Quest Payment Systems QP1 User manual

QP1 Thermal Printer
User Guide
152-0005-01

2
INTRODUCTION
What’s in the box?
•QP1 Printer with Paper Roll
•Customer Support information card
Features
1. Thermal Print head
2. Paper feed button
3. ‘Paper out’ indicator light
4. ‘Error’ indicator light
5. Automatic Paper cutter
6. Tear bar, for manual paper cutting
7. Lid release button
8. Paper roll bucket
9. Paper Feed roller
10. Lid
11. ‘Cable Interface Box’ release button
12. COM cable
IMPORTANT INFORMATION
The power supply and all other cables are included with the QT720 Payment terminal,
NOT the QP1 printer. If you find something is missing from your QT720 Payment Terminal
and QP1 printer, contact the Quest support team (see ‘Support’ section in this guide).

3
Printer controls
‘Feed’ Button
Press the ‘Feed’ button once to advance
paper one line. Hold down the FEED button to
print a ‘Self-Test’ page. See ‘Self-test’ section
for more information.
‘Error’ Light
If the ‘Error’ light illuminates red, it indicates
an error which is preventing normal
operation. The paper may be jammed or the
lid is not closed properly. See the
'Troubleshooting' section in this guide for
more information on errors.
‘Paper out’ Light
This light indicates the end of a paper roll.
Install a new paper roll, and the printer will
continue printing. If the roll runs out whilst
printing a receipt, install a new roll and QT720
will re-print that same receipt.

4
INITIAL SETUP
Connecting QP1 Printer to QT720 Payment Terminal
Connecting the COM cable
Note: Before connecting the main cable to QP1, ensure no power is connected.
1. Place the QP1 upside down on a soft, clean surface. Orientate the 'Interface box'
of the Main cable as shown and lower it into the recess on the underside of the
printer.
2. Slide the ‘Interface box’ toward the back of the printer until it clicks into position.
3. Connect the small black cable exiting the printer to the COM port on the
'Interface box'.
IMPORTANT INFORMATION
The QT720 Standalone terminal is provided to you with a pre-fitted ‘Main cable’.
Other cables included with QT720:
•10m Phone line cable
•5m LAN Cable
•Power supply

5
Connecting the Dialup line
If your site requires you to use ‘Dialup’ as a backup
communication method, plug your landline
telephone cable into the ‘Phone’ port on the
‘Interface box’.
Connecting the Network (LAN) cable
Connect your LAN (Local Area Network) cable into
the LAN port on the ‘Interface box’.
Connecting the Power Supply (DC)
Warning: Only use the power supply provided with
your QT720 Payment Terminal. Using any other
power supply may cause damage, fire or electrical
shock and void your warranty.
1. Connect the DC Jack of the Power supply
provided with your QT720 into the DC
socket on the ‘Interface Box’ fitted to the
QP1 printer.
2. Plug the DC Power supply into an
electrical outlet. Ensure all other
communication cables are fitted before
switching on the power at the electrical
outlet.
3. When power is supplied, the QP1 Printer
lights will momentarily flash and the
QT720 Payment Terminal will begin to
boot up.
4. Your QT720 Standalone Payment Terminal
is now setup.

6
USING THE PRINTER
Inserting a Paper Roll
Note: Be sure to use paper rolls that meet the specifications listed within this guide. Do
not use paper rolls that have the paper glued to the core as the printer cannot detect the
paper end correctly.
1. Ensure the printer is not receiving data; otherwise, data may be lost.
2. Open the paper roll lid by pressing the lid release button. If the button will not
open the lid, see the Troubleshooting section in this guide.
3. Remove and discard any partial paper roll or empty core.
4. Insert the paper roll as shown. When the paper roll is in place, ensure the paper
feeds from the bottom of the roll.
5. Before closing the lid, pull out a small amount of paper, then close the lid by
pressing on both sides of the lid (simultaneously) or press on the middle area of the
lid (near the paper exit). The lid is closed once you hear a “Click”.
6. Tear off any excess paper. QP1 is now ready to print.

7
DO – Press evenly on the Lid to close
DO – Press on the middle area to
close
DO NOT – Press on one side only
Receipt cutting
For your convenience, the QP1 Printer has an auto cutter that will cut the receipt
automatically after printing. A small portion of the paper is left uncut, gently pull the
receipt and the paper will break away.
If the auto cutter fails, a secondary tear bar is included as a backup. Simply pull the
receipt toward you to tear off.

8
MAINTENANCE
Disconnecting QP1 from the QT720 Payment Terminal
In order to swap the QP1 Printer or QT720 Payment Terminal, you will need to disconnect
the Main cable from the QP1 Printer.
Note: The Main cable must remain connected to QT720 at all times. If returning QT720 for
service, leave the Main cable attached to the QT720.
1. Disconnect the power at the electrical outlet.
2. Disconnect the ‘Power’ cable from the back of QP1, then the ‘Phone’ and ‘LAN’
cables. Turn over the QP1 printer and disconnect the ‘COM’ cable by pressing the
plastic tab on the plug and withdrawing the connector from the ‘Interface box’.
3. Push the large button on the underside of QP1 and slide the 'Interface box'
towards the front of the printer.
4. Lift the ‘Interface box’ out.

9
Enclosure cleaning
Note: All cleaning should be done when the power supply is off.
Do not spray water or any liquid directly onto QP1. Any liquid that goes into the product
may cause a failure, fire, or electric shock. Turn off QP1, then gently wipe the outside
surfaces with a micro-fiber cloth dampened with a small amount of water. Do not use
flammable liquids (benzene, thinners, etc.) or a cleaning agent.
Print head cleaning
Cleaning should be done when any one of the following conditions occurs:
•Reduced printing quality
•Unusual noise whilst feeding paper
Do not touch the surface of the printer head with bare hands. Do not use hard tools on
the printer head, rubber platen, and heating element, as this may cause damage.
Do not use organic solvents to clean the printer head, such as gasoline, acetone, etc.
Cleaning steps:
•Turn off the power supply
•Cleaning should be done after the printer head has completely cooled.
•Wipe the heating element of the print head lightly with cotton swabs with
ethyl-alcohol applied.
•Ensure all cleaning solution has completely dried before printing.
Paper Feed Roller cleaning
Cleaning should be done when any one the following conditions occurs:
•Paper has stopped feeding
•Paper feeding is unusually noisy
Cleaning steps:
•Turn off the power supply
•Wipe the Feed roller clean with a lint free cloth with ethyl-alcohol applied
•Ensure all cleaning solution has completely dried before printing.

10
Self-Test
The ‘Self-Test’ lets you know if your printer is operating properly. This test is independent
of the QT720 Payment Terminal, and independent of all software.
Running the Test:
1. Make sure a suitable paper roll is installed and printer lid is closed properly.
2. Hold down the FEED button until the self-test begins. The ‘Self-Test’ will print a
test pattern. The printed pattern should have good contrast and be consistent in
appearance. If the test print is poor, see the Troubleshooting section in this
guide.
3. The printer is ready to receive data as soon as it completes the ‘Self-Test’.
Storage
Do not store the printer in damp places or areas with large temperature variations.
Condensation on the printer may cause damage to the thermal head or unit failure.
Do not store the printer in dusty places.
When storing the printer for longer than six months, the printer lid must be kept open
such that the Paper Feed roller is not in contact with the Thermal Print head. If the Paper
Feed roller and Print head have continued direct contact for prolonged periods the Feed
roller can become deformed and may affect normal operation.
