Questyle Audio Super Hub SHB2 User manual

www.questyle.com
Super Hub SHB2
Super Hub SHB2
用户手册
www.questyle.com
Master
Super Hub SHB2
Super Hub SHB2
Master

02
03
04
05
06
07
08
09
13
13
14
15
18
18
22
22
26
38
39
Contents
About Super Hub SHB2 ...............................................................
In the Box .....................................................................................
Front View ....................................................................................
OLED Display ...............................................................................
Rear View .....................................................................................
Bottom View .................................................................................
Remote Control and Instruction of Buttons ..................................
How to Match with Super Hub SHB2 ...........................................
Getting System Started ................................................................
5G Wireless Pairing ......................................................................
PC System Requirements ............................................................
Install Super Hub SHB2 Driver on Windows OS ..........................
Core Audio Stream Introduction ...................................................
Setup Core Audio Stream on JRiver Media Center ......................
True DSD Technology ..................................................................
Setup DSD on JRiver Media Center ............................................
Install Foobar2000 .......................................................................
Setup on Mac OSX ......................................................................
Specifications ...............................................................................

02 03
Congratulations to you for being the owner of Questyle Audio Super Hub SHB2.
Super Hub SHB2 together with Questyle Audio Digital Audio Player OP2R or update
Digital Audio Players will build a Super Source System, resulting in Questyle taking a
huge leap towards defining the future. You will enjoy high-quality music in a simple
and easy way by virtue of Questyle’s state-of -the-art technologies.
The more complicated the world is, the more concise we are. Simply plug in the
Super Source System and press the play button, then beautiful music will flow
around you.
Super Hub SHB2 has a full range of input and output interfaces, supporting USB,
Optical, S/PDIF and AES digital signals, as well as RCA analog input, balanced and
unbalanced analog outputs. In addition, it supports professional interfaces of AES
and XLR that are used in recording studios. It is user switchable between Studio and
Standard mode. In the Studio mode, the power level will change from 14dBu up to
20dBu instantly, matching it with studio-level professional equipment.
Super Hub SHB2 is easy to use. It can match with various audio equipment and bring
you an exceptional listening experience. With connecting the SHB2 to your PC via a
USB cable, switch the player to Memory mode and it will download the recording files
automatically and sync to the player, which makes it convenient for you to take the
recordings along and listen to them at any time. When streaming Tidal, QuBuzz or
Spotify, your only need is to connect the SHB2 to your PC or a server via USB,
Optical or S/PDIF, switch it to the DAC mode and it will work as a DAC, then you will
get much better sound quality from your PC or the server
The design style of Super Hub SHB2 originates from Questyle’s iF Design Award
winner, which is impressive for its firm structure, smooth faces and unbroken lines
flowing around the perimeter. Along with Foxconn’s high precision machining
technique (0.02mm), the whole system exudes its charm of Quest and Style.
About Super Hub SHB2
In the Box
Super Hub SHB2
Power Cord
Super Hub SHB2 Driver CD
Super Hub SHB2 User Manual
Remote Control
1pc
1pc
1pc
1pc
1pc
Mechanical vibration will affect audio signal processing and sound listening. But
Super Hub SHB2 will avoid resonance by its special structure and material. The
player docking of the SHB2 is made of special silicone and pure aluminum, plus the
stable feet, helping to reduce resonance to a lowest level.
Super Hub SHB2 adopts Questyle’s core patented technologies of Current Mode
Amplification and True DSD. As the “engine” of an audio system, the Current Mode
Amplifier is designed with an all discrete circuit and pure Class A operation that
allows the SHB2 to have outstanding performance and provide users with an experi-
ence of being there listening to the original sound. With the True DSD technology and
the DAC chip AK4490, the SHB2 processes DSD signals without any PCM convert-
ing, providing the original DSD signal processing.
The pre-amplifier of Super Hub SHB2 has excellent performance because of the
customized Current Mode Amplification modules CC630 and CA630. The SHB2’s
analog output can be set to Fixed or Adjustable. It’s very easy for you to build a
lossless audio system since the SHB2 has a full range of input and output interfaces,
plus a remote control. It is user-friendly to match with Hi-Fi amplifiers or active speakers.
There are two versions of Super Hub SHB2, the first is SHB2 (standard version), the
other being SHB2 Master. The SHB2 Master has a “MASTER” laser marking, and it
features the ROGERS Ceramic PCB and selected components to ensure the
ultimate performance on sound quality and specifications.

USB/DAC switch: switch it to have the SHB2 work as a DAC and the DAC
mode indicator is on, then the SHB2 will play music files in your PC via USB. When
the DAC mode indicator is off, your PC will connect to the player, recognize the
player as a USB flash disk and import music files from your PC
DAC mode indicator
5G Wireless mode switch: it is used to turn on/off the 5G Wireless Transmission
5G Wireless mode indicator: it flashes slowly to show that the SHB2 hasn’t
paired with a receiver yet, it flashes quickly to show that the SHB2 is pairing, and it
stays light on to show that the pairing is done and the 5G Wireless Transmission is
working. When the indicator is red, it indicates signals of high sample rate
(>96kHz), and when it is orange, it indicates signals of general sample rate
OLED display: it is used to show volume, sample rate and input mode
information (as shown blow)
04 05
① Power switch
② Power indicator: it flashes quickly with orange light to show the system is
starting and stays the orange light on to show the system has successfully started.
If the indicator flashes quickly with red light, it means the system is in malfunction
and you need to power off the Super Hub SHB2 and restart it. If the problem is not
solved, you have to contact your dealer or the After-Sales Support
③ Remote Control signal receiving zone
④ Docking: it is used for connecting the SHB2 to the Questyle’s player or other
docking devices
⑤ Docking indicator: it flashes with red light to show that the SHB2 is charging for
the player, and it stays red light on to show the player is fully charged. It stays
orange light on to show the player is playing music files, and when you give it a
pause, the orange light is off
⑥ Previous/Fast backward button: it is available only for the player
⑦ Previous/Fast backward indicator: it flashes to confirm the operation
⑧ Pause/Play button: it is available only for the player
⑨ Pause/Play indicator: it stays light on to show the player is playing music files
and it is off when there is a pause
⑩ Next/Fast forward button: it is available only for the player
Next/Fast forward indicator: it flashes to confirm the operation
11
12
13
16
Input mode button: it is used to select the source.
Volume control: it is used to adjust the system volume.
17
18
14
15
Front View
16.a) Source sample rate display
16.b) Input mode display
16.c) Volume display, from “0” to “60”
16.a
16.b 16.c
OLED display:
6
7
5
3
4
8
9
10 12
13 15
14 16 17 18
11
12
OLED display

06 07
① Pre-amp right channel balanced output
② Pre-amp left channel unbalanced output
③ Pre-amp right channel unbalanced output
④ Pre-amp left channel balanced output
⑤ Left channel unbalanced input
⑥ Right channel unbalanced input
⑦ AES/EBU output
⑧ S/PDIF input
⑨ S/PDIF output
⑩ USB input
Optical input
Antenna housing for 5G Wireless part. In order to get clear signals, please DO
NOT use metal or other shielding materials to cover this part
220V/110V voltage switch (Please make sure the indicated voltage is in accor-
dance with the local voltage.)
AC power supply
11
12
13
14
① 5G Wireless Pairing button: it is used to pair the SHB2 with a Questyle 5G
wireless receiver. Go to page n to see “ 5G Wireless Pairing”
② Pre-amp output volume switch between ADJ (Adjustable) and FIX (Fixed).
When you switch it to ADJ, you can adjust the volume via the SHB2 volume control,
which is for connecting the SHB2 to active speakers or power amplifiers without
volume control function. When you switch it to FIX, the output will be at max level
and the volume is unadjustable via the SHB2 volume control, which is for connect-
ing the SHB2 to amplifiers or Pre-amps with volume control function
③ Pre-amp output switch between Studio and Standard mode. When you switch
it to Standard mode, the max output level will be 14dBu, which is for connecting the
SHB2 to ordinary active speakers. When you switch it to Studio mode, the max
output level will be 20dBu, which is for connecting the SHB2 to the professional
active speakers in studios
Bottom ViewRear View

08 09
Remote Control
12
14
16
5
2
10
15
7
1
13
11
9
8
6
4
3
① Standby
② Mute
③ SHB2+Player Connection
④ Source Selection Backward
⑤ Source Selection Forward
⑥ Menu
⑦ Back
⑧ Up
⑨ Previous/Fast Backward
⑩ Next/Fast Forward
Play/Pause/OK
Down
Previous
Next
Volume Down
Volume Up
11
12
13
14
15
16
System and Volume Control Buttons
Source Control Buttons
Player Control Buttons
System and Volume Control Buttons
Note:
Player Control Buttons are only available for Questyle Digital Audio Players and
perform the same function of the buttons on the player. Source Control Buttons and
System and Volume Control Buttons are available for the whole system. Other
buttons are inactive for Super Hub SHB2.
1. Digital Input
Super Hub SHB2 has OPT, S/PDIF, AES/EBU and USB inputs. Digital audio
signals from your PC, music server, CD or Blu-ray can be sent to the SHB2 via
those interfaces. The core patented technologies of Current Mode Amplification,
True DSD and 3X Clock Asynchronous Transmission allow the SHB2 to have
outstanding performance from its DAC and pre-amplifier.
Note: you don’t have to install a USB driver if your music server is Linux system
supporting UAC 2.0.
How to Match with Super Hub SHB2
CAUTION REPLACE WITH SAME TYPE FUSE POWER INPUT ~50-60Hz50VA MAX
CD机
SPDIF IN
电脑、iPad
USB IN

CAUTION REPLACE WITH SAME TYPE FUSE POWER INPUT ~50-60Hz50VA MAX
10 11
3. Used as a DAC/Pre-amplifier
Super Hub SHB2 can be used as a DAC/Pre-amplifier to drive various active
speakers or match with power amplifiers.
·Connect the Pre-amp output of the SHB2 to the input of active speakers or power
amplifiers.
·Set the Pre-amp output of the SHB2. When you connect the SHB2 to ordinary
active speakers or power amplifiers, please switch the Pre-amp output to Standard
mode. When you connect the SHB2 to studio-level speakers , please switch it to
Studio mode.
·Set the Pre-amp output volume. At the bottom of SHB2, you can find the
Pre-amp output volume switch between FIX (Fixed) and ADJ (Adjustable). When
you switch it to ADJ, you can adjust the volume via the SHB2 volume control. When
you switch it to FIX, the output will be at max level and the volume is unadjustable
via the SHB2 volume control.
Note: you don’t have to install a USB driver if your music player is Linux system
supporting UAC 2.0.
2. Used as a DAC for Streaming
Super Hub SHB2 supports Linix system and Windows USB Audio Class 2.0
standard driver, it can be connected to music servers and used as a DAC.
USB INSPDIF IN OPT IN
Music Server
Cloud-based Content
Phone APP

12 13
4. Digital Output
Super Hub SHB2 can output digital signals. Just connect the digital output of SHB2
to the input of a DAC and it will work.
5. 5GHz Wireless Transmission
Super Hub SHB2 can pair with Questyle’s 5G wireless receivers (CMA Twelve).
They will communicate with each other via 5G Wireless Transmission and bring
you a wonderful music listening experience.
44.1/48 88.2/96 176.4/192 352.8/384 UNLOCK
DSD64 DSD128 DSD256
CMA Twelve
USB OPT SPDIF AE S/EBU 5GHz
WIRELESS
POWER
DAC STANDARD
HPAMP HIGH
SOURCE
FUNCTION BIASCONTROL
4.4mmBAL 6.35mmUNBAL 4PINXLR/BAL
·Go to page n to see “5G Wireless Pairing”.
Getting System Started
When you power on the Super Hub SHB2, it starts with the Power indicator flashing
quickly and the OLED display showing a startup picture. It completes the startup
and starts to work when the Power indicator stays light on and the OLED display
shows the volume, sample rate and input mode.
How to pair Super Hub SHB2 with 5G wireless receiver
First, power on Super Hub SHB2 and the 5G wireless receiver (CMA Twelve) ,
make sure both of their 5G Wireless mode switches are on, otherwise they can’t be
paired.
Second, press the 5G Wireless Pairing button on the SHB2 and the receiver, then
the 5G Wireless mode indicator will flash quickly to show that the SHB2 is pairing,
and it will stay light on to show that the SHB2 and the receiver are successfully
paired. If the pairing isn’t done within 30 seconds, the SHB2 will exit the pairing and
the 5G Wireless mode indicator will flash slowly.
If the 5G Wireless Pairing fails, please repeat the pairing steps above. If the SHB2
can’t pair with the receiver, you have to contact your dealer or the After-Sales
Support.
5G Wireless Pairing
Before using the 5GHz Wireless Transmission, you need to pair Super Hub SHB2
with the 5G wireless receiver.

14 15
1) Operation System
Super Hub SHB2’s driver and hardware support Win XP / Vista / Win7 / Win8 /
Win8.1/ Win10. For Apple Mac OS, later versions than the 10.5.7 are well matched
without installing any driver.
2) Media Player
Super Hub SHB2 is not limited to any special media player. Any PC compatible
player (including video players) is well matched.
3) File Format
File format is up to the media player on your PC. Super Hub SHB2 can decode any
file format that the media player supports.
4) Requirements for PC Configuration
At least one USB port is required. An acceptable USB2.0 high-speed cable of type
A-to-B plug. We suggest using the high-quality USB cable to ensure the stability
andreliability of data transmission and guarantee the best performance of
Super Hub SHB2.
Your Super Hub SHB2 can be recognized by PC after installing the Super Hub
SHB2
Driver on Windows OS. We take Win7 64bit OS for an example to show the
Driver installation.
1) Connect your
Super Hub SHB2 to its power supply and switch it on;
2) Connect your Super Hub SHB2 to PC with a USB cable;
3) Put the provided Super Hub SHB2 Driver disc into your PC and open the folder
labeled “
Super Hub SHB2 Driver/For Windows 7, 8, 8.1 and 10/” and then
double click “Setup.exe”.
PC System Requirements Install Super Hub SHB2 Driver on Windows OS

16 17
Click “Install” (Default install location is C drive) Installation is completed, click “Next”
5) Restart your PC and the CMA Twelve Driver is finished installation;
6) Installation on Win XP, Vista is similar to the above.
Click “Finish” to exit the installation
Installation will take 3 or 5 minutes

18 19
Core Audio Stream has formats of ASIO, KS and WASAPI, all of which can be
supported perfectly by CMA Twelve. Besides, Super Hub SHB2 supports DSD
format.
According to general audio processing procedures of PC, all the sound from
applications and systems is processed by SRC, going through the lengthy system
processing and hardware layer transmission, and then output to the external
device. The output data are totally different after all those procedures. To output the
pure, original and “bit-perfect” data, we must open a high-speed and dedicated
channel for audio device, which is the core audio stream technology.
Super Hub SHB2 supports ASIO and KS on Win XP systems, and supports ASIO
and WASAPI on Vista, Win7, Win8, Win10 systems. For example, when you
enable WASAPI + Exclusive Mode between CMA Twelve and player software (like
JRiver), you can't control the volume through system controller, the sound from the
system or any other application will not be heard at the Super Hub SHB2 output,
which is because the system has opened the Core Audio Stream channel for CMA
Twelve and the audio data directly get to the DAC of Super Hub SHB2 with
high-speed.
We recommend using Jriver Media Center 20 for getting the best performance.
JRiver Media Center is a fully functional media management and playback
software. It can manage your music in groups and can stream music from the
Internet. It also can be used for MP3 or DVD burning. JRiver can support kinds of
audio files including MP3, MusicEx, WAV, OGG, RealAudio, RealVideo, AVI, Quick-
Time etc.
Let’s take JRiver Media Center player 20 on Win7 32bit OS for an example to
explain how to setup WASAPI.
Core Audio Stream Introduction
Setup Core Audio Stream on JRiver Media Center
I Download and Install
1) Go to JRiver website (http://www.jriver.com/download.html), and click
to download JRiver Media Center
20.0.131;
2) Install JRiver Media Center 20.
II Import Songs
1) Open “JRiver Media Center”, click “Tools”-“Import” and select “Configure Auto
Import ”, and then click “Next”;

20 21
I Download and Install
1) Go to JRiver website (http://www.jriver.com/download.html), and click
to download JRiver Media Center
20.0.131;
2) Install JRiver Media Center 20.
II Import Songs
1) Open “JRiver Media Center”, click “Tools”-“Import” and select “Configure Auto
Import ”, and then click “Next”;
2) Click “Add”-“Browse”,
select the folder that
contains songs, and then
click “OK”-“Finish”.
III JRiver Output Setup
1) Click “Tools” and select “Options”;
2) Select “Audio Device” under “Options”, and click ”Questyle ASIO Driver[ASIO]”
and select “Default Audio Device”, and then click “OK”.

22 23
Nothing is better than the true. The True DSD technology is one of the core patent-
ed technologies of Questyle Audio. It processes DSD signals without any PCM
converting and provides True DSD, which is fundamentally different from DoP and
Native DSD.
When the system processes DSD signals, hardware mode switches to the True
DSD channel. In this case, options for digital filter and digital volume control fail,
strictly following the process of SACD playback.
True DSD（Direct Stream Digital）Technology
1) Connect your Super Hub SHB2 to its power supply and switch it on;
2) Connect your Super Hub SHB2 to PC with a USB cable;
3) Open JRiver Media Center, click “Tools” and then select “Options”;
4) Select “Questyle ASIO Driver[ASIO]” under “Audio Device”;
Setup DSD on JRiver Media Center
（China Intellectual Property Office Patent No. 201520211945.X）
AK4490
DSD
PCM
DSD
DAC
PCM
DAC
DSD
PCM
True DSD DAC
PCM
DSD
PCM PCM
5) Select “Device Settings” under “Audio Device” and click ”Open Driver Control
Panel” under the ASIO, then select “Format”-“2Channels,24Bits”; select “Buffer
Settings”-”Safe”,”Auto”; then close and click “OK” .

24 25
6) Click “DSP & output format” under “Settings”. Make sure nothing on the left row
is ticked. (To wit: without any processing to DSD data, ensuring original sound.)
7) Select “Custom” under “Bitstreaming: Yes(DSD) ”
8) Tick “DSD” and then click “OK”.

26 27
Save and exit. The setup is completed.
9) With a song playing, put the mouse pointer at where the arrow is pointing to view
current input and output.
Foobar2000 is a free and multifunctional audio player as well as a powerful tool for
audio processing.
I Download the Following Software and Plugins
1. Take Foobar2000 V1.3.9 for an example
http://www.foobar2000.org/download
2. ASIO channel plugin
http://www.foobar2000.org/components/view/foo_out_asio
3. WASAPI channel plugin (no need for higher versions than WIN7)
http://www.foobar2000.org/components/view/foo_out_wasapi
4. Core Audio Stream channel plugin (no need for WINDOWS XP)
http://www.foobar2000.org/components/view/foo_out_ks
5. ASIO driver (take ASIOProxyInstall-0.8.4 for an example)
http://sourceforge.net/projects/sacddecoder/files/foo_input_sacd/
Install Foobar2000 After the unzipping, you will see the following:
You will get 5 files after the above download (as shown below):

II Install Foobar2000 V1.3.9
1. Double click to install Foobar2000, and then click “Next”.
2. Click “I Agree”. 5. Click “Next”.
3. Select “Standard installation”.
4. Click “Next” to choose Foobar2000 install location. (Default install location is C
drive)
28 29

30 31
6. Click “Install”. (Default installation of all the components) 7. Click “Finish” and run Foobar2000.
III Install Plugins
1. Install plugins according to the following steps highlighted from 1 to 8.

32 33

34 35
2. Restart Foobar2000 and go to the install location to confirm that the three
plugins highlighted in the following figure are installed successfully. If so, you will
see two more options on the left of the interface. (as shown in the figure below)
These two plugins are
needed for playing DSD files.
Other high-speed channel on
Windows
3. Install ASIO driver: double click
in the unzipped folder and then install the three components one by one.
If you come to this step, you have completed all the preparations.

36 37
IV Setup the Software
1. Connect your CMA Twelve to a PC with a USB cable and finish the software
setup according to the following steps highlighted from 1 to 9. Close and restart the
software, then Foobar2000 is ready for playing PCM and DSD files.
2. In addition, installing plugins for Core Audio Stream channel requires copying the
“foo_out_ks.dll” (highlighted in the figure below) to “components” under installation
directory. Then restart the software and it is ready for playing files.
If the DSD files fail to play, please try the following:
1. Exit the antivirus software and reinstall the CMA Twelve Driver. Maybe the Super
Hub SHB2 program is mistakenly deleted by the antivirus software.
2. Every time you finish setting Foobar2000, please restart the Foobar2000
software.
Fig. 1
