QUAN SHENG TG-UV2PLUS User manual

User’s Manual

Thank you for purchasing this QS Radio. We believe this easy-to-use
radio will provide reliable and dependable communication. QS Radio
incorporates the latest advanced technology. As a result, we know that
you will be pleased with the quality and features of this product.

1.Multiband TX&RX,dual
display dual standby
2.H (High) , M (Medium) , L (Low)
output power selective
3.Double frequency, double channel
display of the LCD.
4.Built-in VOX function
5.Dual-watch operation
6.Respectively receive/transmit
CTCSS/DCS code
7.Repeater shift direction set
8.Auto code search
9.Reverse frequency function
10.Voice scrambler
11.Multi channel steps
12.Frequency deviation setting
13.Busy channel lock
14.Time-out-Timer
15.Channel, channel-frequency,
channel-name display.
16.Priority scan
17.Wide/narrow bandwidth
18.Channel delete
19.Reset
20.Up/down scan function
21.Main/sub channel shift
22.1750Hz call tone
23.Cross-band receiving/transmitting
24.Squelch level
25.Channel name edit
26.Channel store
27.Frequency and channel mode
shift
28.Keypad lock
29.Main/sub channel display shift
30.Channel scan list
31.200 channels
32.PC Programmable
33.High capacity Li-ion battery
34.Smart charger
35.FM Radio (88-108MHz)
i
PRECAUTIONS BEFORE USING
Please read the User’s Manual before using. It gives you important
information about how to operate the portable radio.
Please put the radio and accessories where the children can not touch.
Maintenance can only be performed by professional technicians.
Please use the standard battery pack and charger in order not to
destroy the radio.
Please use the standard antenna, in order not to shorten the distance.
Do not expose the radio to sunlight for a long period of time, nor put it
near the heat,nor use it in a high temperature environment.
Do not put it in extreme dust nor wet or on unsteady surfaces.
Keep it dry. (Rain or moisture will erode the electronic board).
Do not transmit when the antenna is not installed.
If you find bad smell or smog, please turn off the radio immediately.
And take the battery off the radio, then contact with QS agent.

SUPPLIED ACCESSORIES-----------------------1
CHARGING NOTES(1)(2)----------------------- 2-3
ATTACHING/RELEASING
THE BATTERY PACK------- -------------------------4
INSTALLING BELT CLIP---------------------------- 5
INSTALLING EXTERNAL
SPEAKER/MICROPHONE--------------------------5
DIAGRAM---------------------------------------------6-7
LCD DISPLAY------------------------------------------ 8
BASIC OPERATION-----------------------------------9
FAST MENU OPERATION FLOW------------10-13
FUNCTION INSTRUCTION---------------------14-29
Transmitting output power choose (H/M/L)----- 14
Receiving CTCSS/DCS setting (RC)---------14-15
Transmitting CTCSS/DCS setting (TX)-----------15
Fequency deviation setting (+/-) ------------------ 16
VOX function---------------------------------------16-17
Research CTCSS/DCS code (RC)----------------17
Reverse (REV)------------------------------------17-18
Voice scrambler (SCR)------------------------------ 18
Dual-watch operation (DW)-------------------18-19
ii
Priority scan (PCH)----------------------21-22
Wide/Narrow bandwidth (W/N)----------- 22
Channel delete (DEL)------------------ 22-23
Reset------------------------------------------- 23
Upward/downward scanning--------------23
Main/sub channel shift------------------2 3-24
Transmitting 1750Hz call tone------------ 24
Cross-band receiving-transmitting
working shift---------------------------------- 24
Squelch level setting------------------------25
Channel name edit-------------------------- 25
Channel storing-------------------------- 26-27
Frequency and channel mode shift--- ---27
Keypad lock-----------------------------------27
“↓” symbol switch--------------------------- 27
Frequency band shift------------------------28
Ja ckl igh t-- ----- --- ----- --- ----- --- ----- --- --- -- 28
FM Radio----------------------------------28 -29
PC programmable -------------------------- 29
The annunciation of no transmitting----- 29
CTCSS list------------------------------------30
DCS list--------------------------------------- 31
Specifications------------------------------ 32
CONTENTS
Channel display mode (DSP)-------------- 21
1
SUPPLIED ACCESSORIES
Carefully unpack the portable radio. We suggest that you check the
followingitems before you throw away the packing materials.
User’s manual
Li-ion battery
Battery charger
Antenna Belt clip
Adapter
Use r’s Man ual

23
CHARGING NOTES(1)
Chargingthebatterypack:
CAUTIONS
After the battery is charged to its highest capacity, and then used on
the radio. If the radio still shows low power, please change a new
battery pack.
Do not short-circuit the battery terminals or throw the battery into fire.
Never attempt to remove the casing from the battery pack.
Batterypacks are not charged when they are shipped.Charge
them before use.
Initially charging the battery pack after purchase or extended
storage (longer than 2 months) will not bring the battery pack to its
greatest capacity or its normal charge, which can be done only after
repeated charging and discharging two or three times.
The average use time of battery pack is 16 hours.
CHARGING NOTES(2)
Plug the AC adapter into the back of the
charger.Then plug the power cable of the
adapter into 220V power.
Slide the Li-ion battery pack or radio with a Li-ion
battery pack into the charger.
Make sure the battery pack is in connected withthe
charging terminals.
When charging begins, the RED LED light displays.
When the battery packischargedtoits greatest
capacity, GREEN LED light displays.
After the GREEN LED light displays, take the battery pack or the portable
radio out of the charger.

45
Slide the battery pack into the back of the radio in the direction of the
arrow ( ), then lock itwiththe battery release button.
Slide the battery pack until the battery releasebutton makes
a clicking sound." "
Turn off the radio before releasing the battery pack.
Push the battery release button in the direction of the arrow()as shown
below.
The battery pack is then released.
ATTACHING THE BATTERY PACK
RELEASING THE BATTERY PACK
Conveniently attaches toyour belt.
Attach the belt clip with the supplied screws
using a phillips screw driver.
INSTALLING BELT CLIP
INSTALLING EXTERNAL SPEAKER/
MICROPHONE
Insert the speaker/microphone plugs into the
speaker/microphone jacks.
The radio is not fully rain resistant while
using the external speaker/microphone.
PS:

67
DIAGRAM
Antenna connector
LCD display
Keypad
Jacklight
Power/Volume switch
Receive/Transmit
indicator lamp
Speaker
Microphone
Function key
Up key
Down key
PTT switch
Monitor
Jacklight switch
Ear/Mic jacks
Battery pack

89
P-1
P-2
P-3
Dual watch operation
Priority scan
DCS
CTCSS
Transmit indicator
Function key
Signal
TX/RC signal indicator
VOX transmit function
Priority scan channel
Repeater shift direction
Reverse function
U-U, V-V, U-V mode
Keypad sound
H /M / L p o we r
Frequency display
Scan function
Battery capacity indicator
Keypad lock
Battery capacity indicator (Full)
Note:
The rest capacity of the battery
The battery is exhausted, please
change a new battery or charge the
battery
Rece i ve s ignal indicator
LCD DISPLAY BASIC OPERATION
Turn the Power/Volume knob clockwise to turn
the power on. When you turn it on, it will beep
and the channel willdisplay on the LCD.
The LCD backlight shows. (P-1)
Turn Power/Volume knob counter-clockwise to
turn off the radio. (P-2)
Note:
Press and hold the Monitor button, thenrotate
thePower/Volume knob to turn up and down the volume.
To make a call, press and hold the PTT switch, then " "
speak into the microphone in normal speaking tone.
Hold the microphone approximately 1.5inches (3-4cm)
from yourlips.
Release PTT to receive signals. (P-3)" "

10
F+1
1
3
4
5
6
7
H/M/ L
F+2 RC .
***
F+3 TC .
***
F+4 + -
F+5 VO X.
*
F+6 RC .
***
F+7 R
P14
P14
-15
P15
-16
P16
P16
-17
P17
P18
2
11
8
9
10
11
13
14
15
F+8 SC R.
** MR/
VFO
F+9 DW
F+0+1 STP.
*** MR/
VFO
F+0+2 0.00000 MR/
VFO
F+0+3 BCL.
** MR/
VFO
12
F+0+4 TOT.
** MR/
VFO
F+0+5 DSP.
** MR/
VFO
F+0+6 PCH.
*MR/
VFO
自动
P18
P18
-19
P19
P20
P20
P21
P21
P21
-22
FAST MENU OPERATION FLOW
NO. Feature Fast key LCD
display Parameter Selectable
Confirm
VFO
mode Page
Power switch
Receive code
Transmit code
Frequency
deviation
VOX function
Code search
Reverse
Repeatedly
press F+1
Press BAND to
change the
mode and then
press or to
choose
Press BAND to
change the
mode and then
press or to
choose
Repeatedly
press F+4
Press or
Press BAND
to change
mode
Repeatedly
press F+7
H: (5W)
M: (2.5W)
L: (1W)
MR/
VFO
CTCSS (67.0-254.1)
DCS (D023N-D754N)
DCS (D023I-D754I)
MR/
VFO
CTCSS (67.0-254.1)
DCS (D023N-D754N)
DCS (D023I-D754I)
+/-/ No disp lay
1-9 level/OFF
MR/
VFO
CTCSS (67.0-254.1)
DCS (D023N-D754N)
DCS (D023I-D754I)
PTT
Press
MR/VFO
confirm.
Press
F+MR/
VFO
channel
store
R/No d ispla y
Auto Auto
Auto
Auto
Auto Auto
Auto
Auto Auto
NO. Feature Fast key LCD
display Parameter Selectable
Confirm
VFO
mode Page
ON/O FF
DW: ON
Nodisplay: OFF
5/6.25/10/12.5/
15/20/25/30/50/
100KHz
0-69 .995M Hz
choo se
ON/O FF
1-9 level, 60s/
level OFF
CH/F R/NA
thre e kinds o f
mode
Voice scrambler
Dual watch-
operation
Channel step
Frequency
deviation
Busy lock
Time-Out-Timer
Channel display
mode
Priority scan
Press or
Repeatedly
press F+9
Press or
Input numbers
directly
Press or
Press or
Press or
Press or
Any ch annel
can be s tored .
F+9
F or
PTT
F or
PTT
F or
PTT
F or
PTT
F or
PTT
F or
PTT
Auto

12 13
NO. Feature Fast key LCD
display Parameter Selectable
Confirm
VFO
mode
Page
16 F+0+7 W/N
*F or
PTT
MR/
VFO
F+0+8 DEL
H
* F or
PTT
F+0+9 RESET F or
PTT
F+ S PTT
F+ S PTT
F+MAIN
F+PTT TX 1750
F+LED F+
LED
WX
17
18
19
20
21
22
23
F+MON SQL.
* MR/
VFO
24
P22
P22
-23
P23
P24
P24
P25
P23
P23
-24
Wide/narrow
bandwidth
Channel delete
Reset
Upward scanning
Downward
scanning
Main/sub
channel shift
Sending 1750
signal
C r o s s - b a n d
receive/transmit
Squelch level
Top/bottom
rows display
shift
Press or
Press or
Press or
Press or
Press or
or input num-
bers directly
Repea tedly
press F +MAIN
W: 25k
N: 12. 5k
Any cha nnel
be sto red
Press MR/VFO, it
will display "RUST".
? to remind you wh-
ether you want to
delete.
Upwa rd
Down ward
Main /sub
Only t his
0-9: 9 L evels
0: Low est
9: Hig hest
Press
twice
MR/
VFO
Press
MR/
VFO
again
Auto
Auto
Auto
Auto
Auto
Auto
Repea tedly
pre ss F+PTT
Any setting within
frequency range
P23
NO.Feature Fast key
LCD
display Parameter Selectable
Confirm
VFO
mode Page
25
26
27
F+MR/
VFO SAV H
**
Shift
between
F0,F1,
F2,F3,F4
S F+MR/
VFO
F+MR /VFO
MR/
VFO
agai n
MR /
VF O
F+MR/
VFO
F0-F4
32
33
MR/
VFO
_Glitters
F+BAND
29
30
31
28
P25
P26
-27
P27
P27
P27
P28
P28
P28
P28
-29
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Channel store
Keylock
"↓"shift
Frequency
bands shift
Jacklight
FM Radio
Press F
long
P ress
MAIN
P r e s s
BAND
Directly input
when on
frequency
mode
F * and
chan nel
shif t
"↓"up/
down row
shift
Press or ,
press BAND to
enter the next
letter
Press or
to directly
input number
Repeatedly
press MR/VFO
Press BAND
ON/O FF
Program by
computer or
direct input
Press MR/VFO, it
will display"SAVE".
?to remind you
whether to store
Press F for more than
2 seconds, you may
keylock or unlock
"↓"i ndi cates
ma in ch annel
F0 to F4
Displays: ON
Not Displays:
OFF
ON/O FF
Frequency range
88-108MHz
Letters (A-Z)
Numbers (0~9)
Symbols (+ * - /)
Scan list
additive
Channel
name edit
Chan nel/
Freq uency
Frequency
channel mode
shift

14 15
1. On standby mode, press + , the LCD will displays "RC.***"( as picture 2)
2. Press to change CTCSS/DCS, press OFF to turn it off.
CTCSS: 67.0-254.1
DCS: N023-N754 ( Normal DCS)
DCS: I023-I754 ( Inverse DCS)
3. Press or to choose the code.
4. After setting, press to confirm, then it will automatically turn back to the
standby mode.
NOTICE
FUNCTION INSTRUCTION
1POW
F
M 06 440.02500
M 01 46.0250 0
H
This model has double-frequency-display function. On frequency mode, it can show two
different receiving and transmitting frequencies at the same time; on channel mode, it
can display two different channels and their related parameters at the same time.
On frequency or channel mode, press"MAIN"to shift between main channel and sub
channel. If"↓"points to main channel, then all of the operations are processed with main
channel frequency or channel; if"↓"points to sub channel,then all of the operations are
processed with sub channel frequency or channel.
Transmitting Output Power Choose (H/M L)-----Menu 1
Using this function may choose the transmitting output power.
1. On frequency mode, press and , the LCD will displays as picture 1.
3. When setting is finished, it would be back to standby state automatically.
2. Operating it repeatedly may shift between (H) 5W, (M) 2.5W, (L) 1W.
NOTICE
2RX.
T
BAND
MR/
VFO
F
RC.off
M 01 46.0250 0
H
Picture 2
NOTICE
There are 50 groups DCS and 208 Normal/inverse DCS. See the attached list (P30-P31).
On each channel, CTCSS/DCS may be used and set together.
Transmitting CTCSS/DCS Setting (TX) -----Menu 3.
1. On standby mode, press + , the LCD displays"TC.***" (as picture 3).
F3TX.T
Using the function may set your personal private and prevents disturbance from
others or matching with the code of other radios.
MR/
VFO
2. Press to shift between CTCSS/DCS (see Menu 2).
3. Press or to select.
4. After setting, press to confirm, and then it would automatically return to
standby mode.
BAND
tC.off
M 01 46.0250 0
H
Picture 3
NOTICE
There are 50 groups CTCSS and 208 Normal/inverse DCS. See attached list (P30-31).
On each channel, CTCSS/DCS may be used together.
On channel mode, the output power may be changed directly. But changing channels or
turn the power on, it will make it back to the initial setting.
Choosing high power may improve the calling quality; low power may lower the radiation
and usage of battery.
Receiving CTCSS/DCS Setting (RC)-----Menu 2
Using the function may set your personal private and prevents disturbance from others
or matching with the code of other radios.

16 17
1. On standby mode, press + to enter, the LCD displays as picture 5.
2. Press or to choose VOX level, which has levels (OFF~9), OFF.
(1) is the lowest level, (9) is the highest level.
3. After setting is finished,press to confirm, then the system will
automatically return to standby mode. ( LCD displays as picture 6).
1. On frequency mode, press + , the LCD displays as picture 4.
2. By operating it repeatedly, you may select frequency deviation mode between (+) (-).
Frequency deviation mode.
a. If trasmitting frequency is higher than receiving frequency , it is normal direction (+).
b. If trasmitting frequency is lower than receiving frequency, it is inverse direction (-).
c. Signal without (+) (-) means it has no setting.
3. After setting, the system will confirm automatically
F4RPT
M 06 440.02500
M 01 46.0250 0
H
Picture 4
+
Fequency Deviation Setting (+/-)-----Menu 4
This function is a way used with repeater or other working stations.
NOTICE
Select correct frequency deviation direction according to the station you use.
This function is invalid under channel status.
F5VOX
MR/
VFO
vox 3
M 01 46.0250 0
H
Picture 5
H
M 06 440.02500
M 01 46.0250 0
VOX
VOX Function-----Menu 5
When this function is on, the system will inspect your talking to the microphone and
then it will automatically shift to transmitting mode without manual operation.
This function is more convenient for headset users.
Picture 6
1. On frequency mode, press + to enter, the LCD displays "RC.***" .
( as picture7).
2. Code scanning is started.
3. Press to change the code mode, after searching the code, it would stop
automatically.
Code mode: CTCSS: 67.0-254.1 (CTCSS)
DCS: NO23-N754 (Normal DCS)
DCS: I023-1754 (Inverse DCS)
4. After setting, press to confirm. Press PTT to return to standby mode.
NOTICE
The higher the level is , the higher the sensitivity of microphone is.
When scanning, FM radio or dual watch, this function is invalid.
F6SEAR
BAND
Rc.670
M 01 46.0250 0
H
Picture 7
MR/
VFO
Research CTCSS/DCS Code (RC)-----Menu 6
Using this function may search and store the CTCSS/DCS code other radios
send. When other stationshas the same frequency but different CTCSS/DCS.
BAND
FMR/
VFO
If one of the code modes doesn't search code, press to change the code
mode and search again.
If you want to store to channel mode, press + (see Menu 26).
Reverse (REV)-----Menu 7
NOTICE
When using this function, the receiving and transmitting frequency will reverse,
together with the CTCSS/DCS set.

1. O n stan dby mo de, press + + to enter, the LCD di spla ys "STP.**".
2. P ress o r to cho ose. There are 5/6.25/10/12.5/15/20/25/30/50/100khz to choose.
3. Af ter se ttin g, press to confirm. Press or PTT to ret urn to s tandby mode.
18 19
1. On standby mode, press + to enter, the LCD displays "R". (as picture8)
2. Operating it repeatedly means turning on or off.
3. After setting, the system will confirm automatically, and return to
standby mode.
1. On standby mode, press + to enter, the LCD displays DW (as picture 9).
2. Repeatedly press + , you may choose"ON"or "OFF”.
3. After setting, the system will automatically confirm. At this time, the main and sub
channels have been in dual-watch.
4. If you want to return to standby mode, press + , the LCD will not show "DW".
F7REV
H
Picture 8
M 06 440.02500
M 01 46.0250 0
R
F8SCR
MR/
VFO
NOTICE
REV is available only when in different frequencies. This function is invalid when in
the same frequency.
Voice Scrambler (SCR)-----Menu8
This function may guarantee the secracy of your talk, that is: when in voice scrambler
talking, other radios without voice scrambler can receive your signal but can't hear your
talking content.
1. On standby mode, press + to enter, the LCD displays "SCR.OFF".
2. Press or to choose "ON" or "OFF".
3. After setting, press to confirm and it would automatically return to standby mode.
NOTICE
Com mu nica t ion i s ava ilab l e onl y whe n two rad io s ha v e vo i ce sc ra mble r at t he sa me ti me .
Vo i ce s c ramb l er b o ard i s nee de d be f ore v oice scr a mble r.
Dual Watch Operation (DW)-----Menu9
Example: Main channel frequency is 460.125MHz, sub channel frequency is151.235MHz.
Want to set dual watch, operates it as following:
9DW
9DW
F
F
Picture 9
M 05 460. 2500
M 02 5 .23500
DW
1. On standby mode, press + to enter, the LCD displays DW (as picture 9).
2. Repeatedly press + , you may choose"ON"or "OFF”.
3. After setting, the system will automatically confirm. At this time,
the main and sub channels have been in dual-watch.
4. If you want to return to standby mode, press + , the LCD will not show "DW".
Example: Main channel frequency is 460.125MHz, sub channel frequency is151.235MHz.
Want to set dual watch, operates it as following:
9DW
9DW
F
9DW
F
F
H
Picture 9
M 05 460. 2500
M 02 5 .23500
DW
NOTICE
If any channel or frequency receives signal, you must reply in 7 seconds. Otherwise
the radio will return to dual-watch mode.
If sub channel doesn't receive a signal, only the main channel can transmit normally.
You should exit this function before changing the data and information of other
frequencies and channels.
F0SET 1POW
MR/
VFOF
NOTICE
Channel Step (STP)-----Menu 10
Using this function may choose the correspond step frequency to the radio you want to set .
On channel mode, this function setting is invalid.
Frequency Deviation-----Menu 11

1. On standby mode, press + + to enter, the LCD shows "TOT.***".
2. Press or to choose time-limit level. The TOT of this radio may set 60-
540seconds, and has 1-9 grades, level 1 is 60 seconds, level 2 is 120 seconds, infer
from this. OFF is turning off.
3. After setting, press to confirm. Press or PTT to return to standby mode.
1. On standby mode, press + + to enter, the LCD displays "BCL.***".
2. Press or to choose"ON" or "OFF".
3. After setting, press to confirm, press or PTT to return to standby mode
When this function is on, you may prevent interrupting other radios that are talking. If the
selected channel is being used by other radios, when you press PTT , the radio you use
will beep, and LCD displays "BUSY". Release the PTT , "BUSY" wil disappear and
return to receiving mode.
21
20
This function is to limit the continuous long-time transmitting. When the continuous
transmitting time exceeds the time you set, the transmitting will be stopped, and you
will hear a beep, LCD displays”OVER" (as picture 10).
Using this function, you may set deviation between receving and transmitting.
Generally, only repeaters use this. The frequency deviation of this radio is : 0-69.995MHz
1. On standby mode, press + + to enter, the LCD displays "0.00000".
2. Press numbers to input the frequency deviation you want to set. If you want to input
5MHz, input 0,5,0,0,0.
3. After setting, press . Press or PTT to return to standby mode.
F0SET2RX.
T
MR/
VFOF
NOTICE
Setting direction of freqeuncy deviation, please see Menu 4.
F0SET3TX.T
MR/
VFOF
Busy Channel Lock (BCL)-----Menu 12
NOTICE
The turning-on of this function may affect your normal talk.
H
Picture 10
M 06 over
M 01 46.0250 0
Time-Out-Timer (TOT)---Menu 13
F0SET4RPT
MR/
VFOF
Channel Display Mode (DSP)-----Menu 14
Using this function may choose the LCD display in your favor.
1. On channel mode, press + + to enter, the LCD displays"DSP.**"
2. Press or to choose, there are 3 display ways to choose.
5VOX
F0SET
a. CH: channel number display ( as picture 11).
b. FR: channel frequency+channel number display (as picture 12).
c. NA: channel name+channel number display ( as picture 13).
3. After setting, press to confirm, press or PTT to return to standby mode.
MR/
VFOF
NOTICE
H
Picture 11
ch - -06
ch - -0
M 06 440.02500
M 01 46.0250 0
M 06 QFC
01 CH--0
This function is invalid on frequency mode.
The display of channel name can't be shown until channel name edit is finished,
otherwise it would display as channel number. For steps of channel name edit,
please see Menu (25).
H
Picture 12
H
Picture 13
Priority Scan (PCH)-----Menu15
Using this function may monitor the channel and frequency usage of other radios and
check the activity of a prior channel/frequency.
Example: if the radio sets 5 channels, you want to set CH-00 as priority channel.
1. On channel mode, press + + to enter, the LCD displays "PCH.**".
2. Press or to choose "0" channel. LCD displays "PCH.0" or directly input number
0,0,0.
6SEAR
F0SET

3. After setting, press to confirm, it would remind you whether you would delete.
LCD displays "DEL?"
4. If you want to delete, press to confirm again.
1. On standby mode, press + + to enter, the LCD displays "W/N.*".
2. Press or to choose W(wide 25k) or N( narrow 12.5K). After setting, press to
confirm. Press or PTT to return to standby mode.
22 23
3. After setting is finished, press to confirm. Press or PTT to return to standby
mode.
4. If you want upward priority scan, press + + . LCD displays "PRI.T". LCD
channel displays: 00→01→00→02→00→03 ......
If you want downward priority scan, Press + + . LCD displays"PRI.T". LCD
channel displays: 00→05→00→04→03→02 ......
MR/
VFO F
FF
NOTICE
This function is invalid in frequency state
Scanning steps may refer to Menu (19)、(20).
Wide/Narrow Bandwidth (W/N)-----Menu 16
This fucntion is used to set the working band of radio.
FF
7REV
F0SET
MR/
VFO
F
NOTICE
The radio normally uses wide band.
Channel Delete (DEL)-----Menu17
This function is used to delete channels and information of the radio.
1. On channel mode, press + + to enter, the LCD displays "DEL. 0H”
2. Press or to choose the channel you want to delete, or directly input number.
Example: If you want to delete CH-01, then input 0,0,1.
F0SET8SCR
MR/
VFO
MR/
VFO
RESET---Menu18
1. On standby mode, press + + to enter, the LCD displays"RESET" ( as
picture 14).
2. Press to confirm, it will remind you whether to reset. LCD displays"SURE?"
3. If you want to reset, press to confirm
F0SET9DW
MR/
VFO
H
Picture 14
RESET
M 01 46.0250 0
MR/
VFO
NOTICE
After resetting, the channels and information that the radio has stored will all be
deleted and return to VFO mode.
Upward/Downward Scanning------Menu 19&20
Using this function may monitor the frequency of other radios, and check
the activity of a certain channel frequency.
1. On frequency mode, press + or is general scanning. According to
the step frequency you set, you may scan upward or downward.
2. On channel mode, press + or is general scanning. According to
the channel you set, you may scan upward or downward. Press again,
you may shift to priority scan.
F
F
F
NOTICE
For priority scan, refer to Menu 15.
Main/Sub Channel Shift----Menu 21

24 25
Using this function may shift between main and sub channels when in frequency or
channel mode. On standby mode, press + , the frequency or channel will shift
the top or bottom row. But the "↓"of the upper row main channel will not shift, the
frequency/channel that "↓"shows is still the main channel. (as picture 15)
H
M 06440.02500
M 01 46.0250 0
M 01 46.0250 0
M 06 440.02500
Picture 15
H
FMAIN
Transmitting 1750Hz Call Tone-----Menu 22
This function is used to turn on a transmitting signal by European users.
Cross-Band Receiving/Transmitting Working Shift-----Menu 23
1. On standby mode, press +LED, the LCD displays "WX" (as picture 16). "↓
"shows receiving freqeuncy. Without "↓"is transmitting frequency.
2. Press to shift.
3. Then press +LED to exit the setting of this funciton.
Example: If the frequency of main channel is 148.875, the frequency of sub
channel is 468.875.
a. Press +LED, "↓"shows on main channel 148.875 (as picture 17). Now 148.875
is receiving frequency,while 468.875 is transmitting frequency.
b. Press , "↓"shows on sub channel 468.847 ( as picture 18) shows.
Now 468.875 is receiving frequency, 148.875 is transmitting frequency.
F
MAIN
F
F
Picture 16
H
M 06 440.02500
M 01 46.0250 0
wx
Picture 17
H
M 04 48.8750 0
M 03 468.87500
wx
Picture 18
H
M 04 48.8750 0
M 03 468.87600
wx
MAIN
NOTICE
FM radio: Only receiving is acceptable, see the FM radio frequency details Menu 33.
Once this function is on, other functions are invalid until you exit, and you’ll hear"beep".
Squelch Level Setting-----Menu 24
This function makes the squelch level"ON"or"OFF"via choose the signal level of radio.
1. On standby, press key + MON , the LCD will displays"SQL *" (as picture 19).
2. Press key or to choose the squelch level from 0-9.
F
Picture 19
H
SQL 4
M 01 46.0250 0
NOTICE
Setting the high squelch level will make failure receiving of weak signal, contrarily,
it will be interferred by other noise or signal if the squelch level is too low.
Channel Name Edit-----Menu 25
This function can enable you to edit your desired letters on the channel storing mode,
it's convenient to distinguish other users.
1. On the main channel mode, press + . (as picture 20).
2. Press or to choose the character,and then press to set next character.
The channel name makes up of the following:
26 letters: A - Z 10 numbers: 0 - 9 4 symbols: (-) (+) (*) (/)
3. Press to confirm and return to the standby mode.
FBAND
BAND
MR/
VFO
NOTICE
The channel name can edits as many as 6 characters. (Any 1-6 characters of
channel name is acceptable).
Choose the (-) symbol means this character is empty.
For channel name display see Menu 14.
Picture 20
H
M 06 UHF
M 01 46.0250 0

Press key each time, the "↓"symbol will display in turn between the main
frequency/channel and sub-
frequency/channel. Next you can change the frequency or data such as frequency、
channel number、output power、 CTCSS/DCS code and so on.
Example: Channel 3 (same frequency).
Receiving frequency: 466.675MHz CTCSS: 71.9KHz
Transmitting frequency: 466.675MHz CTCSS: 71.9KHz
Channel 5 (different frequency)
Receiving frequency: 465.575MHz
Transmitting frequency: 460.575MHz CTCSS: 88.5KHz
First, storing channel 3:
a: The radio on frequency working mode, input key 4、6、6、6、7、5 ordinal.
b: Press key + , and then press key to enter the CTCSS mode(see Menu 2).
Press or to choose the receiving CTCSS 71.9, then press key to confirm.
c: Press key + , and then press key to enter the CTCSS mode(see Menu 3).
Press or to choose the transmitting CTCSS 71.9, then press key to confirm.
d: Press key + , and then press or to choose the channel number "SAV.3H".
e: Press key again to confirm. It doesn't operate the b and c step if you don’t set the
CTCSS.
Next, storing channel 5:
a: The radio on frequency working mode,input key 4、6、5、5、7、5.
b: Press key + , and then press key to enter the CTCSS mode
c: Press or to choose the transmitting CTCSS 88.5, and then press key to
confirm.
26 27
Channel Storing-----Menu 26
When the radio on the frequency working and standby mode, input the desired
frequency and parameters.
1. Press key + , the LCD will displays"SAV**H". (as picture 21).
2. Press key or to choose the channel number.
3. Press key to save or not, the LCD will displays"SAVE?". (as picture 22).
4. Press key to save again.
FMR/
VFO
MR/
VFO
Picture 21
H
sav 2h
M 01 46.0250 0
Picture 22
H
save ?
M 01 46.0250 0
F2RX.
TBAND
MR/
VFO
F3TX.T
BAND
MR/
VFO
FMR/
VFO
MR/
VFO
F3TX.TBAND
MR/
VFO
MR/
VFO
d: Press key + repeatedly until the repeater shift direction shows (-). (see Menu 11).
e: Press key + + , and then input key 0、5、0、0、0 ordinal.
f: Press key to confirm.
g: Press key + ,and then press or to choose the channel number "SAV.5H".
h: Press key again to confirm.
4RPT
F
2RX.
T
F0SET
MR/
VFO
MR/
VFO
F
MR/
VFO
NOTICE
MR/
VFO
Press key to shift the radio between frequency and channel mode after setting.
Frequency and Channel Mode Shift-----Menu 27
This function is mainly shift the frequency and channel mode of the radio.
Press key each time, the radio will shift between frequency and channel mode.
MR/
VFO
NOTICE
The frequency and channel mode shift can be done only when the LCD shows a"↓"symbol.
Keypad Lock-----Menu 28
Press key more than 2 seconds, keypad lock; operate again, keypad unlock. (as picture 23).
F
M 06440.0 2500
M 01 46.0250 0
H
Picture 23
"↓"Symbol Switch-----Menu 29
MAIN

Using this function can choose the channel you setting is to scan or not.
1. On the channel mode, press key + , the LCD displays "S", it means the
channel accept scan.
2. Press key + again to exit, the LCD will not displays"S", it means the channel
you choose is not in scanning.
28 29
Frequency Band Shift-----Menu 30
This function is convenient to choose the frequency band of the radio.
1. On the frequency mode,press key each time to choose the frequency band. The
LCD displays "F*".
BAND
Scan list-----Menu 31
FMR/
VFO
FMR/
VFO
NOTICE
For scan function see Menu 15、19、20.
Jacklight-----Menu 32
Press key , the jacklight turn on; operate it again, the jacklight turn off.
FM Radio-----Menu 33
On the frequency mode, input the FM frequency of the radio, the FM frequency range:
88-108MHz.Example: FM frequency: 88.1MHz
1. On the frequency mode . (as picture 24).
2. Input number key 0、8、8、1、0、0 directly. (as picture 25).
H
F0 00.0000 0
08 440.02500
H
F0 88. 0000
08 440.02500
Picture 24
NOTICE
The FM frequency also can be stored in the channel.
PC Programmable
The radio can be programmed by computer. For operation details see QS PC software.
The Annunciation Of No Transmitting
1. If busy channel lock, LCD displays "BUSY".
2. If PLL unlock, LCD displays "LOST".
3. If the battery voltage is lower than normal, LCD displays "LOW".
4. If Time-Out-Timer, LCD displays "OVER".
5. If it is in the frequency: 470-519.995MHZ, LCD displays "DIS".

30 31
CTCSS
1
2
3
4
5
6
7
8
9
10
11
1 2
1 3
1 4
1 5
1 6
1 7
1 8
1 9
2 0
2 1
2 2
2 3
2 4
2 5
2 6
2 7
2 8
2 9
3 0
3 1
3 2
3 3
3 4
3 5
3 6
3 7
3 8
3 9
4 0
4 1
4 2
4 3
4 4
4 5
4 6
4 7
4 8
4 9
5 0
6 7 . 0
6 9 . 3
7 1 . 9
7 4 . 4
7 7 . 0
7 9 . 7
8 2 . 5
8 5 . 4
8 8 . 5
9 1 . 5
9 4 . 8
9 7 . 4
1 0 0 . 0
1 0 3 . 5
1 0 7 . 2
1 1 0 . 9
1 1 4 . 8
1 1 8 . 8
1 2 3 . 0
1 2 7 . 3
1 3 1 . 8
1 3 6 . 5
1 4 1 . 3
1 4 6 . 2
1 5 1 . 4
1 5 6 . 7
1 5 9 . 8
1 6 2 . 2
1 6 5 . 5
1 6 7 . 9
1 7 1 . 3
1 7 3 . 8
1 7 7 . 3
1 7 9 9
1 8 3 . 5
1 8 6 . 2
1 8 9 . 9
1 9 2 . 8
1 9 6 . 6
1 9 9 . 5
2 0 3 . 5
2 0 6 . 5
2 1 0 . 7
2 1 8 . 1
2 2 5 . 7
2 2 9 . 1
2 3 3 . 6
2 4 1 . 8
2 5 0 . 3
2 5 4 . 1
.
DCS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
43
44
45
46
47
48
49
50
5
1
52
53
54
55
56
57
58
59
60
61
62
63
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
1
00
101
102
103
104
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
D023N
D025N
D026N
D031N
D032N
D036N
D043N
D047N
D051N
D053N
D054N
D065N
D071N
D072N
D073N
D074N
D114N
D115N
D116N
D122N
D125N
D251N
D252N
D255N
D261N
D263N
D265N
D266N
D271N
D274N
D306N
D311N
D315N
D325N
D331N
D332N
D343N
D346N
D351N
D356N
D364N
D365N
D532N
D546N
D565N
D606N
D612N
D624N
D627N
D631N
D632N
D654N
D662N
D664N
D703N
D712N
D723N
D731N
D732N
D734N
D743N
D754N
22
23
24
25
26
27
28
29
30
31
32
33
34
64
65
66
67
68
69
70
71
72
73
74
75
76 105
106
107
108
109
110
111
112
113
114
115
116
117
147
148
149
150
151
152
153
154
155
156
157
158
15
9
D131N
D132N
D134N
D143N
D145N
D152N
D155N
D156N
D162N
D165N
D172N
D174N
D205N
D371N
D411N
D412N
D413N
D423N
D431N
D432N
D445N
D446N
D452N
D454N
D455N
D462N D023I
D025I
D026I
D031I
D032I
D036I
D043I
D047I
D051I
D053I
D054I
D065I
D071I
35
36
37
38
39
40
41
42
77
78
79
80
81
82
83
84
118
119
120
121
122
123
124
125
16
0
161
162
163
164
165
166
167
201
202
203
204
205
206
207
208
D212N
D223N
D225N
D226N
D243N
D244N
D245N
D246N
D464N
D465N
D466N
D503N
D506N
D516N
D523N
D526N
D072I
D073I
D074I
D114I
D115I
D116I
D122I
D125I
D331I
D332I
D343I
D346I
D351I
D356I
D364I
D365I
D703I
D712I
D723I
D731I
D732I
D734I
D743I
D754I
168
169
170
171
172
173
174
175
176
177
178
1
7 9
180
181
182
183
184
185
186
187
188
D131I
D132I
D134I
D143I
D1 45 I
D152
I
D155I
D156
I
D162I
D165I
D172I
D174I
D205I
D212I
D223I
D225I
D226I
D243I
D244I
D245I
D246I
D371I
D411I
D412I
D413I
D423I
D431I
D432I
D445I
D446I
D452I
D454I
D455I
D462I
D464I
D465I
D466I
D503I
D506I
D516I
D523I
D526I
189
190
191
192
193
194
195
196
197
198
199
200
D251I
D252I
D255I
D261I
D263I
D265I
D266I
D271I
D274I
D306I
D311I
D315I
D325I
D532I
D546I
D565I
D606I
D612I
D624I
D627I
D631I
D632I
D654I
D662I
D664I

32
RX:136-174MHz，400- 0 MHz
GENERAL
Frequency
sensitivity
Rated Voltage
Memory channel
Antenna disposition
Antenna impedance
Working manner
5PPm
DC7.2V (rechargeableLi-ionbattery)
Frequency range
SPECIFICATIONS
110mmX56mmX37mm
-122dB(12dB SINAD)
≥60dB ≥55dB
≥65dB ≥60dB
0.5W
<10%
≥85dB
≥65dB
200 channels
Inductivelyloadedantenna
Samef reque ncysin gleoperation or
differ entfre quencysingleope ratio n
10W/4W/1W
16K F3E /11K F3E
<5k/< 2.5kHz
<7uW
6dB
<2.8A (H10)
0.75kHz±50Hz,
0.37kHz±30Hz
12mV
Outputpower
<5%
(wide/narrow)
Intermodulation
TRANSMITTER RECEIVER
Spuri ous radiation
Modul ation character
Emiss ion current
Spuri ous rejection
Sensi tivity
Audio f requency power
Audio d istortion
Block ing
Adjacent channel selectivity
50
All stated specifications are subject to change without notice or obligation.
Modulation mode
(wide/narrow)
Maximum
CTCSS /DCS
devia tion(wide/narrow)
Modul ation sensitivity
Modul ation distortion
TX:1 44-148MHz，420-450M Hz
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
52
