Quality MOSKITRAP GW001 User manual

Model:GW001
INSTRUCTION MANUAL
PLEASE READ THIS MANUAL CAREFULLY BEFORE USING THE APPLIANCE.
KEEP MANUAL IN A SAFE PLACE FOR EASY REFERENCE.
STICKY FLY CATCHER
Quality Lifesciences Pvt. Ltd
Ahmedabad, Gujarat. INDIA
Customer care No. [phone]

HOW IT WORKS
SAFETY PRECAUTIONS
PLEASE READ THE FOLLOWING SAFETY INSTRUCTIONS CAREFULLY TO AVOID THE RISK OF
ELECTRIC SHOCK, SHORT CIRCUIT, FIRE HAZARD AND DAMAGE TO THE UNIT
1.Keep out of reach of children. Children or any person with visual, mental or physical impairment should
only use this unit under the supervision of an adult responsible for their safety.
2.Do not tamper, modify or attempt to repair the plug, cord or unit. Repairs should only be carried out by a
qualified electrician or service technician.
3.Ensure that the unit is plugged into an electrical outlet of the correct voltage. The unit voltage is 220-
240V~ 50/60Hz
4.Avoid prolonged eye contact with the light.
5.Keep away from children. Children should be closely supervised if they are in the vicinity of the
appliance when it is operating.
6.Do not insert fingers or foreign objects into the appliance at any time.
7.Always disconnect from the electrical supply before emptying the insect container or cleaning the unit
with a soft dry cloth.
8.Keep away from all sources of moisture. Do not operate the unit near any water source.Do not expose
the unit to moisture or liquid at any time.
9.If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the
manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
10.This appliances not intended for use by persons(including children) with reduce physical,sensory or
mental capabilities,of lack of experience and knowledge,unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
11.Conformity to the appliance provisions of applicable US Federal requirements, including the
Performance Standards for Light-Emitting Products, 21 CFR, Part 1040, Chapter 1, Subchapter J,
Radiological Health.
12.WARNING: Skin or eye damage may result from directly viewing the light produced by the lamp in this
apparatus. Always turn off the lamp before opening this cover.
SAVE THESE INSTRUCTIONS
Front Cover
Sticky Paper slide guide
Electrical Box
Sticky paper holder
Sticky paper
Supporter post
STRUCTURE AND PARAMETER
PRODUCT LIST
STICKY PAPER
Sticky paper×2
MANUAL
Instruction manual×1
Covering cap×2Screw×3Wall Plug×3
Stick Fly Catcher×1
UV TUBE
The tubes send out a light at
a 36 5 n m w a v e l e ng t h t o
attract flies, mosquitoes and
other flying insects
STICKY PAPER
When an insect flies near the
tubes and land on a sticky paper
they get stuck
★The tubes have a life span of six months. After that the attraction effect starts to deteriorate and it is
suggested that the tubes be replaced
1 2
Tube holder
Tube
PCB
Base
Lock
Covering cap
Supporter
Rated voltage:220-240V~
Rated power:35W
Rated frequency:50/60Hz

HOW TO INSTALL
195mm
294mm
40mm
back
1. Install Fly trap at a height of 1.8 to 2 meters
from the floor, near a plug socket and avoiding
direct sunlight.
2.Drill three holes with 5mm bit, depth 28mm.Insert
swell plastic buttons into the holes (screw hole
facing out)
3. Screw the tapping screws into the wall
plugs leaving 5mm of the screw sticking out to
hang the fly trap on.
4. Hold the fly trap on both sides and align the
mounting holes with the screw and hang the fly
trap. Install the covering caps on top two screws.
WARNING
1.This fly catcher is for indoor use ONLY.
2.Installing the Fly trap under strong light (Lamps or sunlight) will lessen the effect.
3.Avoid installing the fly trap in dusty, windy or in high humidty environments.
Handle of sticky
paper holder
LOCK
UNLOCK
HOW TO USE
1.Press lock on the panel & unlock it. 2.Lift up the front cover in certain angle, hook the
supporter onto the supporter post.
3. Push the handle of the sticky paper holder
slowly until the handle makes contact with the
electrical box.
4.Remove the coating from a new sticky paper, insert
it to sticky paper holder by aiming for the guide slot
5. Pull the handle of the sticky paper holder
slowly upwards until you hear the click. Hold the
panel and remove the supporter from the post
and slowly lower the panel and push to lock it
closed.
6. Plug the fly catcher in and it will start to work.
Tips
During Winter or when there are not many flies in your environment, it is recommended to replace the
sticky paper every second weed.
During Summer or when there are many flies in your environment it is recommended to replace the
paper weekly.
If more than 2/3 of the paper is covered in flies, it is recommended that you replace the paper
Dusty areas will effect the tackiness of the paper and will therefore need to be replaced more often.
Sticky paper
Sticky
paper
Lock
Covering
cap
Supporter
Supporter post
Front Cover
3 4
Electrical box
★
★
★
★

REPLACING THE TUBES
1.Unplug fly catcher before replacing tubes.
2.Hold the two ends of the tube, rotate it in 90 degree (pic 1), lift it upward and take it out gently. Mark the
used tubes to avoid reuse. Insert a new tube to the tube holder socket, hold the two ends and rotate it in
the opposite direction.
Tips: Remove the sticky paper before replacing the tube.
MAINTENANCE
1.The tubes are recommended to be replaced in 6 months.
2.Clean the inner part of the catcher with soft cleaning cloth and neutral detergent (unplug it before cleaning)
SUITABLE PLACES
This Fly catcher has been designed for use in the Home, stables, the food industry, medical
industry,electronics industry, precision instruments industry, chemical industry and packaging industry. It
can also be used in restaurants, canteens and other public places.
TROUBLESHOOTING GUIDE
Does not work No power Plug in
Lamp damaged Replace new tube
Lamp doesn't working Plug out check and plug in
Ballast damaged Replace new ballast
Flies are not getting trapped
Incorrect installation position Install according to the manual
Tubes are not attracting flies Replace the tubes
The sticker paper has expired Replace the sticky paper
Problem Possible Reason Recommendation
5
lamp
