QuantAsylum QA450 User’s Manual
Programmable 4/8 Ohm Load
SW Release 1.11
January 2019

QuantAsylum QA450 User’s Manual
Page 2
Safety Notice
❖This device is not designed for working on potentially dangerous voltages.
❖This device is not designed for working on high energy circuits.
❖Know and understand the voltage and current limits for each input
❖See additional safety notices throughout this document.
Limited Warranty
This product has a limited warranty for 6 months from the time of purchase. During this time, a device
failure that occurs under normal operating conditions will be replaced or repaired for free, not including
shipping. Generally, you will be responsible for shipping to us, and we will be responsible for shipping it
back to you.
Devices that have suffered a failure due to operation in excess of specified parameters can usually be
repaired for a nominal fee.
The contents of this document are provided “as-is” and may be changed or updated without notice. The
specifications on a particular product may also be changed at any time and without notice as we seek to
improve a product or improve availability of a product.
The limit of our warranty will not exceed the value of the product purchased under any conditions.

QuantAsylum QA450 User’s Manual
Page 3
Contents
SW Release 1.11........................................................................................................................................1
October 2018 ............................................................................................................................................1
Safety Notice.................................................................................................................................................2
Limited Warranty..........................................................................................................................................2
Legal..............................................................................................................................................................5
In the Box ......................................................................................................................................................5
Important Things to Know ............................................................................................................................5
Ground Reference.....................................................................................................................................5
Current Sense Inputs.................................................................................................................................5
Load Inputs................................................................................................................................................5
QA450 Programmable Load Features...........................................................................................................6
QA450 Front Panel........................................................................................................................................6
Front Panel Summary................................................................................................................................6
LEDs...........................................................................................................................................................6
Current Sense Inputs.................................................................................................................................7
DUT Power Soft Start ................................................................................................................................7
Load Inputs................................................................................................................................................8
BNC Outputs..............................................................................................................................................8
QA450 Software............................................................................................................................................8
Application Temperature Sensing.............................................................................................................9
Application Current Sensing......................................................................................................................9
DUT Power ................................................................................................................................................9
Fault Conditions......................................................................................................................................10
QA450 Load Resistors .................................................................................................................................10
Audio Bursts............................................................................................................................................11
Low Temperature Operation ..................................................................................................................11
Soft-Start.....................................................................................................................................................12
Thermal Considerations..............................................................................................................................12
Impact of Switchover..............................................................................................................................13
Appendix I: Typical Connection Diagram....................................................................................................14
Appendix II: QA450 Specifications..............................................................................................................15

QuantAsylum QA450 User’s Manual
Page 4

QuantAsylum QA450 User’s Manual
Page 5
Legal
This document and the associated computer codes, hardware design and hardware configuration files
are copyright © 2011 - 2018 by QuantAsylum USA LLC. All rights are reserved. You may share the
associated documents in PDF format freely. The EXE programs and code in the developer section is for
use only with QA products. The hardware and software designs are protected and the property of
QuantAsylum USA LLC.
In the Box
Your QA450 box contains the following:
•QA450 Programmable Load
•Power supply and Speaker connectors that mate with the QA450. These are installed on the
QA450 and can be removed by gently pulling.
Installation software, this manual, and application notes for the analyzer are available on the web at
http://www.QuantAsylum.com.
Important Things to Understand
Ground Reference
The QA450 USB interface shares a ground with the PC. The load portion and current sensing portion of
the analyzer does not. You should measure, and from time to time confirm, that the BNC grounds are
electrically isolated from the USB grounds.
This isolation is limited to 50V. Do not connect the QA450 to a product that has its ground reference
more than +/-50V from the PC ground.
Current Sense Inputs
The QA450 has a 3-wire current sense connector (S+ from power supply, S- to DUT, and DUT GND) for
monitoring the high-side DC supply of an amplifier. The voltages on the S+ pin of this connector must
not exceed 50V DC and must be greater than 5V to ensure switching control. The DUT GND pin of this
connector must be connected to your DUT ground. All of these pins are isolated from the PC/USB
ground. Isolation is measured to be >10 GOhm at 1 KV.
WARNING: Do not plug/unplug an amplifier power supply when using the current sensing AND the
green DUT LED is active. On very large amplifiers, this can cause hundreds of amps to flow for hundreds
of microseconds which may destroy the high-side switch. Always ensure the green LED is off before
connecting amplifiers. See the second below
Load Inputs
The load inputs are isolated from the PC/USB subsystem and also from the current sense subsystem.
You will connect the amplifier outputs to the L- and L+ inputs for the left channel, and the R- and R+
inputs for the right channel.
Depending on your specified settings, the QA450 will present either a 4, 8 or open load to the amplifier.

QuantAsylum QA450 User’s Manual
Page 6
When 4 or 8 ohm loads are selected, attenuated (by 6 dB) versions of the speaker signals will appear at
the BNC outputs of the QA450. For example, the L- speaker input will appear at the L- BNC output,
attenuated by 6 dB.
If you are using a single-ended amplifier, then the negative load inputs the QA450 must be connected to
the DUT ground.
QA450 Programmable Load Features
The QA450 features:
•Programmable load values of 4, 8 or infinite (open) ohms.
•Current sensing of amplifier DC supply.
•On/off control of the DC supply via high-side PMOS switch
•Power handling up to 300W (duration limited)
•Current limiting of supply for accidental shorts (trips when >15A for more than 2mS)
•Soft-start, allowing gentle turn-on of the amplifier DUT
•First order filter to limit the slew rate of “filterless” class D amplifiers
We hope you enjoy your purchase! Check back from time to time for new software updates.
QA450 Front Panel
This section covers the various connectors on the analyzer and reviews the input and/or output
characteristics of these connectors.
Front Panel Summary
The front panel is shown in the picture below. From left to right, the following items are explained.
LEDs
Link LED This LED indicates the QA450 is connected to the PC and talking to the QA450
application.
8 Ohm LED This LED indicates the QA450 is presenting an 8 ohm load at the load inputs
4 Ohm LED This LED indicates the QA450 is presenting a 4 ohm load at the load inputs

QuantAsylum QA450 User’s Manual
Page 7
DUT Power LED This LED indicates if the high-side switch is enabled or not. If the LED is flashing
rapidly, then soft-start is in process.
If both the 8 and 4 ohm LEDs are flashing, then it means the QA450 has reached a thermal limit. This is
not harmful to the QA450. When this happens, the QA450 will open the relays automatically and ensure
the load inputs are removed from the internal load resistors.
Current Sense Inputs
The QA450 uses an isolated Hall sensing device to measure the power supply DC. The positive terminal
of the amplifier’s DC power supply flows into the S+ pin on the front panel, is sensed by the Hall sensing
device, and then flows out of the S- terminal to the amplifier (see Appendix I Connection Diagram). The
Hall sensor used is an Allegro Micro ACS711, with +/- 15A of measurement range. On the QA450, only
positive current (from DC supply to the amp) are reported. If a negative current is measured, it is
clamped at 0 amps.
For the high-side PMOS switch to work, the DUT GND must be connected. Additionally, the voltage
controlled by the switch must be at least 5V (S+ to DUT GND) and not exceed 50V (S+ to DUT GND). If
the voltage is too low (less than 10-15V), the PMOS switch cannot be fully turned on. If the voltage is too
high (more than 50V) internal components may be overstressed and could fail. The QA450 is designed to
operate continuously at 50V and can withstand normal transients excursions above 50V.
The current sensing is not required to be used. For example, if you are testing Class D amplifier boards, it
might make sense to use the current sense and power the boards from a fixed external supply. But if
you are testing finished amplifiers that run from AC, then the DC measurement provided by the QA450
isn’t useful and can be skipped.
ATTENTION! DO NOT CONNECT THE CURRENT SENSE CONNECTOR WHEN THE DUT LED IS ON!
Do not swap amplifier boards when the DUT LED is on!
If your power supply and amplifier both have massive capacitors, and you connect the amplifier while
the DUT power is enabled, then potentially hundreds or even thousands of amps can flow through the
high-side switch and cause it to fail as the charge is re-distributed
The Current Sense connector on the QA450 is a Molex 39536-0003. The mating connector is a Molex
39534-0003. This connector has a rating of 300V and 15A per pin.
Do not exceed the 10A RMS rating or 15A max rating of the Current Sense subsystem.
DUT Power Soft Start
When the DUT Power is activated, the DUT Power LED will flash rapidly for 1 second. This indicates that
soft-start is underway. During soft-start the DUT amplifier is connected to the high-side rail (S+) through
a 10 ohm resistor. This allows amplifiers with very large filter caps to charge at current levels that won’t
stress components in the power supply, the QA450 and the DUT amplifier. A large amplifier might have
10 mF of bulk capacitance. The RC time constant of the 10 mF and 10 ohm is 100 mS. Thus, the one-
second soft-start allows 10 time constants of soft-start to elapse before bypassing the soft-start resistor.
See the discussion below on Faults for more analysis.

QuantAsylum QA450 User’s Manual
Page 8
Load Inputs
The load inputs are where the amplifier/DUT will connect. The loads are switched internally by relays
rated for 12A at 250VAC and 12A at 24VDC. The loads are DC coupled, but it’s expected that ONLY AC
signals will be presented to the QA450. Given the QA450 maximum ratings, the voltage on the load
inputs must not exceed 50VAC RMS
The maximum currents at the QA450 maximum ratings occur when the load is set to 4 ohms at 300W.
This corresponds to an 8.66A RMS current.
The Load Input connector on the QA450 is a Molex 39536-0004. The mating connector is a Molex 39534-
0004.
Do not exceed the 200W for 220 mS rating of the Amplifier Load subsystem.
BNC Outputs
The BNC outputs are attenuated version of the load inputs. The attenuation is 6 dB. This means if your
amplifier is 10 dBV = 3.16Vrms (as measured with DVM in AC mode across L+ and L-) and the QA450
load is set for 8 ohms, then the QA450 will be dissipating (3.16^2)/8 = 1.24W. The BNC outputs will
measure 6 dB lower, which would be 4 dBV = 1.58Vrms
The first order low-pass filter in the QA450 has its corner at 34 KHz.
QA450 Software
The QA450 will appear on your PC as a “HID” device with a USB VID:PID of 0x16C0:0x4E2C. It doesn’t
need drivers. It will show up in the Device Manager as a “HID-compliant vendor-defined device.”
When you first plug in the QA450 device, Windows should spend a bit of time configuring the device.
Download and install the QA450 application from Github. After launching the application, you should
see the following UI:
In the title bar, you can see the version of the software, shown here as 1.11. In the status bar, we can
see the hardware device is “opened” and that this is firmware version 24. You will be alerted if the
firmware version is incorrect and given a chance to re-flash the QA450 hardware. It is important to NOT
use the application if the firmware version is reported as incorrect as malfunctions could occur.

QuantAsylum QA450 User’s Manual
Page 9
When the QA450 and application are “talking”, should see the “LINK” LED on the QA450 hardware
illuminated.
If you press the “8 Ohms” button, you will hear a “click” from the QA450 relays and the application will
report the 8 ohm load is active as shown below. At this point, you can use a DVM to measure across the
L+ and L- Load Input pins and confirm that 8 ohms is being presented. You can repeat the experiment for
4 ohms, too, and also for the right channel.
Pressing an illuminated load button again will turn the loads off. When both the 4 and 8 ohm buttons
are off, then the QA450 presents an “infinite” or open load to the amplifier. Note that when the QA450
is open, the QA450 +/- outputs are meaningless. That is, the input signals cannot be measured when the
loads are disconnected.
Application Temperature Sensing
On the right side of the QA450 application, you can see the temperature for both the left and right
channels. Generally, under normal operation, these temperatures must remain under 60C. Above 60C or
below 5C, the QA450 will disconnect the loads and require time to cool down or warm up. The sensors
are very accurate and respond very quickly. Generally, as long as you do not impart more than 300W of
power per channel, you do not need to worry about harming the QA450. It will self-protect. The
temperature readings are provided for information only.
Application Current Sensing
The QA450 reports the current measured by the Current Sensing subsystem. The resolution is around 30
to 40 mA. That is, you will see readings jump by perhaps +/- 20 mA. For high-power amplifiers that might
draw 10A or so, this generally isn’t a problem. Of course, if you want to measure an amp with a max
current of 100 mA, then this resolution can contribute significant errors.
DUT Power
The DUT POWER button is used to the turn on the high-side PMOS in the QA450. When enabled, the S+
and S- will be connected by a low impedance of 25 mOhms or so. This is Rds(on) of the high-side PMOS
pass device.
If the QA450 application is closed or stops responding, or if the QA450 is disconnected from the USB,
then the QA450 will automatically open the load relays and disable the load power.

QuantAsylum QA450 User’s Manual
Page 10
Fault Conditions
If absolute current exceeds 15A for more than 2 milliseconds, the high-side PMOS will be disabled. A
fault will be reported on the QA450 application and the USB power must be removed and re-applied to
clear the fault and restore normal operation.
If the DUT GROUND wire is lost due to broken lead or disconnect, then you will lose the ability to turn
the DUT POWER on, and it will revert to OFF if currently ON. The DUT POWER LED will still appear
functional, however.
QA450 Load Resistors
The QA450 uses a special type of load resistor called a “Pulse Withstanding” load resistor. These are
specially formulated resistors built on metal substrates designed to handle extremely large pulses of
power for very short periods of time. They are non-inductive.
An example resistor used for the QA450 is the Bourns PWR163 series. The QA450 has 16 of these
resistors—8 per channel. When presenting an 8 ohm load, four 2 ohm resistors per channel are used
(4S1P). When presenting a 4 ohm load, eight 2 ohm resistors per channel are used (4S2P). There are half
as many resistors used when presenting an 8 ohm load versus a 4 ohm load. This has implications for
maximum power handling.
The PWR163 resistors are each rated to handle 25W when the case temperature is 25C. That 25W figure
is de-rated by about 15% as the backplate temperature reaches 50C. If the resistors are near room
temperature and the QA450 is configured for 4 ohms (8 resistors), then you can hit the load with 8 * 25
= 200W for several seconds until the thermal protection kicks in. The temperature will quickly rise over
several seconds and further de-rating will be necessary as it increases. When the resistor temperature
exceeds 60C, the QA450 will self-protect and disconnect the loads.
The PWR163 spec also shows the pulse power rating, reproduced here:

QuantAsylum QA450 User’s Manual
Page 11
For 1 second, the spec has prescribed 25J (25W * 1sec @ 25C). For 100 mS, we see a single load resistor
can handle 10J of energy. Note that 1J = 1W for 1 second, and thus 10J = 100W for 100 mS. So, the array
of 8 resistors (when configured as a 4 ohm load) can handle 800W for 100 mS. If using as an 8 ohm load,
this this figure is 400W for 100 mS.
Tabularizing the observations above, we see the following:
The table above shows regions that may overstress the QA450 and should be avoided. For example, the
resistors would survive an 85 mS burst of audio—which is a 2K FFT @ 48Ksps—at 114W per R. This
would deliver 916W into the load. But this would result in 15.1A of connector current and 60Vrms.
These overstresses are marked in red. Limiting the max load power to 200W for 220 mS into 8 ohms and
4 ohms provides a reasonable reliability margin. This is an 8K FFT.
The temp sensing on the QA450 has a lag. If the load resistors are hit with 800W for 100 mS, then the
temperature of the resistor active area will climb very quickly while the temp sensor located 2-3 mm
away from the resistor body will remain unchanged. Because of this lag, the 200W figure must not be
exceeded as the QA450 won’t be able to protect itself quickly enough. But at power levels below 200W,
the QA450 can fully protect itself and you don’t need to worry about harming the QA450.
Audio Bursts
The QA401 Audio Analyzer operates on bursts of audio. It is these bursted modes where the utility of
the QA401 and QA450 combine to allow thorough testing at high power levels.
The QA450 is obviously not the platform you’d chose for burning-in amplifiers. But a test suite that has
an average power level of 4-5W can run continuously without stressing the QA450.
Low Temperature Operation
The temperature sensors used on the QA450 are absolute sensors with a tolerance around +/-1%. The
QA450 firmware expects to see a temperature of at least 5 degrees. This ensures the sensors are
properly communicating with the CPU. If the ambient temperature is near 5 degrees, the QA450 will not
allow load control.

QuantAsylum QA450 User’s Manual
Page 12
Soft-Start
The QA450 is designed to enable very low-cost audio testing bays. The idea is that expensive lab-grade
programmable power supplies can be replaced with commodity open-frame power supplies. For
example, a 1KW fixed 48V power supply with fixed current limiting is under $100, while a 1 KW
adjustable lab supply with programmable current limiting costs several thousand dollars.
To make use of these low-cost fixed supplies in a test environment where a new board is being fixtured
for test every minute, the ability to control the power supply is needed. If the supply is left on
continuously, when the operator “plugs in” the board to be tested extremely high currents will flow as
the massive amplifier capacitors charge. These currents can easily reach hundreds of amps,
overstressing components.
The QA450 provides an “on/off” switch for supplies up to 50V. This allows a commodity fixed power
supply to be used in the test bay. While the operator is connecting the amp to be tested, there won’t be
any arcing or high currents flowing because the power to the amp is off due to the QA450 switch.
When instructed to turn on, the QA450 will always apply a 1 second “soft start” where the amp is
connected to the power supply through a 10 ohm resistor. During this time, the massive amp capacitors
can charge though the 10 ohm resistor. After 1 second, the 10 ohm resistor is bypassed and the amp is
directly connected to the supply. This happens automatically when the QA450 power switch is enabled.
If the amp has bulk capacitance greater than 10 mF or so, then the 1 second soft start time may not be
enough. Assume for a moment you are running an amp with 50 mF of bulk capacitance. When the
power switch is turned on, an RC circuit comprised of the 10 ohm soft-start resistor and the 50 mF bulk
capacitance begins to charge. One time constant will be 10 * 50 m = 500 mS, and thus after one time
constant the voltage will have risen to 31.6V. At that point, the 10 ohm is bypassed and the current
increases rapidly leading to an overcurrent condition.
If you have more than 10 mF of bulk capacitance, and you are getting overcurrent warnings when
turning on the switch, contact us at the support alias and we can work to help solve the problem.
Thermal Considerations
The QA450 is NOT designed for sinking 10’s of watts for long periods of time. The QA450 cannot
dissipate the heat that comes from those power levels. The QA450 is designed for high-speed testing of
amplifiers. That is, you will subject the amplifier to many short bursts of audio, typically around 1-2
seconds each. The power levels of these tests may be anywhere from milliwatts to hundreds of watts.
The average power you subject the QA450 to must be around 5-10W or so. That is, if you compute the
watt*second product of your tests, and then divide that by your total test time (including operator
change over to the next amplifier), then the average should be around 5-10W to ensure continuous
operation. This depends somewhat on your factory. If you keep the factory near 25C with good airflow
you can be closer to the 10W figure, otherwise, the 5W figure might be more appropriate.
The table below shows what a test plan might look like. Test #1 would subject the board to 300W for a
short test of THD at max power (300W). Test 2 might look at THD at 100W, and test 3 perhaps 50W.

QuantAsylum QA450 User’s Manual
Page 13
Subsequent tests would focus more on noise measurements, IMD, and other parameters at a typical
listening level.
Finally, “switchover” in the table below refers to the time it takes an operator to remove the amplifier
that was just tested and replace it with another amplifier. The 20 second figure used in the table below
suggests a very fast switchover operation, most likely automated and extremely high volume. The test
flow below suggests a 15 hour (2-shift) production of 1200 amplifiers tested per day per test bay.
Impact of Switchover
The impact of switchover time is significant in the average power calculation. If the switchover time is 2
minutes, due in part to an operator managing several bays and a fully manual switchover, then the
average power drops to 1.5W.
In summary, you need to plan your thermal budget ahead of time to ensure the QA450 can meet your
needs. Hitting the thermal targets above will ensure continuous operation without having to wait for
cooldowns.
Because the QA450 can also report the temperature to other applications via the REST web interface,
it’s also possible to program your test flow to wait for the temperature to fall below a threshold before
you begin testing a new amplifier.

QuantAsylum QA450 User’s Manual
Page 14
Appendix I: Typical Connection Diagram

QuantAsylum QA450 User’s Manual
Page 15
Appendix II: QA450 Specifications
Current Sense Inputs
S+ Max Voltage (normal operation)
50V (relative to DUT GND)
S- Max Voltage (normal operation)
50V (relative to DUT GND)
USB Isolation
>10 GΩ@ 1KV
Max Current
10A RMS continuous, 15A peak
Trip Current
>15A for 2 mS
Soft Start
10 ohm for 1 second
Load Inputs
Load Options
4 and 8 ohms
Max Voltage on any pin
50Vrms AC relative to DUT GND
Max Current on any pin
10Arms
Max Power into Load Inputs
200W per channel for 220mS
Load Tolerance
+/- 5%
USB Isolation
>10 GΩ@ 1KV
Output
Attenuation
6 dB
Frequency Response
F3db = 34 KHz
Output Impedance
~100 ohms
General
Interface
USB, 12Mbps
Power
USB, < 500 mA
Ambient Operating Temperature
15 to 30C
