts(M5-3EA) originally equipped on
mounting bolt on bottom of the product.
Indoor Outdoor
▪If using voltage is seriously higher or lower than rated voltage, it
can reduce the self-life of the product or can cause a problem on
product operating. Make sure the using voltage does not exceed
+/-5% of the rated voltage.
▪If lens or body of the product is contaminated by chemicals such
as thinner, benzene, the product can be damaged, discolored or
deformed. Please be careful.
▪Do not give strong impact to the product. It can be a reason of
wire disconnection or short circuit.
▪In case of product using AC voltage, do not allow power supply
either to common line or signal line.
Wiring Instruction
Mounting
Caution

Situation
Main reason
Solution
Non-lighting
Bulb mis-connecting
Bulb change
Feeble Lighting
&Revolving, twisted
sound tone
Supplying Voltage
Lower than Rated
Voltage
Making Sure Using
Voltage
Short Self-Life of Bulb
Supplying Voltage
Higher than Rated
Voltage
Making Sure Using
Voltage
Defect of
transformer(AC
Voltage Type)
Using the bulb over
rated capacity change
Change the rated
capacity bulb
Non Revolving
Problem with Motor
Contact Q.Light or Their
Agent
Over-volume sound
Supplying Voltage
Higher than Rated
Voltage
Making Sure Using
Voltage
Output 2 kinds of
sounds
Signal sound line short
Making Sure connection
Problem Sound tone
Selection
Switch
Contact Q.Light or Their
Agent
No sound
Problem with Horn
Contact Q.Light or Their
Agent
Wrong Wiring
Making Sure connection
Trouble shooting
Q-LIGHT CO., LTD.
http://www.qlightkr.com
E-mail : qlightk[email protected]
Overseas Marketing Team /Plant
Tel) 055-328-4082Fax)055-328-4083
178-1 Woogye-Ri, Sangdong-Myun, Kimhae-Si,
KyungNam, Korea
