1. Introduction
The water resistant GL300VC is a powerful GPS/GNSS locator designed for lone worker,
vehicle, pet and asset tracking applications. The thumb sized button makes this device ideal
for applications requiring rapid notification of emergency alert or regular setting of
geo-fences based on current location. Its built-in GNSS receiver has superior sensitivity and
fast time to first fix. Its CDMA2000-1X allowing the GL300VC's location to be monitored in
real time or periodically tracked by a backend server and mobile devices. Its built-in 3-axis
accelerometer allows motion detection and extends battery life through sophisticated
power management algorithms. System integration is straightforward as complete
documentation is provided for the full featured @Track protocol. The @Track protocol
supports a wide variety of reports including emergency, geo-fence boundary crossings, low
battery and scheduled GPS/GNSS position.
Queclink
Confidential

GL300VC User Manual
TRACGL300VCUM001 - 5 -
2. Product Overview
2.1. Appearance
2.2. Buttons/Mini USB Interface Description
Button /Mini USB Interface Description
Power Key Turn on GL300VC

Turn off GL300VC when without charging. (If power key is
enabled)
Function Key Geo-Fence mode
Long press the key to enable/disable Geo-Fence ID0
Geo-Fence in current position mode
Long press the key to enable/disable Geo-Fence ID0. If
enable Geo-
Fence ID0, using the current position as the
center of Geo-Fence 0.
SOS mode (default)
Long press the key to active SOS alarm
Mini USB interface Connect a 5V DC adapter can power GL300VC and charge
the internal battery
Connect a 3.7V Li-ion or Li-
Polymer battery can power
GL300VC

Backend server developer or administrator can use the
Data_Cable_M to configure GL300VC
Queclink
Confidential

GL300VC User Manual
TRACGL300VCUM001 - 6 -
2.3. LEDs Description
There are three LED in GL300VC, the description as following.
2.4. External Power Interface
2.4.1 External DC Charger Interface
The Pin2 on Mini-USB connector are used for charging and named as VCHG pin, It can be
connected to a 5V DC power supply to power GL300VC and charge the internal battery.
LED Event State
CELL LED Searching network Fast flash
Network has been registered Slow flash
Power off Dark
SIM-PIN Locked Solid
Receives a valid protocol command Turn on for 3 seconds
<LED on> is 2
Dark
GPS LED GPS has fixed Solid
GPS is in fixing Fast flash
GPS is on and GPS data wrong Slow flash
GPS is off Dark
If <LED on> is 0, 150 seconds later after powers
on.
Dark
<LED on> is 2 Dark
PWR LED Power on and normal Dark
Charger inserted and charging completed Solid
Charger inserted and charging Fast flash
Power key was pressed and prepare to power off Fast flash
Abnormal Fast flash
Power low alert Slow flash
Power off or turn off the power light by
command
Dark
<LED on> is 2 Dark
Queclink
Confidential

GL300VC User Manual
TRACGL300VCUM001 - 7 -
2.4.2 External Battery Interface
The Pin 8 on Mini-USB connector is for external battery and named as EXTBAT pin, It can be
connected to 3.7V Li-ion or Li-Polymer battery to power GL300VC.
2.5. Ignition Detection
The Pin 7 on Mini-USB connector is for ignition detection when GL300VC is used in vehicle
tracking application, It is named as IGN_IND pin.
Queclink
Confidential

GL300VC User Manual
TRACGL300VCUM001 - 8 -
Another easy way is to connect PIN7 to a power output in the fuse box of the vehicle which
is only enabled after the vehicle is ignition on. For example: the power output for radio FM.
2.6. External Input Interface
The Pin 5 on Mini-USB connector is a negative trigger input in newer hardware version, It is
named as NSW pin.
For negative trigger input the electrical conditions are:
Logical State Electrical State
Active 0V to 0.8V
Inactive 1.7V to 32V or Open
An input example is shown as following figures:
Queclink
Confidential

GL300VC User Manual
TRACGL300VCUM001 - 9 -
Example of NSW pin connect to a panic button
3. Getting Started
3.1. Parts List
Name Picture Remark
GL300VC Locater The CDMA-1X/GPRS/GPS
locator.
AC-DC Power Adapter
(Standard accessory)
It is used to charge the
internal battery of GL300VC.
GL300VC Data Cable
(Optional accessory)
It is the USB data cable which
can be used for firmware
upgrading and configuration.
GL300VC External Cable
(Optional accessory)
It is the extend cable which
include the charger interface
and external battery interface
on GL300VC. It also includes
the ignition detection
interface on the GL300VC.
3.2. Battery Charging
Please connect AC-DC power adapter with GL300VC.
Insert the AC-DC power adapter into the power socket.
During charging, the PWR LED is flashing fast. When the battery is full charged, the PWR
LED will be Ever-light.
You can also charge the battery by USB cable which connects GL300VC with the PC.
Charging time is about 5 hours.
Note: Before the first time using GL300VC, please full charge the battery.
