DATA SHEET
PRELIMINARY
QLE8042
Dual Port 10Gbps Ethernet to PCIe
Converged Network Adapter (CNA)
High Performance
10Gbps throughput for high bandwidth data transfer•
150,000 IOPS per port deliver high I/O transfer•
rates for storage applications
Full support for TCP/IP performance enhancements•
such as jumbo frames, 802.3x flow control, 802.1p
priority service, and checksum offload
Lower Total Cost of Ownership (TCO)
Reduced hardware, cabling, power, cooling, and•
management costs through convergence of data
and storage networking
Preservation of familiar data and storage concepts•
resulting in lower training and administrative costs
Investment Protection
Works seamlessly with existing Fibre Channel (FC)•
storage
Communicates via Ethernet, the most common•
networking technology in the world
Compatible with existing FC and networking drivers•
that have been deployed in millions of existing
systems
Fibre Channel over Ethernet (FCoE) Technology. FCoE provides an
opportunity to reduce data center costs by converging data and storage
networking. Standard TCP/IP and Fibre Channel traffic can both run
on the same high speed 10Gbps Ethernet wire, resulting in cost savings
through reduced adapter, switch, cabling, power, cooling, and management
requirements. FCoE has gained rapid market traction because it delivers
excellent performance, reduces data center TCO, and protects current data
center investment.
High Performance. The QLE8042 CNA provides superior data and networking
storage performance at 10Gbps speeds, which benefits bandwidth hungry
applications. This performance also enables increased levels of server
virtualization, as multicore servers running dozens of virtual machine
OS images will need the cutting edge 10Gbps bandwidth to prevent I/O
starvation.
Lower TCO. The QLE8042 reduces data center costs through convergence.
Now, one CNA can do the work of a discrete FC Host Bus Adapter (HBA) and
Ethernet NIC. This convergence also means fewer cables, fewer switches,
less power consumption, reduced cooling, and easier management. The
QLE8042 also preserves familiar FC concepts such as WWNs, FC-IDs, LUN
masking, and zoning, thereby eliminating training costs that would be
required for a new storage technology.
Investment Protection. The QLE8042 and FCoE are designed to preserve
existing investment in Fibre Channel storage and core Ethernet switches
and routers for data networking. The QLE8042 leverages the same identical
software and driver stacks that have been deployed and battle-hardened in
millions of previous installations.
Leading CNA Vendor. QLogic has an unparalleled advantage in delivering this
new CNA technology. QLogic is the undisputed leader in both FC and iSCSI
HBAs, with years of experience providing FC and Ethernet based products.
While some competitors have expertise in either networking or storage, no
other I/O provider can match QLogic’s expertise in FC and Ethernet hardware
and software solutions.

DATA SHEET
Corporate Headquarters QLogic Corporation 26650 Aliso Viejo Parkway Aliso Viejo, CA 92656 949.389.6000 www.qlogic.com
Europe Headquarters QLogic (UK) LTD. Quatro House Lyon Way, Frimley Camberley Surrey, GU16 7ER UK [phone]
QLE8042 Dual Port 10Gbps Ethernet to PCIe Converged Network Adapter (CNA)
© 2008 QLogic Corporation. Specifications are subject to change without notice. All rights reserved worldwide. QLogic, the QLogic logo, and SANsurfer are registered trademarks of QLogic Corporation. AMD Opteron is a trademark of Advanced Micro Devices,
Inc. Red Hat is a registered trademark of Red Hat Software, Inc. Linux is a registered trademark of Linus Torvalds. SuSE is a registered trademark of Novell, Inc. Intel is a registered trademark of Intel Corporation. Windows is a registered trademark of Microsoft
Corporation. All other brand and product names are trademarks or registered trademarks of their respective owners. Information supplied by QLogic Corporation is believed to be accurate and reliable. QLogic Corporation assumes no responsibility for any errors
in this brochure. QLogic Corporation reserves the right, without notice, to make changes in product design or specifications.
PRELIMINARY
FE0158001-00 A 2
Host Bus Interface Specifications
Bus interface
PCI Express x8•
Hardware platforms
IA32 (x86); Intel64, AMD64 (x64)•
Compliance
PCI Express Base Specification •, rev. 1.0a, PCI
Express Card Electromechanical Specification ,
rev. 1.0, PCI Bus Power Management Interface
Specification , rev. 1.1
Ethernet Specifications
Throughput
10Gbps full duplex line rate•
Topology
Any 10Gb Ethernet Network•
Ethernet Frame
1500 byte or 9600 byte (Jumbo Frame)•
Compliance
IEEE: ,803.3ae (10Gb Ethernet) 802.1q (VLAN), 802.3ad •
(Link Aggregation), 802.1p (Priority Encoding), 802.3x
(Flow Control), 802.3ap (KX/KX4), 802.3ak (CX4), IEEE
1149.1 (JTAG), IPv4 Specification (RFC 791), IPv6
Specification (RFC 2460), TCP/UDP Specification (RFC
793/768), ARP Specification (RFC 826)
Fibre Channel over Ethernet (FCoE)
Specifications
Performance
150,000 IOPS per port•
Topology
Switched fabric•
Logins
Support for 512 concurrent logins and•
1024 active exchanges per port
Class of service
Class 3•
Protocols
FCP (SCSI-FCP), FC-TAPE (FCP-2)•
Compliance
SCSI-3 Fibre Channel Protocol (SCSI-FCP), Fibre •
Channel Physical and Signaling Interface (FC-PH),
Fibre Channel 2nd Generation (FC-PH-2), Third
Generation Fibre Channel Physical and Signaling
Interface (FC-PH-3), , Fibre Channel Tape (FC-TAPE)
profile, SCSI Fibre Channel Protocol-2 (FCP-2),
Second Generation FC Generic Services (FC-GS-2),
Third Generation FC Generic Services (FC-GS-3),
Fibre Channel Framing and Signaling (FC-FS)
Tools and Utilities
Management tools
SANsurfer•®FC HBA Manager (GUI and CLI)
Intel•®PROSet for Windows Device Manager
Device utilities
Utilities for programming boot code; Linux•®
scripting tools
Boot support
BIOS•
APIs
SNIA HBA API V2, SMI-S, and FDMI•
NDIS 5.•
x , NDIX 6. x , and WMI
Operating systems
Windows•®2003, Windows 2008, Red Hat®
Linux®5, SuSE®Linux 10
Physical Specifications
Ports
Dual 10Gbps Ethernet•
Connections
Small form factor pluggable (SFP+)•
Form factor
Standard height PCI Express card: 24.13 cm ו
11.12 cm (9.50 in. × 4.376 in.)
Environment and Equipment
Specifications
Airflow
100 LFM•
Temperature
Operating: 0°C/32°F to 55°C/131°F•
Storage: -20°C/-4°F to 70°C/158°F•
Humidity
Relative (non-condensing): 10% to 90%•
Storage: 5% to 95%•
Power dissipation
22.0W (nominal, QLE8042-SR)•
Cable Distances
Cable Type Optical Copper
Description SR Twinax
Distance 300m 10m
Agency Approvals—Product Safety
US/Canada
UL60950-1; CSA C22.2 60950-1•
Europe
EN60950-1:2001+A11; EN60825-•
1:1994+A1+A2; EN60825-2:2004
Agency Approvals—EMI and EMC
US/Canada
FCC CFR Title 47, Part 15, Subpart B:2006 Class•
A; ICES-003:2004 Class A
Europe
EN55022:2006 Class A; EN55024:1998;•
EN61000-3-2: 2006; EN61000-3-3:1995
Asia/Pacific
VCCI:2007-04 Class A (Japan), MIC (Korea), AS/•
NZS; CISPR 22:2006 Class A (Australia/NZ), BSMI
CNS 13438:2006 Class A (Taiwan)
Ordering Information
QLE8042-CK•
Ships without transceivers (twinax cable sold–
separately)
QLE8042-SR-CK•
Ships with two SR optical transceivers–
All -CK parts ship in an individually packed box with
a CD and Quick Start Guide.
