HPi110 & HPi210 Quick Rig (QR) Systems
User
Manual

Introduction ......................................1
CAUTION .................................................1
Safety Matters and Precautions ...................... 2
Simple Hanging Without Accessories .................. 3
SAFETY TIP ...............................................3
Kit Summary .....................................4
Table 1: Ready to use Rigging Kits.............................4
Kit QR1: Fixed Wall Mounting without Panning ........... 6
Mounting The Speaker & Rigging System .......................7
Setting The Angle Of The Cabinet .............................8
Kit QR2: Fixed Wall Mounting Tilt and Pan .............. 9
Installation Spine ...........................................9
Installation of the Spine on the HPi110 .........................10
Setting the Angle of the Cabinet...............................11
Kit QR3: Horizontal Two Speaker Array ................. 14
Mounting the Speaker & Rigging System. . . . . . . . . . . . . . . . . . . . . . . . 15
Kit – QR4: Horizontal Tri Speaker Array................. 16
Mounting the Speaker & Rigging System. . . . . . . . . . . . . . . . . . . . . . . . 17
Kit – QR3X & QR4X: Extended Horizontal Arrays.......... 18
Controlling the Tilt of the Array................................19
Attaching the Brackets to the Boxes ...........................21
Kit – QRUB: HPi110 U-Bracket. . . . . . . . . . . . . . . . . . . . . . . . 22
Horizontal Mounting of a Single Speaker........................22
Mounting the Speaker & Rigging System. . . . . . . . . . . . . . . . . . . . . . . . 23
Configuring the Horn Flare Wave Guide for Horizontal Installation ...23
Summary of Separate Assemblies & Parts .............. 24
Separate Assemblies Table...................................24
Spare Parts Table ..........................................25
Fasteners .................................................25
Contents

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
1
CAUTION
• Avoid locating the speaker box in high traffic areas where people may be injured on the
equipment and cords, or incur injury due to very high sound pressure level.
• Do not operate the unit for an extended period of time with the sound distorting. This is an
indication of a malfunction, which in turn can cause heat to generate within the speaker box and
possibly result in a fire.
• Have the rigging and installation fittings checked periodically by a competent technician or
rigging specialist. Failure to do so may result in corrosion or damage to the speaker system and
rigging leading to a life threatening situation.
• Check that all elevated work platforms or other height access devices (ladders etc) will safely
carry the weight of the products to be elevated and the weight of the installation personnel
before starting the job.
Introduction
The HPi110/210 speaker system is designed for live mobile and permanent installation using a
hardware system to cover every installation environment and array configuration. The QR (Quick
Rig) system has been developed so that the majority of the hardware rigging options are designed
to suit both the HPi110 and HPi210 models.
The HPi110/210 can be flown with weight rated high tensile eye bolts inserted into the many
box inserts but this can only be done following the standard rigging conventions understood by
licensed riggers.
Kits are available to facilitate simple and tidy installations while more sophisticated configurations
can be achieved by adding optional components to the basic kits.
Quest Engineering recommends that all available rigging and bracket options be reviewed for your
installation as a successful audio installation is greatly enhanced by correct speaker positioning.
The rigging options give a wide range of choices to direct the sound to where it is needed and
the prospect of very fine and accurate adjustments in all directivity planes. Numerous speaker
configurations for one, two or three speaker options are available with the HPi110/210 series and
flying an array of up to three boxes is possible with variable angles between the boxes.
The HPi110\210 QR system aims to be the most versatile rigging system in the world.

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
2
Safety Matters and Precautions
• Avoid installing the mounting hardware on unstable structures, such as on un reinforced walls or
ceiling members that are not intended for carrying extra weight.
• Refer all installation work to the dealer from whom the speaker was purchased. Installation for
flying speaker systems requires extensive technical knowledge and experience. The speaker
or rigging hardware may detach if not correctly installed, resulting in serious injury to anybody
below.
• Be sure to follow the flying instructions exactly as described. Do not take shortcuts during the
installation and flying process. Identify any possible risks or hazards before beginning the setup\
installation. Time and care should be taken so as not to expose yourself or other workers to
danger with unsafe practices.
• Check to confirm that suspension wires are strong enough, correctly terminated and sufficient to
carry the total load with at least a 4:1 safety rating.
• The connectors of the suspension wires and belts must be securely linked with those of the
speaker or rigging hardware.
• All parts and components (such as enclosures, metal pieces, and screws) must be free from any
damage, cracks and\or corrosion.
• Be sure to use screws supplied with the optional flying hardware when installing any mounting
hardware or the speaker itself.
• Install the unit only in a location that can structurally support the weight of the unit and the
mounting bracket.
• When hanging a rigged array, be sure that at least two persons are available to install the unit.
Failure to do so could result in personal injury.
• Do not use other methods than those specified to mount the speaker boxes.
• Use nuts and bolts that are appropriate for the ceilings or wall’s structure and composition.
• Tighten each nut and bolt securely. Ensure that the hardware has no loose accessories.
• Use only the specified mounting brackets. No warranty is provided due to damage resulting from
a failure of after-market accessories.
• Do not mount the unit in locations exposed to constant excessive vibration. Fittings on the
mounting bracket or fly-ware may become loose causing components to detach and cause injury
below.

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
3
Simple Hanging Without Accessories
The structure and construction of the HPi110/210 allow for a variety of hanging possibilities.
Both the HPi110 and HPi210 include 9 x M10 lifting points, and as well as a pole mount plate, to
bring maximum flexibility even without additional accessories.
All points are either straight on the metallic handle or connected to an internal metal brace.
When hanging the box with eye bolts, rigging conventions dictate that the box must be attached
by two independent fixation points and both points must be able to carry the weight of the flown
installation plus the mandated safety factor.
Each Side:
2 points on the
aluminium handle.
Top 2 points
SAFETY TIP
On both HPi110 and HPi210, the safest
place to hook a safety link is to the
aluminium handle; particularly the rods
that join the handle to the speaker (as
shown here).

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
4
Kit Summary
The QR System includes various mounting options and components for the HPi 110/210. Whether
your requirements are for touring or highly specific installations, there is a perfect solution readily
available. Several kit options have been designed which include everything required for most
applications.
Name &
Reference Application In the Kit Kit Illustration
Kit QR1
Order Ref:
ACHPiQR1
• 1 Speaker
• Wall Mounting
• Tilt (0-30o)
• No Panning
• Wall-Mount
Assembly (fixed)
• i-Spine
• Quick pin 8x50
• Screws (2x M10)
Kit QR2
Order Ref:
ACHPiQR2
• 1 Speaker
• Wall Mounting
• Tilt (0-30o)
• Full Pan (-/+ 75o)
• Wall-Mount
Assembly
(swivelling)
• i-Spine
• Quick Pin 8 x 50
• Screws (2x M10)
Kit QR3
Order Ref:
ACHPiQR3
• 2 Speakers
• Hanging
• Variable Angle between
speakers
• Vertical Tilt (-10/+20˚)
• Hanging Plate 2
• Screws (4x M10)
Kit QR3X
Order Ref:
ACHPiQR3X
• 2 Speakers
• Hanging
• Variable angle between
speakers
• Extra vertical Tilt
(+25/+45˚)
• Hanging Plate 2
• Extension Arm
Assembly
• Screws (4x M10)
Kit QR4
Order Ref:
ACHPiQR4
• 3 speakers
• Hanging
• Variable angle between
Speakers
• Vertical Tilt (+15/+20˚
approx)
• Hanging Plate 3
• Screws (6x M10)
Table 1: Ready to use Rigging Kits

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
5
Table 1: Ready to use Rigging Kits (cont.d)
Name &
Reference Application In the Kit Kit Illustration
Kit QR4X
Order Ref:
ACHPiQR4X
• 3 Speakers
• Hanging
• Variable angle between
speakers
• Extra vertical Tilt
(+25/+45˚ approx)
• Hanging Plate 3
• Extension arm
assembly (x2)
• Screws (6x M10)
Kit QR5
Order Ref:
ACHPiQR5
• 2 speakers
• Vertical array
• Hanging
• Variable tilt of both
speakers
• t-Spine assembly
(includes 1 quick pin +
2M10 screws)
• i-Spine (includes 1
quick pin + 2M10
screws)
• Vertical link bar
HPi110
bracket
Order Ref:
ACHPiWB110
• 1 speaker
• Horizontal bracket
• Mounting on walls/ truss
• Variable angulations (-15˚
to 90˚ in both directions)
• Bracket frame
• Bracket bottom plate
• M6 flat head (x1)
• M10 flat head (x2)

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
6
The QR1 kit
(standard for fixed
wall mounting
installations) comes
complete and
assembled, with the
right screws and
bolts to install a
single HPi110.
The installation Spine (i-Spine) offers
a more elegant solution for permanent
installations. The row of holes at the rear
of the spine allows for vertical tilt when
wall-mounted.
The i-Spine comes with an M8x50 custom
Quick Pin (Q-Pin) as well as a pair of long
M10 counter sunk screws.
Ordering reference:
ACHPiATS
Option Note for QR-1
(Available as a separate component)
The touring Spine (t-Spine) is
recommended for a precise and easy
hanging setup of the speaker when
used when flying a single speaker.
The holes, on each side, allow for a
5o stepped tilt of the cabinet [from
-15˚ to +45˚] Only one rated shackle
is necessary to use the Spine in
most applications (a quick-pin is also
included with the t-Spine).
The t-Spine can also be used as part
of a more complex rigging system.
Primary applications include:
• Wall Mount applications where tilt is
not needed
• Vertically Arraying 2 Speakers
Kit QR1: Fixed Wall Mounting without Panning
Name & Reference Application In the Kit
Kit QR1
Order Ref: ACHPiQR1
• 1 speaker
• Wall Mounting
• Tilt (0-30o)
• No panning
• Wall-Mount assembly (fixed)
• Installation Spine
• Quick pin 8x50
• Screws (2x M10)

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
7
Mounting The Speaker & Rigging System
Installation of the Spine on the HPi110
NOTE: The 2 x M10 bolts supplied with both the i-Spine and t-Spine should replace the previously
installed screws in the speaker. The M10 bolts are designed with a longer thread which provides
increased strength and security to the system.
Remove the 2 top
screws that are
installed in the speaker
then insert the lip of
the Spine to grab the
casing handle.
1Swing it flat on the
top of the speaker.
2Bolt in and secure
(using Loctite or similar
fastener securing
compound) the Spine
onto the speaker with
the 2 x M10 bolts
included.
3
Installing an HPi110 becomes incredibly easy
with the QR wall-mounting system.
Once the spine has been installed (as
described above) install the wall-mount as
follows:
1. Bolt the wall mount assembly (without
the speaker attached) onto the wall.
2. Lift the speaker (now installed with
Spine) and hook it onto the wall-mount.
The wall-mount is designed to safely
support the weight of the box from this
point.
3. Set the angle by sliding the quick-pin
into the right hole (see next section for
angles).
HPi110 with
i-Spine
Fixed hook
assembly

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
8
Setting The Angle Of The Cabinet
Once the speaker has been mounted correctly, the angle at which the speaker will be fixed can be
adjusted by fitting the Q-Pin into the correct hole. Four angles are available:
HPi110 with Kit QR1 Standard HPi110 with Kit QR1 Long Side Plates
7.5 degrees 15 degrees 30 degrees0 degrees
The standard kit offers the possibility to hang
a speaker at 0˚ and 7.5˚.
If extra tilt (15˚ or 30˚) is needed, optional
extension plates can be purchased separately
and inserted in the wall-mount assembly.
Order Reference:
ACHPiEX2
Option Note for QR-1
(Available as a separate component)
• Take the medium side plates off the
assembly by removing the bolts.
• Use the same bolts, washers and
nuts for the long plates (all bolts,
washers and nuts should be re-used)
• Long side plates can be ordered
for adding ‘x’ of additional distance
from the wall. (sold separately)

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
9
QR2 Assembled Kit
(shown with the i-Spine) HPi110 with the
QR2 Kit
Installation Spine
The installation Spine (i-Spine) offers a more elegant solution for permanent installations. The row
of holes at the rear of the spine allows for vertical tilt when wall-mounted.
The i-Spine comes with an M8x50 custom Quick Pin (Q-Pin) as well as a pair of long M10 counter
sunk screws.
The kit QR1 (standard kit for fixed wall mounting installations) comes complete and assembled,
with the right screws and bolts to install a single HPi110.
Kit QR2: Fixed Wall Mounting Tilt and Pan
Name & Reference Application In the Kit
Order Ref: ACHPiQR2
• 1 speaker
• Wall Mounting
• Tilt (0-30˚)
• Full Pan (-/+ 75˚)
• Wall-Mount assembly (swivelling)
• i-Spine
• Quick pin 8x50
• Screws (2x M10)
Ordering reference:
ACHPiEX2
Option Note for QR-2
(Available as a separate component)
• Take the medium side plates off the
assembly by removing the bolts.
• Use the same bolts, washers and
nuts for the long plates (all bolts,
washers and nuts should be re-used)
• Long side plates can be ordered
for adding ‘x’ of additional distance
from the wall. (sold separately)

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
10
Installation of the Spine on the HPi110
NOTE: The 2 x M10 bolts supplied with both the i-Spine and t-Spine should replace the
previously installed screws in the speaker. The M10 bolts are designed with a longer thread
which provides increased strength and security to the system.
Primary Applications Include:
• Wall Mount applications where tilt is
not needed
• Vertically Arraying 2 Speakers
The touring Spine (t-Spine) is
recommended for a precise and easy
hanging setup of the speaker when
used when flying a single speaker.
The holes, on each side, allow for a 5o
stepped tilt of the cabinet [from -15o
to +45o]
Only one rated shackle is necessary
to use the Spine in most applications.
(A quick-pin is also included with the
t-Spine)
The t-Spine can also be used as part of
a more complex rigging system. Ordering reference:
ACHPiATS
Remove the 2 top
screws that are
installed in the speaker
then insert the lip of
the Spine to grab the
casing handle.
Swing it flat on the
top of the speaker.
Bolt in and secure
(using Loctite or similar
fastener securing
compound) the Spine
onto the speaker with
the 2 x M10 bolts
included.
12 3

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
11
Installing an HPi110 becomes easy with the
QR wall-mounting system.
Once the spine has been installed (as
described above) install the wall-mount as
follows:
1. Bolt the wall mount assembly (without
the speaker attached) onto the wall.
2. Lift the speaker (now installed with
Spine) and hook it onto the wall-mount.
The wall-mount is designed to safely
support the weight of the box from this
point.
3. Set the angle by sliding the quick-pin
into the right hole (see next section for
angles). HPi110 with
i-Spine
Fixed hook
assembly
HPi110 with Kit QR2 Standard HPi110 with Kit QR2 Long Side Plates
7.5 degrees 15 degrees 30 degrees0 degrees
Setting the Angle of the Cabinet
Once the speaker has been mounted correctly, the angle at which the speaker will be fixed can be
adjusted by fitting the Q-Pin into the correct hole. Four angles are available:
The standard kit offers the possibility to hang
a speaker at 0˚ and 7.5˚.
If extra tilt (15˚ or 30˚) is needed, optional
extension plates can be purchased separately
and inserted in the wall-mount assembly.

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
12
Adjusting and Locking Horizontal Pan.
The advantage of the swivelling assembly is the ability to set the pan angle from -75˚ to +75˚.
The cabinet can be locked in position by tightening the screw located on top of the pivot axis of the
rigging assembly.
Swivel of a HPi110 mounted on a kit QR2
Tighten the top screw
2
Turn the Cabinet
1
If more vertical angle is required, two optional
side plate can be inserted in the assembly
(replacing the medium plates), and give the
ability to either set the speaker closer to the
wall, or reach a down tilt of 15 or 30 degrees.
Exploded view of swivelling wall mount

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
13
Installation Examples
Tilt = 0˚
Pan=-30˚
Standard medium side plates
replaced by spacers (the
speaker is looser to the wall)
Tilt = 7.5˚
Pan=+30˚
Standard medium side plates
Tilt = 30˚
Pan=+45˚
Standard medium side plates
replaced by long plates

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
14
Kit QR3: Horizontal Two Speaker Array
The QR3 kit allows for a pair of HPi110 or HPi210 speakers to be hung horizontally with the utmost
of ease. The top plate has several fastening positions which provide several options for speaker
positioning providing complete control over the dispersion of audio.
The QR3 kit comes complete and assembled, with the right screws and bolts to install a pair of
HPi110 speakers.
Name & Reference Application In the Kit
Order Ref: ACHPiQR3
• 2 speakers
• Hanging
• Variable Angle Between Speakers
• Vertical Tile (-10/+20˚)
• Dual speaker hanging plate
• Screws (4x M10)
Kit QR3
HPi110 Installed with QR3 Kit
Option Note for QR-3 (Extended Horizontal kit – QR3X)
The QR3X includes an extension arm which increases the
array’s tilt to achieve angles between 15˚ up to 35˚.
For more information on the QR3X kit, please see The
section on Extended Horizontal Arrays.

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
15
Mounting the Speaker & Rigging System
The hanging plate for 2 speakers allows for 3 sets of angles.
For application where wider dispersion is required, the 2 speakers can be angled at 10˚ or 20˚ in
addition to the standard 30˚ when the speakers are positioned side by side.
Please ensure that regardless of the angle, each speaker is secured with 2 x M10 screws.
Installation Examples
2 HPi110 in a dual horizontal array : kit QR4 ; angle=30˚ (Standard)
2 HPi110 in a dual horizontal array : kit QR4 ; angle=40˚
2 HPi110 in a dual horizontal array : kit QR4 ; angle=50˚

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
16
Kit – QR4: Horizontal Tri Speaker Array
The QR4 kit allows for three HPi110 or HPi210 speakers to be hung horizontally with the utmost of
ease. The top plate has several fastening positions which allowing you to adjust the angles of the
left and right speakers providing complete control over the dispersion of audio.
The QR4 kit comes complete with the right screws and bolts to install three HPi110 speakers.
Name & Reference Application In the Kit
Order Ref: ACHPiQR3
• 3 speakers
• Hanging
• Variable Angle Between Speakers
• Vertical Tile (-15/+20˚)
• Two speaker hanging plates
• Screws (6x M10)
HPi110 Installed with QR4 Kit
QR4 Kit
Option Note for QR-4 (Extended Horizontal kit – QR4X):
The QR4X includes an extension arm which increases the
array’s tilt to achieve angles between 15˚ up to 35˚.
For more information on the QR4X kit, please see The
section on Extended Horizontal Arrays.

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual
HPi110 & HPi210 Quick Rig (QR) Systems
17
Mounting the Speaker &
Rigging System
The hanging plate for 3 speaker allows for 3
sets of angles. Installation Examples
For application where wider dispersion is
required, the 3 speakers can be angled at 15
o or 20o delivering an extremely simple to
install wide dispersion array solution.
Please ensure that regardless of the angle,
each speaker is secured with 2 x M10 screws.
Mounting the hanging plate:
1. Remove the 2 M10 screws at the top of
each speaker.
2. Place the hanging plate on top of the 3
speakers and align to the desired angles.
3. Bolt in the 6 M10 x35 counter sunk
screws included in the kit. (Add Loctite
to give additional fastener security)
Top view of 3 x HPi110’s installed with the QR4 kit.
Installation Examples

HPi110 & HPi210
Quick Rig (QR) Systems
User Manual HPi110 & HPi210 Quick Rig (QR) Systems
18
Kit – QR3X & QR4X: Extended Horizontal Arrays
The QR3X and QR4X kits include an extension arm which increases the array cluster’s tilt to
achieve angles between 15˚ and 35˚.
Name & Reference Designed For: QR-3 Kit Includes:
Order Ref: ACHPiQR3X
• 2 speakers
• Hanging
• Variable Angle Between Speakers
• Extra Vertical Tilt
• (-25/+45 o)
• Dual Speaker Hanging Plate
• Screws (4 x M10)
QR4X Kit
HPi110 Installed with QR4X Kit
Name & Reference Designed For: QR-4X Kit Includes:
Order Ref: ACHPiQR4X
• 3 speakers
• Hanging
• Variable Angle Between Speakers
• Extra Vertical Tilt (-25/+45 o)
• Tri speaker hanging plate
• Screws (6 x M10)
HPi110 Installed with QR3X Kit
QR3X Kit
