Qls QA-360 User manual

QA-360User sGuideQLS-HiFi
1
Contents
1.Overview 3
1.1.ProductIntroduction 3
1.2.AudioFormat 3
1.3.ProductFeature 4
2.FunctionalInterface 5
2.1.PlayerLayout 5
2.2.InterfaceLayout 7
3.OperatingInstructions 9
3.1.Startup 9
3.2.FileBrowsing 9
3.3.MusicPlaying 9
3.4.CUEOperation 9
3.5.Favorites10
3.6.SongDeleting 10
3.7.VolumeOperation 10
3.8.KeyLock 11
4.FunctionSettings 11
4.1.PlayingMode 11
4.2.PlayingRange 11
4.3.MemoryPlay/AutoPlay 12
4.4.GapBetweenTracks 12
4.5.TrackNameRolling 12
4.6.DigitalOutput 12
4.7.FilteringMode 12
4.8.DSDFiltering 13
4.9.VolumeLock 13
4.10.VolumeIntensity 13

QA-360User sGuideQLS-HiFi
2
4.11.VolumeProtection 13
4.12.VolumeBalance 13
4.13.CursorColor 13
4.14.MainColor 13
4.15.InterfaceColor 13
4.16.InterfaceStyle 14
4.17.DisplayBrightness 14
4.18.AutomaticOff-screen 14
4.19.AutomaticShutdown 14
4.20.KeyReactionSpeed 14
4.21.ChargingSwitch 15
4.22.Language 15
4.23.SystemInformation 15
4.24.FactorySettingsReset 15
5.FirmwareUpdate 16
AppendixI.ProductWarrantyCard 17
Attention: Thecopyright of thisdocument belongstoour
company,andwereservethefinalrightofinterpretation.
As forthealterationofproductdesignandspecification,
furthernotificationwill notbeissued,pleasereferto
ourwebsite.

QA-360User sGuideQLS-HiFi
3
1.Overview
1.1.Product Introduction
QA360isahigh-fidelitydigitalaudioplayerwith
lossless audiofilesasthesource andtheSDcardas the
storagemedium. The player integrates DACdecoding and
headphoneamplifiercircuit withthebuilt-in
large-capacityrechargeablelithiumpolymerbattery,
whichimprovesportability. Theplayerisdesignedwith
coaxialoutputandopticaloutput, actingasanabsolute
digitalsound source.Connectedwith differentDAC from
theoutside,youcanenjoy different musicstyles.Apart
fromthat,it alsohas analogsignaloutput whichcanbe
directlyconnectedtoamplifierorpreamp.
1.2. Audio Format
lWAV:16/24bit,44.1~192KHz;
lAIFF:16/24bit,44.1~192KHz;
lFLAC:16/24bit,44.1~48KHz,compression levels 0~8;
lAPE:16bit,44.1KHz,compression levels:fastand
normal;
lALAC:16bit,44.1KHz;
lMP3:16bit,44.1~48KHz,96kbps~320kbps,CBR/VBR/ABR
encoding;
lDIFF:DoPv1.0,DSD64encoding,1bit,2-channelstereo,
Samplingfrequency:2.8224MHz;
lDSF:DoPv1.0,DSD64encoding,1bit,2-channelstereo,
Samplingfrequency:2.8224MHz;

QA-360User sGuideQLS-HiFi
4
lSACD:SACD-ISOmirror imagefiles, DoPv1.0,DSD64
encoding,1bit,2-channelstereo,Sampling frequency:
2.8224MHz;
lCUE:WAV/AIFF/FLAC/APE/ALACcanberelatedtoCUE,
ANSI/UNICODE/UTF-8encoding.
1.3.Product Feature
lSD cardwasusedasthestoragemedium,supportive
of SD/SDHC/SDXC,andthemax capacityis128G;
lThereare variousoutputpatterns such as digital
outputandanalogoutput;
lItisinfavorofDSDharddecodingand SACDISO
directplaying;
lItis in favorofseveral playingmodes andplaying
filesindifferentfolders;
lIt is in favorofsimplifiedChinese,traditional
Chinese,andEnglishversions.
lIt isinfavorofautomaticstartupplayingand
memoryplaying.

QA-360User sGuideQLS-HiFi
5
2.FunctionalInterface
2.1.Player Layout
Mark
Definition Description1 Description 2
Description3
A SD card slotStorage Medium
B Navigation key
Cursor up Previous
track
Long press for
quick song
switching
C Navigation key
Page down Modify
settings Long press for fast forward
D Navigation key
Enter Play/Pause Long press for Favorites
operation

QA-360User sGuideQLS-HiFi
6
E Navigation key
Page up Modify
settings Long press for fast back
F Navigation key
Cursor down Next track Long press for quick song
switching
G 3.5 Headphone
jack Headphone signal output
H 3.5 Line/Optical
jack
Line signal
output Optical signal output
I 3.5 Coaxial
jack Coaxial signal output
J 3.5 Power jack
Power input
K Indicator Charging status
indication
L Power switch Startup and
shutdown
M Back key Pages switching
Long press
for song
deletion
N Locking key Key locking
O Setting key Enter the
setting page Exit setting page
Long pressto
recover the
default
P Volume key Decrease the
volume
Long pressto
the next
track
Q 2.4-inch LCD
screen Show information
R Volume key Increase the
volume
Long pressto
the previous
track
S Remote control extension wire
jack
Remote-control
extension input

QA-360User sGuideQLS-HiFi
7
2.2.Interface Layout

QA-360User sGuideQLS-HiFi
8
Mark
Interface Definition
aCurrentplayingrange
bCurrentplayingmode
cAudioformat
dProgressbar
eFoldername
fCurrentelapsedtimeoftrack
gFolderindex/totalnumberof folders
hTrackindex/totalnumberoftracks
iTotaltimeofthetrack
jPlay/Pause
kTrackname
lSamplingrate(DSD64indicates2.8224MHz)
mSamplingdigits(Bitratefor MP3)
nBatterycapacity
oVolume

QA-360User sGuideQLS-HiFi
9
3.Operating Instructions
3.1.Startup
Turn on thepowerbypushingthe switchupwards onthe
rightsideofthe player,and turn offthe power
downwards.
3.2.Files Browsing
Theplayerconsistsofthe maininterface,folderlist,
tracklist,CUElist,favoriteslistandplaying
interface. TheBACKkeycanbeusedtoswitchinterfaces.
TheUP/DOWNkeyscanbeused tomovethecursor. The
LEFT/RIGHTkeys canbe usedtoturnthepages upand down.
TheENTERkeycanbeusedtoenterthepageofthenext
level.
3.3.Music Playing
Oncethetargetsongis selected,youcanplayasongby
pressing theENTERkey.Ontheplayinginterface,youcan
pressENTERkeytoplayorpause,pressUP/DOWNkeysto
switch songs,andlongpressLEFT/RIGHTkeysfor fast
forwardandfastback.
3.4.CUEOperation
SelecttheCUEfile,enter the list,andselectsongsto
play.The CUEmodeissupportiveofsuchplaying modes
as loop,random, single loop,playing once andreverse.
Thecurrent playingscopeis limitedtothecurrent CUE

QA-360User sGuideQLS-HiFi
10
listwiththeplayinginterfaceshowing"album".
3.5.Favorites
Howtoaddanddeletesongsfromthefavorites？
(1).Inthefolderlist,tracklistandplayinginterface,
if youpresstheENTERkeyfor1to2seconds, thenit
will show"Addtofavorites",select"OK" toaddthe
selectedfolderorsong.The maximumcapacityis99.
(2).In thefavoriteslist,ifyoupressENTERkeyfor1
to 2seconds, itwillshow"Deletefromfavorites",
select"OK"todeletesong.
Note: TheFavoritesissupportiveofsuchplayingmodes
as loop,random, single loop,playing once andreverse.
Theplayingscopeislimitedtothecurrentfavoritelist
withtheplayinginterfaceshowing"Favorites".
3.6.Song Deleting
In thelist ofsongs orplayinginterface,if youselect
thetrack youwanttodeleteandpress theBACKkey for
1to2seconds,itwillshow"DeleteSong",select"OK"
to delete.
Note: Thesongis deletedpermanentlyfrom theSD card
Pleasetakecautionasitis unrecoverable.
3.7.Volume Operation
Momentarypress orlongpress of thevolume keycanadjust
thevolumewithintherange of0to150cells.You can
setvolumeprotectionandleft-and-rightchannels

QA-360User sGuideQLS-HiFi
11
balance,andthevolumeisunadjustableunderthelocking
status.
3.8.KeyLock
In orderto preventpushingthekeysby mistake,you can
pushtheLOCKkey upwardstolocktheplayer, vice versa.
Note: In ordertorealizeblindoperation,whenthekeys
arelocked, youcan adjust thevolumebymomentarily
pressing thevolumekeys, andswitchingsongsby long
pressing thevolumekeys. (Note:thisisunder the
non-volume-adjustingstate).
4.Function Settings
4.1.Playing Mode
TheplayingmodeincludesLOOP, RANDOM,SINGLELOOP,ONCE,
andREVERSE.
4.2.Playing Range
ALL : AllsongsontheSDcardcanbeeffectivefiles.
FOLDER: Onlythesongs underthecurrent foldercan be
played,andyou canonlyselectthesongs underthis
folderaswell.
Note: Theplayeris supportive of 2-levelcatalogue. In
ordertolocatesongsquickly, it issuggested that you
namethemasterfolderwiththe singer name,and name the
subsidiaryfolderswiththe albumsof this singer.Each
subsidiaryfoldershouldonly storeonealbum.

QA-360User sGuideQLS-HiFi
12
4.3.Memory Play/Auto Play
OFF : Turnoffthememorymode,andthe masterinterface
willshowafterstartup.
PAUSE: Turn onthe memorymode,andtheplayinginterface
willshowafterstartup,readyfortheusertoplay.
AUTO : Turn on thememorymode,the playinginterface will
showafterstartup,andsongsinmemorywill beplayed.
4.4.GapBetween Tracks
Youcansetthetimegapbetweentracksas0,500,1000,
1500and2000ms.
4.5.Track Name Rolling
Youcan settherollingfrequency of filenames as"static,
onesecond,twoseconds,and threeseconds".
4.6.Digital Output
Youcan setcoaxial or fiberoptical digitaloutputon
oroff. If it is seldomused,you mayturnitofftosave
power.
4.7.Filtering Mode
Theslowdescentor roll-offofdigitalfiltering canbe
selectedfromthemenu,whichwillfiltertheout-of-band
noisefarawayhigherthantheaudiofrequency,releasing
twosoundstyles.

QA-360User sGuideQLS-HiFi
13
4.8.DSDFiltering
Youcan decide whetherthe DSDsignalwillgothrough the
digitalfilterbyselectinginthe menuwithtwoDSD sound
styles.
4.9.Volume Lock
ThevolumecanbesetasONorOFF.
4.10.Volume Intensity
Thecurrent volume intensitycan be setranging from 0
to 150cells.
4.11.Volume Protection
Themaxadjustablevolumecan besetforprotection.
4.12.Volume Balance
Theleftand rightchannelsarerespectivelyadjustable
with10cellsavailableand5dBmaximumattenuation.
4.13.Cursor Color
Thecoloroftheselectedfontcanbeset.
4.14.Main Color
Thecolorofthemainfontcanbeset.
4.15.Interface Color
Thereare 27kinds ofcolorscanbesetfor theinterface.

QA-360User sGuideQLS-HiFi
14
4.16.Interface Style
Thereare 23kinds ofstylescanbesetfor theinterface.
4.17.DisplayBrightness
Thebrightnessofthe LCDdisplay canbeset as three
levels-10,20and30.
4.18.Automatic Off-screen
TheAutomaticoff-screentimeoptionsare "No,10s,20s,
and30s".
It willsavepowerand improve soundqualitytoturn off
thedisplay.
4.19.Automatic shutdown
Theautomatic shutdowntimecanbesetas30, 60,90,120
minutes. ItwillfunctionafteryoupresstheSETTINGkey
andexit. Areminder will popupbefore 10sof the
automaticshutdown,andduringthelast5secondsthe
player willbemuted.Theplayer willbeshutdownwith
thetimercountingdown.
4.20.Key ReactionSpeed
Thekeyreactionspeedmainly referstotheprocessing
speedoflong press,suchas thespeedofmoving the
cursorupwardsanddownwards, FF/FB,etc.
Optionsare10,20,30,40,50,60,70,80,90,and100.

QA-360User sGuideQLS-HiFi
15
4.21.Charging Switch
ThechargingswitchwillcontroltheON/OFFcharging
statusof battery. If youoftenuseanexternalpower,
pleaseselectOFFtoextendthebatterylife.
4.22.Language
TheGBKencodingfont library isadoptedsupportiveof
20,000national wordswiththreelanguages-Simplified
Chinese,traditionalChinese andEnglish.
4.23.System Information
Enterthismenu tocheck thecurrentsysteminformation:
lModel：QA360
lVersion：APP-V1.0
lData:2014.06.01
lDesignBy ：QLS-HiFi
lRunTimers：10：00：00
lShutdown：--：--：--
4.24.Factory Settings Reset
IntheSettingsmenu,youcanpresstheSETTINGkeyfor
1to2secondstoresetthe factorysettings,andremove
allthesongsinFavorites.

QA-360User sGuideQLS-HiFi
16
5.Firmware Update
Theapplicationsandfontlibrarycan beupdated in the
followingsteps:
(1)Copytheupdatedfileto theSDcard.
(2)InserttheSDcardinto theplayer,longpressthe
LEFTkeyand turn on thepowerswitch, thus,the updating
modeisentered.
(3)Selecttheupdatedfileintheupdatinglistandpress
theENTER keytostart updating,and restartthe power
aftercompletion.
Pleasevisitourwebsite http://en.qlshifi.com forthe
latestupdatedfiles.

QA-360User sGuideQLS-HiFi
17
Appendix I: ProductWarranty Card
Please fill thisformcarefully andsendit backtous
alongwiththedamagedproduct.
ProductName QA360Digital
AudioPlayer Serial Number
PurchasingDate
(DD-MM-YY)
UserName ZipCode
MobileNumber Tel
Shipping Address
Feedbackof
Abnormal
Situation
CauseAnalysis
andSolution
(ThisPartshouldbe filled by the
manufacturer)
Remarks
ShenZhenQLSElectronicTechnologyCo.,Ltd(QLS-HiFi)
Contact:ChenXueQian(Clark)
E-mail :[e-mail]
