F133003 : Ragley Pro relax
Welcome
to your item instructions

2
Template version: 2
F133003 : Ragley Pro relax full instructions
Thank you for purchasing this product. At Quest we take every care to ensure that the
product fulfillies your expectations. We hope you enjoy using this product.
General Use
Failure to follow the general use instructions below could lead to damage to the chair or injury to
your person. Always read and follow these instructions when using the product.
• Always ensure that the arms are locked in position before leaning against the back of the chair.
• Always ensure all legs remain in contact with the ground and take extra care when using the
chair on uneven ground as this can lead the chair to move about.
• Children should always be under direct adult supervision when using this product and must not
be allowed to operate any folding or adjustable mechanisms.
• Keep hands away from folding parts to prevent entrapment. Take care when opening, closing
and or adjusting this product.
• Ensure that the side table is folded away before folding the chair.
• Do not force the product at any time, the product will fold away without the need for undue
force.
• Do not leave outside in severe weather conditions.
• Please retain all information for further reference

3
Instruction version: 1
F133003 : Ragley Pro relax full instructions
• Q-Tex 2D mesh: Soft
extra comfortable,
breathable, quick dry
& all weather.
• Slide out side table.
• Step-less recline.
• Extra comfort.
Relax
Includes free adjustable
head cushion
Relax
Full Instructions
Instructions, warranty and additional information can
be found on the Quest manual download site by using
the QR code or website URL above.
Warranty : 24 Months warranty.
www.questleisure.com
Size: 65  80  118 cm.
Seat Height: 51 cm.
Seat Width: 53 cm.
Folded: 65  15  98 cm.
Weight: 10.5 kg.
Max Load: 120 kg.
Side Table Max Load: 5 kg.
Quest Elite® Ragley Pro range
Quest manual download site
www.questleisure.com/manuals
055924 803317
5>
Relax chair
Code: F133003
Hang Tag Artwork : Below is a copy of the hang tag that came with your product. This is just
for your reference and you should still keep the original that came with your product.

4
Template version: 2
F133003 : Ragley Pro relax full instructions
image 1
image 4 image 5 image 6
image 2 image 3
Folding, adjusting the recline and unfolding.
• Take the chair from the bag and stand the chair upright as shown in image 1. Ensure that the
arms are unlocked (as shown in image 7). Standing at the side of the chair with one hand of the
back rest and one hand on the arm rest push these apart by pushing in opposite directions. If
the chair does not want to open as shown, then the arms of the chair may be pushed too far
back and inhibiting the chair from opening. If this is the case, release the arms by moving them
forward and then try opening the chair again.
• When the chair is open with the legs fully apart (image 3) you can pull the back rest up into
the upright position and lock the arms into position (as shown in the image 8).
• Now slide the side table from under the chair (image 4) and locate onto the locking pin on the
side of the chair (image 5)
• To adjust the recline, set the locks to unlocked (as shown in the image 7), sit in the chair, place
your legs on the bottom bar of the chair and push back also using your legs to pull up (as
shown in image 6).
• When folding the chair make sure you unclip the side table and slide it back under the chair
first, then unlock the chair (as shown in image 7), pull arm on the arms rest and pull the back of
the chair forward until the chair is closed, you might then need to fully close the chair by push-
ing the frame together. Once done lock the legs (as shown in image 8).
You can also follow this process using the QR code (video link) on the next page or going directly
to the URL : https://youtu.be/ztAdyTgmKxY

5
Instruction version: 1
F133003 : Ragley Pro relax full instructions
Video Linkimage 7 image 8
Storage
To help keep your product looking newer for longer and prolong the life and use of the product,
we recommended that the product is covered when not in use.
If the product is not going to be used for an extended period (such as a winter period) we
recommend that it is carefully folded away and stored in a clean, dry and free from damp
location.
Care and Cleaning Instructions
Never use and harsh or abrasive cleaners or brushes when cleaning this product as the frame
and fabric may be damaged when doing so.
Never fold and put the product away when wet as this can trap water in the product, which can
lead to mould and mildew build up.
• Fabric : We recommend using a dedicated fabric cleaner for the fabric, if one is not available
simply warm soapy water. After it has been cleaned, rinse with clean water to make sure
there's no soap or cleaner left inside the fabric. Once rinsed allow the product to dry
naturally before folding away and storing.
• Frame : First allow any dirt to dry and brush with a soft brush to remove loose dirt. Once this
is done wipe the frame down with warm soapy water and a soft cloth. Once cleaned allow to
dry naturally before storing away.
• Side Table (If applicable) : Simply wipe the table down with warm soapy water and a soft
cloth. Once cleaned dry with a towel or soft cloth afterwards.

6
Template version: 2
F133003 : Ragley Pro relax full instructions
Warranty : 24 Months (2 Years) warranty.
Warranty Claim
• In the unlikely event of a warranty claim, you must contact your retailer.
• If you have not registered your product, first fill out the registration form overleaf and take this
with you when you go to your retailer.
• Take the product to your retailer that you purchased it from along with your proof of purchase
and explain the issue with the retailer.
• The retailer will then check the product and get in touch with the wholesaler or manufacturer.
• The retailer will keep you informed of the progress of the claim.
• The wholesaler or manufacturer will not (unless under special circumstances) get in touch with
you as all information will be passed back directly to the retailer.
Warranty Information
• This product comes with a full 24 month manufacturers defect warranty and covers any
manufacturers defects for two (2) year from the date of the original purchase. It does not cover
any damage occured though:
• The product falling or being dropped.
• The product has been technically changed by the owner or another third party
• Improper use of the product.
• Colour fading, or normal wear and tear.
• The aected part will be replaced or repaired (manufacturers option) if they are found to be
defective within the two (2) year time frame.
• The warranty will be void if the product has been subject to neglect, misuse, improper installation,
misapplication, alteration or accident including, but not limited to, improper installation,
maintenance or use of unauthorised parts or attachments.
• Damage caused by not following the instruction manual in full will invalidate the warranty, if
this results in consequential damages, Quest will not be liable for these damages or any costs
incurred due to these damages.
• Quest will not be liable for material damage or personal injury caused by improper use or if the
safety instructions are not properly executed in full.
• All claims must be made though the retailer you purchased the product from and not direct with
the wholesaler or manufacturer.
• Warranty claims cannot be honoured without an original dated receipt and or proof of purchase.
• By executing repairs the original warranty period of two (2) years will not be extended, nor the
right to a complied new warranty. This warranty is only legal on European soil.
• This warranty does not overrule the European directive 2011/83/EU.
• This product may not be amended or changed.

7
Instruction version: 1
F133003 : Ragley Pro relax full instructions
This Ragley Pro chair is part of the Quest Elite® Ragley Pro range of furniture. This range includes the
following items that are matched with your product.
Cat No F133003 Ragley pro relax in blue
• Powder coated steel frame • Adjustable padded head rest • All weather Q-tex 2D mesh fabric
• Size: 65  80  118 cm • Folded size: 65  15  98 cm • Seat height: 51 cm • Seat width: 53 cm
• Weight: 10.5 kg • Max load: 120 kg • Side table max load: 5 kg.
Exclusive
slide-out
table
Exclusive
All weather
fabric
Extra
Comfort
elastics
Q-Tex 2D Mesh
Breathable, quick dry and durability.

8
Template version: 2
F133003 : Ragley Pro relax full instructions
Cat No F133002 Ragley pro comfort in blue
• Powder coated aluminium frame • Adjustable padded head rest • All weather Q-tex 2D mesh fabric
• Size: 63  70  120 cm • Folded size: 61  11  120 cm • Seat height: 46 cm • Seat width: 52 cm
• Weight: 5.9 kg • Max load: 120 kg. • Side table max load: 5 kg.
Exclusive
slide-out
table
Exclusive
All weather
fabric
Extra
Comfort
elastics
This Ragley Pro chair is part of the Quest Elite® Ragley Pro range of furniture. This range includes the
following items that are matched with your product.
Q-Tex 2D Mesh
Breathable, quick dry and durability.

9
Instruction version: 1
F133003 : Ragley Pro relax full instructions
Cat No F133001 Ragley pro recline in blue
• Powder coated hybrid frame • Adjustable padded head rest • All weather Q-tex 2D mesh fabric
• Size: 59  69  114 cm • Folded size: 59  11  96 cm • Seat height: 44 cm • Seat width: 49 cm
• Weight: 6.1 kg • Max load: 120 kg • Side table max load: 5 kg.
Exclusive
slide-out
table
Exclusive
All weather
fabric
Adjustable
Padded
head rest
This Ragley Pro chair is part of the Quest Elite® Ragley Pro range of furniture. This range includes the
following items that are matched with your product.
Q-Tex 2D Mesh
Breathable, quick dry and durability.

10
Template version: 2
F133003 : Ragley Pro relax full instructions
This Ragley Pro chair is part of the Quest Elite® Ragley Pro range of furniture. This range includes the
following items that are matched with your product.
Cat No F133004ST Ragley pro lounge in blue
• Powder coated aluminium frame • Adjustable padded head rest • All weather Q-tex 2D mesh fabric
• Size: 70  175  90 cm • Folded size: 70  20  82 cm • Seat height: 51 cm
• Seat length (when flat): 200 cm • Weight: 6.3 kg • Max load: 120 kg.
Exclusive
slide-out
table
Exclusive
All weather
fabric
Extra high
Easy to
use
Q-Tex 2D Mesh
Breathable, quick dry and durability.

11
Instruction version: 1
F133003 : Ragley Pro relax full instructions
Cat No F133008 Ragley pro rest in blue
• Powder coated steel frame • All weather Q-tex fabric
• Size: 48  100  46 cm • Height: 46 cm • Folded: 48  90  9 cm
• Weight: 1.5 kg • Max load: 30 kg.
Extremely
light
weight
Exclusive
All weather
fabric
This Ragley Pro chair is part of the Quest Elite® Ragley Pro range of furniture. This range includes the
following items that are matched with your product.
Q-Tex 2D Mesh
Breathable, quick dry and durability.

12
Template version: 2
F133003 : Ragley Pro relax full instructions
Along with the other items in the Ragley Pro range there are other optional accessories
available for your product.
Cat No 118914DP Clamp on sun shade
• Adjustable position • U.V. protection
• Universal use • Anti glare • Can be used on
chairs, tables, prams, push chairs and more
• Canopy radius: 68.5 cm • Height: 105 cm
• Folded size: 7  7  94 cm
• Weight: 0.3 kg.
Cat No 124900 Quest Elite®furniture bag
• New improved colour and more durable material
• Premium quality
• Complete with its own carry bag
• Can fit multiple chairs in one bag • Universal use
• Fabric: 600D Fabric • Size: 67  18  113 cm
• Weight: 1.1 kg
Cat No 124901 Quest Elite spare elastics
• Elasticated cord • Metal end caps
• Fits all relax and comfort chairs
• QTY: 4 cords (2 different lengths)
• Length: 36 inches and 72 inches
