QOLSYS IQ PANEL User manual

IQ Hubv1.1
All Rights Reserved
IQ Hub User Manual
Qolsys, Inc.

IQ Hub v1.0
Contents
QOLSYS, INC.CONTENTS.......................................................................................................................................... 1
CONTENTS................................................................................................................................................................... 2
REVISION HISTORY................................................................................................................................................... 2
1FOREWORD............................................................................................................................................................. 3
1.1 COPYRIGHT NOTICE ........................................................................................................................................................ 3
1.2 NOTES ............................................................................................................................................................................. 3
1.3 STATEMENT..................................................................................................................................................................... 4
1.4 DISCLAIMER.................................................................................................................................................................... 4
1.5 LIMITATION OF LIABILITY/NON-WARRANTY.................................................................................................................... 4
1.6 SAFETY INSTRUCTIONS.................................................................................................................................................... 4
1.7 PRECAUTIONS ................................................................................................................................................................. 5
1.8 SAFETY INSTRUCTIONS FOR POWER CABLES AND ACCESSORIES..................................................................................... 6
1.9 WARNINGS,CAUTIONS AND NOTES................................................................................................................................. 7
1.10 PRODUCT USAGE ENVIRONMENT............................................................................................................................................ 7
2OVERVIEW .............................................................................................................................................................. 9
2.1 INTRODUCTION................................................................................................................................................................ 9
2.2 ORDERING INFORMATION.............................................................................................................................................. 10
3IQ HUB HARDWARE INSTRUCTIONS ...................................................................................................................... 11
3.1 PRODUCT APPEARANCE................................................................................................................................................. 11
3.2 SPECIFICATIONS ............................................................................................................................................................ 12
3.3 INTERFACE INSTRUCTIONS ............................................................................................................................................ 13
3.4 DIMENSION ................................................................................................................................................................... 14
3.5 POWER/SLEEP/WAKE BUTTON ...................................................................................................................................... 14
3.6 INTERFACE DESCRIPTION .............................................................................................................................................. 15
3.6.1 MIC......................................................................................................................................................................... 15
3.6.2 WIFI and BT ........................................................................................................................................................... 15
3.6.3 Z-wave..................................................................................................................................................................... 15
3.6.4 LTE (FCC ID: XMR201807EG91NA IC:10224A-2018EG91NA)....................................................................... 15
3.6.5 PowerG (FCC ID: WP3PGMODEMLP IC:1467C-PGMODEMLP).................................................................. 15
3.6.6 Speaker.................................................................................................................................................................... 15
3.6.7 Buzzer ..................................................................................................................................................................... 15
3.6.8 Gas Gauge .............................................................................................................................................................. 15
3.6.9 Front Camera.......................................................................................................................................................... 15
3.6.10 RTC......................................................................................................................................................................... 15
3.7 PACKING LIST................................................................................................................................................................ 16

IQ Hub v1.0
4SOFTWARE INSTRUCTIONS.................................................................................................................................... 17
4.1 BRIEF INTRODUCTION ................................................................................................................................................... 17
5SAFETY INSTRUCTION ........................................................................................................................................... 18

IQ Hub v1.1
2/ 23
Revision History
No. Version Description Date
1 v1.0 First release 2019/03/08
2 V1.1 2nd edition 2019/12/05

IQ Hub v1.1
3/ 23
1Foreword
1.1Copyright Notice
While all information contained herein have been carefully checked to assure its accuracy in
technical details and printing, Qolsys, Inc. assumes no responsibility resulting from any error or
features of this manual, or from improper uses of this manual or the software. Please contact our
technical department for relevant operation solutions if there is any problem that cannot be solved
according to this manual.
Qolsys, Inc. reserves all rights of this manual, including the right to change the content, form,
product features, and specifications contained herein at any time without prior notice.
The trademarks and registered trademarks in this manual are properties of their respective owners.
No part of this manual may be copied, reproduced, translated or sold. No changes or other
purposes are permitted without the prior written consent of Qolsys, Inc.
Qolsys, Inc. reserves the right of all publicly-released copies of this manual.
1.2Notes
Applicable notes are listed in the following table:
Sign Notice Type Description
Notice Important information and regulations
Caution Caution for latent damage to system or harm to personnel

IQ Hub v1.1
4/ 23
1.3Statement
It is recommended to read and comply with this manual before operating IQ Hub which provides
important guidance and helps decreasing the danger of injury, electric shock, fire, or any damage
to the device.
1.4Disclaimer
Qolsys, Inc. assumes no legal liability of accidents resulting from failure of conforming to the
safety instructions.
1.5Limitation of Liability/Non-warranty
For direct or indirect damage to this device or other devices of Qolsys, Inc. caused by failure of
conforming to this manual or the safety instructions on device label, Qolsys, Inc. assumes neither
warranty nor legal liability even if the device is still under warranty.
1.6Safety Instructions
Keep and comply with all operation instructions, warnings, and information. Pay attention to
warnings on this device. Please read the following precautions so as to decrease the danger of
injury, electric shock, fire, or any damage to the device.

IQ Hub v1.1
5/ 23
1.7Precautions
Pay attention to the product labels/safety instructions printed on silk screens.Do not try repairing
this product unless declared in this manual.Keep away from heat source, such as heater, heat
dissipater, or engine casing. Do not insert other items into the slot (if any) of this device. Keep the
ventilation slot ventilated for cooling.System fault may arise if other items are inserted into this
device.Installation: ensure correct installation according to instructions from the manufacturer
with recommended installation tools.
Ensure ventilation and smoothness according to relevant ventilation standard.

IQ Hub v1.1
6/ 23
1.8Safety Instructions for Power Cables and Accessories
Proper power source only
Start only with power source that satisfies voltage label and the voltage necessary according to
this manual. Please contact technical support personnel of Qolsys, Inc. for any uncertainty about
the requirements of necessary power source.
Power adapter Spec.
Model: SW-120100
INPUT:100-240V~50/60Hz 0.68A Max
OUTPUT: DC12.0V,1000mA
MADE IN CHINA BY SURE-POWER
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
MAKE SURE THE MECHINE IS POWER-OFF BEFORE TAKE OUT BATTERIES
Place cables properly:
Do not place cables at any place with extrusion danger.
Cleaning Instructions
Please power off before cleaning the device.
Do not use spray detergent.
Clean with a damp cloth.
Do not try cleaning exposed electronic components unless with a dust collector.
Support for special fault: Power off and contact technical support personnel of Vantron in case of
the following faults:
The device is damaged.
The temperature is excessively high.

IQ Hub v1.1
7/ 23
Fault is still not solved after the operation according to the manual.
1.9 Warnings, Cautions and Notes
Warning! Warnings indicate conditions, which if not observed, can cause personal injury!
Caution! Cautions are included to help you avoid damaging hardware or losing data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to
recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type
recommended by the manufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.
1.10 Product Usage Environment
The usage is attached on the wall
When attached on the wall.
First, Screw the wall bracket on the wall.
Wall bracket

IQ Hub v1.1
8/ 23
Second. Slide the device onto the wall bracket
device attached on the wall

IQ Hub v1.1
9/ 23
2Overview
2.1Introduction
Thank you for choosing Qolsys, Inc.. It is our commitment to provide our valued customers with
the embedded devices equipped with the state-of-the-art technology and the best product services.
IQ Hub enables the interaction between operators/users and applications, connecting industrial
control products such as wireless, transducer, battery inside, storage, etc. IQ Hub adopts a display
for displaying and input units such as touch screen, keyboard,audio, kind of sensors etc. for
writing working parameters or inputting operation commands. As a digital device for realizing
information interaction between human and machine, IQ Hub is composed of hardware and
software. Based on its ample function interfaces and powerful user operational interface, it is very
suitable for control units such as medical device, intelligent transportation, industrial field, etc.
Qolsys, Inc. products are based on the most advanced ARM, Rockchip processors and have
low-power consumption and high integration. The products are designed for applications such as
industrials, medicals, and transportations etc.

IQ Hub v1.1
10/ 23
2.2Ordering Information
CPA-G1A-UNA4
7’ TFT LCD
1024*600
RK-3368H, Octa-core 1.5GHz
Speakerand MIC
3.7V/2600mAh battery
WIFI/BT
Z-wave
LTE-1
PowerG
5M Camera

IQ Hub v1.1
11/ 23
3IQ Hub Hardware Instructions
3.1Product Appearance
FrontView
Back View

IQ Hub v1.1
12/ 23
3.2Specifications
CPU Processor RK-3368H , ARM Octa-core Cortex-A53,
Quad Core CPU,1.5GHz
Memory RAM 2GB LPDDR3
Flash 16GB EMMC Flash
Display
LCD 7" TFT LCD
Resolution 1024*600 24bit Color
Display Colors 16.7M
Brightness 300cd/m2
View Angle 85U/85D, 85L/85R
Touch Screen Cap-touch, multi-point
Supported
format
Audio MP3, 3GPP, WAV
Video MP4, 3GPP
Picture BMP, GIF, JPEG, PNG
Interface
Wireless 1xwifi 802.11a/b/g/n/ac,
1xBluetooth4.2
1x Z-wave
1x LTE
1x PowerG
(above all with inner FPC antenna)
Internal Audio Internal Speaker, Buzzer
Internal MIC
RTC Supported
10-85%RH
(Non-Condensation),
operating and storage
Supported
2G, 9-26Hz (10 times
in X,Y,Z directions)
1x5M Front Camera(Fixed Focus)
LED Bi-color LED (Green and Red)
Software OS Android 7.1+
Power Battery 3.7V, 2600mAh

IQ Hub v1.1
13/ 23
DC Power Supply 12V,1.0A
Mechanical Dimensions 196.4x155x25.6mm
Weight 0.65 Kg
Environment
Condition
Temperature Operating Temperature: 0℃~ +40℃
Storage:-30℃~ +70℃
Humidity 10-85%RH(Non-
Condensation), operating
and storage
3.3Interface Instructions
Front View
Front Camera
MIC
Bi-color LED
Speaker

IQ Hub v1.1
14/ 23
Back View
3.4Dimension
Whole device Size: 196.4x155x25.6mm
3.5Power/Sleep/Wake Button
Power/Sleep/Wake Button
When you are not using the panel, you can turn off the display by press button
Lock IQ Hub
Press the Power/Sleep/Wake button
Unlock IQ Hub
Press the Power/Sleep/Wake button to wake from sleep, then drag the slider.
Turn IQ Hub on from power-off
Press and hold the Power/Sleep/Wake button until logo appears.
Never apply excessive pressure to a button, because this may cause unexpecteddamage
that is not covered under the warranty
IQ Hub cannot be turned off by pressing the button
DC Jack
Power/Sleep/
Wake button
Buzzer

IQ Hub v1.1
15/ 23
3.6Interface Description
3.6.1 MIC
Internal MIC with outstanding sensitivity and high SNR makesit very suitable for recording
while suppressing the environment noise.
3.6.2 WIFI and BT
The IQ Hub supports 802.11 a/b/g/n/ac WiFi and BT 4.2. With a good performance internal
antenna, both WIFI and BT can achieve better connectivity.
3.6.3 Z-wave
The IQ Hub has the function of Z-wave (Fre: 908.4MHz-916MHz) connectivety so we can use
it in a lot of aspects such as access control, appliance control, AV control, building automation,
energy management, lighting,security, and sensor networks for the “Internet of Things”.
3.6.4 LTE (FCC ID: XMR201807EG91NA IC:10224A-2018EG91NA)
The IQ Hub supports LTE Cat 1 function, delivering M2M-optmized speeds of 10Mbps
downlink and 5Mbps uplink. And it features ultra-low power consumption which can extend
the battery lifecycle without DC adapter plugging in.
3.6.5 PowerG (FCC ID: WP3PGMODEMLP IC:1467C-PGMODEMLP)
RF Card, 912.75 - 919.106MHz, 56mm x 24.6mm
3.6.6 Speaker
IQ Hub has an internal 1 watt speaker
3.6.7 Buzzer
There is a high SPL buzzer in IQ Hub. It features high sound when turned on
3.6.8 Gas Gauge
A gas gauge is used to monitor the capacity of the li-polymer battery so we can figure out the
status of it precisely and immediately
3.6.9 Front Camera
IQ Hub has the ability to take beautiful photo and record the high resolution video.
3.6.10 RTC
IQ Hub has internal RTC so the system time can keep a long time if we didn’t turn it on.

IQ Hub v1.1
16/ 23
3.7Packing List
No Part Description Quantity Remark
1 CPA-G1A-UNA4 1 PCS Power adapter
Wall mount bracket

IQ Hub v1.1
17/ 23
4Software Instructions
4.1Brief Introduction
IQ Hub has been pre-loaded with Android image, so that the system can run Androidtool to
flash the system image

IQ Hub v1.1
18/ 23
5Safety Instruction
This section provides warnings that precede potentially dangerous procedures throughout this manual.
Instructions contained in the warnings must be followed during all phases of operation, service, and repair
of this equipment. You should also employ all other safety precautions necessary for the operation of the
equipment in your operating environment. If you are not sure about the precautions applicable to your
operating environment, please contact your company’s safety administrator. For basic information you
may also refer to the safety precautions per IEC704-1 listed below although Qolsys, Inc. disclaims all
responsibility for the accuracy of any statements contained therein and its applicability for your specific
environment. Failure to comply with these precautions or with specific warnings elsewhere in this manual
could result in personal injury or damage to the equipment.
Qolsys, Inc. intends to provide all necessary information to install and handle the IQ Hub in this manual.
Because of the complexity of this product and its various uses, we do not guarantee that the given
information is complete. If you need additional information, contact your Qolsys, Inc. representative.
The product has been designed to meet the standard industrial safety requirements. It must not be used
except in its specific area as specified in product specification.
Only personnel trained by Qolsys, Inc. or persons qualified in electronics or electrical engineering is
authorized to install service or maintain the product. The information given in this manual is meant to
complete the knowledge of a specialist and must not be used as replacement for qualified personnel.
Operating personnel must not remove equipment covers. Only factory authorized service personnel or
other qualified service personnel may remove equipment covers for internal subassembly or component
replacement or any internal adjustment.
Do not install substitute parts or perform any unauthorized modification of the equipment or the warranty
may be voided. Contact your local Qolsys, Inc. representative for service and repair to make sure that all
safety features are maintained.
Safety Precautions per IEC704-1
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid
or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily
accessible.
