Quark-Elec QK-A026 User manual

6. Connect via WiFi if desired
You can connect to our wireless products in 2 ways...
Disclaimer: This product is designed to aid navigation and should be used to augment normal navigational
procedures and practices. It is the user’s responsibility to use this product prudently. Neither Quark-elec, nor
their distributors or dealers accept responsibility or liability either to the product user or their estate for any
accident, loss, injury or damage whatsoever arising out of the use or of liability to use this product.
Email: [e-mail]
V1.1(10/19)
QK-A026
Ad-hoc mode WiFi (direct A026 to phone/tablet/PC) is the default setting, this requires no
Windows configuration.
 On your device (phone/tablet/PC): 15 seconds after the A026 has powered up, you can scan
for a WiFi network with an SSID similar to ‘QK-A026xxxx’. Connect the device to ‘QK-
A026xxxx’ with the default password: ‘88888888’.
 In your chart software: set the protocol as ‘TCP’, IP address as ‘192.168.1.100’ and the port
number as ‘2000’ in the chart software.
Station mode WiFi (A026 through a router/access point - to phone/tablet/PC) allows you to
access your data at the same time as your other WiFi network data. This option requires
configuration to set up the connection between the A026 and your router. See the
‘Configuration’ section of the manual and configuration instructions on the CD provided.
7. You can adjust baud rates if needed
To change the baud rate from the default settings (input 4800bps and output 38400bps), adjust
these settings using the Configuration software.
See the ‘Configuration’ section of the manual and configuration instructions on the CD provided.
Ad-hoc mode WiFi Station mode WiFior
SET-UP GUIDE
 What You Need
 Installation Overview
 Notes
QK-A026
WIRELESS AIS RECEIVER
WITH GPS + WIFI
All products are CE, RoHS certified
www.quark-elec.com
Please recycle your packaging

This is an overview only. Familiarize yourself with the manual and the manuals of
any connecting devices before installation. It is always recommended that
electronic equipment be installed by an experienced installer.
QK-A026
BEFORE LEAVING HOME:
We recommend pre-installing the Configuration software and drivers if needed, as you might not
have a CD reader/internet access on site.
Driver and Configuration software are optional and only needed for specific features.
If you will access data on a Mac/Linux/Windows PC:
 Driver required for Windows. If using Windows 10, the driver should install automatically, if
not, it is included on the Free CD and at Quark-elec.com.
 Driver not required for Mac or Linux.
If you will connect to the A026 through Station mode WiFi: (e.g. through a router, see page 4)
 Configuration software (Windows) required. Driver may be required as above.
If you will adjust NMEA 0183 baud rates: The NMEA 0183 baud rates are set to 4800bps (input)
and 38400bps (output) as default, as these are the settings used by most input and output NMEA
devices. You can adjust the baud rates if desired, using the Configuration software.
 Configuration software (Windows) required. Driver may be required as above.
Configuration Software and specific instructions are on the FREE CD and at www.quark-elec.com.
INSTALLATION
1. Mounting: Consider your location…
 Dry, sturdy location 0.5m from other WiFi equipment.
 Ensure you have the correct length of cables needed for VHF, GPS and the 5.0V power via
micro USB. If drilling holes for your cabling, seal around any holes to prevent damage to your
vessel or equipment.
2. Connect your Antennas: VHF and GPS
 Connect VHF: If you want to use one VHF antenna for both AIS and radio (or other purposes),
then you will need an active splitter. An active splitter will protect the A026 and your other
VHF equipment (VHF radio). If not, the two signals will significantly damage each device
connected as well as reducing the signal.
If using two VHF antennas, place them as far away as possible from each other (at least 3
metres).
 Connect GPS if desired: The GPS antenna should be located outside where the sky is visible
for best results.
3. Connect Power
The A026 uses 5.0V power. This is connected via a micro USB. USB cable is provided. This can
connect to a mobile or PC. If a mobile electronic device isn’t available then we recommend using
your vessels battery power. The power must be 5.0V, any higher will damage the A026.
4. Check LED lights are working on the A026
Flashing green lights indicate a valid signal is coming through the A026 from either GPS or AIS.
Power: Top LED (red) flashes at 3 second intervals.
AIS：Middle LED flashes for each valid message received.
GPS：Bottom LED flashes every second while valid message received.
QK-A026
We do not recommend using a cigarette charger.
A low noise power connecter designed for marine applications is available at
www.quark-elec.com/12to5vconverter
5. Disconnect power and connect NMEA input and output if desired
Connect the ‘+’ and ‘-‘ terminals of the NMEA input/output on the A026 to the ‘+’ and ‘-‘
terminals of the output/input on the instrument.
The A026 uses NMEA 0183-RS422. If your connecting device uses the older NMEA 0183-RS232
and you are having issues with your NMEA connection, you may find swapping these
terminals works for your device. Alternatively, connect it using a Quark-elec Protocol
Bridge (QK-AS03).
