QRP Labs QLG1 User manual

1
QLG1 GPS Receiver kit
1. Introduction
Thank you for purchasing the QRP Labs QLG1 GPS Receiver kit. This kit will provide a highly sensitive,
highly accurate GPS receiver module, using the popular MediaTek chipset. This chipset features high
sensitivity (as good, or better, than any other popular chipset) and an extremely accurate 1pps time pulse
(10ns rms). The kit features provide a number of advantages compared to using a ready-built GPS
module:
1) A kit –fun and educational to build –easy construction with no SMD components
2) High sensitivity: the large ground plane area provides an additional 7.5dBic of antenna gain,
compared to a typical patch antenna arrangement in which the PCB is the same size as the patch
3) Built-in patch antenna, or the ability to connect your own external antenna via SMA if you wish
4) Hobbyist-friendly, 0.1-inch pitch connections
5) Three on-board LEDs provide a visual indication of what is going on
6) Proper 5V level conversion, no need for any pull-up resistors
7) Direct connection to QRP Labs kits by shielded cable, no need for pull-ups or capacitors
2. Antenna
The QLG1 GPS receiver kit can be built with two antenna options: either an on-board patch antenna, or an
externally mounted active antenna (with SMA connector). The module can supply a regulated voltage
suitable for powering the external antenna. The external antenna option may be useful if you wish to
mount the antenna separately to the module; furthermore active external antennas typically provide the
highest receive sensitivity. This may be useful in particularly challenging locations. However, the supplied
custom-tuned patch antenna is already highly sensitive and will be suitable for most situations.
Antenna gain
This chart of antenna gain vs size of the
square ground plane dimension, is extracted
from the manufacturer’s datasheet.
The QLG1 PCB is sized 3.6 x 2.5 inches (91
x 64mm). The right hand side of the PCB is
used for the voltage regulator and level
converter circuits. In this way, the patch
antenna is mounted on the reverse of the
PCB, in the middle of a virtually un-
interrupted ground-plane 64 x 64mm. This is
indicated on the chart by the red line. You will
note that it provides 7.5dBic gain over a more
typical 30 x 30mm0sized ground-plane. This
is an important feature of the QLG1 kit, providing high sensitivity!

2
3. Design
The design is quite simple. Note the circuit diagram above. The GPS receiver RF module does all the hard
work. The additional circuits are supply filtering, voltage regulation (the module requires 3.3V operation),
level shifting, and LED indication.
Supply voltage filtering is undertaken by two 0.1uH inductors in series with both the +5V and ground
supplies, and plenty of smoothing/decoupling capacitors (the 0.1uF and 22uF capacitors). The voltage
regulator is an LM317LZ configured for 3.3V output. Additionally there is a 3V Li rechargeable battery on
the board. This is charged automatically during operation. When power is removed, it retains ephemeris
information in the RF receiver module. This enables a faster fix, next time the GPS receiver is powered.
The data output and 1pps output from the RF module are at 2.8V level (via internal voltage regulation
within the module). The 74ACT logic family are perfect for the purposes of level conversion, because the
“high” voltage threshold specification for this family is below the 2.8V “high” output voltage of the RF
module. This is therefore converted to 5V by the 74ACT08 quad AND-gate, which is configured as four
buffers. The voltage to the serial data input of the RF module is restricted by zener diode D1.
The kit includes three 3mm LEDs. It is suggested to fit the Red LED to be permanently on, to show power
to the board. The Yellow and Green LEDs indicate respectively, serial data and the 1pps signal. They are
driven by the remaining two AND gates of the 74ACT08. Note that the serial data output is idle-high, i.e. at
5V in the pause between data bursts. Therefore the yellow LED is connected to 5V, so as to light when the
serial line is LOW. It will therefore pulse once per second during the data burst. The green 1pps LED will
only pulse once a GPS fix is attained –the Green colour traditionally indicating “All is well”.

3
4. Parts List
4.1 Resistors (may be supplied either with 4-band or 5-band colour codes, see below)
R1 1K resistor (brown-black-red-gold OR brown-black-black-brown-brown)
R2 1K resistor (brown-black-red-gold OR brown-black-black-brown-brown)
R3 470-ohm resistor (yellow-purple-brown-gold OR yellow-purple-black-black-brown)
R4 470-ohm resistor (yellow-purple-brown-gold OR yellow-purple-black-black-brown)
R5 470-ohm resistor (yellow-purple-brown-gold OR yellow-purple-black-black-brown)
R6 1K resistor (brown-black-red-gold OR brown-black-black-brown-brown)
R7 560-ohm resistor (green-blue-brown-gold OR green-blue-black-black-brown)
R8 470-ohm resistor (yellow-purple-brown-gold OR yellow-purple-black-black-brown)
R9 470-ohm resistor (yellow-purple-brown-gold OR yellow-purple-black-black-brown)
R10 Not supplied –space is provided on the PCB for an active external antenna voltage supply
4.2 Capacitors
C1 0.1uF (ceramic, marking 104)
C2 0.1uF (ceramic, marking 104)
C3 22uF (electrolytic)
C4 22uF (electrolytic)
C5 0.1uF (ceramic, marking 104)
4.3 Semiconductors
IC1 74ACT08, 14-pin DIP chip
IC2 LM317LZ voltage regulator, three-wired TO92
D1 3.6V zener diode
LED, red 3mm red LED for power indication
LED, yellow 3mm yellow LED for serial data output indication
LED, green 3mm green LED for 1pps indication
4.4 Inductors
L1 0.1uH axial inductor
L2 0.1uH axial inductor
L3 Not supplied–space is provided on the PCB for an active external antenna voltage supply
4.5 Miscellaneous
Printed Circuit Board (PCB), 91 x 64mm size
Mediatek chipset GPS engine RF module, pre-soldered to PCB
25 x 25mm ceramic patch antenna, custom-tuned to match the PCB layout and ground-plane
3V rechargeable Lithium coin cell battery
4pcs 12mm nylon hex spacer
4pcs M3 nylon screw
5. Construction
Parts placement is defined by the silkscreen printed legend on the PCB, so please observe it carefully,
paying particular attention to the correct orientation of all the semiconductors, and the two electrolytic
capacitors C3 and C4.

4
Note that components R10 and L3 are not supplied in the kit. The PCB has space for these components,
which may optionally be fitted for those wishing to supply power to an external active antenna.
Please refer to the parts placement diagram below.
Pay special attention to the orientation of the semiconductor IC1. The dimple in the PCB silkscreen must
be aligned with the dimple at the top of IC1.
It’s a good idea to use a jeweller’s loupe like the
one pictured, or a magnifying glass, to inspect each
soldered joint. A strong light is also very useful.
Look for excess solder that could cause short
circuits (solder bridges) to adjacent tracks. Also
look for joints where the solder has not correctly
flowed into the joint, i.e adhered to the component
lead and the PCB.
The QLG1 PCB has a ground plane on both sides
of the board. Component connections to the ground plane need a little extra heat, because of the heat
dissipation of the ground plane. Even though the solder pads are thermally “isolated” in the PCB layout,
there is still significant heat loss into the ground plane. My suggestion for components with a ground
connection, is to solder the non-ground lead(s) first –this anchors the component in place and makes it
easier to get a good connection when you come to soldering the grounded lead. Again, use the jeweller’s
loupe to make a careful inspection.

5
The order of construction is not important. However, a good principle to follow is to install the smaller
components first, so that the larger ones do not prevent easy access.
In the following photograph, all the resistors, capacitors, inductors, LM317LZ voltage regulator (3-pin TO92
package), 74ACT08 chip, and 3.6V zener diode have been fitted. Be careful to ensure the correct
orientation of the semiconductors (IC1, IC2, zener diode); also the electrolytic capacitors C3 and C4. The
silk-screen legend on the PCB may be too small to read, so please refer to the parts placement diagram.
Battery
Correct orientation of the battery is particularly
critical! Since the battery will already hold some
charge when it arrives, you must ensure that it is
NOT inserted into the PCB in the wrong way, even
temporarily –since it would supply reverse power
to the RF module and potentially damage it.
The 3V rechargeable battery has two pins, that fit
the holes on the board. The TOP of the battery, is
the positive connection. This pin fits the hole
labelled “+”. Please study the photograph to the
right, showing the battery correctly installed on the
board.
When soldering the battery, please make it quick. Hot Lithium probably is not a good idea.

6
LEDs
It is critical of course, to ensure correct LED orientation. The
cathode of the LEDs is indicated by the flat on the body of
the LED. However, on 3mm LEDs the “flat” is not so easy to
see (though quite clear, using magnification). So note that
the cathode is also indicated by the shorter wire (before
you’ve cut them!) and also by the larger electrode. The
larger electrode can be seen clearly if you hold the LED in
front of a strong light. The diagram to the right illustrates the
three ways of identifying the LED cathode.
In actual operation using the patch antenna (not externally mounted active antenna), the patch antenna is
fitted on the solder-side of the board (see next section). This side will be facing up so that it has a good
view of the sky. In this case, it is helpful to install the three LEDs on the component-side of the board. The
side without the silkscreen printed component outlines. This will ensure that you can see the LEDs in
operation.
If you are using an external active antenna, then you could continue to use the LED’s on the component
side of the board. Additionally, 2 x 3 header connection pads are provided, in case you want to wire the
LEDs to be mounted off-board, for example, to fit into an enclosure or front panel (headers not supplied).
Regardless of whether you wish to have
the LEDs fitted on the component or
solder side of the PCB, you need to
ensure the flats (cathodes) of the LEDs
are aligned with the silkscreen on the
PCB. The cathodes/flats/short-wires are
inserted into the PCB holes nearest to
the PCB centre.
This photograph shows the usual method
of assembly, with the LED’s on the
solder-side of the PCB so that with the
patch antenna installed on-board, they’ll
be visible.
Patch antenna installation
The supplied 25 x 25mm patch antenna has been custom-manufactured, with tuning to match it to the
characteristics of this PCB. The tuning is indicated by the small cuts you may be able to see in the metallic
surface of the top side of the patch antenna. Do not be tempted to substitute another patch antenna,
which will not have been tuned to match this PCB layout!
To install the patch antenna, first
remove the plastic film that
protects the self-adhesive sticker
on the underside of the antenna,
as shown in these two
photographs (far right: after
removal).

7
The patch antenna connection pin is not in the
exact centre of the square patch. Please refer to
the photograph (above). The connection pin should
be furthest away from the through-hole
components section of the PCB, as shown. The
patch should be positioned on the solder side of the
PCB.
Insert the connection pin of the patch antenna into
the centre-hole of the SMA socket. The photograph
(right) illustrates the connection pin location. Solder
the connection on the component side of the PCB.
Remote active antenna installation
If you decide to use an external active antenna, then do not install the supplied patch antenna. Instead,
you can fit a SMA socket such as the one pictured
here (left).
Install the SMA socket on the PCB as
shown in the photograph (right).
In this case you may also need to supply
power to the external active antenna.
Then you should fit R10 and L3 (not supplied).
Typically R10 should be 10 ohms, and L3 27nH (or a
ferrite bead). You will need to solder a wire from the
lower end of L3, to the SMA centre connector. This arrangement supplies power to the external antenna,
from the RF Vcc supply output of the RF module. Note that it does not have short-circuit protection!

8
Mechanical mounting considerations
The kit is supplied with four 12mm nylon M3 hex spacers, and
four nylon M3 screws. The PCB has a suitable mounting hole
in each corner.
The patch antenna specifications recommend that the
distance between the ground-plane and any conducting
materials below it, should be a minimum of 10mm.
When using the supplied patch antenna, the recommended
mounting of the QLG1 PCB should therefore involve the PCB
orientated with the component side downwards, and the patch
antenna facing up to the sky. The hex nylon spacers should
be used as pillars, suspending the PCB above the enclosure.
The hex nylon spacers will be on the component side of the
PCB (lower), with the screws on the solder side (upper).
The enclosure material must NOT be conductive, which would
shield the patch antenna!
If using an externally mounted active antenna, the mounting considerations are
much less critical.
Input/output signal connections
The diagram (right) shows a section of the silkscreen printing from the component
side of the QLG1 PCB, at the right side of the board.
There are two sets of connections, a 6-way set and a 4-way set. Both use 0.1-inch
pitch pads, suitable for using standard 0.1-inch pin header connectors (not supplied
with the kit), or soldering wires. The pads are large and easy to solder to.
The 6-way set of connections provides access to the full set of signals, for general
purpose use of this GPS receiver module. Note that TXD is the serial data output of
the module, at 5V Logic levels. The 1 pulse per second (1pps) timing signal is also
5V. The pulse is 100ms long and active-high (the leading edge of the pulse indicates
the 1 second event). RXD is the serial data input signal, at 3.3V logic level; however
5V logic level inputs are also supported due to the onboard zener diode D1.
The 4-way set of connections is intended for connection of the QLG1 GPS receiver module to the
Ultimate3S QRSS/WSPR transmitter kit, and other QRP Labs kits. These are the only four signals required
by these kits, which do not communicate serial data back to the GPS, they only listen to the GPS serial
data stream and 1pps signals.
Connecting the QLG1 to an Ultimate3S QRSS/WSPR kit
The 4-way connector on the QLG1 can be connected directly to the 4-way connector of the U3S (and other
QRP Labs kits), via a length of shielded cable. No pull-up resistors, extra voltage regulator, or
smoothing/decoupling capacitors are needed since these are all already incorporated into the QLG1. The
order of connection pads on the QLG1 is also the same as those on the U3S. Note that the QLG1 TXD
(output) signal connects to the U3S RXD signal (input). The cable shield should be connected to ground at
the U3S end only, not the QLG1 end. 2m or 3m of cable is typically a good length to use.

9
Connecting LEDs off-board
The LEDs can also be connected off-board, you may wish to do this if you
are considering boxing the QLG1, and want to still see the status LEDs, for
example on a front panel.
The PCB has a 2 x 3 connector pad at the bottom right (component side)
as in this diagram (right). Each pair of 2 connections is for one LED, as
shown. The cathodes are the pads nearest the board edge.
LED indication in operation
RED The red power LED will always be lit, when power is applied to the QLG1 board.
YELLOW The data LED pulses in time with the serial data burst
GREEN The green 1pps LED will flash once per second, for a duration of 0.1 seconds
Note that the green LED will not flash (indicating 1pps signal) until the module has received sufficient
satellites to compute a position fix solution. This can take some time, particularly the first time the unit is
powered up. Initial acquisition of a satellite requires higher Signal to Noise Ratio (SNR) than tracking.
Once acquired, the satellites orbital characteristics are stored, so that subsequent tracking is possible at
the lower SNR, as soon as the satellite comes into view. Download of all the satellite orbital data in the
constellation can take around 1 hour. So it is quite normal for performance of a GPS module to improve
during the first hour after power up (in terms of number of tracked satellites etc).
Until all the satellites are received the yellow data LED may pulse somewhat erratically, not necessarily
producing one data burst per second.
Once the fix is computed, the 1pps signal is enabled. The green LED will flash for 0.1 seconds, starting
with the commencement of each second. The data burst is initiated at the end of the 0.1 second pulse, and
lasts for perhaps 0.5 seconds (varies depending on data payload).
Default Baud Rate
The default baud rate of the QLG1 is 9,600 baud. This is compatible with the default settings of the
Ultimate3S QRSS/WSPR TX kit (and other QRP Labs products). The list of default NMEA sentences is
described in a later section. The RF module (Mediatek chipset) can also accept serial commands that
change its baud rate and the NMEA sentences in the serial data burst. This is beyond the scope of this
document.
Powering from 3.3V
The QLG1 GPS Receiver module can also be powered at
3.3V if desired. In this case, simply do not install the LM317LZ
voltage regulator, and you may also omit R6 and R7. Instead,
install a wire link as shown (right), to bypass this voltage
regulator.
When powering with 3.3V, the TXD and 1pps output signals
will also have 3.3V levels.

10
6 Resources
Please see the kit page http://www.qrp-labs.com/qlg1 for information on latest updates and issues.
The kit page also has a copy of the datasheet for the RF module. This datasheet contains the RF
specifications, and also the details of the NMEA sentence structure.
Finally, please join the QRP Labs YahooGroups forum, if you have not already. The forum members can
provide support for any questions regarding issues, and share your success stories too.
9. Version History
0 10-Jun-2015
•First version
1 05-Apr-2016
•Correction to page 7, “components side” should be “solder side”, for positioning the patch antenna
2 04-May-2016
•Correction to remove the reference to an IC socket, which is not in fact used or supplied in this kit.
Also clarification that pin headers are not supplied either.
