qpcom QP-S108 User manual

User’s Manual
QP-S108
8-Port 10/100 Ethernet Switch
www.qpcom.com

www.qpcom.com
QP-S108
2
LED Color Status Description
Power
Green O N This indicator lights when the
Switch powers on.
— OFF
If this indicator is not lighting,
please check the DC power
connector to ensure the correct
connection of the power
adapter.
Link/Act
Green O N The other devices connect to
the port of the Switch.
Green B linking The port is transmit- ting or
receiving data packets.

www.qpcom.com
QP-S108
3
1 2 3 4 5 6 7 8
RJ
-
45 CONECTOR
1 2 3 4 5 6 7 8
Router
SERVER
PC1
PC2 PC3
RJ-11 RJ-45
CABLE/DSL Modem
Internet

www.qpcom.com
QP-S108
4
Standards
IEEE802.3 10Base-T Ethernet
IEEE802.3u 100Base-TX Fast
Ethernet
Protocol CSMA/CD
Topology Star
Network Cables
10 Base -T: Cat.3 UTP or above
100 Base -TX: Cat.5 UTP /STP
Speed 1 0/100Mbps
Transmission Method F ast store-and-forward
MAC Address Table 1K(S108)
Packet Filtering/
Forwarding Rate
14880pps(10Mbps)per port
148800pps(100Mbps)per port
MAC Address Learning S elf-learning, auto-aging.
Backplane Bandwidth 1.6Gbps(S108)
Power E xternal universal power supply
DC INPUT DC 5V 600mA
Power Consumption 4.2W(S108)
Operating Temperature 0 ℃-40℃
Storage Temperature -40℃-70℃
Working Humidity 10%～90% RH (no condensing)
～
