Qtx QTFX-B3 User manual

QTFX-B3
MEGA BUBBLE MACHINE
Order ref: 160.560UK
User Manual

160.560UK User Manual
INTRODUCTION:
QTFX-B3 MEGA BUBBLE MACHINE
Unique o QTX, his ligh weigh bubble machine fea ures barrel rolling wands which
produce an incredible amoun of bubbles. I is made from heavy du y ABS plas ic
and fea ures a high quali y low noise fan. Ideal for even s, par ies and mobile discos.
•Very high bubble ou pu
•High speed fan wi h low noise
•Made from Ligh weigh heavy du y plas ic
•Easy fill and emp y ank
•Includes handheld remo e
•For bes resul s use wi h Q x bubble fluid 160.574UK (1L) or 160.575UK (5L)

160.560UK User Manual
PACKAGE CONTENTS:
Please check he con en s o ensure ha he produc has been received in good
condi ion.
QTFX B2 bubble machine x 1pcs User’s Guide x 1pcs
Power Cord x 1pcs
If you find any accessory is missing or he machine has arrived wi h any problems,
please con ac your local dealer a once. Do no ry o fix his i em yourself or you
will lose he warran y. Please keep he original package and invoice for any possible
replacemen or re urned demand.
RECOMMENDED FLUID:
For he QTFX-B2 bubble machine we s rongly recommend he following fluid which
has been specifically formula ed for he bes resul s.
QTX Ref
Code Desc iption Size Results
160.574UK 1 Li re
160.575UK
High Quali y Bubble
Fluid 5 Li re S able bubbles
SETUP:
1. Unpack he bubble machine.
2. Place on a fla surface.
3. Pour he con en s of he bubble fluid in o he fron ank so he bubble wands
a he bo om of he wheel are comple ely submerged.
4. Connec he IEC mains plug and power up.
5. Af er use unplug from he mains and emp y he remaining con en s back in o
he bubble fluid con ainer or dispose of appropria ely.
6. Clean he fron ank fully before he nex use.

160.560UK User Manual
MOUNTING INSTRUCTIONS:
The fix ure may be moun ed in any posi ion provided here is adequa e room for
ven ila ion and he fluid can no leak.
I is impor an never o obs ruc he fron of he machine, fan or ven s pa hway.
Moun he fix ure using a secure clamp.
Adjus he angle of he fix ure loosening bo h knobs and il ing he fix ure. Af er
finding desired posi ion, re- igh en bo h knobs.
When selec ing ins alla ion loca ion, ake in o considera ion refilling he ank and
rou ine main enance. Safe y cables mus always be used when ins alled a a heigh .
Never moun in places where he fix ure will be exposed o rain, high humidi y,
ex reme empera ures changes or res ric ed ven ila ion.
CAUTION! TO PREVENT MORTAL ELECTRICAL RISK AND LONG LIFE OPERATION:
For your safe y, please kindly pay a en ion o all of he warnings lis ed below:
Always plug in he power plug las and disconnec from he mains when he
device is no in use or before cleaning.
Do no ins all and opera e he device in rain or ex reme hea , mois ure or
dus y environmen s.
This device is for indoor use only and in a dry environmen .
Do no swi ch on immedia ely bu wai un il i reaches o room empera ure if
he device has been exposed o dras ic empera ure fluc ua ions.
Do no shake he device and avoid bru e force when ins alling or opera ing.
Do no use he device during hunders orms and please disconnec he power.
Do no use solven s or aggressive de ergen o clean he device. Use a sof
and clean clo h.
Do no modify he device or he connec ed power cord wi hou au horiza ion.
Use appropria e safe y-rope for safe y.
Clean he machine regularly using warm wa er

160.560UK User Manual
CONNECT WITH POWER SUPPLY – THE GROUND WIRE MUST BE CONNECTED:
Use he plug o connec o he main power supply as follows:
Wi e Connection Inte national signal
Brown Live L
Blue Neu ral N
Yellow /Cyan Ear h
QUICK TROUBLE SHOOTING
If the unit is not functioning p ope ly
Check if main power is on and fuse hasn’ blown
Check here is fluid in he ank
Check he correc fluid has been used.
REPLACING FUSE
Disconnec from he main power supply firs , hen remove he fuse holder above he
IEC Socke o reveal he fuse. Replace he correc fuse ra ing as s a ed on ligh ing or
user guide. Then, lock he fuse holder cover back in o place.

160.560UK User Manual
GENERAL MAINTENANCE
To main ain op imum performance and minimize wear, he i em should be cleaned
frequen ly. Usage and environmen are con ribu ing fac ors in de ermining
frequency. As a general rule, fix ures should be cleaned af er use o avoid dus build-
up and blockages.
Which can resul in poor performances, overhea ing and breakages. Be sure o
power off fix ure before conduc ing main enance.
Unplug fix ure from power. Use a vacuum or air compressor and a sof brush o
remove dus collec ed on ex ernal ven s and in ernal componen s. Clean he ex ernal
case when he fix ure is cold wi h a dry clo h or issue, and drag dir and grime o
he ou side case.
To ensure a con inuing high performance i is recommended o use warm wa er o
clean he in ernal ank.

160.560UK User Manual
LAYOUT:
1. Bubble Ou pu / Pour Fluid in here (Max 1.8L)
2. Carry Handel
3. Handheld remo e

160.560UK User Manual
REAR LAYOUT:
1. POWER IN (Use IEC Lead provided)
2. Power ON/OFF (No e when remo e is no plugged in and uni is swi ched on he
machine will opera e con inuously)
3. Remo e inpu
4. Fan (do no cover)

TECHNICAL SPECIFICATION
Powe supply 230Vac, 50Hz
Fuse F1A
Powe consumption 40W
Fluid Capacity 1.8l
Dimensions 340 x 175 x 210mm
Weight 1.2kg
DISPOSAL:
Please disposal of the unserviceable device according to the current statutory requirements.

160.560UK User Manual
Errors and omissions excep ed.
Copyrigh © 2012. AVSL Group L d.
