Quantum QF72 User manual

QUANTUM QFLASH MULTI BRACKET QF72/73
INSTRUCTIONS
The Multi Bracket is used to mount Qflash in the center of an umbrella, to mount Qflash in a light box, and to
mount a Radio Slave with Qflash either as a remote stationary flash or roving flash.
Supplied with QF72
Tilting
Umbrella
Clamp
"L" Bracket
Supplied with QF73 - user already has an umbrella clamp, or wishes to mount without umbrella.
"L" Bracket
For use with Auto flash mode - Qflash sensor aimed at the subject!
To set up Qflash with an umbrella - for use in a manual flash mode or TTL:

To use Qflash and Radio Slave as a remote flash - either on a tripod or roving:
The "L" bracket has threaded holes for 1/4" and 3/8" threads.
