Quatro Bio-scan b300 User manual

30 Hymus Blvd., Pte-Claire, Quebec, Canada H9R 1C9 Tel.: (514) 630-4444 Fax: (514) 630-4454

“Fresh-Air” Purifier

Bio-Scan B300 & Bio-Scan B301

Instruction Manual

------------------------------------------------------------------------------------------------------------------------------------------------------------

1- INTRODUCTION

Congratulations! You are now owner of a QUATRO purifier, an advanced effective purifier, designed specifically for the human respiratory system. You can expect

a noticeable improvement in air quality as the unit begins the process of reducing microscopic airborne particulate, dust, harmful gases, smoke, pollen etc.

2- SAFETY PRECAUTION

Read all of the instructions contained within this manual before operating this unit. Keep this manual, as it contains information for proper operation and

maintenance. Keep all fastening hardware tight to ensure that the unit is in safe working condition. Familiarise yourself with the way in which filters are installed &

replaced. All filters must be in place whenever this machine is in operation. Use only on a grounded electrical circuit; do not use any two-wire electrical prong

adapters to defeat proper grounding. If servicing the unit, be careful not to touch the motor as soon as it has been turned off. It is hot and can cause injury. Do

not substitute any other filters odor granules.

3- ALWAYS UNPLUG FROM SUPPLY BEFORE DOING ANY MAINTENANCE OR FILTER SERVICE

Upon arrival, inspect unit for either visible or concealed damage. Damage should be immediately reported to the transport company.

4- PRE START-UP CHECKLIST

a) All filters are present and are correctly installed prior use;

b) Labels and serial numbers are present for future identification;

c) Verify that power supply is compatible with equipment. Check the unit is plugged into a grounded receptacle;

d) The casters (wheels) must be secure in place prior the moving the air purifier.

5- START-UP

a) Place the air purifier in the desired area for use. Ensure all filters are installed;

b) Make sure the air intake area (bottom) is not obstructed in any way.

c) Insert male end of power cord into grounded circuit;

d) Turn power toggle switch to "HIGH" position.

e) Air purifier should now be functioning and operational; WARNING: DO NOT OPERATE UNIT UNLESS ALL FILTERS ARE IN PLACE.

6- OPERATION

Unit is designed to remove light odor (B301) and dust particles (large & small) that are suspended in the air. Particles will enter the unit at the top, and clean fresh

air exits at the bottom. This unit is designed to operate 24 hours per day, 7-days a week. The unit must operated at its highest speed for optimum performance.

Quatro’s “FILTER ALERT” Warning System will advise you when the unit is not operating at its peak efficiency, and maintenance must be performed. When the

filter is spent, light on the Control Panel will illuminate, advising you to replace filter.

7- FILTER MAINTENACE

Bio-Scan (B301-Odor & HEPA Air Purification) Bio-Scan (B300-HEPA Air Purification)

Part No.: Stage # Filter Type Repl. Intreval Part No.: Stage # Filter Type Repl. Intreval

F071(6/bx) Stage I Dust Filter Every 6 months F073 (2/bx) Stage I Dust Filter Every 12 months

Nc-gpc Stage II Odor Granule refill When odor is detected F075 Stage II Hepa Filter 24 months

F075 Stage III Hepa Filter 24 months

7- SPECIFICATIONS

Dimensions, Height: 26.25”(667mm) Voltage / Current 120/1/60 / 1.0amps

Dimensions, Width: * 12.75” (324mm) Max. Power Consumption: 85watts

Dimensions Length: 15.75” (400mm) Approx. Weight: 48lbs (22kgs)

QUATRO

Air Technologies Inc.

8 - FILTER REPLACEMENT – Bio-Scan…B301

Proper maintenance is critical to extend the life of the filtration system. QUATRO has therefore included in this unit a “FILTER ALERT” Warning System. When the

appropriate Filter Replacement Indicator Illuminates, it is time to replace the filter. The information presented below outlines basic maintenance procedures

ensuring the unit will provide trouble-free operation for years to come.

Stage I (Top) DUST FILTER p/n F071

- Change the Dust Filter approximately every 6 months depending on the dust level in the area;

- To do this, turn OFF the unit. Unplug from wall outlet, unlatch the top section and remove;

- Replace with new Dust filter (make sure air flows are pointing up) Secure top back into position and both latches . The airtight seal should be maintained.

Stage II (Middle)**Filter Tray Odor Granules

It is important the odor granules be replaced immediately upon any detection of odor from air purifier.

(odor granule, refill only, p/n NC-GPC)

To refill tray with new odor granules:

a) Ensure that the unit is unplugged, unlatch top section and remove.

b) Pull out filter tray and discard any remaining odor granules, refill with new odor granules.

c) Put filter tray back into position (Stage II / middle). Secure top back into position and both latches. The airtight seal should be maintained.

Stage III (Bottom) HEPA p/n F075

- Under typical applications, should last approximately between 24 to 36 months (depending on applications);

- To do this, turn OFF the unit . Unplug from wall outlet. Unlatch the top section and remove;

- Remove Dust Filter (F071) and odor filter (F072-GPC), Pull out HEPA Filter and replace;

9- FILTER REPLACEMENT – Bio-Scan B300

Stage I (Top) HiCapacity DUST FILTER p/n F073

- Change the Dust Filter approximately every 12 months depending on the dust level in the area;

- To do this, turn OFF the unit. Unplug from wall outlet, unlatch the top section and remove;

- Replace with new Dust filter. Secure top back into position and both latches. The airtight seal should be maintained.

Stage II (Bottom) HEPA p/n F075

- Under typical applications, should last between 24 to 36 months (depending on applications);

- To do this, turn OFF the unit . Unplug from wall outlet. Unlatch the top section and remove;

- Remove Dust Filter (F073), Pull out HEPA Filter from the top;

10- RESETTING FILTER LIGHTS

When filters need to be replaced, the filter light illuminates and beeper sounds for 2 seconds every 4 hours.

After replacing filters, WHILE THE UNIT IS OPERATING, reset filter lights as follows:

1) To go into FILTER RESET MODE, hold down UP & DOWN Speed Arrows until panel “BEEPS” (in 5 seconds). Once panel BEEPS, appropriate Filter

Replacement Light(s) flash.

- To RESET LIGHTS: HOLD DOWN arrow UP until panel BEEPS, or

- to go to next light below press arrow DOWN

- If you HOLD DOWN arrow UP until panel BEEPS to reset the light, next light will automatically flash if it requires to be reset.

If no other filter needs to be replaced (no other light is on), unit automatically goes to OPERATION MODE.

(If you need to return to light that was skipped over while in Filter Replacement Loop, continue pressing arrow DOWN to get out of Filter Replacement Loop.

Go to 1) & press arrow UP/DOWN until it BEEPS & start over.

12- SPEED CONTROL

- Dial in desired level of speed (Note: faster speeds provide superior levels of air purification)

13- MOTOR SERVICE

- The motor is brushless. No user motor maintenance is required .

14- ANNUAL GENERAL INSPECTION

Every 12 months, verify that all gaskets (seals) are in proper condition. Should the gaskets adhere to the filter, lubricate its surface with a transparent grease

or petroleum jelly. Should the unit be relocated continuously for optimum efficiency, ensure all casters (wheels) are tightly fastened and secure.

QUATRO

Air Technologies Inc.

15- TROUBLESHOOTING GUIDE

Symptoms Possible Cause Suggested Solution

Unit will not start Faulty Power supply

Return or supply grille blocked

HEPA filter improperly installed

Blown fuse

Unit not plugged into receptacle

Check breaker box

Remove obstruction

See Section 9, 10,11

Replace fuse

Plug unit in

Excessive noise Motor wheel contacting inlet ring

Fan isolators loose or off Realign/replace motor

Replace isolator

Insufficient airflow Obstruction in system or clogged filters Remove obstruction or replace filters

Excessive airflow Filters not in place Install filters

16- REDUCTION IN AIRFLOW

As the unit cleans the air, the filters are removing the particles of dust and dirt in the air. As the filters accumulate dirt (both visible and microscopic), a restriction on

the motor is created. As the restriction becomes greater, the air capacity delivered by the motor decreases and the air purification less effective. IT IS VERY

IMPORTANT TO CHANGE FILTERS ON A REGULAR BASIS (See filter maintenance above).

17- WARRANTY

QUATRO Air Technologies warrants its equipment to be free from defect in material and workmanship under normal use and service for a period of two year

from date of shipment. QUATRO's obligation under this warranty shall be limited to replacing any parts, thereof, which shall be demonstrated to have been

defective. This is expressly in lieu of all other warranties, express or implied, including the warranties of merchantability and fitness.

QUATRO claims no warranty as to merchantability or as to the fitness of the merchandise for any particular use and shall not be liable for any loss or

damage. No person, firm or corporation is authorised to assume for QUATRO any other liability in connection with the sale of these goods. Equipment, parts

and material manufactured by others and incorporated in QUATRO's equipment are warranted by QUATRO only to the extent of the original manufacturer's

liability to QUATRO Air Technologies Inc.

Conditions and Limitations:

This warranty does not cover abuse, misuse, maintenance negligence, improper assembly, acts of vandalism, acts of God, fear wear, modifications of the
