Qomo Infrared Interactive Whiteboard User manual


1

InfraredInteractiveWhiteboard
UserManual

Contents
Foreword .................................................................................................. 2
SystemRequirement ................................................................................ 3
ProductIntroduction ................................................................................ 4
MountingGuidance .................................................................................. 5
Calibration ................................................................................................ 7
WhiteboardCalibration ......................................................................... 7
HotKeyCalibration ................................................................................ 9
Hints&Tips.......................................................................................... 12
WhiteboardUse...................................................................................... 13
TroubleShooting .................................................................................... 14
Specification ........................................................................................... 15
ElectronicFeature:............................................................................... 16
FCCStatement ........................................................................................ 16


2


Foreword
Don’texposetheproductintherainorhumiditytoreducefireriskandelectric
shock.
Keepwhiteboardawayfromfireandelectricattackandavoidlong‐timesun
exposure.
Theproductnetweightisasheavyas15kilos.Pleaseuseexpansionscrewfor
stablefixationtoensurethesafety.
Don’tstareatthelightfromprojectorforalongtime,especiallyforthechildren.
ThismanualisonlyavailableforQOMOIRinteractivewhiteboard.
PlasticpensorQpenoptionalprovidedbyQOMOareavailabletousewith
whiteboard.
Theproductadoptsinfraredpositioningtechnology.Keepthewhiteboardaway
fromexternalhardobjects’squeezingtoavoiddeformation.
Makesurewhiteboardcableiswellconnectedwithcomputer.It’sbettertohidethe
USBcablestoavoidpulling.
Pleaseusetheextensioncablesinthebox.Othercablesmaynotmatchwiththe
product.
Donotscratchthewhiteboardsurfaceordrill&pinonthewhiteboard.
PleaserefertosoftwareUserManualforsoftwareusingintroduction.Norelevant
descriptioninthismanual.


3


SystemRequirement
TheLowestHardwareRequirement:
CPU:1.0GHz×86
Memory:256Morabove
Displaycard:support256colors
Harddisk:1G
Supportresolutions:800×600,1024×768,1280×1024
USB1.1port

ConfigurationRecommended:
CPU:2.0GHz×86
Memory:512Morabove
Displaycard:support256colors
Harddisk:2G
Supportresolutions:1024×768,1280×1024
USB2.0port
OperationSystem:MicrosoftWindowsXP/7/8.1/10(32bitor64bit)














4

ProductIntroduction
QOMO’sInteractiveWhiteboardusesinfraredtechnology.Workingseamlesslywitha
projectorandcomputer,theQOMOInteractiveWhiteboardprovidesmore
convenient,interactiveandeffectivepresentations.Perfectforschoolauditoriums,
conferencerooms,tradeshows,symposiumsandlecturehalls.Userscanwriteon
thescreenusingtheincludedpens,wandortheuser’sfinger.

Writing:Write,drawandperformmousefunctionswithyourfinger.The
Whiteboarddisplaysyourpenmanshipinstantaneously.
Annotating:Theusercanoperateandannotateoveranycomputerapplications,
orsavenotesdirectlyintoFlow!WorksProSoftware,includingPowerPoint,Word,
Excel,MEPGJPEG,AVIandetc.
TouchSystem:QOMOInteractiveWhiteboardissensitivetotouchspeedandcan
beusedasahigh‐resolutioninteractivewhiteboard.
TouchRecognition:Canrecognizetouchofasingle‐finger,certaingesture,
right‐click,left‐clickanddoubleclick.
HotKeys:Hotkeyslocatedontheside(s)oftheboardsprovidingquickaccessto
frequentlyusedkeys.
Qpencustomize:QOMOwhiteboardsoftwaresupportQpenfunctionscustomize.
Allthebuttonsfunctionsonthepencanbedefinedinyourfavor.
IntelligentPen‐tray:itsupportsintelligentpen‐tray,fourcolorpensoption(blue,
greenandblack)
FreeDriveMode:HIDstandarddesign,freedrivemode.
EnergySaving:Powerconsumptionlessthan0.5Wandworkswithoutexternal
powersupply.



5

MountingGuidance
HardwareMounting




Wall


6

1. Setfourholesonthewallbasedonindicatedwhiteboardsize;(Holesize:
ø=12mm，Height=60mm)
2. Securetheexpansionbolts(M8*60mm)intothefourholesandusenutsto
tightenfirmlyintowall;(Keepnuts5mmwithSpringWasher)
3. AligntheWall‐mountingBracketsontothebolts;makesuretheWall‐mounting
BracketholesshouldbefixedbetweentheSpringWasherandandnuts.
4. Checkandscrewthenuts.
InteractiveSystemConstruction
1. Makesurethewhiteboardhasbeenwellfixedbeforeinteractivesystem
construction.
2. Adjustthecorrespondingpositionbetweenprojectorandwhiteboardsothatthe
entireimageprojectediswithinthewhiteboardwritingarea.
3. ConnecttheUSBcableintothewhiteboardUSBport.MakesuretousetheUSB
cableintheboxinsteadofothers.
4. ConnecttheotherendofUSBcablecomputerUSBinterface.
5. Connectcomputerwithprojector.


7


Calibration
WhiteboardCalibration
1．Flow!WorksServerProappearsatthelowerrightoftaskbarafterdrive
installation(asfigure1).Left‐clickFlow!WorksServerProandproceedtomain
driveinterface(asfigure2).

(Figure1)


8


(Figure2)

2.Click“Calibrate”buttontopopupcalibrationinterface(asfigure3);Clickand
holdthecenterofthecross.Completethecalibrationprocessasinstructed.

(Figure3)
3.Confirmationinterfacepopsupafterpositioning.Click“Yes”afterit
completes(asfigure4)


9


(Figure4)
HotKeyCalibration
Flow!WorksProserverofferstwokindsofhotkeyscalibration,either12keys
calibrationtogetherorseparatelyisaccepted.

Calibrationtogether

1. Click“HotkeySettings”buttontoenterintothehotkeycalibrationwindow
(asfigure5).


10


(Figure5)
2. Choose“CalibrateAltogether”andclick“Calibrate”buttontoenterinto
hotkeycalibrationinterface.Tapcorrespondingpositionaccordingtothered
arrow’spoint(asfigure6).

(Figure6)



11

3. Hotkeycalibrationinrealenvironmentreference(asfigure7).

(Figure7)
4. Click“Yes”tosavewhenconfirmationwindowpopsupafteritcompletes(as
figure8).

(Figure8)
CalibrateSeparately
1. Choose“CalibrateSeparately”andclickeverysingle“Calibrate”buttonback
ofthehotkeys(asfigure9).


12


(Figure9)

2. Everysinglehotkeycalibrationreference(asfigure10).

(Figure10)
Hints&Tips
Toensurethewritingaccuracy,usethepenprovidedratherthanafingerto


13

performcalibration.
Calibrationerrorsmaycausetouchfunctionsfailure.Inthatcase,please
performcalibrationagain.
Tap“ESC”onthekeyboardtocancelthecurrentpositioningprocess.
Thecalibrationinterfacevariesfordifferentsoftwareversions.But
calibrationwayissimilar.
Hotkeycalibrationfitforwhiteboardwithhotkeys.Pleasefollowthe
instructionstocalibrate.





WhiteboardUse
Whiteboardcanworknormallyaftercalibration,evenwithoutopeningFlow!Works
Pro.Somecommonoperationscanbeimplementedrapidlythroughwhiteboard.

Click
Usepenorfingertocontrolthecursorpositiononthewhiteboardtoachievemouse
leftkeyclickfunction.Itisgenerallyusedtoselectorpointtoobjects.

Double‐click
Doubleclickwithpenorfingeronthewhiteboardtoachievemousedouble‐click
function.
DoubleclicktheFlow!WorksProicononthedesktostartthesoftware.

RightClick


14

Holdfingerorpenonthewhiteboardforabout2Stoachievemouserightclick
function.








TroubleShooting
TroubleShooting
FailurePhenomenon/Feature PossibleCauseSolution
Flow!WorksServerwasnot
started.
StarttheServer.Flow!WorksServeris
notrunning.
Flow!WorksServerwasnot
installed.
InstalltheServer.
Whiteboardwasnot
connectedwithcomputer.
Usecableprovidedto
connectthecomputer.
Whiteboardfailsto
self‐inspection.
Checkwhetherthereare
objectspressingagainstthe
whiteboard.Ifthereare,
pleaseclearthemaway.
Driveiconisred.
Drivedamage.Reinstallthedriveafter
uninstallation.
Whiteboardfails
towork
Driveiconisgreen.Thepositioningis
inaccurate.
Re‐positioningaccordingto
thereferenceabove.
Partsof
calibrationcross
pointsare
invisibleonthe
whiteboard.
Calibrationcross
cursorisinvisibleon
thewhiteboard.
Projectormis‐position
causeImageprojected
exceedingthewhiteboard
area.
Adjusttheprojector.


15

Mousecursoris
movingwhilethere’s
nohandwriting.
Softwareisnotinwriting
mode.
Switchtothewritingmode
andthemousecursoricon
showspen.
U
nabletowrite
Mousecursoricon
showspenbutfailto
writeinwritingmode.
Thepenstrokecolorare
thesameasorsimilarto
thebackgroundcolor.
Changepenstrokecoloror
background.
Inaccuratepositioning.Re‐positioning.Writingaccuracy
deviation
Largedeviationat
somepartsofthe
whiteboard.
ProjectivedistortionAdjustprojector.
Conflictwithantivirus
software.
Closetheantivirussoftware.Thewriting
delayed

Toomanyprogramsare
runningatthesametime.
Shutdownprogramsnot
usedforthemoment.
Hardwareconfigurationis
toolow.
Upgradehardware
configuration.

Specification
Highprecisioninfraredtouchingframe,Resolutionupto32767*32767through
interpolationalgorithm;
Supportingmulti‐touch:2points,4pointsand6points;
Resolution:32767*32767;
ResponseSpeed:≤20ms;
TouchingAccuracy:90%touchingarea±2mm;
InputMode:Finger,penoranyotheropaqueobject;
OutputMode:Coordinateoutput;
NumberofClicksinTheory:Infinite;
TheMinimumInputObject:5mm;
Anti‐phototaxis:Allangleanti‐highlight
InterfaceType:USB;



16

ElectronicFeature:
PowerSupplyMode:USB;
SupplyVoltage:DC+5V±5%;
OperatingCurrent:<200mA.




FCCStatement
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB
digitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedto
providereasonableprotectionagainstharmfulinterferenceinaresidential
installation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergy
and,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmful
interferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevision
reception,whichcanbedeterminedbyturningtheequipmentoffandon,theuseris
encouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
Reorientorrelocatethereceivingantenna.
Increasetheseparationbetweentheequipmentandreceiver.
Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhich
thereceiverisconnected.


17


Notes:
1. Pleasekeepthismanualforfuturereference.
2. Thismanualisavailableforallseriesofinfraredwhiteboardsotheremaybesome
differencesbetweentheactualproductandtheproductexplainedinthismanual.
