QSC AcousticDesign AD-S52 Operating manual

AcousticDesign Multi-Purpose Loudspeakers 1
AD-S52, AD-S52T, AD-S82, AD-S82H Technical Service Manual
Technical Service Manual
AcousticDesign™
Multi-Use Loudspeakers
▲▲
▲▲
▲AD-S52
▲▲
▲▲
▲AD-S52T
▲▲
▲▲
▲AD-S82
▲▲
▲▲
▲AD-S82H
*TD-000175-00*
TD-000175-00
Rev. B
QSC Audio Products, Inc.
Costa Mesa, CA 92626 USA
www.qscaudio.com

2QSC Audio Products, Inc.

AcousticDesign Multi-Purpose Loudspeakers 3
AD-S52, AD-S52T, AD-S82, AD-S82H Technical Service Manual
Table of Contents
Product Specifications ....................................................................................................................................................................... 4
AD-S52 and AD-S52T ............................................................................................................................................................................. 4
AD-S82 and AD-S82H ............................................................................................................................................................................. 6
Replacement Parts ............................................................................................................................................................................... 8
AD-S52 .................................................................................................................................................................................................... 8
AD-S52T .................................................................................................................................................................................................. 8
AD-S82 .................................................................................................................................................................................................... 9
AD-S82H .................................................................................................................................................................................................. 10
Drawings................................................................................................................................................................................................. 11
AD-S52 .................................................................................................................................................................................................... 11
AD-S52T .................................................................................................................................................................................................. 12
AD-S82 .................................................................................................................................................................................................... 13
AD-S82H .................................................................................................................................................................................................. 14
IMPORTANT NOTICE:
This document contains proprietary information that is the property of QSC Audio Products, Inc., (QSC) and may not be disclosed,
reproduced or used without express or written consent from QSC.
Specifications, components, assembly, etc., are subject to change without notice.
QSC Audio Products, Inc.
Technical Services Group
1665 MacArthur Blvd.
Costa Mesa, California 92626 USA
Toll Free (USA only): 1-800-772-2834
Telephone: [phone]
Fax: [phone]
Web: www.qscaudio.com (product information and technical support)
www.qscstore.com (parts and accessory sales)
E-mail: tech_[email protected]
AcousticDesignTM Multi-Use Loudspeakers
AD-S52 / AD-S52T / AD-S82 / AD-S82H
Technical Service Manual

4QSC Audio Products, Inc.
Product Specifications
AD-S52 and AD-S52T

AcousticDesign Multi-Purpose Loudspeakers 5
AD-S52, AD-S52T, AD-S82, AD-S82H Technical Service Manual
AD-S52 and AD-S52T (continued)

6QSC Audio Products, Inc.
Product Specifications
AD-S82 and AD-S82H

AcousticDesign Multi-Purpose Loudspeakers 7
AD-S52, AD-S52T, AD-S82, AD-S82H Technical Service Manual
AD-S82 and AD-S82H (continued)

8QSC Audio Products, Inc.
Replacement Parts
AD-S52 Parts List
Part Number Description Quantity Item
CH-000361-XX C3 5 IN GRILLE 1 1
CO-000268-00 POST, BINDING 2 2
CO-000297-00 FASTON, MALE, .210X.032 2 3
HW-000062-00 EYE BOLT, M6X1 1 4
MS-000214-00 FIBERFILL, POLYESTER, 7X5X1.5 1 5
NW-000023-00 NUT, M4X0.7, BRASS 2 6
NW-000024-00 LOCKNUT, M6, W/NYLON, SS 1 7
NW-000026-00 WASHER, SPLIT-LOCK, M4 BRASS 2 8
NW-000027-00 WASHER, M4, SS, FLAT 4 9
NW-250520-04 WASHER, M6, SS 1 10
PL-000215-01 NUT, WITH INSERT, BINDING POST 1 11
PL-000215-02 NUT, WITH INSERT, BINDING POST 1 12
RD-000117-00 LABEL, SERIAL 1
PL-000236-XX PLUG, INSERT, .375 4 14
PL-000244-00 O-RING, -018, TEFLON 1 15
PL-000309-XX PLUG, SWITCH HOLE 1 16
PL-000310-00 BAFFLE, AD-S52 1 17
PL-000311-00 PORT, FLARE, AD-S52 1 18
PL-000312-00 GASKET, BAFFLE, AD-S52 1 19
PL-000366-01 GASKET, BADGE, AD-S52, BLACK 1 20
PL-000313-XX LOGO, BADGE, AD-S52 1 21
PL-000374-00 GASKET, WOOFER, 5" 1 22
SB-000015-XX HOUSING, AD-S52 1 23
SC-000000-10 SCREW, PHILLIPS, PANHEAD, M3.5X1.25, 10L 3 24
SC-000002-15 SCREW, PHILLIPS, PANHEAD, M4X1.4, 15L 10 25
SC-000011-18 SCREW, PHILLIPS, PANHEAD, M4X1.4, 6 26
SP-000058-00 ZYLUX WOOFER, 5.25 IN, FG CONE, SHIELDED 1 27
SP-000061-00 TWEETER, 1" 1 28 ,
WP-000253-00 PCB, AD-S52, ASM 1 29
HW-000061-00 INSERT, POST/BALL, AD-S52 1
HW-000060-00 INSERT, M10X1 BRASS 4
AD-S52T Parts List
Part Number Description Quantity Item
CH-000360-00 PLATE, MOUNTING, SWITCH 1 1
CH-000361-01 C3 5INCH GRILLE 1 2
CO-000268-00 POST, BINDING 2 3
CO-000297-00 FASTON, MALE, .210x.032 2 4
HW-000062-00 EYE BOLT, M6x1 1 5
MS-000214-00 FIBERFILL, POLYESTER, 7x5x1.5 1 6
NW-000023-00 NUT, M4x0.7, BRASS 2 7
NW-000024-00 LOCKNUT, M6, W/NYLON, SS 1 8
NW-000026-00 WASHER, SPLIT-LOCK, M4, BRASS 2 9
NW-000027-00 WASHER, M4, SS, FLAT 4 10
NW-250520-04 WASHER, M6, SS 1 11
PL-000215-01 NUT, WITH INSERT, BINDING POST 1 12
PL-000215-02 NUT, WITH INSERT, BINDING POST 1 13
PL-000234-00 GASKET, TWEETER 1 14
PL-000236-01 PLUG, INSERT, .375 4 15
PL-000244-00 O-RING, -018, TEFLON 1 16
PL-000308-01 KNOB, XFMR TAP SWITCH 1 17

AcousticDesign Multi-Purpose Loudspeakers 9
AD-S52, AD-S52T, AD-S82, AD-S82H Technical Service Manual
AD-S52T (continued)
Part Number Description Quantity Item
PL-000310-00 BAFFLE, AD-S52 1 18
PL-000311-00 PORT, FLARE, AD-S52 1 19
PL-000312-00 GASKET, BAFFLE, AD-S52 1 20
PL-000313-01 LOGO, BADGE, AD-S52 1 21
PL-000362-00 GASKET, TRANSFER, AD-S52 1 22
PL-000366-01 GASKET, BADGE, AD-S52, BLACK 1 23
PL-000374-00 GASKET, WOOFER, 5" 1 24
RD-000117-00 LABEL, SERIAL 1
SB-000015-01 HOUSING, AD-S52, BLK 1 26
SC-000000-10 SCREW, PHILLIPS, PANHEAD, M3.5x1.25, 10L 3 27
SC-000002-15 SCREW, PHILLIPS, PANHEAD, M4x1.4, 15L 12 28
SC-000011-18 SCREW, PHILLIPS, PANHEAD, M4x1.4, 6 29
SP-000058-00 WOOFER, 5.25 IN, FG CONE, SHIELDED, AD-S52, ZYLUX 1 30
SP-000061-00 TWEETER, 1" 1 31 ,
SW-000103-00 SWITCH, XFMR TAP 1 32
WP-000253-00 PCB, AD-S52, ASM 1 33
XF-000205-00 TRANSFORMER, 30W 1 34
HW-000061-00 INSERT, POST/BALL, AD-S52 1
HW-000060-00 INSERT, M10X1 BRASS 4
AD-S82 Parts List
Part Number Description Quantity Item
CH-000215-01 GRILLE, C3-8, BLK 1 1
CH-000219-01 CATCH, C3-8 BLK 1 2
CH-000220-01 PLATE, TERMINAL, C3-8, BLK 1 3
CH-000276-00 PIN, CATCH, SS 1 4
CO-000268-00 BINDING POST 2 5
CO-000297-00 FASTON, MALE, 0.210 X 0.032 2 6
HW-000040-00 RETAINER, ID, 0.312 1 7
HW-000041-00 EYE BOLT, 6MM, SS 1 8
HW-000060-00 INSERT, M10 X 1, BRASS 2 9
MS-000210-00 FIBERFILL, POLY, 13.4X9.9X2.0 1 10
MS-000211-00 FIBERFILL, POLY, 7.1X5.9X2.0 2 11
NW-000022-00 LOCKNUT, M4 X 0.7, W/NYLON, SS 4 12
NW-000023-00 NUT, M4 X 0.7, BRASS 2 13
NM-000024-00 LOCKNUT, M6, W/NYLON, SS 1 14
NW-000026-00 WASHER, SPLIT-LOCK, M4, BRASS 2 15
NW-250520-04 WASHER, M6, SS 1 16
PL-000212-01 RECEPTACLE, BADGE,BLK 1 17
PL-000213-01 BADGE, 0.45 X 1.87, BLK 1 18
PL-000214-00 BACKPLATE, BINDING POST 1 19
PL-000215-01 NUT, WITH INSERT, BINDING POST, BLK 1 20
PL-000215-02 NUT, WITH INSERT, BINDING POST, RED 1 21
PL-000216-01 FLARE, PORT, C3-8, BLK 1 22
PL-000217-01 BASE, BINDING POST, C3-8, BLK 1 23
PL-000233-00 GASKET, WOOFER 1 24
PL-000234-00 GASKET, TWEETER 1 25
PL-000235-00 GASKET, CATCH 1 26
PL-000236-01 PLUG, INSERT, 0.375, BLK 2 27
PL-000237-00 GASKET, TERMINAL PLATE 1 28
PL-000238-00 GASKET, WAVE-GUIDE 1 29
PL-000239-00 GASKET, BAFFLE, NEOPRENE, BLACK 1 30
SB-000003-01 BUCKET, C3-8, BLK 1 31
SB-000004-01 BAFFLE, C3-8, BLK 1 32
SC-000000-10 SCREW, PHILLIPS,PANHEAD, M3.5X1.25, 10L BLK 3 33
SC-000000-12 SCREW, PHILLIPS,PANHEAD, M3.5X1.25, 12L 6 34

10 QSC Audio Products, Inc.
SC-000002-18 SCREW, PHILLIPS,PANHEAD, M4X1.4, 18L 8 35
SC-000011-15 SCREW, PHILLIPS,PANHEAD, M4X1.4, 15L BLK 8 36
SC-000011-23 SCREW, PHILLIPS,PANHEAD, M4X1.4, 23L BLK 16 37
SP-000067-00 WOOFER, 8", CELESTION—all [xx5xxxxxx] or later serial number
138
SP-000061-00 TWEETER, 1"—all [xx5xxxxxx] or later serial number 1 39
SP-000032-00 WAVE-GUIDE, TWEETER, C3-8 1 40
WP-000409-00 PCB ASSY, X-OVER, C3-8,SP61/67—all after [xx5xxxxxx] or later serial number
141
AD-S82H Parts List
Part Number Description Quantity Item
CH-000215-01 GRILLE, C3-8 1 1
CH-000219-01 CATCH, C3-8 1 2
CH-000220-01 PLATE, TERMINAL, C3-8 1 3
CH-000276-00 PIN, CATCH, SS 1 4
CO-000268-00 BINDING POST 2 5
CO-000297-00 FASTON, MALE, 0.210 X 0.032 2 6
HW-000040-00 RETAINER, ID, 0.312 1 7
HW-000041-00 EYE BOLT, 6MM, SS 1 8
HW-000060-00 INSERT, M10 X 1, BRASS 2 9
MS-000210-00 FIBERFILL, POLY, 13.4X9.9X2.0 1 10
MS-000211-00 FIBERFILL, POLY, 7.1X5.9X2.0 2 11
NW-000022-00 LOCKNUT, M4 X 0.7 W/NYLON SS 4 12
NW-000023-00 NUT, M4 X 0.7, BRASS 2 13
NW-000024-00 LOCKNUT, M6, W/NYLON,SS 1 14
NW-000026-00 WASHER, SPLIT-LOCK. M4,BRASS 2 15
NW-250520-04 WASHER, M6, SS 1 16
PL-000212-01 RECEPTACLE, BADGE 1 17
PL-000213-01 BADGE, 0.45 X 1.87 1 18
PL-000214-00 BACKPLATE, BINDING POST 1 19
PL-000215-01 NUT, WITH INSERT, BINDING POST, BLK 1 20
PL-000215-02 NUT, WITH INSERT, BINDING POST, RED 1 21
PL-000216-01 FLARE, PORT, C3-8 1 22
PL-000217-01 BASE, BINDING POST, C3-8 1 23
PL-000235-00 GASKET, CATCH 1 24
PL-000236-01 PLUG, INSERT, 0.375 2 25
PL-000237-00 GASKET, TERMINAL PLATE 1 26
PL-000238-00 GASKET, WAVE-GUIDE 1 27
PL-000239-00 GASKET, BAFFLE, NEOPRENE, BLACK 1 28
PL-000258-00 PLUG, WAVE GUIDE, HI OUTPUT, C3-8 2 29
SB-000003-01 BUCKET, C3-8,BLK 1 30
SB-000004-01 BAFFLE, C3-8 1 31
SC-000000-12 SCREW, PHILLIPS,PANHEAD, M3.5X1.25, 12L 6 32
SC-000002-18 SCREW, PHILLIPS,PANHEAD, M4X1.4, 18L 8 33
SC-000004-15 SCREW, PHILLIPS,PANHEAD, M5X0.8, 15L BLK 2 34
SC-000011-15 SCREW, PHILLIPS,PANHEAD, M4X1.4, 15L BLK 8 35
SC-000011-23 SCREW, PHILLIPS,PANHEAD, M4X1.4, 23L, BLK 16 36
SP-000009-00 WOOFER, 8 IN, NEO 1 37
SP-000021-00 COMPRESSION DRIVER, 1" 1 38
SP-000031-00 WAVE-GUIDE, HI OUTPUT, C3-8 1 39
WP-000109-00 PCB, CROSSOVER, C3-8, HO 1 40
AD-S82 (continued)
Part Number Description Quantity Item

AcousticDesign Multi-Purpose Loudspeakers 11
AD-S52, AD-S52T, AD-S82, AD-S82H Technical Service Manual
13
1
28
1
24
3
18
1
25
4
25
2
15
1
16
1
14
4
23
1
12
1
11
1 2 2 4 1
3 2
8 2
6 2
29
1
10
1
7 1
5 1
19
1
25
4
9 4
27
1
22
1
17
1
20
1
21
1 1 1
26
6
Figure 1. AD-S52 Exploded View
20
2
Item number Quantity per unit
Legend

12 QSC Audio Products, Inc.
14
1
31
1
27
3
19
1
28
4
32
1
28
216
1
15
4
13
1
12
1 3 2
5 1
9 2
4 2
7 2
33
1
11
1
8 1
6 1
28
4
20
1
10
4
30
1
24
1
18
1
21
1
23
1 2 1
29
6
28
2
1 1
34
1
22
1
26
1
17
1
Figure 2. AD-S52T Exploded View
20
2
Item number
Quantity per unit
Legend

AcousticDesign Multi-Purpose Loudspeakers 13
AD-S52, AD-S52T, AD-S82, AD-S82H Technical Service Manual
140 3925 22 33 29 32 24 30 34 38 11
927
31 28 12 4 2 3 5 20
36232619861341
1016143735
7
17 18
11612111111 3111411 1 2 1
22
1 1 1
111168
81111221
21
1
15
2
Figure 3. AD-S82 Exploded View
20
2
Item number Quantity per unit
Legend

14 QSC Audio Products, Inc.
129 3834 39 22 27 31 28
11 30 925 12 26 4 2 3
352324819613
10 4014 1637 323633
7
17 18
1
21
11 1121 12
41111
22
1 1 1
111116168
8111122
5
20
2
1
15
2
21
1
Figure 4. AD-S82H Exploded View
20
2
Item number
Quantity per unit
Legend

AcousticDesign Multi-Purpose Loudspeakers 15
AD-S52, AD-S52T, AD-S82, AD-S82H Technical Service Manual

16 QSC Audio Products, Inc.
QSC Audio Products, Inc., 1675 MacArthur Boulevard Costa Mesa, California 92626 USA PH: [phone] FAX: [phone]
“QSC” and the QSC logo are registered with the U.S. Patent and Trademark Office.
